- Page 1 Z5385 Rigging manual 1.4 en...
- Page 2 General information Z5385 Rigging manual Version: 1.4 en, 07/2016, D2703.EN .01 Copyright © 2016 by d&b audiotechnik GmbH; all rights reserved. Keep this manual with the product or in a safe place so that it is available for future reference.
-
Page 3: Table Of Contents
2.3. Order of assembly..............6 2.4. Hoisting and securing the array (secondary safety)..... 9 Care and maintenance..........10 3.1. Transport / Storing............... 10 3.2. Visual and functional inspection.......... 10 Declarations..............11 4.1. Manufacturer's declaration..........11 4.2. Disposal................. 11 d&b Z5385 Rigging manual 1.4 en... -
Page 4: Z5385 V Flying Adapter
10. 1.1.3. Load safety information NOTICE! The Z5385 V Flying adapter is designed to suspend a total of 4 x V8 or V12 cabinets which corresponds to a total system weight of 136 kg (300 lb) – SWL. -
Page 5: Assembly
Choose the appropriate hole position in the center bar according to the ArrayCalc calculation and attach the Rota clamp correspondingly. Note: Please observe the relevant mounting instructions which are enclosed with the Rota clamp. d&b Z5385 Rigging manual 1.4 en... -
Page 6: Preparing The Setup
1. At the front release both Locking pins and slide out the Front link. 2. Insert and lock one Locking pin to fix the link in place. 2. On the rear release both Locking pins and fold out the Splay link. d&b Z5385 Rigging manual 1.4 en... - Page 7 0° to 14° in 1° steps. Þ Preselect the splay angle according to your ArrayCalc simulation and insert and lock one Locking pin in the appropriate hole. d&b Z5385 Rigging manual 1.4 en...
- Page 8 Check the splay angle settings and the Splay links on the rear of the cabinets and ensure all Locking pins are properly inserted and locked. – In "Single pick point operation" check the desired total vertical aiming of the entire array using an inclinometer. d&b Z5385 Rigging manual 1.4 en...
-
Page 9: Hoisting And Securing The Array (Secondary Safety)
The chain hoist motors must raise the system slowly and evenly so that it does not swing or move from side to side during hoisting. When the array is in its final operating position the secondary safety must be applied. d&b Z5385 Rigging manual 1.4 en... -
Page 10: Care And Maintenance
® – Regularly lubricate the Locking pins using WD-40 or a similar product. Z5385 V Flying adapter Visual inspection regarding deformation and damage (e.g. cracks and corrosion) including all drilled holes of the component. d&b Z5385 Rigging manual 1.4 en... -
Page 11: Declarations
When out of use the rigging components must be disposed of in accordance with the national environmental regulations. Ensure that damaged rigging components are disposed of in a way that they cannot be used again. d&b Z5385 Rigging manual 1.4 en... - Page 12 www.dbaudio.com...
