ACR3901T-W1
Secure Bluetooth
®
Contact Card Reader
User Manual V1.00
Subject to change without prior notice
info@acs.com.hk
www.acs.com.hk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACR3901T-W1 and is the answer not in the manual?

Questions and answers

Related Manuals for ACS ACR3901T-W1

Summary of Contents for ACS ACR3901T-W1

  • Page 1 ACR3901T-W1 Secure Bluetooth ® Contact Card Reader User Manual V1.00 Subject to change without prior notice info@acs.com.hk www.acs.com.hk...

  • Page 2: Table Of Contents

    Set up device pairing with built-in Bluetooth adapter ............25 4.3. Set up device pairing with Bluetooth USB dongle ............... 27 4.4. Using the ACS Bluetooth Device Management Tool ............28 4.4.1. Install a device ......................28 4.4.2. Uninstall a device ......................31 4.5.

  • Page 3: Introduction

    Section 3.0 - provides procedures on how to install and use Bluetooth (BT) demo application with ACR3901T-W1 using Android device and library • Section 4.0 – provides procedures on how to install ACS Bluetooth driver, pair Bluetooth devices and use the ACS Bluetooth Device Management Tool Page 3 of 33 ACR3901T-W1 –...

  • Page 4: For Ios

    2.0. For iOS 2.1. Install the Bluetooth demo application 1. You can access the device library when you download the iOS & Mac EVK from the ACS website. 2. Using XCode application, open BTDemo.xcodeproj. 3. Transfer BTDemo.xcodeproj to your mobile device. Choose your mobile device, and then click Play.

  • Page 5: Using The Acs Bluetooth Demo Application

    2.2.1. Connect a device 1. Turn on the Bluetooth mode of ACR3901T-W1 to make it discoverable. To do this, press the button on the top surface of the device as shown below. 2. Turn on your device’s Bluetooth by going to Settings > Bluetooth.
  • Page 6 6. When the pairing is successful, tap OK to close the prompt. Page 6 of 33 ACR3901T-W1 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...

  • Page 7: Get The Device Information

    2.2.2. Get the device information To get the reader’s information, tap Device Information. Page 7 of 33 ACR3901T-W1 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...

  • Page 8: Get The Battery Status

    2.2.3. Get the battery status To get the battery status, tap Get Battery Status. Page 8 of 33 ACR3901T-W1 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...

  • Page 9: Get The Card's Atr (Answer Toreset)

    Get the card’s ATR (Answer ToReset) To get the ATR of the card: 1. Insert smart card into the ACR3901T-W1 reader. 2. In the demo application, tap Authenticate Reader. 3. When the authentication is successful, tap OK to close the prompt.

  • Page 10: Transmit An Apdu Command

    2.2.5. Transmit an APDU command To transmit APDU command: 1. Insert smart card into the ACR3901T-W1 reader. 2. In the demo application, tap Authenticate Reader. 3. Tap Transmit APDU. 4. The Response APDU will be displayed. Note: You can edit the APDU command by tapping Command APDU.

  • Page 11: Transmit An Escape Command

    2.2.6. Transmit an escape command To transmit an escape command: 1. Insert smart card into the ACR3901T-W1 reader. 2. In the demo application, tap Authenticate Reader. 3. Tap Power On Card, and then tap Transmit Escape Command. 4. The Escape Response will be displayed.

  • Page 12: For Android

    3.1. Install the Bluetooth demo application 1. Connect your mobile device to the computer. 2. In the internal storage of your device, create a folder where the ACR3901T-W1 BTdemo will be placed. 3. You can access the device library when you download the Android EVK from the ACS website.
  • Page 13 5. Disconnect your mobile device from the computer. Locate the BTDemo.apk using a file manager application. 6. To start the installation, tap the BTDemo.apk file. Page 13 of 33 ACR3901T-W1 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...
  • Page 14 7. Complete the action using Package Installer. 8. A prompt will ask for hardware control access. Tap Install to proceed. 9. Once the installation is complete, you can now open the BT demo application. Page 14 of 33 ACR3901T-W1 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...

  • Page 15: Using The Acs Bluetooth Demo Application

    3.2.1. Connect a device 1. Turn on the Bluetooth mode of ACR3901T-W1 to make it discoverable. To do this, press the button on the top surface of the device as shown below. 2. Turn on your device’s Bluetooth by going to Settings | Bluetooth.
  • Page 16 5. On the right top corner, click Connect. The reader and mobile device will start bonding. 6. Once the bonding is complete, ACR3901T-W1 is now ready to be used with the mobile device. Page 16 of 33 ACR3901T-W1 – User Manual info@acs.com.hk...

  • Page 17: Getting The Device Information

    3.2.2. Getting the device information To get the reader’s information, tap Get Device Info. Page 17 of 33 ACR3901T-W1 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...

  • Page 18: Getting The Battery Status

    3.2.3. Getting the battery status To get the battery status, tap Get Battery Status. Page 18 of 33 ACR3901T-W1 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...

  • Page 19: Get The Card's Atr (Answer To Reset)

    Get the card’s ATR (Answer To Reset) To get the ATR of the card: 1. Insert smart card into the ACR3901T-W1 reader. 2. In the demo application, tap Authenticate. 3. Once it is finished, it will show an Authentication Success message.

  • Page 20: Transmit Apdu Command

    3.2.5. Transmit APDU command To transmit APDU command: 1. Insert smart card into the ACR3901T-W1 reader. 2. In the demo application, tap Authenticate. 3. Once it is finished, it will show Authentication Success message. 4. Tap Transmit APDU, and response APDU will be displayed under APDU command.

  • Page 21: Transmit Escape Command

    3.2.6. Transmit escape command To transmit an escape command: 1. Insert smart card into the ACR3901T-W1 reader. 2. In the demo application, tap Authenticate. 3. Once it is finished, it will show an Authentication Success message. 4. Tap Power On Card, and then tap Transmit Escape Command.

  • Page 22: For Windows

    2. The Setup Wizard will show. To start the installation, click Next. 3. Click Next to install the driver to the default destination, located at X:\Program Files\Advanced Card Systems Ltd\ACS Unified Bluetooth Driver 1.0.0.14\, with X as your local Windows drive.
  • Page 23 4. Click Install. 5. Wait while the driver installs. Page 23 of 33 ACR3901T-W1 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...
  • Page 24 6. Once the installation is complete, click Finish. Page 24 of 33 ACR3901T-W1 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...

  • Page 25: Set Up Device Pairing With Built-In Bluetooth Adapter

    Bluetooth 4.0/Bluetooth Low Energy interface. To pair using this setup: 1. Turn on the Bluetooth mode of ACR3901T-W1 to make it discoverable. To do this, press the button on the top surface of the device as shown below. 2. Go to PC Settings , choose PC and devices, and then click Bluetooth.
  • Page 26 4. Select ACR3901T-W1, and then click Pair. 5. The pairing is complete when you see ACR3901T-W1 is connected. 6. To complete the installation of the Bluetooth card reader, go to Using the ACS Bluetooth Device Management Tool. Page 26 of 33 ACR3901T-W1 –...

  • Page 27: Set Up Device Pairing With Bluetooth Usb Dongle

    3. Wait while the device driver installs. 4. When it is ready to use, click Close. 5. When you open the Using the ACS Bluetooth Device Management Tool, it automatically pairs the dongle to your system. Page 27 of 33 ACR3901T-W1 –...

  • Page 28: Using The Acs Bluetooth Device Management Tool

    Uninstall a device). To begin: 1. Turn on the Bluetooth mode of ACR3901T-W1 to make it discoverable. To do this, press the button on the top surface of the device as shown below. 2. Run the ACS Bluetooth Device Management Tool.
  • Page 29 Note: The default authentication key is FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF. 7. Wait while the application installs the driver. 8. A message will appear confirming a successful installation. Click OK, and then reset your device. Page 29 of 33 ACR3901T-W1 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...
  • Page 30 9. The list in the ACS Bluetooth Device Management Tool would be updated. 10. After a successful driver installation, you can now use ACR3901T-W1 with various smart card applications. Below is a sample of ACR3901T-W1 connected in QuickView. Page 30 of 33 ACR3901T-W1 –...

  • Page 31: Uninstall A Device

    Note: Since the TI USB dongle can only work on a one-to-one connection with a Bluetooth card reader, you must first uninstall the previous device to connect to another one. Page 31 of 33 ACR3901T-W1 – User Manual info@acs.com.hk www.acs.com.hk...

  • Page 32: Check If Bluetooth Card Reader Is Installed Correctly

    4.5. Check if Bluetooth card reader is installed correctly 1. Go to the Device Manager. 2. Under Smart card readers, the ACR3901T-W1 reader should show as ACR3901 BLE ICC Reader. 3. Right-click on the device, and then click Properties. Page 32 of 33 ACR3901T-W1 –...
  • Page 33 The Bluetooth® word, mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Advanced Card Systems Ltd. is under license. Windows is a registered trademark of Microsoft Corporation in the United States and/or other countries. Page 33 of 33 ACR3901T-W1 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...
