Zaxcom IFB200
Extended Menu
Group ID Select
REMOTE CONTROL
GROUP CODE = 1
This menu allows you to set your IFB200 to a ZaxNet "GROUP." This is the group code that the IFB200 is
controlled in – not what group the IFB200 is controlling.
Group ID lets you set your IFB200 to a "GROUP" that will be controlled via ZaxNet.
So for example set to Group 1 will be controlled by a ZaxNet transmitter set to Group 1 and a group 2 will be
controlled by a Group 2 ZaxNet transmitter. This allows one group to be controlled without affecting others.
This will also help if two or more people on set are sending ZaxNet commands each person will be
independent and won't interfere with each other. Most users leave this set to 1 on all of their Zaxcom
products. Group codes can be set from 1 to 99.

Audio Input Select

INPUT: ANALOG
This menu sets the audio input type.
ANALOG - This setting is used when the IFB200 will input an analog audio signal.
•
DIGITAL L - This setting is used when Inputting a digital signal on pins 1, 2, 3 on the TA5 connector.
•
DIGITAL R - This setting is used when inputting a digital signal on pins 1, 4, 5 on the TA5 connector.
•

Minimum Frequency

MIN FREQ: 512.0
(TVCHAN MIN 21)
This menu sets the lowest UHF frequency that the IFB200 will cycle to when remote controlling TRX
transmitters. This eliminates having to cycle through frequencies that are out of the range that you are
working in.

Maximum Frequency

MAX FREQ: 698.0
(TVCHAN MIN 51)
This menu sets the highest UHF frequency that the IFB200 will cycle to when remote controlling TRX
transmitters. This eliminates having to cycle through frequencies that are out of the range that you are
working in.
19
