ACS ACR3901U-S1 User Manual

Bluetooth contact card reader
Hide thumbs Also See for ACR3901U-S1:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Reference Manual, User Manual
ACR3901U-S1
Bluetooth Contact Card
Reader
User Manual V1.00
Subject to change without prior notice
info@acs.com.hk
www.acs.com.hk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACR3901U-S1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ACS ACR3901U-S1

Summary of Contents for ACS ACR3901U-S1

  • Page 1 ACR3901U-S1 Bluetooth Contact Card Reader User Manual V1.00 Subject to change without prior notice info@acs.com.hk www.acs.com.hk...

  • Page 2: Table Of Contents

    Getting the device information ..................21 3.2.3. Getting the battery status .................... 22 3.2.4. Getting the ATR ......................23 3.2.5. Transmitting command APDU ..................24 3.2.6. Executing escape command ..................26 Page 2 of 27 www.acs.com ACR3901U-S1 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...

  • Page 3: Introduction

    1.0. Introduction ACR3901U-S1 Bluetooth Contact Card Reader combines the latest technology in the world of smart card readers with Bluetooth connectivity. This compact and wireless smart card reader brings together sophisticated technology with fresh design to meet different requirements in various smart card-based applications using Bluetooth-enabled devices, such as smart phones and tablets.

  • Page 4: For Ios

    2.0. For iOS 2.1. Installing the application 1. Download the device library from ACS website under ACR3901U-S1 category. 2. Using XCode application, open the BTDemo.xcodeproj. 3. Transfer the BTDemo.xcodeproj to your mobile device by choosing your mobile device and then clicking the play button.

  • Page 5: Using The Application

    2.2. Using the application This section provides a simple step-by-step procedure on how to use the ACR3901U-S1 Bluetooth Card Reader using the BT Demo application. 2.2.1. Connecting the reader 1. Enable your iOS device’s Bluetooth by going to Settings > Bluetooth.
  • Page 6 6. A Bluetooth Pairing Request message will be displayed. Tap Pair to continue. 7. A prompt will be shown that the pairing was a success. Tap OK to close the prompt. Page 6 of 27 www.acs.com ACR3901U-S1 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...

  • Page 7: Getting The Device Information

    2.2.2. Getting the device information To get the reader’s information, tap Device Information. Page 7 of 27 www.acs.com ACR3901U-S1 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...

  • Page 8: Getting The Battery Status

    2.2.3. Getting the battery status To get the battery status: 1. Tap Get Battery Status. 2. Battery status will be displayed. Page 8 of 27 www.acs.com ACR3901U-S1 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...

  • Page 9: Getting The Atr

    2.2.4. Getting the ATR To get the ATR of the card: 1. Insert smart card into the ACR3901U-S1 reader. 2. Tap Authenticate Reader to validate device. Page 9 of 27 www.acs.com ACR3901U-S1 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...
  • Page 10 3. A prompt will be shown that the authentication was a success. Tap OK to close the prompt. 4. Tap Power On Card. Page 10 of 27 www.acs.com ACR3901U-S1 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...
  • Page 11 5. Card’s ATR will be displayed. Page 11 of 27 www.acs.com ACR3901U-S1 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...

  • Page 12: Transmitting Command Apdu

    2.2.5. Transmitting command APDU To transmit APDU command: 1. Insert smart card into the ACR3901U-S1 reader. 2. Tap Authenticate Reader to validate device. 3. Tap Transmit APDU. Page 12 of 27 www.acs.com ACR3901U-S1 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...
  • Page 13 4. Response APDU will be displayed. *Note: User could edit the APDU command by tapping Command APDU. Page 13 of 27 www.acs.com ACR3901U-S1 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...

  • Page 14: Executing Escape Command

    2.2.6. Executing escape command To execute an escape command: 1. Insert smart card into the ACR3901U-S1 reader. 2. Tap Authenticate Reader to validate device. 3. Tap Power On Card, and then Transmit Escape Command. Page 14 of 27 www.acs.com ACR3901U-S1 – User Manual info@acs.com.hk...
  • Page 15 4. Escape Response will be displayed. Page 15 of 27 www.acs.com ACR3901U-S1 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...

  • Page 16: For Android

    3.1. Installing the application 1. Connect your mobile device to the computer. 2. In the internal storage of your device, create a folder where the ACR3901U-S1 BTdemo will be placed. 3. Download the device library from ACS website under ACR3901U-S1 category.
  • Page 17 5. Disconnect your mobile device from the computer, and then locate the BTDemo.apk using a file manager application. 6. Tap the BTDemo.apk file to start the installation process. Page 17 of 27 www.acs.com ACR3901U-S1 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...
  • Page 18 8. A prompt will ask for hardware control access. Tap Install to proceed. 9. Once the installation is complete, you may now open the BT Demo application. Page 18 of 27 www.acs.com ACR3901U-S1 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...

  • Page 19: Using The Application

    Connecting the reader 1. Enable your Android device’s Bluetooth by going to Settings > Bluetooth. 2. Enable ACR3901U-S1’s Bluetooth mode by switching the toggle to the right. 3. Open ACS BT Demo application. 4. Choose the reader to pair your Android device with, then tap Done.
  • Page 20 5. Click Connect at the right top corner, and ACR3901U-S1 and mobile device will start bonding. 6. Once the bonding is complete, ACR3901U-S1 is now ready to be used with the mobile device. Page 20 of 27 www.acs.com ACR3901U-S1 – User Manual info@acs.com.hk...

  • Page 21: Getting The Device Information

    3.2.2. Getting the device information To get the reader’s information, tap Get Device Info. Page 21 of 27 www.acs.com ACR3901U-S1 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...

  • Page 22: Getting The Battery Status

    3.2.3. Getting the battery status To get the battery status, tap Get Battery Status. Page 22 of 27 www.acs.com ACR3901U-S1 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...

  • Page 23: Getting The Atr

    3.2.4. Getting the ATR To get the ATR of the card: 1. Insert smart card into the ACR3901U-S1 reader. 2. Tap Authenticate to validate device. 3. Once it is finished, it will show an Authentication Success message. 4. Tap Power On Card to power on card and display ATR.

  • Page 24: Transmitting Command Apdu

    3.2.5. Transmitting command APDU To transmit APDU command: 1. Insert smart card into the ACR3901U-S1 reader. 2. Tap Authenticate to validate device. 3. Once it is finished, it will show Authencation Success message. 4. Tap Transmit APDU, and response APDU will be displayed under APDU command.
  • Page 25 5. APDU command response will be displayed. Note: User could edit the APDU command by tapping Command APDU. Page 25 of 27 www.acs.com ACR3901U-S1 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...

  • Page 26: Executing Escape Command

    3.2.6. Executing escape command To execute an escape command: 1. Insert smart card into the ACR3901U-S1 reader. 2. Tap Authenticate to validate device. 3. Once it is finished, it will show an Authentication Success message. 4. Tap Power On Card, and then Transmit Escape Command.
  • Page 27 5. Escape Response will be displayed. Android is a trademark of Google Inc. Page 27 of 27 www.acs.com ACR3901U-S1 – User Manual info@acs.com.hk www.acs.com.hk Version 1.00...
