INSTALLATION INSTRUCTIONS
PACKAGED HEAT PUMP
I30H1-A
I36H1-A
I30H1-B
I36H1-B
I30H1-C
I36H1-C
I36H1DA
I30H1DA
I30H1DB
I36H1DB
I30H1DC
I36H1DC
Bard Manufacturing Company, Inc.
Bryan, Ohio 43506
www.bardhvac.com
I-TEC
SERIES
®
Models:
I42H1-A
I42H1-B
I42H1-C
I42H1DA
I42H1DB
I42H1DC
I48H1-A
I48H1-B
I48H1-C
I48H1DA
I48H1DB
I48H1DC
MIS-2957 A
Manual:
Supersedes:
Date:
I60H1-A
I60H1-B
I60H1-C
I60H1DA
I60H1DB
I60H1DC
2100-549Q
2100-549P
6-14-17
Page
1 of 61
