FCC TEST REPORT
Report No.: EMC-FCC-R0067
http://www.emc2000.co.kr
Appendix 6.
User manual
EMC
compliance
Ltd.
Page: 1 of 1
480-5 Shin-dong, Yeongtong-gu, Suwon-city, Gyunggi-do, 443-390, Korea
82 31 336 9919 (Main) 82 31 336 4767 (Fax)
This test report shall not be reproduced except in full, Without the written approval.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS6204W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CommScope CS6204W

  • Page 1 FCC TEST REPORT Report No.: EMC-FCC-R0067 http://www.emc2000.co.kr Appendix 6. User manual compliance Ltd. Page: 1 of 1 480-5 Shin-dong, Yeongtong-gu, Suwon-city, Gyunggi-do, 443-390, Korea 82 31 336 9919 (Main) 82 31 336 4767 (Fax) This test report shall not be reproduced except in full, Without the written approval.
  • Page 2: Key Features

    VoIP, and Wi-Fi service at the speed of up to 300 Mbps per subscriber. CS6204W allows up to 32 subscribers to share the data of 1.25Gbps with one optic cable via passive optical distribution device. It adopts the state-of-the-art E-PON technology.
  • Page 3: Contents Of The Package

    Power Adaptor Precautions Warning Before you install the CS6204W, read this section. This section contains important safety information you should know before working with the system. Power Considerations Be careful when connecting the system to the supply circuit so that wiring is not ...
  • Page 4: Disposing Of The System

    PON ONT To completely turn off the system, disconnect the power connection to all power  supplies. For DC power supplies, locate the circuit breaker on the panel board that  services the DC circuit, switch the circuit breaker to the off position, and tape the switch handle of the circuit breaker in the off position.
  • Page 5: Installation

    1. Connect the SC/APC connector on the side of a yellow single-mode optical fiber into the optical terminal of the optical outlet and the other connector into the PON port of CS6204W by pushing them until you hear a clicking sound. 2. Connect CS6204W and PC with Ethernet cable.
  • Page 6 PON ONT 8. Make sure that the PON LED is ON in several seconds or minutes. If PON LED is red, the optical signal is very low, so please contact the carrier. 9. If everything is installed properly, the user can see the DATA LED blink while Internet data is sent / received.
  • Page 7: System Architecture

    PON ONT System Architecture Front Panel Name Color Status Function Actions to take Power ON Normal Operation Check Power switch at the back POWER BLUE Power OFF panel-> Power adapter & power outlet Link Up (Normal) Normal Operation BLUE BLINK Link Down.
  • Page 8: Rear Panel

    PON ONT Wireless Link Down CALL Service Provider PHONE Link Up Normal Operation PHONE 1,2 BLUE BLINK Transmitting/Receiving voice data Normal Operation PHONE Link Down CALL Service Provider Rear Panel Indication Description PON Interface 1.25G PON Port Wi-Fi Protect Setup RESET Resets the system to factory default.
  • Page 9: Troubleshooting

    Make sure that the ONT is turned on. Once you turn on the power, the POWER LED on the front panel of CS6204W should be turned on. If the POWER LED is turned OFF, please check if the power cable is connected to the power inlet of ONT properly or switch of power strip if any is turned ON.
  • Page 10: Specification

    PON ONT Specification Item Description Standard IEEE 802.3ah Type Desktop System Architecture Size (mm) 215(W) x 160(D) x 45(H) Input: 110~220 V ± 15%, 60 ± 3Hz Power Output: 12V, 1.5A (power adaptor used) Consumption: Max 10.0W PON interface 1.25G 1000Base-PX, 1 Core SMF User interface 4 10/100base-Tx (IEEE 802.3u) Available Interface...
  • Page 11 PON ONT - Support SIP - RTP / RTCP Support RFC 3550 & RFC 3551 - Support call waiting, call holding, call forwarding - Three Party Service - Support caller ID display (Type 1 and 2) - Support DTMF - Support OAM Remote Loop back test. System Operation Link...
