Page 5: Introduction/Welcome
INTRODUCTION/WELCOME WELCOME FROM FCA US LLC Congratulations on selecting your new FCA US LLC vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality - all essen- tials that are traditional to our vehicles. Your new FCA US LLC vehicle has characteristics to enhance the driver's control under some driving conditions.
Page 6 INTRODUCTION/WELCOME VEHICLES SOLD IN CANADA With respect to any vehicles sold in Canada, the name FCA US LLC shall be deemed to be deleted and the name FCA Canada Inc. used in substitution (excluding legal lines). WARNING! • Pedals that cannot move freely can cause loss of vehicle control and increase the risk of serious personal injury.
Page 7 If your symptoms persist, please see an authorized dealer. When it comes to service, remember that your authorized dealer knows your vehicle best, has factory-trained technicians and genuine MOPAR ® parts, and cares about your satisfaction. RAM is a registered trademark of FCA US LLC.
Page 8: Controls At A Glance
CONTROLS AT A GLANCE DRIVER COCKPIT 1. Headlight Switch pg. 35 7. Keyless Engine Starting/Stopping pg. 13 2. Electronic Vehicle Information Center (EVIC) Controls pg. 120 8. Four Wheel Drive Operation pg. 130 3. Turn Signal/Wiper/Washer/High Beams Lever pg. 34 9.
Page 9 CONTROLS AT A GLANCE 11. Switch Panel 12. Power Inverter Outlet pg. 127 13. Glove Compartment • Diesel Exhaust Brake 14. Power Outlet • Tow/Haul pg. 147 15. Shifter • Electronic Stability Control pg. 178 16. Hood Release (below steering wheel at base of instrument •...
Page 10: Instrument Cluster
CONTROLS AT A GLANCE INSTRUMENT CLUSTER Warning Lights - Low Fuel Warning Light - Transmission Temperature Warning Light - Charging System Light** - Seat Belt Reminder Light - Oil Pressure Warning BRAKE Light** - Brake Warning Light** - Anti-Lock Brake (ABS) - Malfunction Indicator Light** Light (MIL)**...
Page 11 CONTROLS AT A GLANCE Indicators - Turn Signal Indicators - Electronic Stability Control (ESC) Off Indicator - High Beam Indicator - Cargo Lamp On Indicator - Park/Headlight ON Indica- tor* - Door Ajar Indicator - Front Fog Light Indicator - Electronic Speed Control Set Indicator - Vehicle Security Indicator* - Check Fuel Filler...
Page 12: Getting Started
GETTING STARTED KEY FOB This feature allows the driver to operate the ignition switch with the push of a button, as long as the Remote Keyless Entry (RKE) transmitter is in the passen- ger compartment. The Keyless Ignition Node (KIN) has four operating positions, three of which are labeled and will illuminate when in posi- tion.
Page 13 GETTING STARTED The Wireless Ignition Node (WIN) oper- ates similar to an ignition switch. It has four operating positions, three with de- tents and one that is spring-loaded. The detent positions are OFF, ACC, and ON/ RUN. The START position is a spring- loaded momentary contact position.
Page 14: Keyless Enter-N-Go
GETTING STARTED • When remote key fob lowering is requested the vehicle will send a series of chirps and flashes to alert the customer that the operation has begun and will continue these alerts until it successfully lowers. • If the feature is unable to lower the vehicle due to certain conditions not being met, the horn will chirp twice and the vehicle will not lower.
Page 15 GETTING STARTED To Lock The Vehicle’s Doors • With a valid Keyless Enter-N-Go™ Key Fob transmitter within 5 ft (1.5 m) of the driver or passenger front door handles, press the door handle LOCK button to lock all doors. DO NOT grab the door handle, when pressing the door handle lock button. This could unlock the door(s).
Page 16: Remote Start
GETTING STARTED 3. To stop the cranking of the engine prior to the engine starting, press the button again. NOTE: In case the ignition switch does not change with the push of a button, the RKE transmitter (Key Fob) may have a low or dead battery. In this situation a back up method can be used to operate the ignition switch.
Page 17: Vehicle Security Alarm
GETTING STARTED VEHICLE SECURITY ALARM To Arm: • Lock the door using either the power door lock switch (one door must be open) or the LOCK button on the Remote Keyless Entry (RKE) transmitter (doors can be open or closed), and close all doors. NOTE: The Vehicle Security Alarm will not arm if you lock the doors with the manual door lock plungers.
Page 18: Supplemental Restraint System (Srs) - Air Bags
GETTING STARTED A belt that is too loose will not protect you properly. In a sudden stop you could move too far forward, increasing the possibility of injury. Wear your seat belt snugly. A frayed or torn belt could rip apart in a collision and leave you with no protection. Inspect the belt system periodically, checking for cuts, frays, or loose parts.
Page 19: Child Restraints
GETTING STARTED WARNING! • Relying on the air bags alone could lead to more severe injuries in a collision. The air bags work with your seat belt to restrain you properly. In some collisions, the air bags won't deploy at all. Always wear your seat belts even though you have air bags.
Page 20 GETTING STARTED LATCH Anchors And Tethers For CHildren (Mega Cab/Crew Cab Split Bench Seat) • Your vehicle is equipped with the child restraint anchorage system called LATCH, which stands for Lower Anchors and Tethers for CHildren. • All rear seating positions have lower anchors and top tether anchors. LATCH System Weight Limit •...
Page 21 GETTING STARTED 2. Attach the lower hooks or connectors of the child restraint to the lower anchorages in the selected seating position. 3. If the child restraint has a tether strap, connect it to the top tether anchorage. See below for directions to attach a tether anchor. 4.
Page 22 GETTING STARTED 6. Finally, pull up on any extra webbing to tighten the lap portion around the child restraint while you push the child restraint rearward and downward into the vehicle seat. 7. If the child restraint has a top tether strap and the seating position has a top tether anchorage, connect the tether strap to the anchorage and tighten the tether strap.
Page 23 GETTING STARTED 2. Route the tether strap to provide the most direct path between the anchorage and the child seat. The tether strap should go between the head restraint posts underneath the head restraint. You may need to adjust the head restraint to the upward position to pass the tether strap underneath the head restraint and between its posts.
Page 24 GETTING STARTED 3. Pass the tether strap hook under the head restraint behind the child seat, through the tether strap loop behind the seat and over to the center tether strap loop. Tether Strap Through Outboard Tether Strap Loop 4. Attach the hook to the center tether strap loop (see diagram). Tighten the tether strap according to the child seat manufacturer’s instructions.
Page 25 GETTING STARTED 3. Pass the tether strap hook under the head restraint behind the child seat, through the tether strap loop behind the seat and over to the right or left outboard tether strap loop. Tether Strap Through Center Tether Strap Loop 4.
Page 26: Head Restraints
GETTING STARTED 4. Attach the hook to the outboard tether strap loop. 5. Tighten the tether straps according to the child seat manufacturer’s instructions, tightening the right and left tether straps before the center tether strap. WARNING! • In a collision, an unrestrained child, even a tiny baby, can become a projectile inside the vehicle.
Page 27: Front Seats
GETTING STARTED Rear Head Restraints The rear seats are equipped with adjustable head restraints. To raise the head restraint, pull upward on the head restraint. To lower the head restraint, press the adjustment button, located on the base of the head restraint, and push downward on the head restraint.
Page 28 GETTING STARTED Memory Seat The memory seat feature allows you to save the driver's seat position (excluding lumbar position), driver's outside mirror position, adjustable brake and accelerator pedals, Automatic Temperature Control (ATC) temperature setting and radio station preset settings. The driver's memory buttons are located on the outboard side of the driver's seat cushion.
Page 29: Heated/Ventilated Seats
GETTING STARTED WARNING! • Adjusting a seat while the vehicle is moving is dangerous. The sudden move- ment of the seat could cause you to lose control. The seat belt might not be properly adjusted, and you could be severely injured or killed. Only adjust a seat while the vehicle is parked.
Page 30 GETTING STARTED Vehicle Equipped With Remote Start On models that are equipped with remote start, this feature can be programmed to come on during a remote start. If your vehicle is equipped with a touchscreen, this feature can be programmed through the Uconnect ®...
Page 31 GETTING STARTED REAR HEATED SEATS The rear heated seat switches are located on the rear of the center console. • Press the switch once to select High- level heating. • Press the switch a second time to select Low-level heating. •...
Page 32: Heated Steering Wheel
GETTING STARTED HEATED STEERING WHEEL The steering wheel contains a heating element that heats the steering wheel to one temperature setting. The heated steering wheel control button is located on the center instrument panel below the climate controls. If your vehicle is equipped with a touch- screen, the heated steering wheel control button is located within the climate or controls screen of the touchscreen.
Page 33 GETTING STARTED Vehicle Equipped With Remote Start On models that are equipped with remote start, this feature can be programmed to come on during a remote start. If your vehicle is equipped with a touchscreen, this feature can be programmed through the Uconnect ®...
Page 34: Tilt Steering Column
GETTING STARTED TILT STEERING COLUMN The tilt lever is located on the steering column below the turn signal lever. • To tilt the column, simply pull the tilt lever rearward toward you and then move the steering wheel upward or downward as desired.
Page 35: Operating Your Vehicle
OPERATING YOUR VEHICLE ENGINE BREAK-IN RECOMMENDATIONS A long break-in period is not required for the engine and drivetrain (transmission and axle) in your vehicle. Drive moderately during the first 300 miles (500 km). After the initial 60 miles (100 km), speeds up to 50 or 55 mph (80 or 90 km/h) are desirable. While cruising, brief full-throttle acceleration within the limits of local traffic laws contributes to a good break-in.
Page 36: Turn Signals/Wiper/Washer/High Beams Lever
OPERATING YOUR VEHICLE TURN SIGNALS/WIPER/WASHER/HIGH BEAMS LEVER Turn Signal/Wiper/Washer/High Beam Lever Turn Signals/Lane Change Assist • Tap the lever up or down once and the turn signal (right or left) will flash three times and automatically turn off. Wipers Intermittent, Low And High Operation •...
Page 37: Headlight Switch
OPERATING YOUR VEHICLE HEADLIGHT SWITCH Automatic Headlights/Parking Lights/Headlights • Rotate the headlight switch, located on the instrument panel to the left of the steering wheel, to the first detent for parking lights and to the sec- ond detent for headlights •...
Page 38: Speed Control
OPERATING YOUR VEHICLE Cargo Light The cargo light is strategically placed lighting that helps illuminate the bed area of the truck. A cargo light symbol will illuminate in the cluster to indicate the light is on. • Push the button to turn ON/OFF the cargo lighting. SPEED CONTROL The Speed Control switches are located on the steering wheel.
Page 39 OPERATING YOUR VEHICLE Accel/Decel To Increase Speed • When the Electronic Speed Control is set, you can increase speed by pushing the RES + button. The speed increment shown is dependant on the speed of U.S. (mph) or Metric (km/h) units: U.S.
Page 40: Eight-Speed Automatic Transmission - If Equipped
OPERATING YOUR VEHICLE Cancel • Push the CANCEL switch or apply the brakes to cancel the set speed and maintain the set speed memory. • Push the ON/OFF switch to turn the system off and erase the set speed memory. WARNING! •...
Page 41: Electronic Range Select (Ers) Operation
OPERATING YOUR VEHICLE ELECTRONIC RANGE SELECT (ERS) OPERATION • Electronic Range Select (ERS) allows you to limit the highest available trans- mission gear, and can be activated dur- ing any driving condition. When towing a trailer or operating the vehicle in off- road conditions, using ERS shift control will help you maximize both perfor- mance and engine braking.
Page 42 OPERATING YOUR VEHICLE • For maximum deceleration (engine braking) move the console shift lever left (-) and hold, or toggle the switch on the column shift lever down (-) and hold. Your vehicle will automatically select the lowest safe gear for optimal engine braking. •...
Page 43: 1500 Air Suspension System
Center (EVIC)” in “Understanding Your Instrument Panel” in the Owner’s Manual on the DVD for further information. • Aero Mode (Lowers the vehicle approximately .6 in (15 mm) – 1500 Models Only - This position provides improved aerodynamics by lowering the vehicle. The vehicle will...
Page 44 OPERATING YOUR VEHICLE NOTE: Automatic Aero Mode may be disabled through vehicle settings in the Electronic Vehicle Information Center (EVIC) when equipped with Uconnect 3.0, or your Uconnect ® Radio when equipped with UConnect ® 5.0, 8.4A, or 8.4AN. • Entry/Exit Mode (Lowers the vehicle approximately 2 in (51 mm) - This position lowers the vehicle for easier passenger entry and exit as well as lowering the rear of the vehicle for easier loading and unloading of cargo.
Page 45: 2500-3500 Air Suspension System
OPERATING YOUR VEHICLE NOTE: This mode is intended to be enabled with engine running. Protection Mode • In order to “protect” the air suspension system, the vehicle will enter Protection Mode when the payload has been exceeded or load leveling cannot be achieved. Refer to “Electronic Vehicle Information Center (EVIC)”...
Page 46 OPERATING YOUR VEHICLE Transport Mode • To assist with flat bed towing, the air suspension system has a feature which will put the vehicle into Entry/Exit height and disable the automatic load leveling system. Refer to “Electronic Vehicle Information Center (EVIC)” in “Understand- ing Your Instrument Panel”...
Page 47: Manual Climate Controls Without Touchscreen
OPERATING YOUR VEHICLE MANUAL CLIMATE CONTROLS WITHOUT TOUCHSCREEN Air Recirculation /Max A/C • Use Recirculation for maximum A/C operation. • For window defogging, turn the Recirculation button off. • Recirculation is not allowed in defrost. • Recirculation is allowed in floor mode and defrost/floor (mix modes) for approxi- mately five minutes.
Page 48: Manual Climate Controls With Touchscreen
OPERATING YOUR VEHICLE MANUAL CLIMATE CONTROLS WITH TOUCHSCREEN Touchscreen Manual Climate Controls Climate Control Knobs Air Recirculation • Use Recirculation for maximum A/C operation. • For window defogging, turn the Recirculation button off. Heated Mirrors The mirrors are heated to melt frost or ice. This feature is activated whenever you turn on the defroster.
Page 49: Automatic Climate Controls With Touchscreen
OPERATING YOUR VEHICLE AUTOMATIC CLIMATE CONTROLS WITH TOUCHSCREEN Touchscreen Automatic Climate Controls Climate Control Knobs • Push the AUTO button or press the AUTO soft-key. • Select the desired temperature by pushing the up or down temperature buttons for the driver or passenger. •...
Page 50: Parksense® Front And Rear Park Assist
OPERATING YOUR VEHICLE Air Conditioning (A/C) • If the air conditioning button is pressed while in AUTO mode, the system will exit AUTO mode and stay in A/C. The mode and blower will be set at the closest mode and blower position that the system was operating in AUTO. SYNC Temperature Soft-Key •...
Page 51: Parkview® Rear Back-Up Camera
OPERATING YOUR VEHICLE Cleaning The ParkSense® Sensors If “CLEAN PARK ASSIST SENSORS” appears in the Electronic Vehicle Information Center (EVIC), clean the ParkSense sensors with water, car wash soap and a soft ® cloth. Do not use rough or hard cloths. Do not scratch or poke the sensors. Otherwise, you could damage the sensors.
Page 52: Power Sliding Rear Window
OPERATING YOUR VEHICLE POWER SLIDING REAR WINDOW The switch for the power sliding rear window is located on the overhead console. • Push the switch right to open the glass and pull the switch left to close the glass. POWER SUNROOF •...
Page 53: Wind Buffeting
OPERATING YOUR VEHICLE Closing Sunroof Express Closing • Press the switch forward and release it within one-half second. The sunroof will fully close automatically from any position. Manual Closing • Press and hold the switch forward to close the sunroof. Any release of the switch will stop the movement, and the sunroof will remain in a partially closed position until the switch is pressed again.
Page 54: Electronics
ELECTRONICS YOUR VEHICLE'S SOUND SYSTEM 1. Uconnect ® Voice Command Button pg. 114 2. Uconnect ® Phone Button pg. 110 3. Steering Wheel Audio Controls (Left) pg. 119 4. Steering Wheel Audio Controls (Right) pg. 119 5. Volume Knob/Audio Mute Button 6.
Page 55 ELECTRONICS 7. 9-1-1 Button pg. 61 8. Uconnect ® 8.4 Radio pg. 79 9. Screen Off Button 10. Back Button 11. Tune/Scroll Knob/Browse/Enter Button 12. Media Hub: Audio Jack, USB Port, and SD Card Slot (located center console) pg. 85 13.
Page 56: Identifying Your Radio
ELECTRONICS IDENTIFYING YOUR RADIO Uconnect® 3.0 • Two hard-keys on either side of the display Uconnect® 3.0 Uconnect® 5.0 • 5” Touchscreen • Three hard-keys on either side of the display Uconnect® 5.0 Uconnect® 8.4A • 8.4” Touchscreen • Climate soft-key in lower menu bar •...
Page 57: Uconnect® Access
ELECTRONICS Uconnect® 8.4AN • 8.4” Touchscreen • Climate soft-key in lower menu bar • HD Button will be visible on right side of screen when viewing AM or FM • SiriusXM Travel Link feature listed within Apps Uconnect® 8.4AN Uconnect® ACCESS Uconnect®...
Page 58 ELECTRONICS Before you drive, familiarize yourself with the easy-to-use Uconnect® System. 1. The ASSIST and 9-1-1 buttons are located on your rearview mirror. The ASSIST Button is used for contacting Roadside Assistance, Vehicle Care and Uconnect ® Care. The 9-1-1 Button connects you to emergency services. NOTE: Vehicles sold in Canada and Mexico DO NOT have 9-1-1 Call system capabilities.
Page 59 ELECTRONICS 4. Enter your email address into the radio touchscreen. 5. A message will display on the touchscreen indicating your email submission was accepted. 6. At home, or wherever you access your email, look for an email from Uconnect ® Access that contains your personalized registration link.
Page 60 ELECTRONICS iHeartRadio (www.iheart.com) • Click “Sign Up” if you’re new to iHeartRadio, or “Log In” to enter your iHeartRadio account information. • Select “Activate” to continue, • Select “Close” to complete activation. Pandora® (www.pandora.com) • Enter your Pandora username/email address and password, then click “Save.” ®...
Page 61 ELECTRONICS 8. You will receive a confirmation message that your purchase has been submitted. Press the OK button to end the process. Purchasing WiFi Hotspot While In Your Vehicle You must set up a Uconnect Access Payment Account online (log in to ®...
Page 62 ELECTRONICS All Apps — Organizes your Uconnect ® Access Apps (when available). Running Apps — Press this tab to see which apps are currently running. Favorite Apps 1 — Category Tabs 2 — Apps Button Maintaining Your Uconnect® Access Account Reinstalling An App (Uconnect®...
Page 63 ELECTRONICS Selling Your Vehicle When you sell your vehicle, we recommend that you remove your Uconnect ® Access Account information from the vehicle. You can do this using the radio touchscreen in the vehicle (Uconnect® 8.4AN only) or on the Mopar Owner Connect website (moparownerconnect.com).
Page 64 ELECTRONICS connection is made between a 9-1-1 operator and your vehicle, you understand and agree that 9-1-1 operators may, like any other 9-1-1 call, record conversations and sounds in and near your vehicle upon connection. 3. Roadside Assistance (If Equipped) — If your vehicle is equipped with this feature and within wireless range, you may be able to connect to Roadside Assistance by pressing the “Assist”...
Page 65 ELECTRONICS Access, you can purchase a Wifi Hotspot subscription at the Uconnect ® Store. After you've made your purchase, turn on your signal and connect your devices. It's never been easier to bring your home or office with you. Your vehicle must have a working electrical system for any of the in vehicle Uconnect ®...
Page 66 ELECTRONICS To use this feature after the Uconnect ® Access App is downloaded, login using your user name and Uconnect ® Security PIN. Press the “App” button on your smartphone with the closed lock icon to lock the door, and press the “open lock” icon to unlock the driver’s door.
Page 67 ELECTRONICS 5. Wait for the beep and say a contact that is in your phonebook, or a mobile phone number that you would like to send the message to. 6. Uconnect ® will prompt you “Please say the message that you would like to send.” (If you do not hear this prompt, you may not have an active subscription with Uconnect ®...
Page 68 ELECTRONICS To get started using Via Mobile apps, first register your Uconnect ® Access system where you'll be guided through the setup of your Via Mobile (requires a compatible Android or iPhone ® smartphone). Please refer to “Uconnect ® Access Registration” for more information.
Page 69 ELECTRONICS Each time you want to use a Via Mobile app in your vehicle, the Uconnect Access App must be running on your smartphone and the smartphone must be paired via Bluetooth ® If equipped, the Via Mobile apps can be found by selecting the “Apps”...
Page 70 ELECTRONICS NOTE: For detailed information on how to use Via Mobile apps visit the Mopar Owner Connect website (www.moparownerconnect.com) and login using the username and password you set up when registering for Uconnect ® Access. A message will be displayed to remind you that Via Mobile apps utilize the data plan on your connected smartphone to provide content.
Page 71: Uconnect ® 3.0
ELECTRONICS Uconnect® 3.0 Clock Setting 1. Press the Menu button at the bottom of the radio, and push the Enter/Browse button for System Settings. Next, select the Time and Format setting and then select Set Time by pushing the Enter/Browse button. 2.
Page 72 ELECTRONICS Radio Operation Seek Up/Down Buttons • Push to seek through radio stations in AM, FM or SXM bands. • Hold either button to bypass stations without stopping. Store Radio Presets • The Presets are available for all Radio Modes, and are activated by pushing any of the six Preset buttons.
Page 73: Uconnect ® 5.0
ELECTRONICS • If the audio cable is connected to the AUX jack and portable device, press the MEDIA button, then touch the “Source” soft-key and select “AUX” to change the mode to auxiliary device. This allows the music from your portable device to play through the vehicle's speakers.
Page 74 ELECTRONICS • Press the SETTINGS hard-key on the right side of the display, then press the “Clock” soft-key. The Time setting screen is displayed and the clock can be adjusted as described in the following procedure. NOTE: In the Clock Setting Menu you can also select Display Clock. Display Clock turns the clock display in the status bar on or off.
Page 75 ELECTRONICS Store Radio Presets • When you are receiving a station that you wish to commit into memory, press and hold the desired numbered soft-key for more that two seconds or until you hear a confirmation beep. • The Radio stores up to 12 presets in each of the Radio modes. 4 presets are visible at the top of the radio screen.
Page 76 ELECTRONICS Browse • Touch the “Browse” soft-key to scroll through and select a desired track on the Disc. Touch the “Exit” soft-key if you wish to cancel the browse function. USB/Audio Jack (AUX)/Bluetooth® Operation USB/iPod® • USB/iPod ® Mode is entered by either inserting a USB Jump Drive or iPod ®...
Page 77 ELECTRONICS Voice Text Reply (Not Compatible With iPhone®) Once your Uconnect ® system is paired with a compatible mobile device, the system can announce a new incoming text message, and read it to your over the vehicle audio system. You can reply to the message using Voice Recognition, by selecting, or saying one of the 18 pre-defined messages.
Page 78 ELECTRONICS VOICE COMMAND QUICK REFERENCE Uconnect® 5.0 Voice Command Quick Reference If the Uconnect Voice Command button exists on your steering wheel, you ® have the Voice Command feature, which is optimized for the driver. The Voice Command feature lets you keep your hands on the wheel, and your eyes on the road. •...
Page 79 ELECTRONICS Steering Wheel Buttons • You can control many of your radio features using your voice. Press either the Uconnect ® Voice Command button or the Phone Pick Up button on your steering wheel. Available Radio Button Voice Commands Steering Wheel Buttons to Radio Mode Media Mode...
Page 80 ELECTRONICS While In: Voice Command Example: PHONE “Dial 123-456-7890” (phone number) “Call John Smith mobile” (home, office, Call Initiation (Requires that phone has other) been Bluetooth paired with radio) ® “Redial” “Show outgoing” (recent) “calls” “Search for John Smith” (any contact Call Management name in address book) “Show (display list) contacts”...
Page 81: Uconnect® 8.4A
ELECTRONICS Uconnect® 8.4A Uconnect® 8.4A AT A GLANCE Displaying The Time • If the time is not currently displayed on the radio or player main page, touch the “settings” soft-key or the “Apps” soft-key and then the “settings” soft-key. In the Settings list, touch the “Clock”...
Page 82 ELECTRONICS Audio Settings • Touch the “Audio” soft-key to activate the Audio settings screen to adjust Balance\Fade, Equalizer, and Speed Adjusted Volume. • You can return to the Radio screen by touching the “X” located at the top right. Balance/Fade •...
Page 83 ELECTRONICS RADIO • To access the Radio mode, touch the “Radio” soft-key at the lower left of the screen. Selecting Radio Stations • Touch the desired radio band (AM, FM or SXM) soft-key. Seek Up/Seek Down • Touch the Seek arrow soft-keys for less than two seconds to seek through radio stations.
Page 84 ELECTRONICS SiriusXM PREMIER OVER 160 CHANNELS Get every channel available on your satellite radio, and enjoy all you want, all in one place. Hear commercial-free music plus sports, news, talk and entertainment. Get all the premium programming, including Howard Stern, every NFL game, Oprah Radio ®...
Page 85 ELECTRONICS SiriusXM Parental Controls • You can skip or hide certain channels from view if you do not want access to them. Touch the “More” soft-key, then the “settings” soft-key, next touch the” Sirius Setup” soft-key, then select Channel Skip. Touch the box check-mark next to the channel you want skipped.
Page 86 ELECTRONICS Replay Option Description Option Replay Time Displays the amount of time in the upper center of the screen by which your content lags the Live channel. Live Resumes playback of Live content at any time while replaying rewound content. •...
Page 87 ELECTRONICS MEDIA HUB — PLAYING iPod®/USB/MP3 DEVICES There are many ways to play music from iPod ® /MP3 players or USB devices through your vehicle's sound system. Touch your “Media” soft-key to begin. Audio Jack (AUX) The AUX allows a portable device, such as an MP3 player or an iPod ®...
Page 88 ELECTRONICS NOTE: When connecting your iPod device for the first time, the system may take several ® minutes to read your music, depending on the number of files. For example, the system will take approximately five minutes for every 1000 songs loaded on the device.
Page 89 ELECTRONICS iPod®/CD/AUX CONTROLS The iPod ® /CD/AUX controls are accessed by touching the desired soft-key displayed on the side of the screen and choosing between Disc, AUX, iPod ® , Bluetooth or SD Card. NOTE: Uconnect ® will usually automatically switch to the appropriate mode when some- thing is first connected or inserted into the system.
Page 90 ELECTRONICS Finding Points Of Interest (POI) • From the main Navigation menu, touch the “Where To?” soft-key, then touch the “Points of Interest” soft-key. • Select a Category and then a subcategory, if necessary. • Select your destination and touch the “Yes” soft-key. Finding A Place By Spelling The Name •...
Page 91 ELECTRONICS Setting Your Home Location • Touch the “Nav” soft-key in the menu bar to access the Navigation system and the Main Navigation menu. • Touch the “Where To?” soft-key, then touch the “Go Home” soft-key. • You may enter your address directly, use your current location as your home address, or choose from recently found locations.
Page 92 ELECTRONICS • Touch the “Where To?” soft-key, then search for the extra stop. When another location has been selected, you can choose to cancel your previous route, add as the first destination or add as the last destination. • Touch the desired selection and touch the “Yes” soft-key. Taking A Detour •...
Page 93 ELECTRONICS • When your phone finds the system, select “Uconnect” as the paired device. You may be prompted by your phone to download the phonebook. This is so you can make calls by saying the name of your contact (PBAP-Phone Book Access Profile). Complete The Pairing Procedure •...
Page 94 ELECTRONICS Phonebook • Uconnect ® radios will automatically download your phonebook from your paired phone, if this feature is supported by your phone. Entries are updated each time that the phone is connected. If your phone book entries do not appear, check the settings on your phone.
Page 95 ELECTRONICS Voice Text Reply (Not Compatible With iPhone®) Once your Uconnect ® system is paired with a compatible mobile device, the system can announce a new incoming text message, and read it to your over the vehicle audio system. You can reply to the message using Voice Recognition, by selecting, or saying one of the 18 pre-defined messages.
Page 96 ELECTRONICS VOICE COMMAND QUICK REFERENCE Uconnect® 8.4A Voice Command Quick Reference • If the Uconnect ® Voice Command button exists on your steering wheel, you have the Voice Command feature, which is optimized for the driver. The Voice Command feature lets you keep your hands on the wheel, your eyes on the road, and control navigation and media sources.
Page 97 ELECTRONICS Available Radio Soft–Key Voice Commands Steering Wheel (1) Radio (4) Navi- Media Climate Phone (6) APPS Buttons to Mode gation Mode Controls Mode Press: Uconnect ® Destina- AM/FM Voice Media Tem- tion & Satel- Devices perature Selec- Yelp Command ®...
Page 98 ELECTRONICS Voice Command Examples – Uconnect® 8.4A While In: Voice Command Example: GENERAL “Go to Radio” (Media, Climate, Naviga- tion, Phone, Apps) – Settings, and Con- trols are not Voice Command accessible “Cancel” “Help” (to listen to suggested commands specific to current need Anytime “Repeat”...
Page 99 ELECTRONICS While In: Voice Command Example: PHONE “Dial 123-456-7890” (phone number) “Call John Smith mobile” Call Initiation (Requires that phone has (home, office, other) been Bluetooth paired with radio) ® “Redial” “Show outgoing” (recent) “calls” “Search for John Smith” (any contact Call Management name in address book) “Show (display list) contacts”...
Page 100: Uconnect® 8.4An
ELECTRONICS While In: Voice Command Example: APPS “Launch Yelp ® ” – Required 1st voice command to launch Yelp ® “Yelp ® Search” – Required 2nd voice command to activate app functionality Yelp® (Yelp ® adds it's own audible using Steering Wheel Voice prompts, and response time varies Control Button “Hotel”...
Page 101 ELECTRONICS Setting The Time • Model 8.4AN synchronizes time automatically via GPS, so it should not require any time adjustment. If you do need to set the time manually, follow the instructions below for Model 8.4A. • For Model 8.4A, turn the unit on, then touch the time display at the top of the screen.
Page 102 ELECTRONICS RADIO • To access the Radio mode, touch the “Radio” soft-key at the lower left of the screen. Selecting Radio Stations • Touch the desired radio band (AM, FM or SXM) soft-key. Seek Up/Seek Down • Touch the Seek arrow soft-keys for less than two seconds to seek through radio stations.
Page 103 ELECTRONICS HD Radio (US RESIDENTS ONLY) • HD Radio (available on Uconnect 8.4AN) operates similar to conventional radio except it allows broadcasters to transmit a high-quality digital signal. • With an HD radio receiver, the listener is provided with a clear sound that enhances the listening experience.
Page 104 ELECTRONICS SiriusXM Parental Controls • You can skip or hide certain channels from view if you do not want access to them. Touch the “More” soft-key, then the “settings” soft-key, next touch the” Sirius Setup” soft-key, then select Channel Skip. Touch the box check-mark next to the channel you want skipped.
Page 105 ELECTRONICS Replay Lets you replay up to 44 minutes of the content of the current SiriusXM channel. Replay Option Description Option Play/Pause Touch to Pause content playback. Touch Pause/Play again to resume playback. Rewind/RW Rewinds the channel content in steps of five seconds. Touch and hold to rewind continuously, then release to begin playing content at that point.
Page 106 ELECTRONICS MEDIA HUB — PLAYING iPod®/USB/MP3 DEVICES • There are many ways to play music from iPod ® /MP3 players or USB devices through your vehicle's sound system. Touch your Media soft-key to begin. Audio Jack (AUX) • The AUX allows a portable device, such as an MP3 player or an iPod ®...
Page 107 ELECTRONICS NOTE: When connecting your iPod device for the first time, the system may take several ® minutes to read your music, depending on the number of files. For example, the system will take approximately five minutes for every 1000 songs loaded on the device.
Page 108 ELECTRONICS iPod®/CD/AUX CONTROLS • The iPod ® /CD/AUX controls are accessed by touching the desired soft-key dis- played on the side of the screen and choosing between Disc, AUX, iPod ® Bluetooth or SD Card. ® NOTE: Uconnect will usually automatically switch to the appropriate mode when some- ®...
Page 109 ELECTRONICS Finding Points Of Interest • From the main Navigation menu, touch the “Where To?” soft-key, then touch the “Points of Interest” soft-key. • Select a Category and then a subcategory, if necessary. • Select your destination and touch the “Yes” soft-key. Finding A Place By Spelling The Name •...
Page 110 ELECTRONICS Setting Your Home Location • Touch the “Nav” soft-key in the menu bar to access the Navigation system and the Main Navigation menu. • Touch the “Where To?” soft-key, then touch the “Go Home” soft-key. • You may enter your address directly, use your current location as your home address, or choose from recently found locations.
Page 111 ELECTRONICS • Touch the “Where To?” soft-key, then search for the extra stop. When another location has been selected, you can choose to cancel your previous route, add as the first destination or add as the last destination. • Touch the desired selection and touch the “Yes” soft-key. Taking A Detour •...
Page 112 ELECTRONICS SiriusXM Travel Link feature is completely integrated into your vehicle. A few minutes after you start your vehicle, Travel Link information arrives and updates in the background. You can access the information whenever you like, with no waiting. To access SiriusXM Travel Link, press “Apps” button on the touchscreen, then press the “SiriusXM Travel Link”...
Page 113 ELECTRONICS Pairing A Phone • To use the Uconnect Phone feature, you must first pair your Bluetooth phone ® ® with the Uconnect system. ® Start Pairing Procedure On The Radio • Touch the “Phone” soft-key and then the “settings” soft-key. Next, touch “Add Device.”...
Page 114 ELECTRONICS Mute (Or Unmute) Microphone During Call • During a call, touch the “mute” soft-key on the Phone main screen to mute and unmute the call. Transfer Ongoing Call Between Handset And Vehicle • During an on-going call, touch the “Transfer” soft-key on the Phone main screen to transfer an on-going call between handset and vehicle.
Page 115 ELECTRONICS NOTE: To access help, press the Uconnect ® Phone button on the steering wheel and say "help." Touch the display or push either button and say "cancel" to cancel the help session. Voice Text Reply (Not Compatible With iPhone®) Once your Uconnect system is paired with a compatible mobile device, the system ®...
Page 116 ELECTRONICS WARNING! • Any voice commanded system should be used only in safe driving conditions following applicable laws regarding phone use. Your attention should be focused on safely operating the vehicle. Failure to do so may result in a collision causing you and others to be severely injured or killed.
Page 117 ELECTRONICS Voice Command (VR) User TIPs • To hear available commands, press the Uconnect ® Voice Command button and say “Help.” You will hear available commands for the menu displayed. • At any time, you can say the words “Cancel” or “Help.” These commands are universal and can be used from virtually any menu.
Page 118 ELECTRONICS Available Radio Soft-Key Voice Commands Steering Wheel (1) Radio (4) Navi- Media Climate Phone (6) APPS Buttons to Mode gation Mode Controls Mode Press: Uconnect ® Destina- AM/FM Voice Media Tem- tion & Satel- Devices perature Selec- Yelp Command ®...
Page 119 ELECTRONICS Voice Command Examples – Uconnect® 8.4AN While In: Voice Command Example: GENERAL “Go to Radio” (Media, Climate, Naviga- tion, Phone, Apps) – Settings, and Con- trols are not Voice Command accessible “Cancel” “Help” (to listen to suggested commands specific to current need) Anytime “Repeat”...
Page 120 ELECTRONICS While In: Voice Command Example: PHONE “Dial 123-456-7890” (phone number) “Call John Smith mobile” Call Initiation (Requires that phone has (home, office, other) been Bluetooth paired with radio) ® “Redial” “Show outgoing” (recent) “calls” “Search for John Smith” (any contact Call Management name in address book) “Show (display list) contacts”...
Page 121: Steering Wheel Audio Controls
ELECTRONICS While In: Voice Command Example: APPS “Show Fuel prices” “Show Current Weather” – provides access to Forecast as well SiriusXM Travel Link (Traffic function is “Show Weather map” – multiple map not voice command accessible within formats available SiriusXM Travel Link) “Show Sports”...
Page 122: Electronic Vehicle Information Center (Evic)
ELECTRONICS ELECTRONIC VEHICLE INFORMATION CENTER (EVIC) The EVIC features a driver interactive display that is located in the instrument cluster. Pressing the controls on the left side of the steering wheel allows the driver to select vehicle information and Personal Settings. For additional information, refer to “Programmable Features”...
Page 123: Programmable Features
ELECTRONICS PROGRAMMABLE FEATURES Programmable Features The EVIC can be used to view or change the following settings. Press the UP DOWN button until System Setup displays, then press the RIGHT button. Scroll through the settings using the UP or DOWN buttons. Press the RIGHT button to change the setting.
Page 124 ELECTRONICS EVIC Reconfigurable Screen Setup The following settings allow you to change what information is displayed in the instrument cluster as well as the location that information is displayed. Digital Speedometer • Press and release the UP or DOWN arrow button until the Digital display icon is highlighted in the EVIC.
Page 125 ELECTRONICS Fuel Economy • Press and release the UP or DOWN arrow button until the Fuel Economy icon is highlighted. The screen will display the following: • Average Fuel Economy/Miles Per Gallon • Range To Empty (RTE) • Current Miles Per Gallon (MPG) •...
Page 126: Universal Garage Door Opener (Homelink )
ELECTRONICS UNIVERSAL GARAGE DOOR OPENER (HomeLink®) HomeLink replaces up to three hand-held transmitters that operate devices such as ® garage door openers, motorized gates, lighting or home security systems. The HomeLink ® unit is powered by your vehicles 12 Volt battery. The HomeLink buttons that are located in the overhead console or sunvisor ®...
Page 127 ELECTRONICS 2. Place the hand-held transmitter 1 to 3 inches (3 to 8 cm) away from the HomeLink button you wish to program while keeping the HomeLink indicator light in view. 3. Simultaneously push and hold both the Homelink button you want to program and the hand-held transmitter button.
Page 128 ELECTRONICS 4. Continue to hold buttons until the EVIC display changes from “CHANNEL # TRAINING” to “CHANNEL # TRAINED”, then release both buttons. 5. Press and hold the programmed HomeLink ® button and observe the indicator light. NOTE: If the EVIC displays “DID NOT TRAIN” repeat from Step 2. •...
Page 129: Power Inverter
ELECTRONICS POWER INVERTER A 115 Volt, 150 Watt power inverter outlet is located on the lower instrument panel next to the climate control knob. This outlet can power cellular phones, electronics and other low power devices requiring power up to 150 Watts. To turn on the power outlet, simply plug in the device.
Page 130: Power Outlets
ELECTRONICS POWER OUTLETS The auxiliary 12 Volt (13 Amp) power outlets can provide power for in-cab accesso- ries designed for use with the standard “cigar lighter” plug. The 12 Volt power outlets have a cap attached to the outlet indicating “12V DC”, together with either a key symbol or a battery symbol.
Page 131 ELECTRONICS • The rear center console power outlet can be switched to “battery” powered all the time by switching the power outlet right rear quarter panel fuse in the fuse panel.
Page 132: Off-Road Capabilities
OFF-ROAD CAPABILITIES FOUR-WHEEL DRIVE OPERATION — IF EQUIPPED • Four-wheel drive trucks are equipped with either a manually shifted transfer case or an electronically shifted transfer case. Refer to the operating instructions for electronic transfer case, located in this section for further information. •...
Page 133 OFF-ROAD CAPABILITIES NEUTRAL (N) Neutral — This range disengages both the front and rear driveshafts from the powertrain. To be used for flat towing behind another vehicle. Refer to “Recreational Towing” in “Starting And Operating” in your Owner’s Manual located on the DVD for further information.
Page 134 OFF-ROAD CAPABILITIES Electronically Shifted Transfer Case (Five-Position Switch) — If Equipped This is an electronic shift transfer case and is operated by the 4WD Control Switch (Transfer Case Switch), which is located on the instrument panel. This electronically shifted transfer case provides five mode positions: •...
Page 135 OFF-ROAD CAPABILITIES NEUTRAL (N) Neutral — This range disengages both the front and rear driveshafts from the powertrain. To be used for flat towing behind another vehicle. Refer to “Recreational Towing” in “Starting And Operating” in your Owner’s Manual located on the DVD for further information.
Page 136 OFF-ROAD CAPABILITIES Four-Position Electronically Shifted Transfer Case (Eight Speed Transmission Only) — If Equipped This is an electronic shift transfer case and is operated by the 4WD Control Switch (Transfer Case Switch), which is located on the instrument panel. This electronically shifted transfer case provides four mode positions: •...
Page 137 OFF-ROAD CAPABILITIES When additional traction is required, the transfer case 4WD LOCK and 4WD LOW positions can be used to maximize torque to the front driveshaft, forcing the front and rear wheels to rotate at the same speed. This is accomplished by pushing the desired position on the 4WD control switch.
Page 138 OFF-ROAD CAPABILITIES 4WD LOCK Four-Wheel Drive Lock High Range — This range maximizes torque to the front driveshaft, forcing the front and rear wheels to rotate at the same speed. Additional traction for loose, slippery road surfaces only. 4WD LOW Four-Wheel Drive Low Range —...
Page 139: Utility
UTILITY TONNEAU COVER • The Tonneau Cover can be removed and reinstalled by using the locking clamps located underneath the Tonneau Cover. NOTE: Be sure that the Tonneau Cover is secured before driving. EASY-OFF TAILGATE • To simplify mounting of a camper unit with an overhang, the tailgate can be removed.
Page 140: Pickup Box
UTILITY PICKUP BOX • You can carry wide building materials (sheets of plywood, etc.) by building a raised load floor. Place lumber across the box in the indentations provided above the wheel housings and in the bulkhead dividers to form the floor. •...
Page 141 UTILITY Turning Cargo Camera On Or Off — With Uconnect® 8.4A/8.4AN 1. Touch the “Controls” soft-key located on the bottom of the Uconnect ® display. 2. Touch the “Cargo Camera” soft-key to turn the Cargo Camera system ON. NOTE: The Cargo Camera image may be deacti- vated by touching the Uconnect ®...
Page 142 UTILITY WARNING! • The pickup box is intended for load carrying purposes only, not for passengers, who should sit in seats and use seat belts. • Care should always be exercised when operating a vehicle with unrestrained cargo. Vehicle speeds may need to be reduced. Severe turns or rough roads may cause shifting or bouncing of the cargo that may result in vehicle damage.
Page 143: Rambox
UTILITY RAMBOX® • The RamBox ® system is an integrated pickup box storage and cargo management system consisting of three features: • Integrated box side storage bins • Cargo extender/divider • Bed rail tie-down system RamBox® Integrated Box Side Storage Bins •...
Page 144 UTILITY • Storage bins feature two removable drain plugs (to allow water to drain from bins). To remove plug, pull up on the edge. To install, push plug downward into drain hole. • The RamBox storage bins can be locked and unlocked using the vehicle key or ®...
Page 145 UTILITY • Make sure the center handle is unlocked using the vehicle key and rotate the center handle vertically to release the extender side gates. • With the side gates open, position the extender so the outboard ends align with the intended slots in the sides of the bed.
Page 146 UTILITY CAUTION! • Loads applied to the top of the bin lid should be minimized to prevent damage to the lid and latching/hinging mechanisms. • Damage to the RamBox ® bin may occur due to heavy/sharp objects placed in bin that shift due to vehicle motion.
Page 147: Towing & Payload
UTILITY TOWING & PAYLOAD Ram 1500 4x2 SLT/Outdoorsman Sport/Laramie Standard Towing: Standard Towing: 5,000 lbs 5,000 lbs (2 268 kg) (2 268 kg) 3.6L V-6 8–Speed Max Towing: Max Towing: Automatic Transmis- — 7,400 lbs 7,400 lbs sion (3 357 kg)
Page 148 (4 196 kg) Transmission Max Payload: Max Payload: Max Payload: 1,520 lbs (689 kg) 1,520 lbs (689 kg) 1,520 lbs (689 kg) Ram 2500 & 3500 SLT/OUTDOORSMAN/ LARAMIE Max Towing: Max Towing: Max Towing: 13,850 lbs 13,810 lbs 13,350 lbs 5.7L HEMI®...
Page 149: Tow/Haul Mode
UTILITY TOW/HAUL MODE • When driving in hilly areas, towing a trailer, carrying a heavy load, etc., and frequent transmission shifting occurs, press the TOW/HAUL switch to select TOW/HAUL mode. This will improve performance and reduce the potential for transmission overheating or failure due to excessive shifting. When operating in TOW/HAUL mode, transmission upshifts are delayed, and the transmission will automatically downshift (for engine braking) during steady braking maneuvers.
Page 150 UTILITY Setting with the Uconnect® Touchscreen Radio • To make the proper selection in the Uconnect ® touchscreen radio, press the More hard-key (Uconnect ® 5.0) or the Apps soft-key (Uconnect ® 8.4), then press the Settings soft-key to display the menu setting screen and press trailer brake. For additional information, refer to your Owner’s Manual on the DVD.
Page 151: Recreational Towing (Behind Motorhome, Etc.)
UTILITY RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle Wheels OFF The Two-Wheel Drive Four-Wheel Drive Towing Condition Ground Models Models See Instructions: • Automatic trans- mission in PARK • Manual trans- mission in gear Flat Tow NONE NOT ALLOWED (NOT in NEU-...
Page 152 UTILITY Recreational Towing — Four-Wheel Drive Models NOTE: Both the manual shift and electronic shift transfer cases must be shifted into NEUTRAL (N) for recreational towing. Automatic transmissions must be shifted into PARK for recreational towing. Manual transmissions must be placed in gear (NOT in NEUTRAL) for recreational towing.
Page 153 UTILITY Shifting Into NEUTRAL (N) Use the following procedure to prepare your vehicle for recreational towing. WARNING! You or others could be injured or killed if you leave the vehicle unattended with the transfer case in the NEUTRAL (N) position without first fully engaging the parking brake.
Page 154 UTILITY 11. Shift the transmission into PARK or place manual transmission in gear (NOT in Neutral). On 8-speed transmissions the shifter will automatically select PARK when the engine is turned off. 12. Turn the ignition switch to the OFF position, then cycle the key or the Keyless Enter-N-Go™...
Page 155 UTILITY NOTE: When shifting out of transfer case NEUTRAL (N), turning the engine OFF is not required, but may be helpful to avoid gear clash. With the 8-speed automatic transmission, the engine must remain running, since turning the engine OFF will shift the transmission to PARK (and the transmission must be in NEUTRAL for the transfer case to shift out of NEUTRAL).
Page 156: 1500 3.0L Diesel
1500 3.0L DIESEL DIESEL ENGINE BREAK-IN RECOMMENDATIONS • The 3.0 turbocharged diesel engine does not require a break-in period due to its construction. Normal operation is allowed, providing the following recommenda- tions are followed: • Warm up the engine before placing it under load.
Page 157: Diesel Fuel Filter/Water Separator
1500 3.0L DIESEL CAUTION! If the “Water in Fuel Indicator Light” remains on, DO NOT START the engine before you drain the water from the fuel filters to avoid engine damage. Refer to “Maintenance Procedures/Draining Fuel/Water Separator Filter” in “Maintaining Your Vehicle”...
Page 158: Exhaust Regeneration
1500 3.0L DIESEL Fuel Filter Replacement 1. Ensure engine is turned off. 2. Place drain pan under the fuel filter assembly. 3. Open the water drain valve, and let any accumulated water drain. 4. Close the water drain valve. 5. Remove bottom cover using a strap wrench. Rotate counterclockwise for removal.
Page 159 1500 3.0L DIESEL Exhaust System — Regeneration Required Now This message Indicates that the Diesel Particulate Filter (DPF) reached 80% of its maximum storage capacity. By simply driving your vehicle at highway speeds for up to 20 minutes, you can...
Page 160: Cool-Down Idle Chart
1500 3.0L DIESEL COOL-DOWN IDLE CHART TURBO "COOL DOWN" CHART Idle Time (in min- Driving Conditions Load Turbo Temp utes) Before Shut Down Stop and Go Empty Cool Less than 1 Stop and Go Medium Warm Highway Speeds Medium Warm City Traffic Max.
Page 161: Diesel Exhaust Fluid
1500 3.0L DIESEL 4. Pour fuel into funnel opening. 5. Remove the funnel from filler pipe, clean off prior to putting back in the jack storage area under the passenger seat. DIESEL EXHAUST FLUID Diesel Exhaust Fluid (DEF) sometimes known simply by the name of its active component, UREA –...
Page 162 1500 3.0L DIESEL • DEF injector • Electronically-heated DEF lines • NOx sensors • Temperature sensors • SCR catalyst The DEF injection system and SCR catalyst enable the achievement of diesel emissions requirements; while maintaining outstanding fuel economy, drivability, torque and power ratings.
Page 163 1500 3.0L DIESEL DEF Fill Procedure • Remove cap from DEF tank (located behind the fuel door on drivers side of the vehicle). • Insert DEF container or fill nozzle into DEF fill location and fill DEF tank. • Reinstall cap onto DEF tank.
Page 164 1500 3.0L DIESEL 100 miles, remaining range will be continuously displayed while operating the vehicle. Chimes will also accompany the 75, 50 and 25 mile remaining distances. The DEF Low telltale will be on continuously until DEF fluid is topped off.
Page 165 1500 3.0L DIESEL • Engine Will Not Restart Service DEF System See Dealer – This message will display if the DEF system issue detected is not serviced during the allowed period. Your engine will not restart unless your vehicle is serviced by your authorized dealer.
Page 166: 6.7L Cummins® Diesel
6.7L CUMMINS® DIESEL DIESEL ENGINE BREAK-IN RECOMMENDATIONS The Cummins ® turbocharged diesel engine does not require a break-in period due to its construction. Normal operation is allowed, providing the following recommenda- tions are followed: • Warm up the engine before placing it under load. •...
Page 167 6.7L CUMMINS® DIESEL Water In Fuel Message If a Water In Fuel message or indicator appears in the cluster and a chime sounds five times, the fuel/water separator will need to be drained immediately to prevent engine damage. Refer to “Draining Fuel Water Separator” in this guide for draining instructions or see your dealer.
Page 168: Diesel Exhaust Brake (Engine Braking)
6.7L CUMMINS® DIESEL DIESEL EXHAUST BRAKE (ENGINE BRAKING) The Exhaust Brake switch is located on the switch bank below the audio system. This switch is used to enable exhaust brake modes. • Pressing the exhaust brake switch once will enable full strength exhaust brake mode, indicated by a yellow icon in the EVIC.
Page 169: Idle-Up Feature (Automatic Transmission Only)
• The engine RPM will go up to 1100 RPM. To increase the RPM, push and hold the RESUME/ACCEL switch and the idle speed will increase to approximately 1500 RPM. To decrease the RPM, push and hold the SET/DECEL switch and the idle speed will decrease to approximately 1100 RPM.
Page 170 6.7L CUMMINS® DIESEL • Turn the drain valve (located on the side of the filter) counterclockwise 1/4 turn, then turn the ignition switch to the ON/RUN position to allow any accumulated water to drain. • When clean fuel is visible, close the drain and switch the ignition to OFF. •...
Page 171: Underbody Mounted Fuel Filter/Water Separator
6.7L CUMMINS® DIESEL UNDERBODY MOUNTED FUEL FILTER/WATER SEPARATOR Draining Fuel/Water Separator • If the “Water in Fuel” indicator light is illuminated and an audible chime is heard five times, you should stop the engine and drain the water from the separator.
Page 172: Exhaust Regeneration
6.7L CUMMINS® DIESEL CAUTION! • Diesel fuel will damage blacktop paving surfaces. Drain the filter into an appropriate container. • Do not prefill the fuel filter when installing a new fuel filter. There is a possibility debris could be introduced into the fuel filter during this action. It is best to install the filter dry and allow the in-tank lift pump to prime the fuel system.
Page 173: Cool-Down Idle Chart
6.7L CUMMINS® DIESEL Exhaust System — Regeneration Completed This message indicates that the Diesel Particulate Filter (DPF) self-cleaning is completed. If this message is displayed, you will hear one chime to assist in alerting you of this condition. Exhaust Service Required — See Dealer Now This message indicates regeneration has been disabled due to a system malfunction.
Page 174: Adding Fuel - Diesel Engine Only
6.7L CUMMINS® DIESEL ADDING FUEL — DIESEL ENGINE ONLY • Your vehicle is equipped with a cap- less fuel system. • Most fuel cans will not open the flap- per door. • A funnel is provided to open the flap- per door to allow emergency refueling with a fuel can.
Page 175: Diesel Exhaust Fluid
6.7L CUMMINS® DIESEL DIESEL EXHAUST FLUID Diesel Exhaust Fluid (DEF) sometimes known simply by the name of its active component, UREA – is a key component of selective catalytic reduction (SCR) systems, which help diesel vehicles meet stringent emission regulations. DEF is a liquid reducing agent that reacts with engine exhaust in the presence of a catalyst to convert smog-forming nitrogen oxides (NOx) into harmless nitrogen and water vapor.
Page 176 6.7L CUMMINS® DIESEL Diesel Exhaust Fluid Storage Diesel Exhaust Fluid (DEF) is considered a very stable product with a long shelf life. If DEF is kept in temperatures between 10° to 90°F (-12° to 32°C), it will last a minimum of one year. DEF is subject to freezing at the lowest temperatures.
Page 177 6.7L CUMMINS® DIESEL DEF Fill Procedure • Remove cap from DEF tank (located behind the fuel door on drivers side of the vehicle). • Insert DEF container or fill nozzle into DEF fill location and fill DEF tank. • Reinstall cap onto DEF tank. •...
Page 178 6.7L CUMMINS® DIESEL • 5 MPH Max Speed on Restart, Long Idle or Refuel Refill DEF — This message will continuously display when the counter reaches zero, and will be accompanied by a periodic chime. The vehicle will only be capable of a maximum speed of 5 MPH upon the first of the following conditions to occur: •...
Page 179 6.7L CUMMINS® DIESEL NOTE: Under some circumstances this mileage counter may start with a value of less than 150 miles (241 km). For example, if recurring faults are detected in a time interval of less than 40 hours, the counter may restart at the value where it stopped when a previous fault was temporarily remedied, or at a minimum of 50 miles (80 km).
Page 180: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES ROADSIDE ASSISTANCE Dial toll-free 1-800-521-2779 for U.S. Residents or 1-800-363-4869 for Canadian Residents. • Provide your name, vehicle identification number, license plate number, and your location, including the telephone number from which you are calling. •...
Page 181 WHAT TO DO IN EMERGENCIES Please note that the TPMS is not a substitute for proper tire maintenance, and it is the driver’s responsibility to maintain correct tire pressure, even if under-inflation has not reached the level to trigger illumination of the TPMS low EVIC display. Your vehicle has also been equipped with a TPMS malfunction indicator to indicate when the system is not operating properly.
Page 182 WHAT TO DO IN EMERGENCIES We recommend that you do not operate the vehicle or engine damage will occur. Have the vehicle serviced immediately. WARNING! A hot engine cooling system is dangerous. You or others could be badly burned by steam or boiling coolant.
Page 183 WHAT TO DO IN EMERGENCIES WARNING! Driving a vehicle with the red brake light on is dangerous. Part of the brake system may have failed. It will take longer to stop the vehicle. You could have a collision. Have the vehicle checked immediately. - Malfunction Indicator Light (MIL) The Malfunction Indicator Light (MIL) is part of an onboard diagnostic system called OBD II that monitors engine and automatic transmission control systems.
Page 184 WHAT TO DO IN EMERGENCIES - Oil Pressure Warning Light This light indicates low engine oil pressure. If the light turns on while driving, stop the vehicle and shut off the engine as soon as possible. A chime will sound for four minutes when this light turns on.
Page 185 WHAT TO DO IN EMERGENCIES - SERV (Service) 4WD Indicator Light The SERV 4WD light monitors the electric shift four-wheel drive system. If the SERV 4WD light stays on or comes on during driving, it means that the four-wheel drive system is not functioning properly and that service is required.
Page 186: If Your Engine Overheats
WHAT TO DO IN EMERGENCIES IF YOUR ENGINE OVERHEATS In any of the following situations, you can reduce the potential for overheating by taking the appropriate action: • On the highways — slow down. • In city traffic — while stopped, shift the transmission to NEUTRAL, but do not increase engine idle speed.
Page 187: Jacking And Tire Changing
1500 Series Trucks • Remove the jack and tool bag by removing the wing bolt and sliding the jack and...
Page 188 WHAT TO DO IN EMERGENCIES 2500/3500 Series Trucks • Remove the jack and tool bracket assembly by removing the wing bolt and sliding the jack and tool bracket assembly from under the seat. Removing The Spare Tire • Remove the spare tire before attempting to jack up the truck. Attach the wheel wrench to the jack extension tube.
Page 189 WHAT TO DO IN EMERGENCIES Preparations 1. Park the vehicle on a firm, level surface. Avoid ice or slippery areas. 2. Turn on the Hazard Warning flasher. 3. Set the parking brake. 4. Place the shift lever into PARK. On four-wheel drive vehicles, shift the transfer case to the 4L position.
Page 190 3. Placement of the jack: 1500 Series Trucks • When changing a front wheel, place the scissors jack under the rear portion of the lower control arm as shown below.
Page 191 WHAT TO DO IN EMERGENCIES Front 4x4 Jacking Location • Operate the jack using the jack drive tube and the wheel wrench. The tube extension may be used but is not required.
Page 192 WHAT TO DO IN EMERGENCIES • For 4x2 and 4x4 trucks, when changing a rear wheel, assemble the jack drive tube to the jack and connect the drive tube to the extension tube. Place the jack under the axle between the wheel and the shock bracket with the drive tubes extending to the rear.
Page 193 WHAT TO DO IN EMERGENCIES 2500/3500 Series Trucks • For 2500/3500 4x2 series trucks, when changing a front wheel, place the bottle jack under the frame rail behind the wheel. Locate the jack as far forward as possible on the straight part of the frame. •...
Page 194 • Using the lug wrench, finish tightening the wheel nuts using a crisscross pattern. The correct wheel nut tightness is 130 ft lbs (176 N·m) torque (1500 Series), 135 ft lbs (183 N·m) torque for 2500/3500 single-rear wheel (SRW) models, and 140 ft lbs (190 N·m) for 3500 dual rear-wheel models.
Page 195 Do not oil wheel studs. For chrome wheels, do not substitute with chrome plated wheel nuts. Reinstalling The Jack And Tools 1500 Series Trucks 1. Tighten the jack all the way down by turning the jack turn-screw clockwise until the jack is snug.
Page 196 WHAT TO DO IN EMERGENCIES 4. Place the jack and tools in the storage position holding the jack by the jack turn-screw, slip the jack and tools under the seat so that the bottom slot engages into the fastener on the floor. NOTE: Ensure that the jack slides into the front hold down location.
Page 197 WHAT TO DO IN EMERGENCIES 3. Place the jack and tool bracket assembly in the storage position holding the jack by the jack turn-screw, slip the jack and tools under the seat so that the bottom slot engages into the fastener on the floor. NOTE: Ensure that the jack and tool bracket assembly slides into the front hold down...
Page 198 WHAT TO DO IN EMERGENCIES torque. Tighten the wheel nuts to final torque in increments. Progress around the bolt circle, tightening the wheel nut opposite to the wheel nut just previously tightened until final torque is achieved. Recommended torques are shown in the following chart.
Page 199 To Stow The Flat Or Spare NOTE: RAM 1500 vehicles equipped with aluminum wheels cannot be stored under the vehicle because the wheel retainer will not fit through the wheel pilot hole. Secure the flat tire in the bed of the truck. Have the flat tire repaired or replaced immediately.
Page 200 WHAT TO DO IN EMERGENCIES WARNING! • Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull far enough off the road to avoid the danger of being hit when operating the jack or changing the wheel.
Page 201: Jump-Starting
WHAT TO DO IN EMERGENCIES JUMP-STARTING • If your vehicle has a discharged bat- tery it can be jump-started using a set of jumper cables and a battery in an- other vehicle or by using a portable battery booster pack. •...
Page 202 WHAT TO DO IN EMERGENCIES Once the engine is started, remove the jumper cables in the reverse sequence: 1. Disconnect the negative (-) end of the jumper cable from the engine ground of the vehicle with the discharged battery. 2. Disconnect the opposite end of the negative (-) jumper cable from the negative (-) post of the booster battery.
Page 203: Emergency Tow Hooks
WHAT TO DO IN EMERGENCIES WARNING! • Do not connect the cable to the negative post (-) of the discharged battery. The resulting electrical spark could cause the battery to explode and could result in personal injury. EMERGENCY TOW HOOKS •...
Page 204: Shift Lever Override
WHAT TO DO IN EMERGENCIES SHIFT LEVER OVERRIDE If a malfunction occurs and the shift lever cannot be moved out of the PARK position, you can use the following procedure to temporarily move the shift lever. Have your vehicle inspected by your local authorized dealer immediately if the shift lever override has been used.
Page 205 WHAT TO DO IN EMERGENCIES MANUAL PARK RELEASE — EIGHT SPEED TRANSMISSION • In order to push or tow the vehicle in cases where the transmission will not shift out of PARK (such as a dead battery), a Manual Park Release is available. •...
Page 206: Towing A Disabled Vehicle
WHAT TO DO IN EMERGENCIES • While holding the locking tab in the disengaged position, pull the tether strap to rotate the lever rearward, until it locks in place pointing towards the driver's seat. Release the locking tab and verify that the Manual Park Release lever is locked in the released position.
Page 207 WHAT TO DO IN EMERGENCIES...
Page 208: Freeing A Stuck Vehicle
WHAT TO DO IN EMERGENCIES FREEING A STUCK VEHICLE • If your vehicle becomes stuck in mud, sand or snow, it can often be moved using a rocking motion. Turn your steering wheel right and left to clear the area around the front wheels.
Page 209: Event Data Recorder (Edr)
WHAT TO DO IN EMERGENCIES EVENT DATA RECORDER (EDR) This vehicle is equipped with an Event Data Recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed.
Page 210: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE OPENING THE HOOD 1. Pull the hood release lever located below the steering wheel at the base of the instrument panel. 2. Reach into the opening beneath the center of the hood and move the safety latch lever while lifting the hood at the same time.
Page 211: Engine Compartment
MAINTAINING YOUR VEHICLE...
Page 212 MAINTAINING YOUR VEHICLE...
Page 213 MAINTAINING YOUR VEHICLE...
Page 214 MAINTAINING YOUR VEHICLE...
Page 215 MAINTAINING YOUR VEHICLE...
Page 216 MAINTAINING YOUR VEHICLE...
Page 217: Fluids And Capacities
MAINTAINING YOUR VEHICLE...
Page 218 MAINTAINING YOUR VEHICLE...
Page 219 MAINTAINING YOUR VEHICLE...
Page 220 MAINTAINING YOUR VEHICLE...
Page 221 MAINTAINING YOUR VEHICLE...
Page 222 MAINTAINING YOUR VEHICLE...
Page 223 MAINTAINING YOUR VEHICLE...
Page 224 MAINTAINING YOUR VEHICLE...
Page 225 MAINTAINING YOUR VEHICLE...
Page 226 MAINTAINING YOUR VEHICLE...
Page 227: Maintenance Schedule - Gasoline Engine
• 1500 Models Only Under no circumstances should oil change intervals exceed 10,000 miles (16,000 km) or twelve months on 1500 trucks, whichever comes first. • 2500 – 3500 Models Under no circumstances should oil change intervals exceed 8,000 miles (13,000 km) or twelve months on 2500 –...
Page 228 MAINTAINING YOUR VEHICLE Once A Month Or Before A Long Trip: • Check engine oil level • Check windshield washer fluid level • Check tire pressure and look for unusual wear or damage. Rotate tires at the first sign of irregular wear, even if it occurs before the oil indicator system turns on. •...
Page 229 MAINTAINING YOUR VEHICLE...
Page 230 MAINTAINING YOUR VEHICLE...
Page 231 MAINTAINING YOUR VEHICLE...
Page 232: Maintenance Schedule - 1500 3.0L Diesel Engine
MAINTAINING YOUR VEHICLE MAINTENANCE SCHEDULE — 1500 3.0L DIESEL ENGINE Your vehicle is equipped with an automatic oil change indicator system. The oil change indicator system will remind you that it is time to take your vehicle in for scheduled maintenance.
Page 233 MAINTAINING YOUR VEHICLE Maintenance Chart — Diesel Fuel Up To B5 Biodiesel (1500 Diesel) Required Maintenance Refer to the Maintenance Schedules on the following pages for required mainte- nance. At Every Oil Change Interval As Indicated By Oil Change Indicator System: •...
Page 234 MAINTAINING YOUR VEHICLE...
Page 235 MAINTAINING YOUR VEHICLE...
Page 236 MAINTAINING YOUR VEHICLE...
Page 237: Maintenance Schedule - 6.7L Cummins Diesel Engine
MAINTAINING YOUR VEHICLE MAINTENANCE SCHEDULE — 6.7L CUMMINS DIESEL ENGINE CAUTION! Failure to perform the required maintenance items may result in damage to the vehicle. At Each Stop For Fuel Check the engine oil level at least 30 minutes after a fully warmed engine is shut off. Checking the oil level while the vehicle is on level ground will improve the accuracy of the oil level reading.
Page 238 MAINTAINING YOUR VEHICLE Replace the engine oil and oil filter every 15,000 miles (24 000 km) or six months, or sooner if prompted by the oil change indicator system. Under no circumstances should oil change intervals exceed 15,000 miles (24 000 km) or six months, whichever comes first. NOTE: •...
Page 239 MAINTAINING YOUR VEHICLE...
Page 240 MAINTAINING YOUR VEHICLE...
Page 241 MAINTAINING YOUR VEHICLE...
Page 242 MAINTAINING YOUR VEHICLE...
Page 243 MAINTAINING YOUR VEHICLE...
Page 244: Fuses
20 Amp Yellow Emissions Diesel – If Equipped 40 Amp Green Diesel Fuel Heater – If Equipped (Cummins Diesel) 30 Amp Pink (1500 LD Diesel) 40 Amp Green Body Controller/Exterior Lighting #2 50 Amp Red Body Controller/Exterior Lighting #2 – If Equipped with...
Page 245 MAINTAINING YOUR VEHICLE Cavity Cartridge Fuse Micro Fuse Description 20 Amp Yellow Engine Control Module 30 Amp Pink Body Controller #1 30 Amp Pink Driver Door Module 30 Amp Pink Front Wiper Low Speed 30 Amp Pink Front Wiper High Speed 30 Amp Pink Antilock Brakes/Stability Control Module/Valves...
Page 246 Natural 10 Amp Red Voltage Stabilizer Modules – If Equipped 20 Amp Yellow Brake Vacuum Pump Gas/Diesel (Gas & – If Equipped 1500 LD Diesel)/10 Amp Red (Cummins Diesel Engine) 10 Amp Red Coolant Temperature Valve Actuator 10 Amp Red...
Page 247 MAINTAINING YOUR VEHICLE Cavity Cartridge Fuse Micro Fuse Description 10 Amp Red Universal Garage Door Opener/Compass 20 Amp Yellow Trailer Tow Right Turn/Stop Lights 10 Amp Red Steering Column Control Module/Cruise Control 15 Amp Blue Switch Bank/Instrument Cluster 10 Amp Red Airbag Module 10 Amp Red Airbag Module...
Page 248: Tire Pressures
MAINTAINING YOUR VEHICLE TIRE PRESSURES Check the inflation pressure of each tire, including the spare tire, at least monthly and inflate to the recommended pressure for your vehicle. The tire pressures recommended for your vehicle are found on the “Tire and Loading Information”...
Page 249 MAINTAINING YOUR VEHICLE NOTE: Many aftermarket wheel cleaners contain strong acids or strong alkaline additives that can harm the wheel surface. CAUTION! Avoid products or automatic car washes that use acidic solutions or strong alkaline additives or harsh brushes. These products and automatic car washes may damage the wheel's protective finish.
Page 250: Exterior Bulbs
MAINTAINING YOUR VEHICLE EXTERIOR BULBS LIGHT BULBS – Exterior Bulb Number Base Quad Headlamp – Low Beam Base Quad Headlamp – High Beam 9005 Front Turn Signal Lamp (Base Quad 3157NA Headlamp) Premium Bi Halogen Projector Headlamp HIR2 - Low Beam Premium Bi Halogen Projector Headlamp 9005 - High Beam...
Page 251: Customer Assistance
CUSTOMER ASSISTANCE FCA US LLC CUSTOMER CENTER P.O. Box 21–8004 Auburn Hills, MI 48321–8004 Phone: 1-866-726-4636 FCA CANADA INC. CUSTOMER CENTER P.O. Box 1621 Windsor, Ontario N9A 4H6 Phone: 1-800-465-2001 (English) Phone: 1-800-387-9983 (French) ASSISTANCE FOR THE HEARING IMPAIRED To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommunication Devices for the Deaf) equipment at its customer center.
Page 252: Publications Ordering
• A street address is required when ordering manuals (no P.O. Boxes). • The Owner's Manual and User Guide electronic files are also available on the Chrysler, Jeep, Ram Truck, Dodge and SRT websites. • Click on the “For Owners” tab, select “Owner/Service Manuals”, then select your desired model year and vehicle from the drop down lists.
Page 253: Mopar® Accessories
MOPAR® ACCESSORIES AUTHENTIC ACCESSORIES BY MOPAR® The following highlights just some of the many Authentic Ram Truck Accessories by MOPAR ® featuring a fit, finish, and functionality specifically for your Ram Truck. In choosing Authentic Accessories you gain far more than expressive style, premium protection, or extreme entertainment, you also benefit from enhancing your vehicle with accessories that have been thoroughly tested and factory-approved.
Page 254: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS FREQUENTLY ASKED QUESTIONS GETTING STARTED How do I install my LATCH Equipped Child Seat? pg. 17 How do I program my Front Seat Memory? pg. 26 OPERATING YOUR VEHICLE How does the Electronic Range Select (ERS) operate? pg. 39 ELECTRONICS Which radio is in my vehicle? •...
Page 255 How do I shift into different four-wheel drive selections? pg. 130 UTILITY How do I know how much I can tow with my Ram Truck? pg. 145 How do I adjust the gain on the Integrated Trailer Brake Module? pg. 147 WHAT TO DO IN EMERGENCIES How do I change a flat tire? pg.
Page 256: Index
INDEX Adjustable Pedals ...32 Lower Anchors And Tethers For Children ... .17, 18 Air Bag Child Seat ....18 Advance Front Air Bag .
Page 257 INDEX Malfunction Indicator Integrated Trailer Brake Controls . .147 (Check Engine) ..181 Interior and Instrument Lights . . .6, 53 Oil Selection ...215 Intermittent Wipers (Delay Wipers) .
Page 258 INDEX ParkSense ® System, Lap/Shoulder Belts ..15 Front And Rear ...48 Seat Belt Pretensioner ..15 ParkSense System, Rear ..48 Seat Belt Reminder .
Page 259 INDEX Towing Vehicle Behind a Uconnect ® 8.4AN ...98 Motorhome ... . .149 Uconnect ® Access ...55 Traction Control .
Page 260 This guide has been prepared to help you get quickly acquainted with your new RAM and to provide a convenient reference source for common questions. However, it is not a substitute for your Owner’s Manual. For complete operational instructions, maintenance procedures and important safety messages, please consult your Owner’s Manual,...
Page 261 Download a free electronic copy of the Owner’s Manual or Warranty Booklet by visiting the Owners tab at www.ramtrucks.com (U.S.) or www.ramtruck.ca (Canada). 14D241-926-AA RAM Trucks 1500/2500/3500 Eighth Edition User Guide...

This manual is also suitable for:

Ram 3500 Ram 2500

RAM 1500 User Manual

Introduction/Welcome

Controls at a Glance

Getting Started

Operating Your Vehicle

Electronics

Off-Road Capabilities

Utility

1500 3.0L Diesel

6.7L Cummins® Diesel

What to Do in Emergencies

Maintaining Your Vehicle

Customer Assistance

Mopar® Accessories

Frequentlyasked Questions

Index

Quick Links

Need help?

Questions and answers

Related Manuals for RAM 1500

Summary of Contents for RAM 1500

This manual is also suitable for:

Table of Contents
