Writing Desk
ITM. / ART. 1119076
Model # CSC5430WD-3PC
ASSEMBLY INSTRUCTIONS
IMPORTANT,
RETAIN
FOR
FUTURE
REFERENCE: READ CAREFULLY
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
1-877-494-2536 (English, French and Spanish)
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday to Friday
(In U.S., Canada, and Mexico only)
Or visit our website www.baysidefurnishings.com
For customer service outside of North America, please e-mail your request to
parts@baysidefurnishings.com
MADE IN CHINA
Date 2017-12-18 Rev. 0001-B Factory: ZHIFUR
Advertisement
Table of Contents
Related Manuals for Bayside Furnishings CSC5430WD-3PC
Summary of Contents for Bayside Furnishings CSC5430WD-3PC
- Page 1 Writing Desk ITM. / ART. 1119076 Model # CSC5430WD-3PC ASSEMBLY INSTRUCTIONS IMPORTANT, RETAIN FUTURE REFERENCE: READ CAREFULLY If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our toll-free customer service number and have your...
- Page 2 G E N E R A L I N F O R M A T I O N A N D T I P S 1. This product is for indoor domestic use only. 2. Please read the Assembly Instructions prior to assembling this product. 3.
-
Page 3: Important Safety Instructions
FURNITURE POWER DISTRIBUTION CENTER IMPORTANT SAFETY INSTRUCTIONS Carefully read all instructions installing and operating fixture IF YOU HAVE ANY QUESTIONS REGARDING THE PROPER INSTALLATION CONSULT A QUALIFIED ELECTRICIAN. TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK OR INJURY TO PERSONS, PLEASE FOLLOW THE NEXT: •... -
Page 4: Specifications
Furniture Power Distribution Unit User Guide Please read this user guide before installing and using your power distribution Center. This device complies with Part 15 of the FCC Rules. INTRODUCTION Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) The integrated power and USB center offers 480 Mbps this device must accept any interference received, high transmission rate and can connect up to three... - Page 5 Parts and Hardware List PART # PART DESCRIPTION PART FIGURE QUANTITY Desk Top Left Leg Right Leg Stretcher Bolt 2+1 extra Bolt 10+1 extra Lock Washer 10+1 extra Flat Washer 10+1 extra Screw 4+1 extra Cord Clip Hex Wrench Brown Touch-up Pen Gray Touch-up Pen Tipping Restraint 1 set...
- Page 6 Assembly Instructions 1. Using the pilot holes as a guide, attach two cord clips (EE) to the back post of right leg (C) with the hooks pointing towards the same direction, using two screws (FF) per clip as shown. 2. Place the desk top (A) upside down on a level and protective surface. 3.
- Page 7 Assembly Instructions 4. Align and attach the left leg (B) to the left side apron of the desk top (A) with the end dowels fully inserted by using five bolts (BB) and five washers (CC and DD). 5. Using the wood dowels as a guide, attach the stretcher (D) to the bottom rail of left leg (B). 6.
- Page 8 Assembly Instructions 7. Fasten the stretcher (D) between the bottom rail of legs (B and C) with two bolts (AA). 8. Secure the right leg (B) in place with five bolts (BB) and five washers (CC and DD). 9. Ask for assistance to lift the unit upright and position at your desired location. 10.
- Page 9 Assembly Instructions 11. Ask for assistance to position the desk at the desired location against a wall. If necessary, adjust the pre-attached floor levelers at the bottom of legs to level the unit. 12. Follow the instructions printed on the plastic bag containing the tipping restraint hardware to attach the tip-over restraints to the unit and the wall.
-
Page 10: Quality Guarantee
Should this product be defective in workmanship or materials or fail under normal use, we will repair or ® replace it for up to one (1) year from date of purchase. Every Bayside Furnishings product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
