MAINTENANCE AND LUBRICATION
Adjustments

Brakes (Rear)

Periodically measure the freeplay of the rear brakes. To adjust rear
brake freeplay, turn the adjuster nuts (1) at the rear brake drum.
Brake Lever Travel (Rear)
Service the brakes when
brake lever travel reaches
2 1/2" (65 mm). Always
service the brakes when there
is no longer sufficient stopping
ability at the specified lever
travel setting.
82
.40"-.80"
(10-20 mm)
2 1/2"
(65 mm)
1
