Hogtunes REV200RG Kit RM Installation Manual

High performance front speaker kit with 200 watt amplifier for use on rushmore road glide model

Advertisement


Dennis Kirk provides instructions to help our customers better understand how to install the
products we sell. The instructions are exact copies of what the manufacturer includes with the
product being sold.
That means the quality and accuracy of the instructions is solely dependent on what the
manufacturer produces. We do our best to make the text legible and the pictures viewable.
However, the end result depends largely on the quality of instructions the manufacturer
provides.
Therefore, you will find that some instructions are not of the highest quality. Sometimes text is
hard to read and pictures are not easy to see. At times you will find the overall look of the
instructions to be less than professional. However, we feel it is better to provide what we have
rather than provide nothing at all.
To the best of our knowledge the instructions and application information contained in the
instructions is accurate. However, Dennis Kirk assumes no liability related to any errors that
may be contained in the copy of the manufacturer's instructions we provide. Buyers are solely
responsible to insure that product use is consistent with their application.
If you have any questions please contact us at
800-969-7501 so we can further assist you regarding additional product information or any other
business related questions.
Thank you for doing business with Dennis Kirk.

Instruction Disclaimer


customerservice@denniskirk.com
or

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the REV200RG Kit RM and is the answer not in the manual?

Questions and answers

Summary of Contents for Hogtunes REV200RG Kit RM

  • Page 1       Instruction Disclaimer    Dennis Kirk provides instructions to help our customers better understand how to install the products we sell. The instructions are exact copies of what the manufacturer includes with the product being sold. That means the quality and accuracy of the instructions is solely dependent on what the manufacturer produces.
  • Page 2 REV 200RG Kit-RM REV 200RG Kit-RM High Performance Front Speaker Kit with 200 Watt Amplifier High Performance Front Speaker Kit with 200 Watt Amplifier For Use on 1998-2013 Ultra ClassiCs and tri-Glides For Use on rUshmore road Glide models installation Manual installation Manual...
  • Page 3 Thank you for choosing the Hogtunes REV 200RG KIT-RM for Rushmore platform Road Glide models. Since positive word of mouth is the best way to grow our business, we want your system to work as well as it was designed to.
  • Page 4 Step #4: On the back of each stock speaker grill, you will see a rubber gasket and 2 white clips. These gaskets and clips will be removed from the factory grills and re-installed on the Hogtunes grills. Once the gaskets and clips are installed onto the new grills, simply press the new grills back onto your inner fairing.
  • Page 5 ReV 200-RM aMplIFIeR InStallatIon InStRuctIonS Figure 1.1 Before proceeding, please locate the points in the fairing identified by the letters in Figure 1.1. A= mounting points for Headlight assembly B= Wire passage from fairing to bike C= Brake side speaker harness (Pink and Pink with Black Stripe wires) D= Clutch Side Speaker harness (Pink and Pink with Black Stripe wires) E= Factory 2 pin plug for amplifiers (orange) remote turn on lead Step #1: Locate the supplied power harness and plug it into the matching...
  • Page 6 Locate the supplied front output harness and plug it into the “amplified output” plug on the end of the 4 wires coming out of the amp. Step #4: You will see a 3 position switch on the side of the amplifier. For all typical installs, this should be in the “+3”...
  • Page 7 RoutIng the poweR haRneSS The balance of the power harness will exit the inner fairing and go towards the frame of the bike through the “wire passage from fairing to bike” as shown by “B” in Figure 1.1. Just in front of the tank, you will see a structure that attaches the fairing to the frame of the bike.
  • Page 8: Technical Specifications

    AVC position works and sounds best. Your new amplifier has been specifically set-up for this radio setting. 2) Your Hogtunes system is designed specifically for a motorcycle at speed. Exhaust noise and wind noise have been taken into careful consideration in how your system performs.
