Roast Hazelnut Single Pedestal Desk without Basket
Model # RHSPD-UK
ADULT ASSEMBLY REQUIRED
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to
the store where it was purchased. Please call our toll-free customer service number and have
your instructions and parts list ready to provide the model name, part name or factory number:
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday to Friday
Or e-mail your request to parts@baysidefurnishings.com
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Bayside Furnishings
001-877-494-2536 (Service valid only in USA)
Or visit our website www.baysidefurnishings.com
®
LOT NUMBER:
DATE PURCHASED: / /
Page 1
Factory No. 10944
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Bayside Furnishings RHSPD-UK
Summary of Contents for Bayside Furnishings RHSPD-UK
- Page 1 ® O'nin Roast Hazelnut Single Pedestal Desk without Basket Model # RHSPD-UK ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our toll-free customer service number and have...
- Page 2 M A X I M U M R E C O M M E N D E D W E I G H T L O A D S ® MANUFACTURER: Bayside Furnishings ® CATALOG: O'nin Roast Hazelnut Single Pedestal Desk without Basket (RHSPD-UK) DATE OF MANUFACTURE: March 2014 MADE IN CHINA MAXIMUM LOAD 200 lb. (90.7 kg) MAXIMUM LOAD 20 lb. (9 kg) THIS UNIT IS INTENDED ONLY FOR USE WITHIN THE MAXIMUM WEIGHTS INDICATED.
- Page 3 Model # RHSPD-UK Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Desk Top (1) B- Side Panel (1) C- Bottom Panel (1) D- Pedestal Front/Back Panel (2)
- Page 4 Model # RHSPD-UK Assembly Instructions 1. Unpack the unit and confirm that you have all the hardware and required parts. Assembly the unit on a carpeted floor or the empty carton to avoid any scratch. 2. Insert four Small Wood Dowels (8) half way into the pre-drilled holes on the Fixed Shelf (E) by tapping lightly with a rubber mallet, if necessary.
- Page 5 Model # RHSPD-UK Assembly Instructions 5. Insert four Small Wood Dowels (8) into the end holes of bottom Divider Panel (F) and insert three Large Wood Dowels (7) into each end of the Pedestal Front/Back Panels (D). 6. Using the inserted wood dowels as a guide, attach the Bottom Panel (C) to the Pedestal Front/Back Panels (D) by screwing four 2-1/4”...
- Page 6 Model # RHSPD-UK Assembly Instructions 8. Insert four Small Wood Dowels (8) into the end holes of the upper Divider Panel (F) and insert three Large Wood Dowels (7) into each end of the Pedestal Front/Back Panels (D). Position the Desk Top (A) onto the inserted wood dowels and secure it in place by engaging four Cam Locks (9) (Refer to page 2 on Cam lock system operation supplement).
- Page 7 Model # RHSPD-UK Assembly Instructions 10. Proceed to secure the Side Panel (B) to the Desk Top (A) by attaching 2 Metal Connectors (G) at the joints. As shown. Make sure that the curved plates of Metal Brackets (G) face outward.
- Page 8 Model # RHSPD-UK The following steps are only for those who wish to combine the desk with our Roast Hazelnut Room Divider (model # RHRD, sold separately) together. NOTE: The unit is designed to combine with our Roast Hazelnut Room Divider (model# RHRD, sold separately).
- Page 9 Model # RHSPD-UK Assembly Instructions 15. Stand the unit upright and fit the Metal Brackets (H) onto the Center Divider of Roast Hazelnut Room Divider properly. Make sure that the Desk Top (A) and the Side Panels of Room Divider are even with each other.
-
