SPECIFICATIONS

2005 Phoenix 200
Gross Vehicle Weight
Dry Weight
Fuel Capacity
Engine Oil Capacity
Transmission Oil
Rear Gearcase Oil
Rear Rack
Tongue Weight
Tow Capacity
Turn Radius
Ground Clearance
Length
Width
Height
Seat Height
Wheel Base
Engine Model Number / Type
Lubrication
Bore x Stroke
Displacement
Compression Ratio
Engine Cooling
Alternator Output (watts)
Carburetion
Main Jet
Pilot Jet
Jet Needle
Air Screw
Ignition
Timing
Spark Plug Type / Gap
96
Capacities
720 lbs. (326 kg)
395 lbs. (179.2 kg)
2.5 gal. (9.5 l)
41 oz. (1200 ml)
18.6 oz. (550 ml)
4 oz. (120 ml)
70 lbs. (31.7 kg)
30 lbs. (13.6 kg)(Rear rack weight and tongue
weight not to exceed 30 lbs./13.6 kg)
300 lbs. (136 kg)
65 in. (165.1 cm) unloaded
5.7 in. (14.5 cm)
65 in. (165.1 cm)
42 in. (106.7 cm)
42 in. (106.7 cm)
32 in. (81.3 cm)
45 in. (114.3 cm)
Engine & Cooling
4 Cycle, Single Cylinder
Wet Sump
65 x 59
196 cc
9.2:1 Full Stroke
Air cooled
210w @5000 rpm
1 / 22 mm (VM Type)
108
35
2MKNN-4 clip
1 Turn Out
DC CDI
32° ± 2° @ 3000 RPM
NGK R7HSA / 0.6-0.7 mm
