- Page 1 AXIS Q60-S Series AXIS Q6042-S PTZ Dome Network Camera AXIS Q6044-S PTZ Dome Network Camera AXIS Q6045-S Mk II PTZ Dome Network Camera Installation Guide...
- Page 2 2. Every care has been taken in the preparation of this • Low Voltage (LVD) Directive 2006/95/EC. See Safety document. Please inform your local Axis office of any on page 3. inaccuracies or omissions. Axis Communications AB cannot •...
-
Page 3: Hazard Levels
AXIS Q60-S Series Safety Information Read through this Installation Guide carefully before installing the product. Keep the Installation Guide for future reference. Hazard Levels DANGER Indicates a hazardous situation which, if not avoided, will result in death or serious injury. -
Page 4: Safety Instructions
Battery The Axis product uses a 3.0 V BR/CR2032 lithium battery as the power supply for its internal real-time clock (RTC). Under normal conditions this battery will last for a minimum of five years. Low battery power affects the operation of the RTC, causing it to reset at every power-up. When the battery needs replacing, a log message will appear in the product’s server report. -
Page 5: Dome Cover
WARNING • Risk of explosion if the battery is incorrectly replaced. • Replace only with an identical battery or a battery which is recommended by Axis. • Dispose of used batteries according to local regulations or the battery manufacturer's instructions. -
Page 6: Installation Steps
AXIS Q60-S Series Installation Guide This Installation Guide provides instructions for installing AXIS Q6042-S PTZ Dome Network Camera, AXIS Q6044-S PTZ Dome Network Camera or AXIS Q6045-S Mk II PTZ Dome Network Camera on your network. In stallation Steps 1. Make sure the package contents, tools and other materials necessary for the installation are in order. -
Page 7: Optional Accessories
7 mm wrench (ground screw Media Converter Switch) • 8 mm (5/16”) wrench/socket (Sunshield, Pole Bracket T91C67 (hose clamp)) • 10 mm (3/8”) wrench/socket (Bracket adapter AXIS T91C61, AXIS T94S01D, Pole Bracket T91C67) • Cable shoe pliers (ground cable Media Converter Switch) •... -
Page 8: Hardware Overview
AXIS Q60-S Series Hardware Overview Mounting hole for sunshield (3x) Pressure relief valve Multiconnector Hook for safety wire Guide hole Inlet valve Mounting hole (3x) Part number (P/N) & Serial number (S/N) SD card slot (SDHC) 10 Status LED indicator... - Page 9 AXIS Q60-S Series Dome Cover Dome bracket screw T25 (4x) Dome cover Rubber gasket Rubber gasket Dome ring Dome ring screw T20 (4x) Sunshield (Sold Separately) Screw holes...
-
Page 10: Media Converter Switch
AXIS Q60-S Series Media Converter Switch Power connector (DC input) Power connector (DC output) Network connector (internal) Network slot SFP (external) (2x) Network connector RJ45 (external) (2x) Camera LED indicator Network LED indicator (4x) Power LED indicator Ground clip 10 I/O connector (internal) -
Page 11: Media Converter Switch Led Indicators
AXIS Q60-S Series Green Shows steady green for 10 seconds for normal operation after startup completed. Amber Steady during startup. Flashes during firmware upgrade. Amber/Red Flashes amber/red if network connection is unavailable or lost. Flashes red for firmware upgrade failure. -
Page 12: Multi-Connector Cable
The control button is used for: • Resetting the product to factory default settings. See page 31. • Connecting to an AXIS Video Hosting System service or AXIS Internet Dynamic DNS Service. For more information about these services, see the User Manual. Multi-Connector Cable Note The supplied multi-connector cable is required in order to maintain the camera’s NEMA/IP... - Page 13 AXIS Q60-S Series Multi-connector cable overview Power wire (red) Digital I/O wire (blue) Ethernet wire (green/white) Ethernet wire (green) Ethernet wire (orange/white) Ethernet wire (orange) Digital I/O wire (yellow) Ground wire (black) Power wire (red) 10 Ethernet wire foil shield (2x)
-
Page 14: Media Converter Switch Connectors
AXIS Q60-S Series 4 – green Ethernet – receiving Ethernet – transmitting 5 – orange/white 6 – orange Ethernet – transmitting 8 – black 0 V DC 0 V DC (-) 1, 9 – red Used to power camera DC output 12–13.2 V DC... -
Page 15: Specifications
When a signal is received the state changes and the input becomes active (shown under System Options > Port & Devices > Port Status). I/O connector (internal) - 2–pin I/O terminal block. Specifications Operating Conditions The Axis product is intended for outdoor use. Product Classification Temperature Humidity... -
Page 16: Electrical Specification
AXIS Q6045-S Mk II Electrical Specification NO TICE TICE TICE For confirmed compliance with the requirements for Safety Extra Low Voltage (SELV) and Limited Power Source (LPS), use the power supply (sold separately) recommended by Axis. Product Function Description AXIS Q6042-S Input power... - Page 17 AXIS Q60-S Series Connectors SD Card Slot Supports SD cards with up to 64 GB of storage. For best recording performance, use an SDHC or SDXC card with speed class 10. Media Converter Switch Connectors External Connectors Ground Screw Ground screw for connecting the media converter switch to earth ground.
- Page 18 AXIS Q60-S Series Configurable Digital input 0 to max 30 V DC I/O 1 (Input or Output) 0 to max 30 V DC, Digital output (transistor – open drain, 100 mA open collector) Digital input Configurable 0 to max 30 V DC...
-
Page 19: Install The Hardware
If possible, keep the protective plastic on the dome cover until the installation is complete. The Axis product can be installed with the cables routed through or along the wall or roof. Read all the instructions before installing the product. Some installation steps would benefit from being completed together because they require removal of the dome cover. - Page 20 AXIS Q60-S Series Install an SD Card It is optional to install an SD card (not included), which can be used for local recording with removable storage. 1. Loosen the dome ring screws and remove the dome cover. 2. Insert an SD card (not included) into the SD card slot.
- Page 21 For information about regulatory requirements, see Regulatory Information on page 2. Important Axis can only guarantee full functionality with the supplied media converter switch. No other devices are supported. 1. Make sure the mains supply is switched off.
- Page 22 AXIS Q60-S Series 4. Strip off 40 mm (1.57 in) of the multi-connector cable jacket. 5. Leave the braided shield intact, but cut off 30 mm (1.18 in) of the outer foil shield. 6. Fold back the leftover outer foil shield and twist the braided shield into a coil.
- Page 23 AXIS Q60-S Series Power wire (red) Digital I/O wire (blue) Ethernet wire (green/white) Ethernet wire (green) Ethernet wire (orange/white) Ethernet wire (orange) Digital I/O wire (yellow) Ground wire (black) Power wire (red) 10 Power connector (DC output) 11 Ethernet connector (internal)
- Page 24 AXIS Q60-S Series 11. Make sure the clamp is in place, insert the braided shield coil into the ground clip and tighten the screws. NO TICE TICE TICE • The shields and the clamp surfaces shall be in full contact with each other so that the multi-connector cable is grounded.
- Page 25 AXIS Q60-S Series Ground wire Ground screw 13. If applicable, connect an I/O device to the external I/O connector. 14. Connect the power cable (DC input) to the power connector (DC input) via the terminal block plug. 15. Attach the ground wire to the ground screw (position 8 in the illustration).
-
Page 26: Install The Network Camera
AXIS Q60-S Series Power LED indicator Network LED indicator (4x) ETH 1/2/3/4 Camera LED indicator Install the Network Camera NO TICE TICE TICE To comply with the IP66-rated design of the camera and maintain the IP66 protection, the supplied multi-connector cable shall be used. - Page 27 AXIS Q60-S Series Mounting example (wall bracket sold separately) Safety wire 4. Remove the protection cap covering the multi-connector on the camera. 5. Connect the multi-connector cable to the connector on the camera. Use the alignment indicators to find the correct position.
-
Page 28: Reset To Factory Default Settings
AXIS Q60-S Series Mounting example (wall bracket sold separately) Alignment indicator – multi-connector cable Alignment indicator – camera Flange Multi-connector cable Guide hole Reset to Factory Default Settings Important Reset to factory default should be used with caution. A reset to factory default will reset... - Page 29 It is also possible to reset parameters to factory default via the web interface. Go to Setup > System Options > Maintenance. View other Marine Electronics & Navigation made by AXIS Communications on our website.
