Electrical Switches

5
4
1. Light Switch/Hi-Lo Beam Control - The lights won't turn on
unless the main key switch is on.
2. Engine Stop Switch - The engine will not
start or run when the switch is in the OFF
position. Its purpose is to provide the
operator with a quick means of engine
shutdown in case of an emergency. To stop
the engine, press the lower end of the rocker
switch down to the OFF position. Before
starting the engine, press the upper end of the
switch down to the ON position.
3. Main Key Switch - Turn the main key
switch clockwise to the ON position before
starting the engine. Turn the main switch off
to stop the engine and end all electrical
power to the vehicle.
4. Start Button - To start the engine, make sure
the stop switch is in the ON position. Turn
the main key switch on. Press the start
button.
WARNING
Activating the override switch while the throttle is open can cause
loss of control, resulting in severe injury or death. Do not activate
the override switch while the throttle is open.
5. Override Switch (Reverse Speed
Limiter) - This vehicle is equipped
with a reverse speed limiter
system. To gain additional power
while backing, depress the override
switch.

FEATURES AND CONTROLS

1 2
3
2
5
3
