Page 2
FC9252 DISASSEMBLY- AND RE-ASSEMBLY ADVISE REPAIR INSTRUCTION - To open the appliance, first remove the filter cover - If the reel half spring unit is replaced, shaft (M) must be (item 37). lubricated with silicone grease. Do not apply any silicone grease to or spill any grease on terminals (item 53) or - Remove the can with the filters.
Page 3
REPAIR INSTRUCTION FC9252 - Appliances from before WK845 have a potential problem To prevent lever shifting out of position to re-occur, in the cord winder system; the lever of spindle (Pos. 24) can CW support (Pos. 68) must be added as shown in below move out of position.
Page 4
PARTS LIST FC9252 Service code Description Service code Description 4322 005 25400 Handle assy 4322 005 27781 Skate wheel assy Left & Right 4322 003 34210 Handle side rear 4322 005 24150 Exhaust grille assy Cold blue 4322 003 34200...
