INFORMATION FOR USE WHEN ORDERING SPARES:
Cooker Model:
Serial Number:
Colour:
Technical Information
Nominal heat output (total)
Nominal heat output (to water)
Nominal heat output (to space)
Weight of appliance
Minimum chimney draught
Mean flue gas temperature
Flue gas mass flow
This appliance is not suitable for installation in a shared flue system
ADDITIONAL SERVICEABLE PARTS
1. Combuster (shown below)
2. Brick Linings
3. Baffle & plug
ESSE Engineering Ltd. Limited, Long Ing, Barnoldswick, Lancashire BB18 6BN
Tel: 01282 813235 Fax: 01282 816876 Email: enquiries@esse.com Website: http://www.esse.com
kW
7.9kW
kW
3.0kW
kW
4.9kW
Kg
370kg
Pa
12
°C
164
g/s
9,8
08/08
ESSE Woodfired Cooker
INSTALLATION INSTRUCTIONS
MODEL: WD
THIS APPLIANCE MUST BE COMMISSIONED BY A HETAS REGISTERED ENGINEER OR A COMPETENT
PERSON. THE WARRANTY CARD MUST BE RETURNED TO ENSURE GUARANTEE VALIDITY
HETAS
Approved
Advertisement
Table of Contents
Related Manuals for Esse WD
Summary of Contents for Esse WD
- Page 1 2. Brick Linings 3. Baffle & plug ESSE Engineering Ltd. Limited, Long Ing, Barnoldswick, Lancashire BB18 6BN Tel: 01282 813235 Fax: 01282 816876 Email: enquiries@esse.com Website: http://www.esse.com THIS APPLIANCE MUST BE COMMISSIONED BY A HETAS REGISTERED ENGINEER OR A COMPETENT HETAS PERSON.
- Page 2 The illustration below provides essential boiler tapping measurements and will help when appliance, it should not support any part of the selecting the location of the cooker. When installing a WD with a Plus2 module, pipe work will need l Be a minimum 4.6m high from hob chimney level chimney.
- Page 3 steady. The flue draught reading should now be taken, the minimum required is 12 pascals (0.05” w.g.). CHIMNEY AND FLUE Maximum reading: The air slider control can now be opened to allow the appliance to burn at 1) Pressure and suction zones created by wind maximum rate, and the firedoor open on the first catch.
- Page 4 Typical DHW Gravity System HOT WATER SYSTEMS The two connections will be supplied by your installer, both 1” BSP Female (Rp1) – on the left hand side OPEN VENT OPEN VENT for hot water. The storage cylinder should be 30-gallon nominal capacity insulated to prevent heat loss and as close to the cooker as possible.
