Reflex iC60N Reference Manual page 34

Use
Padlocking
This procedure shows how to padlock the integrated control circuit breaker before starting any electrical
work. It is impossible to close the circuit breaker either remotely or locally without removing the padlock
and pushing in the padlocking device.
Step
34
R e fl
1
N e1 .2 .3
x iC 60
-M od
R ef le
R ea dy
I. O N
FF
O . O au to
ea t
O ve rh
O FF
Action
1 Pull out the padlocking device from the Reflex iC60 integrated control circuit breaker
2 Attach the padlock (diameter 3 to 6 mm) to the padlocking device
3 On 3P/4P circuit breaker models attach a second padlock to the circuit breaker using the A9A26970
accessory
4 The integrated control circuit breaker is electrically isolated
e x
Ø3...6 mm
2
R ef le
N e1 .2 .3
x iC 60
-M od
R ea dy
I. O N
FF
O . O au to
ea t
O ve rh
O FF
4P 3
A9A26970
A9MA03EN 02/2012
