Summary of Contents for Esse Plus 500
-
Page 2: Table Of Contents
P.10 STATUTORY WARNINGS. Please read these operating instructions carefully for full information on the safe installation, use and care of your new Esse appliance. This appliance must be correctly installed in accordance with these instructions by a suitably qualified person. - Page 3 Do not let children near the oven during use to avoid the danger of burns or injury. Use of the appliance by the elderly or infirm should be supervised. The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements.
-
Page 4: Technical Data
Induction Zone: After use, switch off the hob element by its control and do not rely on the pan detector. During cooking, food naturally produces steam, which is vented away to prevent excessive build-up within the ovens. As steam can condense to water droplets on the cooler outer trim of the oven, it may be necessary during cooking to wipe away any moisture with a soft cloth. -
Page 5: Your Cooker
YOUR COOKER. The Esse Plus-500 has a 400watt element which heats the Top and lower warming/slow cooking compartments and it thermostatically controlled to between 85°C and 90°C. There are 3 specification options with regard to the Plus 500 top. An unheated anodised aluminium top (Plus-500), a heated aluminium top (Plus-500 HT) which heats up to around 45°C and... -
Page 6: Unpacking Your New Cooker
UNPACKAGING YOUR NEW COOKER. Unpack your new Esse Cooker, removing all of the outer packing and accessories from the top and bottom ovens, including protective film on the door liners. At this time please examine the cooker for any damage to the enamel finish and hob glass. -
Page 7: Connecting Your Cooker
CONNECTING YOUR COOKER For your own safety we recommend that a competent person installs your cooker. Connecting the Plus-500, Plus-500 HT & Plus-500 IT The Plus-500, Plus-500 HT & Plus-500 IT cookers are designed to be installed using a standard 13 Amp plugs. A qualified electrician is not required. -
Page 8: Spacing & Dimensions
SPACING AND DIMENSIONS. Fig. 3 Plus-500 Cooker Dimensions All dimensions are in mm Page 8 PLUS-500-I03-160617... - Page 9 The cooker is not to be grouted or sealed at the back or sides of the worktop as if any maintenance is required the cooker will have to be pulled away from the wall at the rear. This is to allow the cooker top to be lifted.
-
Page 10: Commissioning Checklist
COMMISSIONING CHECKLIST To assist with any potential guarantee claim please complete the following information:- To be completed by the installer. Dealer the appliance was purchased from: Name: Address: Telephone No: ESSENTIAL information: Date Installed Model Description: Serial No: Installation Engineer: Company Name: Address: Telephone No:... -
Page 11: Cooker Controls
COOKER CONTROLS Fig.4: Plus-500 Warming/Slow Cook control. ON/OFF Switch LED lights up RED when on. Fig.5: Plus-500 IT Induction User Interface (UI) Page 11 PLUS-500-I03-160617... - Page 12 WARMING/SLOW COOK OVEN. The oven works with a simple on/off switch with one element heating both the top and bottom chamber. When the Plus-500 HT (Hot Top) specification is selected, a 50 watt stick on element is attached to the underside of the aluminium plate. This is wired in to the Warming/Slow cooking element and is activated and de- activated at the same time as the oven element.
-
Page 13: Oven
Points to remember when slow-cooking: • Preheat the oven before starting to cook. • Do not allow dishes to touch the heating elements either side of the oven. • Bring casseroles, soups etc. to the boil on the hob before placing into a suitable casserole dish for slow cooking. -
Page 14: Induction Zone
INDUCTION ZONE Induction cooking is a safe, efficient and economical cooking method. It works by electromagnetic vibrations generating heat directly in the pan, rather than traditional electric hob technologies that indirectly heat though a glass surface or metal plate. As a result of the induction technology, the glass surface only heats up due to heat transfer from the pan. - Page 15 Some aluminium pans available have a magnetic core inserted in the base which will make them suitable. Esse do not recommend these pans as they have been known to cause issues with induction hobs. Pans should have a thick flat base. Do not use cookware with jagged edges or a curved base Fig.
- Page 16 Always lift pans off the induction hob – do not slide, or they may scratch the glass. Fig. 12 Using your Induction Hob he induction hob has 3 rings or burners. Two are Ø145mm with 1.6kW elements and one Ø210mm ring or burner with a 2kW element. Fig.
- Page 17 The induction is controlled via User Interface (UI) shown in Fig 5. The set power level, any error codes and any selected functions are displayed on the induction status display, shown Fig 5. Each induction zone has 9 power settings, a timed full power boost setting (P) and a timer function.
- Page 18 User interface initial calibration. The User Interface has implemented an initial keyboard calibration focused to adapt the sensibility of the keys, to the final mechanical, environmental and user conditions. Any time the Cooktop is plugged in or there is a power failure that generates a reset in the user interface, the first time the Key Lock is touched the sensitivity of the keyboard is readjusted.
- Page 19 Switching On/Off the Cooktop The cooktop is switched ON by touching the [ON/OFF] key for 1 sec. A beep sounds and all the heater displays show the digit point. Fig. 16 ON/OFF If the selection of a heater is not done in 10 seconds, the cooktop will be turned off automatically.
- Page 20 Switching On a Heater To switch on a heater it is necessary to actuate the desired cooking zone or zones. Once the KEY LOCK is disabled and the hob turned ON, this is done by means of selecting the heater and then selecting the required power level.
- Page 21 When the heater selection finishes, if all the heaters are off, all the heater displays will show the digit point, waiting a heater selection. Fig. 18 Selecting a power level for a heater Once the heater is selected, the power level can be selected by touching the –...
- Page 22 With the heater at Booster level, if the + key is Touched an error beep sounds and the cooking level doesn’t change. With the heater at Booster level, if the - key is Touched a beep sounds and the cook level is reduced to 9. Fast Boil (Booster) Function After a heater has been selected, touch the + key until level 9.
- Page 23 Fig. 21 PRESS SIMULTANEOUSLY Key Lock Touching the KEYLOCK key for 1 second, the key lock function is activated and deactivated. If the LED associated to the key lock key is on, the keyboard is locked. The locking function can be activated when the heaters are on or when the cook top is off.
- Page 24 Automatic Safety Shut Off If the power level is not changed during a pre-set time, the corresponding heater turns off automatically. The maximum time a heater can stay on, depends on the selected cooking level Power Level Maximum Time ON (hours) Operating the timer The timer value can be selected between 1 and 99 minutes.
- Page 25 Fig. 23 When the timer is waiting a time selection, the timer value can be selected between 0 and 99 minutes touching the + or - keys. The remaining time will be displayed in the opposite part of timed heater. If the + or - key is touched continuously the change speed is increased automatically.
- Page 26 Altering the Timer To change the time for a timed heater it is a repeat of the setting process. Fig. 24 Select the timed heater to see the remaining time PRESS Fig. 24 Change the time if desired Fig 25.Accept the time PRESS Page 26 PLUS-500-I03-160617...
- Page 27 Residual Heat Display: After turning off the induction unit, the residual heat on the cooking element is displayed as an H. Pot Detection: If cookware is not detected, the ‘suspended pot’ is shown on the Induction status display. If no cookware is recognised, the induction zone will switch off automatically after 10 minutes.
- Page 28 Heat Setting Suitability Delicate warming for small amounts of food Melting chocolate, butter and foods that burn quickly. Gentle simmering Slow warming. Reheating Rapid simmering Cooking rice Pancakes Sautéing Cooking pasta ...
- Page 29 Page 29 PLUS-500-I03-160617...
- Page 30 Page 30 PLUS-500-I03-160617...
-
Page 31: Caring For Your Esse
Never use the appliance as a work or storage surface. CARING FOR YOUR ESSE COOKER. Your Esse cooker is very easy to keep clean. Splashes and spills on the vitreous enamel should be wiped away as soon as possible, using a damp soft cloth. Micro-fibre cloths are especially good for this. -
Page 32: Extraction
The door handles can be adjusted using the adjustment screw on the lift up latch part of the handle. A video on how to adjust the door handle is on the Esse TV section of www.esse.com. Replacement door ropes can also be purchased form www.esse.com... -
Page 33: Guarantee
Your ESSE is guaranteed against defects arising from faulty manufacture for 2 years when supplied by an ESSE Specialist. Upon registration of the warranty, ESSE will extend the guarantee period to 5 years from purchase. Your details must be registered with us by either returning the completed warranty card or by completing registration on-line at www.esse.com. - Page 34 ESSE dealer or by contacting Esse via telephone (01282 813235) or our website, www.esse.com. Should you have cause for dissatisfaction with your cooker, you should contact your ESSE dealer, who will, in most instances, be able to offer you immediate assistance. You will be required to give the following details.
- Page 35 Page 35 PLUS-500-I03-160617...
- Page 36 ESSE Engineering Limited, Ouzledale Foundry, Long Ing, Barnoldswick, Lancashire BB18 6BJ Tel. 01282 813 235, Fax: 01282 816 876 Website and On-line Store http://www.esse.com Page 36 PLUS-500-I03-160617...
