advanced scale models P-61 Black Widow Assembly Instructions Manual

Hide thumbs Also See for P-61 Black Widow:

Advertisement

The ASM P-61 features advanced lightweight construction giving the model great scale shape and details while maintaining a lighter weight for a better flying
scale model. The model comes from the box built and covered, leaving only final assembly and radio/engine/optional retract installation. In the air, this model
flies as easy as most .60 size planes. The plane can be finished with working retract doors and beautiful aluminum-frame air-retracts (sold separately).
pilot can truly achieve a scale look in the air and on the ground.
A S S E M B L Y INSTRUCTIONS
A Semi-Scale ARF R/C Model of the USA's First Specifically-Designed Night Fighter
History of the P-61 Black Widow
The heavily-armed Black Widow was the USA's first
aircraft specifically designed as a night-fighter. In the
nose, it carried radar equipment which enabled its crew
of two or three to locate enemy aircraft in total darkness
and fly into proper position to attack.
The XP-61 was flight-tested in 1942 and delivery of
production aircraft began in late 1943. The P-61 flew
its first operational intercept mission as a night fighter
in Europe on July 3, 1944, and later was also used as
a night intruder over enemy territory. In the Pacific, a
Black Widow claimed its first "kill" on the night of July 6,
1944. As P-61s became available, they replaced interim
Douglas P-70s in all USAAF night fighter squadrons.
During WW II, Northrop built approximately 700 P-61s;
41 of these were -C variants manufactured in the summer
of 1945 offering greater speed and capable of operating
at higher altitude. Northrop fabricated 36 more Black
Widows in 1946 as F-15A unarmed photo-reconnaissance
aircraft.
Gross Weight: 35,853lb (16,260kg)
Maximum Speed: 425mph (684km/h)
Made in China
Wing Span: 66ft (20.1m)
Length: 49ft 7in (14.1m)
Range: 1,200mi (1932km)
All Contents Copyright © 2006 Advanced Scale Models Version  July 2006
ASM P-61 BLACK WIDOW SPECIFICATIONS AND FEATuRES
Wing Span: 79.5 Inches (2019mm)
Wing Area: 1010 Square Inches (65.42dm
Length: 59.5 Inches (1511mm)
Weight RTF: 13.75 Pounds (6.2kg) with Retractable Landing Gear and Doors
Wing Loading: 31 Ounces Per Square Foot (95gr/dm
Functions: Ailerons, Elevator, Rudders, Flaps, and Throttles (Retracts Optional)
Radio Required: 5-6 Channel or More
Engines Required: 2 x .52-.61 4-Strokes
Advanced Lightweight Construction and Scale Outline
Parts Prepainted and Precovered in Scale Color Scheme
Machined-Aluminum Phneumatic Retracts and Oleo Struts Available
Landing Gear Doors and Actuators Included
Large Size, Yet Easy to Fly
Strong, Prebent Wire Landing Gear and Lightweight Stand-Off Scale Wheels
Includes a Generous Hardware Package
Easy Assembly - Over 50 High-Resolution Digital Photos to Guide You
Height: 14ft 8in (4.4m)
Engines: 2 x Pratt & Whitney 2100hp R-2800 Radials
Service Ceiling: 46,200ft (14,081m)

So, the
2
)
2
)
Kit Product Number A-ASM003

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P-61 Black Widow and is the answer not in the manual?

Questions and answers

Summary of Contents for advanced scale models P-61 Black Widow

  • Page 1 Engines: 2 x Pratt & Whitney 2100hp R-2800 Radials ● Maximum Speed: 425mph (684km/h) Range: 1,200mi (1932km) Service Ceiling: 46,200ft (14,081m) ● ● Kit Product Number A-ASM003 Made in China All Contents Copyright © 2006 Advanced Scale Models Version  July 2006...
  • Page 2: Customer Service Information

    Assorted Modeling Supplies (i.e., Sandpaper, Sanding Block, Airplane Stand, Paper Towels, Etc.) ● Optional Phneumatic Retract Installation ASM Retract Set and Control System for P-61 Black Widow (P/N ASM-ARS02) ● ASM Landing Gear Strut Set for P-61 Black Widow (P/N ASM-CSS02) ●...
  • Page 3: Tips From The Pros

    Double-check the operation of the landing gear, too, if using the optional retractable landing gear. ADVANCED SCALE MODELS P-61 BLACK WIDOW FINAL ASSEMBLY STEP 1: HINGING THE AILERONS AND FLAPS ❑ Hinge the ailerons to the wing panels, using the six C/A-style hinges provided and a generous amount of thin C/A.
  • Page 4 STEP 2: INSTALLING THE AILERON AND FLAP CONTROL LINKAGE ASSEMBLIES iMpoRTANT You may need to trim the servo mounting rails and/or the servo cutout in the outer wing panel to fit your servos. ❑ Install one aileron servo into each wing panel. Each servo output shaft should be toward the leading edge.
  • Page 5 STEP 5: ASSEMBLING AND INSTALLING THE FuEL TANKS ❑ Assemble each of the two fuel tank stopper assemblies, using one straight tube and one 90º tube. The straight tube is the fuel pick-up tube and the 90º tube is the vent tube. ☞...
  • Page 6: Step 8: Installing The Main Landing Gear

    ❑ Install your rudder servos into the servo trays. Notice the position of the servo output shafts. They should be toward the back of the fuselage. ❑ Make a Z-Bend in the pushrod wires and connect them to the servo arms. ❑...
  • Page 7: Step 10: Installing The Nose Gear

    ❑ Locate and drill 5/32" diameter holes through each cowling for the mounting screws. ❑ Install a remote fueling valve into each cowling to make it easy to fuel the airplane, then install the cowlings to the fuselage booms, using the six large wood screws provided.
  • Page 8: Step 13: Hinging The Elevator

    STEP 12: INSTALLING THE COCKPIT DECK AND WINDOW GLASS iMpoRTANT If you are installing the optional retractable landing gear and landing gear doors, do not install the cockpit deck and forward window glass until after installing the nose gear retract and landing gear door assemblies. You need to have access through the cockpit to install the landing gear doors.
  • Page 9 STEP 14: INSTALLING THE ELEVATOR CONTROL LINKAGE ASSEMBLY iMpoRTANT Make sure that you center both the elevator servo and the servo arm before installing your servo. ❑ Mount your elevator servo to the servo mounting hatch cover, using the two plywood blocks provided. ☞...
  • Page 10 ❑ Feed the elevator servo extension down through the slot in the left fuselage boom and into the landing gear bay. iMpoRTANT You may need to adjust the size of the precut slot in the fuselage boom to prevent pinching the servo extension. ❑...
  • Page 11 STEP 17: MOuNTING THE CENTER FuSELAGE POD ❑ Plug the servo leads into your receiver and mount the center fuselage pod to the center wing panel, using the two longer socket-cap screws and two washers provided. iMpoRTANT You'll need to plug a Y-Harness between the steering servo and the rudder Y-Harness. Double-check that the nose gear moves the same direction as both rudders.
  • Page 12: Center Of Gravity

    ❑ Carefully thread one flange-head machine screw through the predrilled hole and into the aluminum wing joiner tube. Tighten the screw gently. Be careful not to overtighten it or you might strip the aluminum. iMpoRTANT The machine screw will cut threads into the softer aluminum without a problem.
  • Page 13 OPTIONAL ASM RETRACTABLE LANDING GEAR INSTALLATION STEP 1: INSTALLING THE MAIN GEAR RETRACT ASSEMBLIES ❑ Remove the wheels from the main gear struts. ❑ Install the main gear struts into the retracts, making sure that the struts are lined up straight and that the scissor links are toward the front of the retracts.
  • Page 14 STEP 4: INSTALLING THE AIR TANK AND FILL VALVE ❑ Install the air tank into the back of the center fuselage pod, using the plywood support provided. ❑ Install the fill valve onto the fuselage side, making sure to tighten the mounting nuts securely.
  • Page 15 STEP 2: INSTALLING THE MAIN LANDING GEAR DOOR ACTuATORS iMpoRTANT The wire leg on one side of each prebent wire bracket assembly is longer than the other leg. When assembling the main landing gear door actuators, make sure to make one right and one left. ❑...
  • Page 16: Our Guarantee

    In that Advanced Scale Models has no control over the final assembly or material used for final assembly, no liability shall be assumed for any damage resulting from the use by the user of the final user-assembled product. By the act of using the final user-assembled product, the user accepts all resulting liability.
