Interior Fuses - Chrysler 200 2016 User Manual

M A I N T A I N I N G Y O U R V E H I C L E
Cavity Cartridge Fuse
F95
F96
F97
F98
F99
F100

Interior Fuses

The interior fuse panel is located in the passenger compartment on the left side dash panel under
the instrument panel.
Cavity
F13
F32
F36
F37
F38
F43
F48
F49
F51
F53
F89
F91
F92
F93
190
Blade Fuse
– 10 Amp Red
– 10 Amp Red
– 10 Amp Red
– 25 Amp Clear
–
–
Blade Fuse
15 Amp Blue
10 Amp Red
10 Amp Red
7.5 Amp Brown
20 Amp Yellow
20 Amp Yellow
20 Amp Yellow
7.5 Amp Brown
10 Amp Red
7.5 Amp Brown
5 Amp Tan
5 Amp Tan
5 Amp Tan
10 Amp Red
Electrochromatic Mirror/Rain/
Pass. Window SW/Power Outlet
Console Illumination/Sensor/
Sunroof – If Equipped
Occupant Restraint Controller
Occupant Restraint Controller
Audio Amplifier – If Equipped
–
–
Description
Low Beam Left
Interior Lighting
Intrusion Module / Siren
Aux. Switch Bank Module (ASBM)
All Doors Lock/Unlock
Washer Pump Front
Horns
Lumbar Support
Driver Window Switch / Power Mirrors – If
Equipped
UCI Port (USB & AUX)
Trunk Lamp
Fog Lamp Front Left
Fog Lamp Front Right
Low Beam Right
Description
(ORC) (Airbag)
(ORC) (Airbag)
Not Used
Not Used
