Troubleshooting Tips
If the Helios 10 is not performing as expected, try the following:
®
a. Confirm that your power input is active from your breaker panel and providing 240
Volts / 50 Amps / 60 Hz to the controller.
b. Check the voltage input of your incoming cord set using a voltage test meter to verify
power is flowing to the controller.
c. Make sure all of your connections are tight. Loose connections can cause "arcing".
d. Then confirm that power is active and proper at your 240 volt outlets.
e. Verify that your power cords and ballasts are functioning properly and that there are
no shorts or arcing occurring.
f. Should you find your circuit breaker keeps tripping, check your breakers in your
panel to verify that they are the right amperage for your application. Replace 50 Amp
breaker in panel if necessary.
g. If you unplug the trigger cord set from 120 Volt power source and your lights remain
on, contact us immediately for resolution.
h. Still having problems with your Helios
Representative to assist you further.
Controller Specifications:
• Size = 13"H x 11"W x 4"D
• Weight = 13 lbs.
• Voltage Input = 240 VAC
• Voltage Output = 240 VAC
• Relay Coil Voltage = 120 Volts
• Maximum Amperage Input = 50 Amps
• Maximum Amperage Output = 40 Amps
• Maximum Wattage = 8000 Watts (1000 watts per outlet)
• Hertz = 60Hz
• Electrical Relay Operations = 100,000 Cycles
• RoHS compliant = Yes
• Storage Temperature = 32°F (0°C) to 135°F (57°C)
• Operating Temperature = 40°F (5°C) to 125°F (52°C)
® 10? Please contact our Technical Service
4
Installation Example
