Introduction

Overview

Introduction
The Reflex iC60 integrated control circuit breaker combines the function for remote control of an
installation and the protection functions of a circuit breaker in a single unit. Reflex iC60 integrated control
circuit breakers are available with 2, 3 and 4 poles.
All Reflex iC60 products have two 230 V AC local controls:
Input Y1: latched order local control or on edges (depending on operating mode)
Input Y2: local one-shot closing and opening control
The Reflex iC60 product version with Ti24 enables the Reflex iC60 circuit breaker to interface directly with
a PLC, in order to:
Execute remote control (input Y3, low level 24 V DC)
Indicate the position (open/closed) of the circuit breaker's poles (O/C contacts) or tripping of the circuit
breaker (auto/OFF contacts)
The iMDU auxiliary is used to control the Reflex iC60 circuit breaker at 24/48 V AC/DC.
Catalog numbers of Reflex iC60 circuit breakers
There are 2 families of integrated control circuit breakers (Reflex iC60N and Reflex iC60H) which are
characterized by their breaking capacity.
Family
Operating voltage Ue
Ultimate breaking capacity Icu
Service breaking capacity Ics
The composition rule for A9C••••• catalog numbers is as follows:
Field A9
Meaning Acti 9 range
Example: Catalog number A9C62316 corresponds to a type N, curve C, 3P, 16 A Reflex iC60 integrated
control circuit breaker with Ti24 interface.
Catalog numbers of Reflex iC60N integrated control circuit breakers with Ti24 interface:
Reflex Number of poles
iC60N
2 P
Tripping curves
Rating B C
10 A A9C61210 A9C62210
16 A A9C61216 A9C62216
25 A A9C61225 A9C62225
40 A A9C61240 A9C62240
63 A A9C61263 A9C62263
Catalog numbers of Reflex iC60N integrated control circuit breakers without Ti24 interface:
Reflex Number of poles
iC60N
2 P
Tripping curves
Rating B C
10 A - A9C52210
16 A - A9C52216
25 A - A9C52225
40 A - A9C52240
63 A - A9C52263
10
Reflex iC60N
220 to 240 V 380 to 415 V
20 kA 10 kA
63 A rating: 50% Icu
Other ratings: 75% Icu
C • = 5 / 6
Control 5 = without Ti24
interface
6 = with Ti24 interface
3 P
D B
A9C63210 A9C61310
A9C63216 A9C61316
A9C63225 A9C61325
- A9C61340
- A9C61363
3 P
D B C
- - A9C52310
- - A9C52316
- - A9C52325
- - A9C52340
- - A9C52263
Reflex iC60H
220 to 240 V
30 kA
All ratings: 50% Icu
• = 1 / 2 / 3 / 4
1 = type N, curve B
2 = type N, curve C
3 = type N, curve D
4 = type H, curve B
4 P
C D B
A9C62310 A9C63310 A9C61410
A9C62316 A9C63316 A9C61416
A9C62325 A9C63325 A9C61425
A9C62340 - A9C61440
A9C62363 - A9C61463
4 P
D B
- -
- -
- -
- -
- -
380 to 415 V
15 kA
• = 2 / 3 / 4 •• = A
2 = 2 poles •• =
3 = 3 poles 10 A/16 A/25 A/
4 = 4 poles 40 A/63 A
C D
A9C62410 A9C63410
A9C62416 A9C63416
A9C62425 A9C63425
A9C62440 -
A9C62463 -
C D
A9C52410 -
A9C52416 -
A9C52425 -
A9C52440 -
A9C52263 -
A9MA03EN 02/2012
