- Page 1 202311Q ( B1 & B2 ) QUEEN SIZE BED ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE www.coastercompany.com PAGE 1 OF 5 REVISION 0 : 03/07/2012 REVISION 1 : 06/28/2012...
-
Page 2: Parts Identification
202311Q (B1 & B2) ITEM : ASSEMBLY INSTRUCTIONS 202311KE ( B1 & B2 ) ASSEMBLY TIPS: 1. Remove hardware from box and sort by size. 2. Please check to see that all hardware and parts are present prior to start of assembly. - Page 3 **BACK VIEW **BACK VIEW IF PURCHASE HEADBOARD ONLY, SKIP BELOW STEPS 202311Q (B1 & B2) - BOX 1 & BOX 2 STEP 3 Align and fasten the bed rails to headboard and footboard using short bolt,lock washer and flat washer and tighten with Allen wrench.
- Page 4 ITEM : ASSEMBLY INSTRUCTIONS 202311Q (B1 & B2) STEP 4 Align and fasten bottom cross rail (I) to bed slat support (G) using pan head screw (11) and tighten with screw driver ( not included ) then place it into the bed.
- Page 5 ITEM : ASSEMBLY INSTRUCTIONS 202311Q (B1 & B2) STEP 5 5.1: Place the center rail (E) onto the bed slat support (G).Place the roll slat (F) onto the bed rail,towards the headboards.Align and fasten the 2nd slat (F) to the center rail (E) and the 1st bed slat support (G) using long bolt (6) and tighten with Allen wrench (10).
