OWNER'S MANUAL
Operation
Maintenance
Specifications
All information in this Owner's Manual is current at the time of publication.
However, Hyundai reserves the right to make changes at any time so that
our policy of continual product improvement may be carried out.
This manual applies to all models of this vehicle and includes descriptions
and explanations of optional as well as standard equipment. As a result,
you may find material in this manual that does not apply to your specific
vehicle.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Azera 2013 and is the answer not in the manual?

Questions and answers

Related Manuals for Hyundai Azera 2013

Summary of Contents for Hyundai Azera 2013

  • Page 1 Specifications All information in this Owner's Manual is current at the time of publication. However, Hyundai reserves the right to make changes at any time so that our policy of continual product improvement may be carried out. This manual applies to all models of this vehicle and includes descriptions and explanations of optional as well as standard equipment.
  • Page 2 CAUTION: MODIFICATIONS TO YOUR HYUNDAI Your Hyundai should not be modified in any way. Such modifications may adversely affect the per- formance, safety or durability of your Hyundai and may, in addition, violate conditions of the limited warranties covering the vehicle. Certain modifications may also be in violation of regulations estab- lished by the Department of Transportation and other government agencies in your country.
  • Page 3 SAFETY AND VEHICLE DAMAGE WARNING This manual includes information titled as WARNING, CAUTION and NOTICE. These titles indicate the following: WARNING This indicates that a condition may result in harm, serious injury or death to you or other persons if the warning is not heeded. Follow the advice provided with the warning. CAUTION This indicates that a condition may result in damage to your vehicle or its equipment if the caution is not heeded.
  • Page 4 Your Owner's Manual will introduce you to the features and operation of your new Hyundai. It is suggested that you read it care- fully because the information it contains can contribute greatly to the satisfaction you receive from your new car.

  • Page 5: Table Of Contents

    Introduction Your vehicle at a glance Safety features of your vehicle Features of your vehicle Driving your vehicle table of contents What to do in an emergency Maintenance Specifications & Consumer information Index...

  • Page 6: Indicator Symbols On The Instrument Cluster /

    Introduction How to use this manual / 1-2 Fuel requirements / 1-3 Vehicle break-in process / 1-5 Indicator symbols on the instrument cluster / 1-6...

  • Page 7: Introduction

    Introduction HOW TO USE THIS MANUAL We want to help you get the greatest The general layout of the manual is pro- will find various WARNINGs, possible driving pleasure from your vehi- vided in the Table of Contents. Use the CAUTIONs, and NOTICEs in this manu- cle.
  • Page 8 Except Europe WARNING Your new HYUNDAI vehicle is designed • Do not "top off" after the nozzle to use only unleaded fuel having an automatically shuts off when Octane Rating of RON (Research refueling.
  • Page 9 Fuel Additives Do not use gasohol containing more than vapor lock or hard starting. HYUNDAI recommends that you use 10% ethanol, and do not use gasoline or good quality gasoline that meets Europe gasohol containing any methanol. Either Fuel standards (EN228) or equivalents.
  • Page 10 Introduction VEHICLE BREAK-IN PROCESS No special break-in period is needed. By following a few simple precautions for the first 1,000 km (600 miles) you may add to the performance, economy and life of your vehicle. • Do not race the engine. •...
  • Page 11 Introduction INDICATOR SYMBOLS ON THE INSTRUMENT CLUSTER Electric parking brake (EPB) Air bag warning light Shift pattern indicator malfunction indicator* Low windshield washer fluid AUTO Seat belt warning light AUTO HOLD indicator* level warning light HOLD Turn signal indicator Charging system warning light Cruise control indicator* CRUISE Front fog light indicator...

  • Page 12: Your Vehicle At A Glance

    Your vehicle at a glance Interior overview / 2-2 Instrument panel overview / 2-3 Engine compartment / 2-4...
  • Page 13 Your vehicle at a glance INTERIOR OVERVIEW 1. Door lock/unlock button ....4-17 2. Central door lock switch....4-17 3. Power window switches ....4-22 4. Power window lock button ....4-25 5. Outside rearview mirror control switch ..........4-42 6. Outside rearview mirror folding button*..........4-42 7.
  • Page 14 Your vehicle at a glance INSTRUMENT PANEL OVERVIEW 1. Instrument cluster .......4-44 2. Horn ............4-39 3. Driver’s front air bag ......3-46 4. Light control/Turn signals....4-78 5. Wiper/Washer ........4-83 6. Steering wheel audio control ....4-126 7. Cruise control switch or Auto cruise control switch...5-36/5-40 8.
  • Page 15 Your vehicle at a glance ENGINE COMPARTMENT ■ ■ 2.4L 1. Engine oil dipstick ......7-27 2. Engine oil filler cap ......7-27 3. Engine coolant reservoir ....7-29 4. Radiator cap ........7-30 5. Brake fluid reservoir......7-31 6. Power steering fluid reservoir ...7-32 7.
  • Page 16 Seats / 3-2 Seat belts / 3-18 Child restraint system / 3-29 Air bag - supplemental restraint system / 3-39 Safety features of your vehicle...

  • Page 17: Seats

    Safety features of your vehicle SEATS Driver’s seat ■ ■ Type A Type B (1) Forward and backward (2) Seatback angle (3) Seat cushion height (4) Lumbar support* (5) Cushion extension* (6) Driver position memory system* ■ Automatic ■ Automatic (7) Active seat* (8) Seat warmer*/ Seat warmer with air ventilation*...

  • Page 18: Safety Features Of Your Vehicle

    Safety features of your vehicle WARNING WARNING WARNING Loose objects Driver respon- - Driver’s seat sibility for passengers Loose objects in the driver’s foot • Never attempt to adjust the seat area could interfere with the opera- while the vehicle is moving. This Riding in a vehicle with the seat- tion of the foot pedals, possibly could result in loss of control,...

  • Page 19: Features Of Your Vehicle

    Safety features of your vehicle WARNING After adjusting the seat, always check that it is securely locked into place by attempting to move the seat forward or reverse without using lock release lever. Sudden or unexpected movement of the driver's seat could cause you to lose control of the vehicle result- ing in an accident.
  • Page 20 Safety features of your vehicle Automatic adjustment The front seat can be adjusted by using the control switch located on the outside of the seat cushion. Before driving, adjust the seat to the proper position so as to easily control the steering wheel, pedals and switches on the instrument panel.
  • Page 21 Safety features of your vehicle OHG030007 OHG030008 OHG030009 Forward and backward Seatback angle Seat cushion height (for driver’s seat) 1. Push the control switch forward or 1. Push the upper part of the control 1. Pull the front portion of the control backward to move the seat to the switch forward or backward to move switch up to raise or down to lower the...
  • Page 22 Safety features of your vehicle ■ Type A OHG030010 ■ Type B OHG030013 OHG030012 Active seat Cushion extension (for driver's seat, if equipped) (for driver's seat, if equipped) • MODE 1 : Continuously activates both 1. Push the switch forward to raise the top and bottom lumber support.
  • Page 23 Safety features of your vehicle WARNING • For maximum effectiveness in case of an accident, the headrest should be adjusted so the middle of the headrest is at the same height of the center of gravity of an occupant's head. Generally, the center of gravity of most peo- ple's head is similar with the height of the top of their eyes.
  • Page 24 Safety features of your vehicle ■ Type A ■ Type A CAUTION OHG034070 OHG034071 ■ Type B ■ Type B OYFH034205 If you recline the seatback towards the front with the head restraint and seat cushion raised, the head restraint may come in contact with the sunvisor or other parts of the OHG034072 OHG034073...
  • Page 25 Safety features of your vehicle ■ Type A WARNING Always make sure the headrest locks into position after reinstalling and adjusting it properly. OHG030017 ■ Type B OHG030016 Forward and backward adjustment The headrest may be adjusted forward to 3 different positions by pulling the head- rest forward to the desired detent.
  • Page 26 Safety features of your vehicle During mild weather or under conditions CAUTION where the operation of the seat warmer WARNING - Seat warmer is not needed, keep the switches in the • When cleaning the seats, do not burns "OFF" position. use an organic solvent such as Passengers should use extreme thinner, benzene, alcohol and...
  • Page 27 Safety features of your vehicle • Each time you push the switch, the air- flow changes as follows: OFF→HIGH( )→MIDDLE( )→LOW( • When the air ventilation seat is turned on, the seat may get cooler after about 5 minutes. • The air ventilation seat defaults to the OFF position whenever the ignition switch is turned to the ON position.
  • Page 28 Safety features of your vehicle WARNING • For maximum effectiveness in case of an accident, the headrest should be adjusted so the middle of the headrest is at the same height of the center of gravity of an occupant's head. Generally, the center of gravity of most peo- ple's head is similar with the height of the top of their eyes.
  • Page 29 Safety features of your vehicle ✽ NOTICE With the seat warmer switch in the ON position, the heating system in the seat turns off or on automatically depending on the seat temperature. CAUTION • When cleaning the seats, do not use an organic solvent such as thinner, benzene, alcohol and gasoline.
  • Page 30 Safety features of your vehicle WARNING - Seat warmer burns Passengers should use extreme caution when using seat warmers due to the possibility of excess heating or burns. The seat warmer may cause burns even at low tem- peratures, especially if used for long periods of time.
  • Page 31 Safety features of your vehicle Folding the rear seat The rear seatbacks may be folded to facilitate carrying long items or to increase the luggage capacity of the vehicle. WARNING The purpose of the fold-down rear seatbacks is to allow you to carry longer objects than could not oth- erwise be accommodated.

  • Page 32: Shift Lever

    Safety features of your vehicle 5. To use the rear seat, lift and pull the seatback backward. Push back the WARNING WARNING Uprighting - Cargo seatback firmly until it clicks into place. seat Cargo should always be secured to Make sure the seatback is locked in prevent it from being thrown about When you return the seatback to its place.

  • Page 33: Seat Belts

    Safety features of your vehicle SEAT BELTS Seat belt restraint system (Continued) (Continued) • Never wear a seat belt over frag- Seat belts should be adjusted as WARNING ile objects. If there is a sudden firmly as possible, consistent with •...
  • Page 34 Safety features of your vehicle Driver's side (1) WARNING Warning light • No modifications or additions • The seat belt warning light will blink for should be made by the user approximately 6 seconds each time which will either prevent the seat you turn the ignition switch ON regard- belt adjusting devices from oper- less of belt fastening.
  • Page 35 Safety features of your vehicle ✽ NOTICE Warning chime (if equipped) • The seat belt warning chime will sound If you are not able to pull out the seat for approximately 6 seconds each time belt from the retractor, firmly pull the you turn the ignition switch ON if the belt out and release it.
  • Page 36 Safety features of your vehicle To raise the height adjuster, pull it up (1). To lower it, push it down (3) while press- ing the height adjuster button (2). Release the button to lock the anchor into position. Try sliding the height adjuster to make sure that it has locked into position.
  • Page 37 Safety features of your vehicle OHG030031 B210A01NF-1 OED030300 When using the rear center seat belt, the To release the seat belt: Pre-tensioner seat belt buckle with the “CENTER” mark must be The seat belt is released by pressing the (if equipped) used.
  • Page 38 Safety features of your vehicle When the vehicle stops suddenly, or if the occupant tries to lean forward too WARNING quickly, the seat belt retractor will lock To obtain maximum benefit from a into position. In certain frontal collisions, pre-tensioner seat belt: the pre-tensioner will activate and pull 1.
  • Page 39 Wash all exposed skin areas thor- being driven, have an authorized touch the pre-tensioner seat belt oughly after an accident in which the HYUNDAI dealer inspect the pre- assemblies for several minutes pre-tensioner seat belts were activat- tensioner seat belt and SRS air bag after they have been activated.
  • Page 40 Body work on the front area of the child restraint appropriate for your vehicle may damage the pre-ten- child's height and weight. sioner seat belt system. Therefore, we recommend that the system be serviced by an authorized HYUNDAI dealer. 3 25...
  • Page 41 Safety features of your vehicle ✽ NOTICE Larger children WARNING - Shoulder belts Children who are too large for child Small children are best protected from on small children restraint systems should always occupy injury in an accident when properly the rear seat and use the available •...
  • Page 42 Safety features of your vehicle Pregnant women Injured person WARNING The use of a seat belt is recommended A seat belt should be used when an for pregnant women to lessen the chance injured person is being transported. Riding with a reclined seatback of injury in an accident.
  • Page 43 This should be done even if no damage serious injury. is visible. Additional questions concern- ing seat belt operation should be directed to an authorized HYUNDAI dealer.
  • Page 44 Safety features of your vehicle CHILD RESTRAINT SYSTEM Children riding in the car should sit in the Before buying a particular child restraint rear seat and must always be properly system, make sure it fits your car seat WARNING restrained to minimize the risk of injury in and seat belts, and fits your child.
  • Page 45 • Never allow two children, or any • After an accident, have an author- tions for installation and use of two persons, to use the same ized HYUNDAI dealer check the the child restraint. seat belt. child restraint system, seat belt, •...
  • Page 46 ■ Forward-facing child restraint system • If the seat belt does not operate as described in this section, have the system checked immediately by your authorized HYUNDAI dealer. • Failure to observe this manual's instructions regarding child...
  • Page 47 Safety features of your vehicle E2MS103005 OEN036101 OEN036104 Installing a child restraint system by 2. Fasten the lap/shoulder belt latch into 3. Buckle the seat belt and allow the seat lap/shoulder belt belt to take up any slack. After installa- the buckle.
  • Page 48 Safety features of your vehicle Child seat restraint suitability for seat position using the seat belt - For Europe Use child safety seats that have been officially approved and are appropriate for your children. When using the child safety seats, refer to the following table. Seating position Age group Front...
  • Page 49 Safety features of your vehicle WARNING WARNING - Child restraint check A child can be seriously injured or killed in a collision if the child Check that the child restraint sys- restraint is not properly anchored tem is secure by pushing and to the car and the child is not prop- pulling it in different directions.
  • Page 50 Safety features of your vehicle Both rear outboard seats are equipped with a pair of ISOFIX anchorages as well as a corresponding top tether anchorage on the shelf behind the rear seats. The ISOFIX anchorages are located between ISOFIX Anchor Position Indicator seat cushion and backrest, marked with the ISOFIX icon.
  • Page 51 Safety features of your vehicle To secure the child restraint seat WARNING WARNING 1. To engage the child restraint seat to the ISOFIX anchor, insert the child • When using vehicle's • Do not install a child restraint restraint seat latch into the ISOFIX "ISOFIX"...
  • Page 52 Safety features of your vehicle (Continued) • Do not mount more than one child restraint to a child restraint lower anchorage point. The improper increased load may cause the anchorage points or tether anchor to break, causing serious injury or death. •...
  • Page 53 Safety features of your vehicle Child seat restraint suitability for vehicle ISOFIX positions- For Europe Vehicle ISOFIX positions Mass Group Size Class Fixture Rear Outboard Rear Outboard Front Passenger Rear Center (Driver side) (Passenger side) ISO/L1 Carrycot ISO/L2 0 : UP to 10kg ISO/R1 ISO/R1 0+ : UP to 13kg...

  • Page 54: Driver's Front Air Bag

    Before scraping a vehicle, we recommend that you contact an authorized HYUNDAI dealer. • Keep the SRS parts and wirings away from water or any liquid. If the SRS components are inoper- ative due to exposure to water or ❈...
  • Page 55 Safety features of your vehicle How does the air bag system It is much more likely that you will sim- ply see the deflated air bags hanging WARNING operate out of their storage compartments after • To avoid severe personal injury •...
  • Page 56 Safety features of your vehicle Noise and smoke ■ Type A Never place a rear-facing child restraint in the front passenger’s seat. If the air When the air bags inflate, they make a loud noise and they leave smoke and bag deploys, it would impact the rear-fac- powder in the air inside of the vehicle.
  • Page 57 If this occurs, have an authorized equipped with side and/or curtain Air bag warning indicator HYUNDAI dealer inspect the pas- air bags, be sure to install the Air bag warning light senger’s front air bag ON/OFF...
  • Page 58 SRS. Have an authorized The SRSCM continually monitors all HYUNDAI dealer inspect the air bag SRS components while the ignition system as soon as possible. switch is ON to determine if a crash •...
  • Page 59 Safety features of your vehicle Driver’s front air bag (1) Driver’s front air bag (2) Driver’s front air bag (3) OHM039103N OHM039102N OHM039104N The front air bag modules are located Upon deployment, tear seams molded A fully inflated air bag, in combination both in the center of the steering wheel, directly into the pad covers will separate with a properly worn seat belt, slows the...
  • Page 60 If this occurs, have your instrument cluster nor on the vehicle immediately inspected by instrument panel surface. an authorized HYUNDAI dealer. It may become a dangerous pro- (Continued) jectile and cause injury if the pas- senger's air bag inflates.
  • Page 61 Safety features of your vehicle ■ The indications of the system's presence ■ Driver’s front air bag Passenger’s front air bag are the letters "SRS AIR BAG" or "AIR Type A • BAG" embossed on the air bag pad cover in the steering wheel and/or on the cover of the driver's side knee bolster located below the steering wheel and the pas-...
  • Page 62 HYUNDAI dealer • Never lean against the door or cen- inflates. Always follow the precau- inspect the air bag system as ter console –...
  • Page 63 Safety features of your vehicle (Continued) (Continued) • Front air bags are not intended to • For maximum safety protection in deploy side-impact, rear- all types of crashes, all occu- impact or rollover crashes. In pants including the driver should addition, front air bags will not always wear their seat belts deploy in frontal crashes below...
  • Page 64 If this occurs, have an authorized bag, insert the master key into the pas- • When the passenger’s front air bag HYUNDAI dealer inspect the pas- senger’s front air bag ON/OFF switch ON/OFF switch is set to the OFF posi- senger’s front air bag ON/OFF...
  • Page 65 A child restraint system must air bag only when the ignition HYUNDAI dealer inspect the pas- never be placed in the front seat. switch is switched off, or the mal- senger’s front air bag ON/OFF Children who are too large for...
  • Page 66 Safety features of your vehicle ■ Side impact air bag (if equipped) Front WARNING Your vehicle is equipped with a side Do not allow the passengers to lean impact air bag in each front and/or out- their heads or bodies onto doors, board rear seat.
  • Page 67 HYUNDAI dealer because your (Continued) They are designed to help protect the vehicle is equipped with side heads of the front seat occupants and impact air bags.
  • Page 68 Make sure to HYUNDAI dealer. position the child restraint sys- Failure to follow the above instruc- tem as far away from the door tions can result in injury or death to side as possible, and secure the...
  • Page 69 Safety features of your vehicle Why didn’t my air bag go off in a collision? (Inflation and non-infla- tion conditions of the air bag) There are many types of accidents in which the air bag would not be expect- ed to provide additional protection. These include rear impacts, second or third collisions in multiple impact accidents, as well as low speed...
  • Page 70 Have the vehicle result in serious personal injury checked and repaired by an or death. authorized HYUNDAI dealer. • If the installation location or • Your vehicle has been designed angle of the sensors is altered in to absorb impact and deploy the any way, the air bags may deploy air bag(s) in certain collisions.
  • Page 71 Safety features of your vehicle Although the front air bags (driver’s and front passenger’s air bags) are designed to inflate only in frontal collisions, they also may inflate in other types of colli- sions if the front impact sensors detect a sufficient impact.
  • Page 72 Safety features of your vehicle OBH038058 1JBA3516 OBH038060 • Frontal air bags are not designed to • Front air bags may not inflate in side • In an angled collision, the force of inflate in rear collisions, because occu- impact collisions, because occupants impact may direct the occupants in a pants are moved backward by the move to the direction of the collision,...
  • Page 73 Safety features of your vehicle 1JBA3517 1JBA3522 1JBA3518 • Just before impact, drivers often brake • Air bags may not inflate in rollover acci- • Air bags may not inflate if the vehicle heavily. Such heavy braking lowers the dents because air bag deployment collides with objects such as utility front portion of the vehicle causing it to would not provide protection to the...
  • Page 74 HYUNDAI dealer. Improper handling of observed. authorized • No objects should be placed over the SRS system may result in serious HYUNDAI dealer knows these or near the air bag modules on the personal injury.
  • Page 75 Safety features of your vehicle Additional safety precautions • Keep occupants away from the air bag covers. All occupants should sit WARNING • Never let passengers ride in the upright, fully back in their seats with cargo area or on top of a folded- •...
  • Page 76 Safety features of your vehicle OHG030051L Air bag warning label Air bag warning labels are attached to alert the driver and passengers of poten- tial risk of air bag system. Note that these government warnings focus on the risk of children, we also want you to be aware of the risks which adults are exposed to which have been described in previous pages.
  • Page 77 Keys / 4-3 Smart key / 4-7 Remote keyless entry / 4-10 Theft-alarm system / 4-13 Door locks / 4-16 Trunk / 4-20 Windows / 4-22 Hood / 4-26 Features of your vehicle Fuel filler lid / 4-28 Panorama sunroof / 4-31 Driver position memory system / 4-35 Steering wheel / 4-37 Mirrors / 4-40...
  • Page 78 Manual climate control system / 4-91 Automatic climate control system / 4-101 Windshield defrosting and defogging / 4-113 Storage compartment / 4-117 Interior features / 4-118 Audio system / 4-125 Features of your vehicle...
  • Page 79 ENGINE START/STOP button is in HYUNDAI dealer. Remove the key code tag and store it in a safe place. Also, the ACC or ON position. Children copy adults and they could place...
  • Page 80 Features of your vehicle When leaving your keys with a parking lot or valet attendant, perform steps 1 to 3 above, and leave the sub key with the attendant. In this manner the sub key can only be used to start the engine and operate door locks.
  • Page 81 Features of your vehicle When leaving your keys with a parking lot Immobilizer system (if equipped) attendant or valet, perform steps 1 to 4 Your vehicle may be equipped with an above, remove the mechanical key from electronic engine immobilizer system to the smart key and leave the smart key reduce the risk of unauthorized vehicle with the attendant.
  • Page 82 If you need additional keys or lose your manufacturer warranty. keys, consult an authorized HYUNDAI WARNING dealer. In order to prevent theft of your vehicle, do not leave spare keys anywhere in your vehicle.
  • Page 83 Features of your vehicle SMART KEY (IF EQUIPPED) Also, the outside rearview mirror will automatically fold if the outside rearview mirror folding switch is in the AUTO posi- tion (if equipped). However, if any door, trunk or engine hood remains open, the hazard warning lights will not operate.
  • Page 84 Features of your vehicle Unlocking Using the button on the smart key Using the button on the smart key All doors are locked if the lock button(1) All doors are unlocked if the unlock but- Using the door handle switch is pressed.
  • Page 85 The trunk is opened if the trunk unlock authorized HYUNDAI dealer to pro- jacket pocket and maintain adequate button(3) is pressed for more than 1 sec- tect it from potential theft.
  • Page 86 The hazard warning lights blink once to contact an authorized HYUNDAI dealer. working correctly, contact an author- indicate that all doors are locked. Also, ized HYUNDAI dealer.
  • Page 87 HYUNDAI dealer. void the user’s authority to operate The word "HOLD" is written on the button • If the transmitter is in close proximity the equipment.
  • Page 88 Dispose the battery according to 3. Install the battery in the reverse order your local law(s) or regulation. of removal. For transmitter replacement, see an authorized HYUNDAI dealer for transmit- ter reprogramming.
  • Page 89 Features of your vehicle THEFT-ALARM SYSTEM (IF EQUIPPED) Armed stage Using the smart key Park the vehicle and stop the engine. Armed Arm the system as described below. stage 1. Turn off the engine. 2. Make sure that all doors, the engine hood and trunk lid are closed and latched.
  • Page 90 Features of your vehicle Using the transmitter • Lock the doors by pressing the lock Theft-alarm stage button on the smart key. Park the vehicle and stop the engine. The alarm will be activated if any of the After completion of the steps above, Arm the system as described below.
  • Page 91 After depressing the unlock button, the malfunction and should only be hazard warning lights will blink twice to Once the trunk is opened and then serviced by an authorized HYUNDAI indicate that the system is disarmed. closed, the trunk will be locked automati- dealer.

  • Page 92: Door Locks

    Features of your vehicle DOOR LOCKS ✽ NOTICE • After removing the cover, turn the key toward the rear of the vehicle to unlock • In cold and wet climates, door locks and toward the front of the vehicle to and door mechanisms may not work lock (3).

  • Page 93: Central Door Lock Switch

    Features of your vehicle • If the inner door handle of the driver’s ■ Driver’s door or front passenger’s door is pulled when the door lock button is in the lock position, the button unlocked and the door opens. • The front door cannot be locked if the ignition key is in the ignition switch and the door is opened.
  • Page 94 Features of your vehicle • When pushing down on the front por- Door lock/unlock features tion (1) of the switch, all vehicle doors WARNING Unlocked Impact sensing door unlock system will lock. vehicles All doors will automatically unlock when • When pushing down on the rear por- Leaving your vehicle unlocked can an impact causes the air bags to deploy.
  • Page 95 Features of your vehicle Shift lever door lock/unlock system 3. Close the rear door. (if equipped) To open the rear door, pull the outside • All doors will automatically lock when door handle (2). the shift lever is moved out of P (Park). Even though the doors may be unlocked, •...

  • Page 96: Driving Your Vehicle

    Features of your vehicle TRUNK WARNING The trunk swings upward. Make sure no objects or people are near the rear of the vehicle when open- ing the trunk. CAUTION Make certain that you close the trunk before driving your vehicle. Possible damage may occur to the OHG042016 OHG040018L...
  • Page 97 Features of your vehicle Closing the trunk WARNING To close, lower the trunk lid, then press • For emergencies, be fully aware down on it until it locks. To be sure the of the location of the emergency trunk lid is securely fastened, always trunk safety release lever in this check by trying to pull it up again.
  • Page 98 Features of your vehicle WINDOWS (1) Driver’s door power window switch (2) Front passenger’s door power win- dow switch (3) Rear door (left) power window switch (4) Rear door (right) power window switch (5) Window opening and closing (6) Automatic power window up/down (7) Power window lock switch ✽...
  • Page 99 Features of your vehicle Power windows The ignition switch must be in the ON position for power windows to operate. Each door has a power window switch that controls the door's window. The driv- er has a power window lock switch which can block the operation of passenger windows.
  • Page 100 Features of your vehicle ✽ NOTICE 1. Turn the ignition switch to the ON posi- tion. The automatic reverse feature for the 2. Close the window and continue pulling window is only active when the “auto up on the driver’s power window switch up”...

  • Page 101: Power Window Switches

    Features of your vehicle CAUTION WARNING - Windows • To prevent possible damage to • NEVER leave the keys in your the power window system, do not vehicle with unsupervised chil- open or close two windows or dren, when the Engine is running. more at the same time.
  • Page 102 Features of your vehicle HOOD Closing the hood 1. Before closing the hood, check the fol- lowing: • All filler caps in engine compartment must be correctly installed. • Gloves, rags or any other com- bustible material must be removed from the engine compartment.
  • Page 103 Features of your vehicle WARNING • Always double check to be sure that the hood is firmly latched before driving away. If it is not latched, the hood could fly open while the vehicle is being driven, causing a total loss of visibility, which might result in an accident.

  • Page 104: Fuel Filler Lid

    Features of your vehicle FUEL FILLER LID Closing the fuel filler lid 1. To install the cap, turn it clockwise until it “clicks”. This indicates that the cap is securely tightened. 2. Close the fuel filler lid and push it light- ly and make sure that it is securely closed.
  • Page 105 Features of your vehicle (Continued) (Continued) WARNING - Refueling dan- Use only approved portable plas- • Do not get back into a vehicle gers tic fuel containers designed to once you have begun refueling Automotive fuels are flammable carry and store gasoline. since you can generate static materials.
  • Page 106 • If the fuel filler cap requires then contact the local fire depart- replacement, use only a genuine ment. Follow any safety instruc- HYUNDAI cap or the equivalent tions they provide. specified for your vehicle. An incorrect fuel filler cap can result...
  • Page 107 Features of your vehicle PANORAMA SUNROOF (IF EQUIPPED) ✽ NOTICE • In cold and wet climates, the sunroof may not work properly due to freez- ing conditions. • After washing the car or after there is rain, be sure to wipe off any water that is on the sunroof before operating CAUTION Do not continue to move the sun-...
  • Page 108 Features of your vehicle OHG043196A OHG040032 OHG043030 Sliding the sunroof Tilting the sunroof Closing the sunroof When the sunshade is closed When the sunshade is closed Press the sunshade CLOSE button. The If you pull the sunroof control lever back- sunroof glass will close then the sun- If you push the sunroof control lever ward, the sunshade will slide all the way...
  • Page 109 Features of your vehicle CAUTION WARNING - Sunroof • Periodically remove any dirt that • Be careful that someone’s head, may accumulate on the guide rail. hands and body are not trapped • If you try to open the sunroof by a closing sunroof.
  • Page 110 OHGC042189 Resetting the sunroof For more detailed information, contact an Whenever the vehicle battery is discon- authorized HYUNDAI dealer. nected or discharged, or related fuse is blown, you must reset your sunroof sys- ✽ NOTICE tem as follows: If you do not reset the sunroof, it may not work properly.

  • Page 111: Driver's Position Memory System*

    Features of your vehicle DRIVER POSITION MEMORY SYSTEM (IF EQUIPPED) Storing positions into memory WARNING using the buttons on the door Never attempt to operate the driver Storing driver’s seat positions position memory system while the 1. Shift the shift lever into P (Park) while vehicle is moving.
  • Page 112 Features of your vehicle Recalling positions from memory Easy access function (if equipped) 1. Shift the shift lever into P (Park) while the ignition switch is ON. With the shift lever in the P (Park) posi- 2. To recall the position in memory, press tion, the system will move the driver's the desired memory button (1 or 2).

  • Page 113: Steering Wheel

    (below - vehicle operation, have the power steer- ment panel warning lights and gauges. 10°C/14°F), the power steering may ing checked by an authorized HYUNDAI require increased effort when the engine dealer. is first started. This is caused by...
  • Page 114 Features of your vehicle OHG040189L OHG040035 OHG040037 Manual type Electric type Heated steering wheel (if equipped) To change the steering wheel angle, pull Adjust the steering wheel angle (2) and down the lock release lever (1), adjust position (3) with the switch (1). Never With the ignition switch in the ON posi- the steering wheel to the desired angle adjust the position of the steering wheel...

  • Page 115: Horn

    Features of your vehicle CAUTION Do not strike the horn severely to operate it, or hit it with your fist. Do not press on the horn with a sharp- pointed object. OHG040038 Horn To sound the horn, press the horn sym- bol on your steering wheel.
  • Page 116 Features of your vehicle MIRRORS Electric chromic mirror (ECM) Inside rearview mirror The electric chromic mirror automatically Adjust the rearview mirror to center on controls the glare from the headlights of the view through the rear window. Make the car behind you in nighttime or low this adjustment before you start driving.
  • Page 117 Features of your vehicle Outside rearview mirror CAUTION Be sure to adjust mirror angles before Do not scrape ice off the mirror driving. face; this may damage the surface Your vehicle is equipped with both left- of the glass. If ice should restrict hand and right-hand outside rearview movement of the mirror, do not mirrors.
  • Page 118 Features of your vehicle CAUTION • The mirrors stop moving when they reach the maximum adjust- ing angles, but the motor contin- ues to operate while the switch is pressed. Do not press the switch longer than necessary, the motor may be damaged.
  • Page 119 Features of your vehicle - The mirror will fold or unfold when the Neutral : When the remote control out- door is locked or unlocked by the but- side rearview mirror switch is ton on the outside door handle. placed in the middle position, the outside rearview mirrors - The mirror will unfold when you will not operate while the vehi-...

  • Page 120: Instrument Cluster

    Features of your vehicle INSTRUMENT CLUSTER ■ Type A 1. Tachometer 2. Turn signal indicators 3. Speedometer 4. Odometer/Trip computer* 5. Fuel gauge 6. Engine temperature gauge 7. Warning and indicator lights ■ Type B * : if equipped ❈ The actual cluster in the vehicle may differ from the illustration.
  • Page 121 Features of your vehicle ■ ■ Type A Type B ■ ´ Type B OHG040048 Instrument panel illumination ■ ´ Type A The instrument panel illumination intensi- ty can be adjusted by pushing the control switch up or down with the headlight ■...
  • Page 122 Features of your vehicle ■ ■ ■ Type A Type B Type A CAUTION Do not operate the engine within the tachometer's RED ZONE. This may cause severe engine damage. OHG040051 ■ Type B OHG040053 Engine coolant temperature gauge This gauge shows the temperature of the engine coolant when the ignition switch is ON.
  • Page 123 Features of your vehicle ■ ■ Type A Type B WARNING WARNING - Fuel gauge Never remove the radiator cap Running out of fuel can expose when the engine is hot. The engine vehicle occupants to danger. coolant is under pressure and You must stop and obtain addition- could cause severe burns.

  • Page 124: Maintenance

    Features of your vehicle Trip computer ■ ■ Type A Type B The trip computer is a microcomputer- controlled driver information system that displays information related to driving on the display when the ignition switch is in the ON position. All stored driving infor- mation (except odometer) is reset if the battery is disconnected.
  • Page 125 Features of your vehicle ■ ■ ■ ■ ■ ■ Type A Type B Type A Type B Type A Type B OHG040057L OHG040058L OHG040060L Tripmeter (km or mi.) Distance to empty (km or mi.) Average fuel economy (l/100 km or MPG) TRIP A : Tripmeter A This mode indicates the estimated dis- This mode calculates the average fuel...
  • Page 126 Features of your vehicle ■ ■ ■ ■ ■ ■ Type A Type B Type A Type B Type A Type B OHG040061L OHG040062L OHG040063L Instant fuel economy Average speed (km/h or MPH) Elapsed time (l/100 km or MPG) This mode calculates the average speed This mode indicates the total time trav- This mode calculates the instant fuel of the vehicle since the last average...
  • Page 127 Features of your vehicle Auto door lock Seat Easy Access (only for Driver ■ ■ Type A Type B Position Memory System equipped Off - The auto door lock operation will be vehicle) canceled. On - The driver's seat will automatically Speed - All doors will be automatically move forward or rearward for the locked when the vehicle speed...
  • Page 128 Features of your vehicle Headlamp Escort Welcome Sound AVG fuel economy On - The Headlamp Escort On - The Welcome Sound function will Auto Reset - The average fuel economy Headlamp Welcome function will be be activated. will reset automatically activated.
  • Page 129 Features of your vehicle ■ ■ ■ ■ ■ ■ Type A Type B Type A Type B Type A Type B OHG040065L OHG040066L OHG040067L Maintenance system Maintenance 2. Select desired maintenance schedule. 1. When the vehicle is at a standstill, The Maintenance system informs the pressing the DISP button for more 3.
  • Page 130 6 seconds when you turned the ignition switch to the ON position or start- ed the engine, or if it comes on while driving, have the SRS inspected by an authorized HYUNDAI dealer.
  • Page 131 Features of your vehicle Turn signal indicator Front fog light indicator High beam indicator (if equipped) This indicator illuminates when the head- This light comes on when the front fog The blinking green arrows on the instru- lights are on and in the high beam posi- lights are ON.
  • Page 132 HYUNDAI dealer before the brakes do not operate properly. the car is driven again. Have the vehicle towed to any author- ized HYUNDAI dealer for a brake sys- tem inspection and necessary repairs.
  • Page 133 Have the vehicle checked by an come on when the ignition switch is for additional engine braking and stop the authorized HYUNDAI dealer as soon as turned to the ON position, this indicates car as soon as it is safe to do so.
  • Page 134 Refill the ignition in any position. 3. If the belt is adjusted properly, a prob- washer fluid as soon as possible. lem exists somewhere in the electrical charging system. Have an authorized HYUNDAI dealer correct the problem as soon as possible.
  • Page 135 ✽ NOTICE engine, have the system checked by an ENGINE START/STOP button with the authorized HYUNDAI dealer. If the engine coolant temperature warn- smart key. If smart key system related ing light illuminates, it indicates over- parts have a problem, the indicator will heating that may damage the engine.
  • Page 136 Have the Engine Control the ignition switch is turned to the ON System inspected as soon as pos- sible by an authorized HYUNDAI position, take your vehicle to your near- est authorized HYUNDAI dealer and dealer.
  • Page 137 ESP indicator will remain take your vehicle to an authorized to green. off. When a slippery or low traction con- HYUNDAI dealer and have the system If the AUTO HOLD malfunction indicator checked. dition is encountered, the ESP will oper-...
  • Page 138 "ON" position. Take your vehicle to an authorized cruise control ON-OFF button on the The TPMS malfunction indicator will illu- HYUNDAI dealer and have the system steering wheel is pushed. minate after it blinks for approximately 1 checked. The indicator light turns off when the...
  • Page 139 Features of your vehicle Overspeed warning LCD display warning (if equipped) WARNING (if equipped) Key is not in vehicle km/h Significantly low tire pressure ■ ■ Type A Type B makes the vehicle unstable and can Overspeed warning light contribute to loss of vehicle control If you drive with the speed of 120 km/h or and increased braking distances.
  • Page 140 Features of your vehicle Key not detected Low key battery Press brake pedal to start engine ■ ■ ■ ■ ■ ■ Type A Type B Type A Type B Type A Type B OHG040073L OHG040075L OHG040076L If the smart key is not in the vehicle or is If the ENGINE START/STOP button If the ENGINE START/STOP button not detected and you press the ENGINE...
  • Page 141 Also, the warning chime sounds for about If the warning illuminates each time you 10 seconds. (if equipped) press the ENGINE START/STOP button, take your vehicle to an authorized HYUNDAI dealer and have the system checked. 4 65...
  • Page 142 Features of your vehicle Press start button while turn steering Check steering wheel lock Please press start button with smart key ■ ■ ■ ■ ■ ■ Type A Type B Type A Type B Type A Type B OHG040080L OHG040081L OHG040074L If the steering wheel does not unlock nor-...
  • Page 143 Features of your vehicle Check stop lamp fuse Door /Trunk open Parking assist warning ■ ■ ■ ■ Type A Type B Type A Type B ■ ■ Type A Type B OHG040082L OHG040084 OHG040086 When the stop lamp fuse is disconnect- This indicator displays which door (or Displays the area an obstacle is detected ed, the warning illuminates for 10 sec-...
  • Page 144 Features of your vehicle REAR PARKING ASSIST SYSTEM (IF EQUIPPED) ■ Type A WARNING The rear parking assist system is a supplementary function only. The operation of the rear parking assist system can be affected by several factors (including environmental conditions).
  • Page 145 When an object is 120 cm tem checked by an authorized assist system to 81 cm (47 in. to 32 in.) HYUNDAI dealer. Operating condition from the rear bumper: • The actual indicator in the vehicle • This system will activate when backing Buzzer beeps intermittently.
  • Page 146 Features of your vehicle Non-operational conditions of The detecting range may decrease Rear parking assist system pre- when: rear parking assist system cautions 1. The sensor is stained with foreign mat- The rear parking assist system may • The rear parking assist system may ter such as snow or water.
  • Page 147 (blinks) ties and limitations. If this occurs, have your vehicle checked by an authorized HYUNDAI dealer as WARNING soon as possible. Pay close attention when the vehi- cle is driven close to objects on the...
  • Page 148 Features of your vehicle PARKING ASSIST SYSTEM (IF EQUIPPED) ■ sensing range objects ■ Front Type A detectable by the sensors are limited. Whenever moving pay as much attention to what is in front and behind of you as you would in a vehicle without a parking assist system.
  • Page 149 Features of your vehicle Type of warning indicator and sound Operation of the parking assist system : with Warning sound Operating condition Warning indicator • This system activates when the park- ing assist button is pressed with the Distance from object Warning sound When driving When driving...
  • Page 150 Features of your vehicle There is a possibility of parking Non-operational conditions of CAUTION assist system malfunction when: parking assist system • This system can only sense 1. Driving on uneven road surfaces such Parking assist system may not oper- objects within the range and loca- as unpaved roads, gravel, bumps, or ate normally when:...
  • Page 151 If this occurs, have your vehicle checked 4. When the sensor is frozen or stained WARNING by an authorized HYUNDAI dealer as with snow or water, the sensor may be soon as possible. inoperative until the stains are Pay close attention when the vehi- removed using a soft cloth.
  • Page 152 Features of your vehicle REARVIEW CAMERA (IF EQUIPPED) HAZARD WARNING FLASHER WARNING • This system is a supplementary function only. It is the responsi- bility of the driver to always check the inside/outside rearview mirror and the area behind the vehicle before and while backing up because there is a dead zone that can't be seen through the...
  • Page 153 Features of your vehicle LIGHTING Battery saver function Headlight escort function Headlight welcome function (if equipped) • The purpose of this feature is to pre- When the headlight is ON or AUTO posi- vent the battery from being dis- tion and all doors (and trunk) are closed If you turn the ignition switch to the ACC charged.
  • Page 154 Features of your vehicle OHG040110 OHG040111 OHG040112 Lighting control Parking light position ( Headlight position ( The light switch has a Headlight and a When the light switch is in the parking When the light switch is in the headlight Parking light position.
  • Page 155 Features of your vehicle CAUTION • Never place anything over sensor (1) located on the instrument panel. This will ensure better auto-light system control. • Don’t clean the sensor using a window cleaner. The cleaner may leave a light film which could interfere with sensor operation.
  • Page 156 Features of your vehicle One-touch triple turn signal (if equipped) To activate an one-touch triple turn signal move the turn signal lever slightly and then release it. The lane change signals will blink 3 times. You can activate or deactivate this fea- ture.
  • Page 157 Features of your vehicle OHG040117 OHG041190L OHG040187L Front fog light (if equipped) Rear fog light (if equipped) Headlight leveling device (if equipped) Fog lights are used to provide improved To turn the rear fog lights on, turn the visibility and avoid accidents when visibil- headlight switch to the headlight on posi- Manual type ity is poor due to fog, rain or snow etc.
  • Page 158 HYUNDAI dealer. headlight lenses. Do not attempt to inspect or • The headlight washer can be operated replace the wiring yourself.

  • Page 159: Wiper/Washer

    Features of your vehicle WIPERS AND WASHERS Windshield wiper/washer Windshield wipers ■ Type A A : Wiper speed control Operates as follows when the ignition switch is turned ON. · MIST / – Single wipe MIST / : For a single wiping cycle, ·...
  • Page 160 Features of your vehicle To vary the speed setting, turn the speed ■ Type A CAUTION control knob (1). When washing the vehicle, set the If the wiper switch is set in AUTO mode wiper switch in the OFF (O) position when the ignition switch is ON, the wiper to stop the auto wiper operation.
  • Page 161 Features of your vehicle ■ The reservoir filler neck is located in the Type A CAUTION front of the engine compartment on the passenger side. • To prevent possible damage to the wipers or windshield, do not operate the wipers when the CAUTION windshield is dry.
  • Page 162 Features of your vehicle INTERIOR LIGHT • DOOR : In the DOOR position, the CAUTION map lamp and the room lamp come on when any door is Do not use the interior lights for opened regardless of the igni- extended periods when the engine tion switch position.
  • Page 163 Features of your vehicle ■ • OFF : The lights turn off even if a door Type A is opened. • ROOM : The map lamp and the room lamp stay on at all times. OHG040123 ■ Type B OHG040125 Trunk room lamp The trunk room lamp comes on for 20 minutes when the trunk is opened.
  • Page 164 Features of your vehicle OHG040126 OHG040127 OHG040128 Door courtesy lamp Glove box lamp Vanity mirror lamp (if equipped) The glove box lamp comes on when the Opening the lid of the vanity mirror will glove box is opened. automatically turn on the mirror light. The door courtesy lamp comes ON when the door is opened to assist entering or The parking lights or headlights must be...
  • Page 165 Features of your vehicle WELCOME SYSTEM (IF EQUIPPED) Also, if the outside rearview mirror folding At this time, if you press the door lock or switch is in the AUTO position, the out- unlock button, the position light and side rearview mirror will unfold automati- headlight will turn off immediately.
  • Page 166 Features of your vehicle DEFROSTER Outside rearview mirror defroster CAUTION (if equipped) To prevent damage to the conduc- If your vehicle is equipped with the out- tors bonded to the inside surface of side rearview mirror defrosters, they will the rear window, never use sharp operate at the same time you turn on the instruments or window cleaners rear window defroster.

  • Page 167: Manual Climate Control System

    Features of your vehicle MANUAL CLIMATE CONTROL SYSTEM CAUTION Operating the blower when the igni- tion switch is in the ON position could cause the battery to dis- charge. Operate the blower when the engine is running. 1. Air conditioning button 5.
  • Page 168 Features of your vehicle Heating and air conditioning 1. Start the engine. 2. Set the mode to the desired position. To improve the effectiveness of heating and cooling; - Heating: - Cooling: 3. Set the temperature control to the desired position. 4.
  • Page 169 Features of your vehicle Face-Level (B, C, D, E, F) Floor-Level (A, C, D, E) Air flow is directed toward the upper body Most of the air flow is directed to the and face. Additionally, each outlet can be floor, with a small amount of air directed controlled to direct the air discharged to the windshield and side window from the outlet.
  • Page 170 Features of your vehicle OHG040134 OHG040135 OHG040136 MAX A/C-Level (B, C, D, E, F) Instrument panel vents Temperature control To select the MAX A/C, turn the temper- The outlet vents can be opened or closed The temperature control knob allows you ature knob to the extreme left.
  • Page 171 Features of your vehicle Temperature conversion Recirculated air position You can switch the temperature mode With the recirculated air between Centigrade to Fahrenheit as fol- position selected, air from lows: the passenger compart- ment will be drawn through 1. Select mode.
  • Page 172 Features of your vehicle ✽ NOTICE WARNING Prolonged operation of the heater in the • Continue using the climate con- recirculated air position (without air trol system in the recirculated air conditioning selected) may cause fog- position may allow humidity to ging of the windshield and side windows increase inside the vehicle which and the air within the passenger com-...
  • Page 173 Features of your vehicle System operation Ventilation 1. Set the mode to the position. 2. Set the air intake control to the outside (fresh) air position. 3. Set the temperature control to the desired position. 4. Set the fan speed control to the desired speed.
  • Page 174 Features of your vehicle ✽ NOTICE Air conditioning Operation Tips • To keep dust or unpleasant fumes from HYUNDAI Air Conditioning Systems are • When using the air conditioning sys- entering the vehicle through the venti- filled with environmentally friendly...
  • Page 175 (fresh) air position is selected. If this hap- in the recirculated air position provides pens, have the climate control air filter maximum cooling, however, continual replaced by an authorized HYUNDAI operation in this mode may cause the dealer. air inside the vehicle to become stale.
  • Page 176 • When the air flow rate suddenly found, have the system inspected by an decreases, the system should be authorized HYUNDAI dealer. checked at an authorized HYUNDAI dealer. ✽ NOTICE It is important that the correct type and amount of oil and refrigerant is used.
  • Page 177 Features of your vehicle AUTOMATIC CLIMATE CONTROL SYSTEM (IF EQUIPPED) ■ ■ Type A 1. Front windshield defroster button 2. Fan speed control knob 3. OFF button 4. Rear window defroster button 5. Dual temperature control selection button 6. Mode selection button 7.
  • Page 178 Features of your vehicle OHG040142 OHG042184 OHG040143 ✽ NOTICE Automatic heating and air condi- 2. Set the temperature to the desired tioning temperature. Never place anything over the sensor 1. Push the AUTO button. located on the instrument panel to ✽...
  • Page 179 Features of your vehicle Manual heating and air condition- The heating and cooling system can be controlled manually by pushing buttons other than the AUTO button. In this case, the system works sequentially according to the order of buttons selected. When pressing any button except the AUTO button while using automatic oper- ation, the functions not selected will be...
  • Page 180 Features of your vehicle Floor-Level Most of the air flow is directed to the floor, with a small amount of air directed to the windshield and side window defrosters. Bi-Level Air flow is directed towards the face and OHG040144 OHG040145 the floor.
  • Page 181 Features of your vehicle ■ ■ Driver’s side Passenger’s side OHG040135 OHG040184 OHG040146 Instrument panel vents Temperature control Adjusting the driver and passenger side temperature individually The outlet vents can be opened or closed The temperature will increase to the separately using the thumbwheel.
  • Page 182 Features of your vehicle Adjusting the driver and passenger side Temperature conversion ■ Type A temperature equally You can switch the temperature mode 1. Press the DUAL button again to deac- between Centigrade to Fahrenheit as fol- tivate DUAL mode. The passenger lows: side temperature will be set to the While pressing the MODE button, press...
  • Page 183 Features of your vehicle ✽ NOTICE Recirculated air position WARNING With the recirculated air Driving on high speed with the recircu- position selected, air from • Continued climate control system lation air position mode, fresh air may the passenger compart- operation in the recirculated air enter the vehicle to ventilate the inside ment will be drawn through...
  • Page 184 Features of your vehicle OHG040148 OHG040149 OHG040150 Fan speed control Air conditioning OFF mode The fan speed can be set to the desired Press the OFF button to turn off the air Press the A/C button to turn the air con- speed by turning the fan speed control climate control system.
  • Page 185 Features of your vehicle System operation Operation Tips • To keep dust or unpleasant fumes from Ventilation entering the vehicle through the venti- 1. Set the mode to the position. lation system, temporarily set the air 2. Set the air intake control to the outside intake control to the recirculated air (fresh) air position.
  • Page 186 Features of your vehicle ✽ NOTICE Air conditioning Air conditioning system operation tips HYUNDAI Air Conditioning Systems are • If the vehicle has been parked in direct • When using the air conditioning sys- filled with environmentally friendly sunlight during hot weather, open the...
  • Page 187 Blower decreases, the system should be Evaporator core causing loss of visibility. In this case, checked at an authorized HYUNDAI Climate control air filter Heater core set the mode selection knob or button dealer.
  • Page 188 The air conditioning system should be serviced by an authorized When the amount of refrigerant is low, HYUNDAI dealer. Improper service the performance of the air conditioning is may cause serious injury to the reduced. Overfilling also has a negative person performing the service.
  • Page 189 Features of your vehicle WINDSHIELD DEFROSTING AND DEFOGGING • For maximum defrosting, set the tem- WARNING perature control to the extreme Windshield right/hot position and the fan speed heating control to the highest speed. Do not use the position • If warm air to the floor is desired while during cooling operation...
  • Page 190 Features of your vehicle OHG040153 OHG040154 OHG040155 To defrost outside windshield Automatic climate control system To defrost outside windshield 1. Set the fan speed to the highest posi- 1. Set the fan speed to the highest To defog inside windshield tion.
  • Page 191 Features of your vehicle Defogging logic To reduce the probability of fogging up the inside of the windshield, the air intake or air conditioning are controlled auto- matically according to certain conditions such as position. To cancel or return the defogging logic, do the follow- ing.
  • Page 192 Features of your vehicle This indicator illuminates If the battery has been disconnected or when the auto defogging discharged, it resets to the auto defog- system senses the moisture ging status. of inside the windshield and ✽ NOTICE operates. If the A/C off or recirculated air position If more moisture is in the vehicle, higher is manually selected while the auto steps operate as follow.

  • Page 193: Glove Box

    Features of your vehicle STORAGE COMPARTMENTS These compartments can be used to store small items required by the driver or passengers. CAUTION • To avoid possible theft, do not leave valuables in the storage compartments. • Always keep the storage com- partment covers closed while driving.
  • Page 194 Features of your vehicle WARNING • Do not keep objects except sun- glasses inside the sunglass hold- er. Such objects can be thrown from the holder in the event of a sudden stop or an accident, pos- sibly injuring the passengers in the vehicle.
  • Page 195 "ready" position. bustible materials may cause a If it is necessary to replace the cigarette fire. lighter, use only a genuine HYUNDAI replacement or its approved equivalent. 4 119...
  • Page 196 Features of your vehicle Cup holder ■ Front CAUTION • Do not place uncovered cups or WARNING Hot liquids unsecured bottles, cans, etc. with • Do not place uncovered cups of liquid in the cup holder while the hot liquid in the cup holder while vehicle is in motion.
  • Page 197 Features of your vehicle ■ Power outlet Front • • The power outlet is designed to provide power for mobile telephones or other devices designed to operate with vehicle electrical systems. The devices should draw less than 10 amps with the engine running.
  • Page 198 Features of your vehicle WARNING Do not put a finger or a foreign ele- ment (pin, etc.) into a power outlet and do not touch with a wet hand. You may get electrocuted or fire may occur. Digital clock Whenever the battery terminals or relat- ed fuses are disconnected, you must OUN026348 OCM039200N...
  • Page 199 HYUNDAI recom- mends that only the HYUNDAI floor mat designed for use in your vehi- cle be installed. 4 123...
  • Page 200 Features of your vehicle ■ Type A OHG040174 ■ Type B OHG040176 OHG040177 The rear curtain will fold automatically Side curtain (if equipped) when you shift the shift lever into R To use the side curtain: (Reverse) and unfold automatically when 1.

  • Page 201: Audio System

    Features of your vehicle AUDIO SYSTEM ✽ NOTICE CAUTION • If you install an aftermarket HID • Do not clean the inside of the rear head lamp, your vehicle’s audio and window glass with a cleaner or electronic device may malfunction. use a scraper to remove foreign •...

  • Page 202: Steering Wheel Audio Control

    Features of your vehicle VOLUME (VOL +/-) (1) RADIO mode • Push up the lever to increase volume. It will function as the PRESET STATION select buttons. • Push down the lever to decrease vol- ume. CDP mode SEEK/PRESET ( ) (2) It will function as the TRACK UP/DOWN button.
  • Page 203 Features of your vehicle FM radio reception AM radio reception OHG040180L JBM001 JBM002 Aux, USB and iPod ® port How vehicle audio works AM broadcasts can be received at greater distances than FM broadcasts. (if equipped) AM and FM radio signals are broadcast This is because AM radio waves are from transmitter towers located around If your vehicle has an aux and/or USB...
  • Page 204 Features of your vehicle FM radio station JBM003 JBM004 JBM005 FM broadcasts are transmitted at high • Fading - As your vehicle moves away • Station Swapping - As a FM signal frequencies and do not bend to follow the from the radio station, the signal will weakens, another more powerful sig- earth's surface.
  • Page 205 Features of your vehicle Using a cellular phone or a two-way Care of discs • Keep CDs in their cases after use to radio protect them from scratches or dirt. • If the temperature inside the vehicle is When a cellular phone is used inside the •...
  • Page 206 Features of your vehicle ■ ■ CD Player : AC110HG/AC100HG CD Changer : AC610HG/AC600HG AC210HG/AC200HG ❋ There will be no logo if the Bluetooth ® Wireless Technology feature is not supported. AC110HG_CDP_BT / AC610HG_CDC_BT...
  • Page 207 Features of your vehicle SEEK Button VOLUME Knob SEEK • When the button is pressed, If the knob is turned clockwise/counter- TRACK clockwise, the volume will increase it increases the band frequency to /decrease. automatically select channel. Stops at the previous frequency if no channel is SETUP Button found.
  • Page 208 Features of your vehicle Features of your vehicle ■ AC210/200HG • SDVC (Speed Dependent Volume • V-EQ Control) Press the button to FILE TUNE This function automatically adjusts the select the Variable EQ the following volume level according to the speed of order : Innocente (Normal), Forza the vehicle and can be turned On/Off (Dynamic), Concerto (Concert) select...
  • Page 209 Features of your vehicle BALANCE Control • CLOCK Press the right button to emphasize right Select this item to enter Clock setup speaker sound(left speaker sound will be mode. Adjust the hour using FOLDER attenuated). When the left button is FOLDER pressed, left speaker sound will be button and press the...
  • Page 210 Features of your vehicle DISP Button Turn ON/OFF the displayed data and light on LCD. When LCD Display is turned OFF, Press any button to turn ON display. AC110HG_CDP_BT 8. PRESET Buttons Push buttons less than 0.8 seconds to play the channel saved in each button.
  • Page 211 Features of your vehicle SEEK • Press button for less than TRACK 0.8 seconds to play the next song. SEEK • Press button for 0.8 seconds TRACK or longer to initiate forward direction AC110HG_CDP_BT AC610HG_CDC_BT high speed sound search of current Button (REPEAT) song.
  • Page 212 Features of your vehicle 10. CD Slot DISC Button FOLDER Button Please face printed side upward and (CD changer : AC610/600HG) FOLDER • Press button to move to child gently push in. When the ignition switch • Preset Change button changes folder of the current folder and display DISC is on ACC or ON and power is off, power...
  • Page 213 Features of your vehicle SEEK • Press button for 0.8 seconds TRACK or longer to initiate reverse direction high speed sound search of current song. AC110HG_CDP_BT AC110HG_CDP_BT SEEK • Press button for less than TRACK Button (REPEAT) 0.8 seconds to play the next song. Press this button for less than 0.8 sec- SEEK •...
  • Page 214 Features of your vehicle AC110HG_CDP_BT FOLDER Button FOLDER • Press button to move to child folder of the current folder and display the first song in the folder. Press button to move to the folder displayed. It will play the first song in the folder.
  • Page 215 Features of your vehicle (Continued) (Continued) CAUTION IN USING • An encrypted MP3 PLAYER is not • If you disconnect the external USB USB DEVICE recognizable. device during playback in USB • To use an external USB device, mode, the external USB device can •...
  • Page 216 Features of your vehicle (Continued) (Continued) • If the USB device is divided by • A SD-to-USB adapter may not logical drives, only the music files work with the car audio system. on the highest-priority drive are • Please avoid using USB memory recognized by car audio.
  • Page 217 Features of your vehicle SEEK Button (RANDOM) • Press button for 0.8 seconds TRACK or longer to initiate reverse direction • Press this button for less than 0.8 sec- high speed sound search of current onds to shuffle order of all songs in song.
  • Page 218 ® DEVICE • Some iPod ® models might not support ed, the system can be switched to • The Hyundai iPod ® Power Cable is the communication protocol and the AUX mode even without iPod ® needed in order to operate iPod ®...
  • Page 219 Features of your vehicle ■ What is Bluetooth ■ BLUETOOTH ® WIRELESS ® Wireless Phone Setup TECHNOLOGY PHONE OPERA- Technology? All Bluetooth ® Wireless Technology-relat- TION (IF EQUIPPED) ed operations can be performed in Bluetooth ® Wireless Technology is a wire- PHONE menu.
  • Page 220 1. Press button to enter SETUP SETUP model. Before attempting to pair vehicles HYUNDAI mode. phone, please see your phone’s AZERA/GRANDEUR, some phones 2. Select “Phone”, then “Select” in User’s Guide for instructions.
  • Page 221 Features of your vehicle ■ ■ Receiving a Phone Call Talking on the Phone • Changing Priority If several phones are paired with the When receiving a phone call, a ringtone When talking on the phone, “Active Calls” audio system, the system attempts to is audible from speakers and the audio message and the other party’s phone connect following order when the...
  • Page 222 Features of your vehicle ✽ NOTICE ■ Bluetooth ® Wireless Technology NOTE: Audio Music Streaming In the following situations, you or the • Not only MP3 files, all the sounds other party may have difficulty hearing that the phone supports can be This audio system supports A2DP (Audio each other: heard by the audio system.
  • Page 223 Features of your vehicle (Continued) CAUTION IN USING • If the cellular phone signal is poor BLUETOOTH ® WIRELESS or the vehicles interior noise is TECHNOLOGY CELLU- too loud, it may be difficult to hear LAR PHONE the other person’s voice during a •...
  • Page 224 Before driving / 5-3 Key / 5-4 Engine Start/Stop button / 5-7 Automatic transaxle / 5-12 Brake system / 5-18 Cruise control system / 5-36 Smart cruise control system / 5-40 Economical operation / 5-53 Special driving conditions / 5-55 Winter driving / 5-59 Vehicle weight / 5-63 Driving your vehicle...
  • Page 225 HYUNDAI dealer. • Do not run the engine in an enclosed area.
  • Page 226 Driving your vehicle BEFORE DRIVING Before entering vehicle Necessary inspections Before starting • Be sure that all windows, outside mir- Fluid levels, such as engine oil, engine • Close and lock all doors. ror(s), and outside lights are clean. coolant, brake fluid, and washer fluid •...
  • Page 227 Driving your vehicle WARNING WARNING - Driving under the influence of alcohol or • When you intend to park or stop drugs the vehicle with the engine on, be careful not to depress the accel- Drinking and driving is dangerous. erator pedal for a long period of Drunk driving is the number one time.
  • Page 228 Driving your vehicle ACC (Accessory) WARNING - Ignition The steering wheel is unlocked and elec- trical accessories are operative. switch • Never turn the ignition switch to ✽ NOTICE LOCK or ACC while the vehicle is moving. This would result in loss If difficulty is experienced turning the of directional control and braking ignition switch to the ACC position, turn...
  • Page 229 Driving your vehicle Starting the engine 1. Make sure the parking brake is CAUTION applied. If the engine stalls while you are in 2. Place the transaxle shift lever in P WARNING (Park). Depress the brake pedal fully. motion, do not attempt to move the •...
  • Page 230 Try locking the steering wheel again. If the problem is not solved, have it checked by an author- ized HYUNDAI dealer. In addition, if the ENGINE START/STOP button is in the OFF position after the dri-...
  • Page 231 Driving your vehicle ACC(Accessory) CAUTION You are able to turn off the engine (START/RUN) or vehicle power (ON), only when the vehicle is not in motion. In an emergency situation Orange Blue while the vehicle is in motion, you are able to turn the engine off and Press the ENGINE START/STOP button Press the ENGINE START/STOP button to the ACC position by pressing the...
  • Page 232 Driving your vehicle ✽ NOTICE START/RUN (Continued) If you leave the ENGINE START/ STOP • Never reach for the ENGINE button in the ACC or ON position for a START/STOP button or any other long time, the battery will discharge. controls through the steering wheel while the vehicle is in Not illuminated...
  • Page 233 Driving your vehicle ✽ NOTICE - Starting the engine 1. Carry the smart key or leave it inside Kick down mecha- the vehicle. nism (if equipped) 2. Make sure the parking brake is firmly WARNING If your vehicle is equipped with a kick applied.
  • Page 234 Driving your vehicle • Even if the smart key is in the vehicle, CAUTION if it is far away from you, the engine may not start. Do not press the ENGINE START/ STOP button for more than 5 sec- • When the ENGINE START/STOP but- onds except when the stop lamp ton is in the ACC position or above, if fuse is disconnected.

  • Page 235: Automatic Transaxle

    Driving your vehicle AUTOMATIC TRANSAXLE Automatic transaxle operation The automatic transaxle has 6 forward speeds and one reverse speed. The indi- vidual speeds are selected automatically, depending on the position of the shift lever. Lock release button ✽ NOTICE The first few shifts on a new vehicle, if the battery has been disconnected, may be somewhat abrupt.
  • Page 236 Driving your vehicle For smooth operation, depress the brake Transaxle ranges CAUTION pedal when shifting from N (Neutral) to a The indicator in the instrument cluster forward or reverse gear. • To avoid damage your displays the shift lever position when the transaxle, do not accelerate the ignition switch is in the ON position.
  • Page 237 Driving your vehicle R (Reverse) D (Drive) Use this position to drive the vehicle This is the normal forward driving posi- backward. tion. The transaxle will automatically shift through a 6-gear sequence, providing the best fuel economy and power. CAUTION Always come to a complete stop For extra power when passing another before shifting into or out of R...
  • Page 238 4. Have your vehicle inspected by an which is better for smooth driving on authorized HYUNDAI dealer immedi- a slippery road. Push the shift lever to ately. the -(down) side to shift back to the 1st gear.
  • Page 239 Driving your vehicle Ignition key interlock system Good driving practices • Exercise extreme caution when driving (if equipped) on a slippery surface. Be especially • Never move the shift lever from P careful when braking, accelerating or The ignition key cannot be removed (Park) or N (Neutral) to any other posi- shifting gears.
  • Page 240 Driving your vehicle Moving up a steep grade from a stand- WARNING WARNING ing start To move up a steep grade from a stand- • Always buckle-up! In a collision, If your vehicle becomes stuck in ing start, depress the brake pedal, shift an unbelted occupant is signifi- snow, mud, sand, etc., then you the shift lever to D (Drive).
  • Page 241 Driving your vehicle BRAKE SYSTEM Power brakes (Continued) WARNING Brakes Your vehicle has power-assisted brakes • Always, confirm the position of that adjust automatically through normal • Do not drive with your foot rest- the brake and accelerator pedal usage. ing on the brake pedal.
  • Page 242 Driving your vehicle In the event of brake failure Disc brakes wear indicator If service brakes fail to operate while the Your vehicle has disc brakes. vehicle is in motion, you can make an When your brake pads are worn and new emergency stop with the parking brake.
  • Page 243 CAUTION does not release all the way, have the system checked by an authorized • Driving with the parking brake HYUNDAI dealer. applied will cause excessive brake pad and brake rotor wear. • Do not operate the parking brake WARNING while the vehicle is moving except •...
  • Page 244 Driving your vehicle CAUTION Do not operate the parking brake while the vehicle is moving except in an emergency situation. It could damage the vehicle system and endanger driving safety. W-75 OHG050015 Check the brake warning light by turning Electric parking brake (EPB) the ignition switch ON (do not start the (if equipped) engine).
  • Page 245 4. Shift lever in R (Rear), D (Drive) or • Have the ignition switch or ENGINE HYUNDAI dealer. Sports mode START/STOP button in the ON posi- • Do not drive your vehicle with the Make sure the brake warning light goes tion.
  • Page 246 Driving your vehicle EPB (electric parking brake) may be ■ ■ Type A Type B WARNING automatically applied when: • The EPB is overheated • To prevent unintentional move- ment when stopped and leaving • Requested by other systems the vehicle, do not use the shift •...
  • Page 247 Driving your vehicle ■ ■ ■ ■ Type A Type B Type A Type B CAUTION • A click sound may be heard while operating or releasing the EPB, but these conditions are normal and indicate that the EPB is func- tioning properly.
  • Page 248 HYUNDAI dealer. If this occurs, have your vehicle checked up. If the EPB warning does not by an authorized HYUNDAI dealer as go off, have the system checked soon as possible. by an authorized HYUNDAI dealer.
  • Page 249 ■ Type A brake) is not released If the EPB does not release normally, take your vehicle to an authorized HYUNDAI dealer by loading the vehicle on a flatbed tow truck and have the sys- tem checked. ■ Type B OHG050023 ■...
  • Page 250 Driving your vehicle ✽ NOTICE 2. When you stop the vehicle completely ■ Type A by depressing the brake pedal, the • The Auto Hold does not operate AUTO HOLD indicator changes from when: white to green. - The driver's seat belt is unfastened 3.
  • Page 251 Take your vehicle to an authorized • With tire chains installed. brake pressure and do not try to pump HYUNDAI dealer and have the sys- (Continued) your brakes. Press your brake pedal as tem checked.
  • Page 252 ABS is malfunctioning. light stays on, you may have a • Do not pump your brakes! problem with your ABS. Contact • Have the battery recharged before an authorized HYUNDAI dealer as driving the vehicle. soon as possible. 5 29...
  • Page 253 Driving your vehicle ■ The Electronic Stability Program (ESP) The Electronic Stability Program (ESP) Type A system is designed to stabilize the vehicle system is an electronic system designed during cornering maneuvers. ESP checks to help the driver maintain vehicle control where you are steering and where the under adverse conditions.
  • Page 254 Driving your vehicle ESP operation ESP operation off When operating When the ESP is in operation, ESP ON condition ESP OFF state ESP indicator light blinks. • When the ignition is turned • To cancel ESP operation, ON, ESP and ESP OFF indi- •...
  • Page 255 Driving your vehicle ESP OFF usage ■ ESP indicator light CAUTION When driving Driving with varying tire or wheel • ESP should be turned on for daily driv- sizes may cause the ESP system to ing whenever possible. malfunction. When replacing tires, •...
  • Page 256 ) or EPS warning effect of brake control and indicates noth- light remains on, take your vehicle to an ing unusual. authorized HYUNDAI dealer and have the system checked. The VSM does not operate when: • Driving on bank road such as gradient ✽...
  • Page 257 Driving your vehicle Hill-start assist control (HAC) Good braking practices WARNING (if equipped) • The Vehicle Stability Management WARNING A vehicle has the tendency to slip back system is not a substitute for on a steep hill when it starts to go after •...
  • Page 258 HYUNDAI dealer for car from rolling. If your car is facing assistance.
  • Page 259 Driving your vehicle CRUISE CONTROL SYSTEM (IF EQUIPPED) ✽ NOTICE ■ Type A WARNING • During normal cruise control opera- • If the cruise control is left on, tion, when the SET switch is activated (cruise indicator light in the or reactivated after applying the instrument cluster illuminated) brakes, the cruise control will ener-...
  • Page 260 Driving your vehicle OHG050033 OHG050035 OHG050034 To set cruise control speed: 3. Push the SET- switch, and release it at To increase cruise control set the desired speed. The SET indicator speed: 1. Push the cruise ON-OFF button on the light in the instrument cluster will illumi- steering wheel to turn the system on.
  • Page 261 Driving your vehicle To temporarily accelerate with the cruise control on: If you want to speed up temporarily when the cruise control is on, depress the accelerator pedal. Increased speed will not interfere with cruise control operation or change the set speed. To return to the set speed, take your foot off the accelerator.
  • Page 262 Driving your vehicle Each of these actions will cancel cruise control operation (the SET indicator light in the instrument cluster will go off), but it will not turn the system off. If you wish to resume cruise control operation, push the RES+ switch located on your steering wheel.
  • Page 263 Driving your vehicle SMART CRUISE CONTROL SYSTEM (IF EQUIPPED) ■ The smart cruise control system allows Type A you to program the vehicle to maintain WARNING constant speed and distance detecting • If the smart cruise control is left the vehicle ahead without depressing the on, (cruise indicator light in the accelerator pedal.
  • Page 264 Driving your vehicle OHG052053K OHG052054K OHG052055K Smart cruise control speed 3. Push the SET- switch, and release it at To increase cruise control set speed: the desired speed. The SET indicator Follow either of these procedures: To set cruise control speed: light, set speed and vehicle to vehicle •...
  • Page 265 Driving your vehicle To temporarily accelerate with the cruise control on: If you want to speed up temporarily when the cruise control is on, depress the accelerator pedal. Increased speed will not interfere with cruise control operation or change the set speed. To return to the set speed, take your foot off the accelerator.
  • Page 266 HYUNDAI dealer. pedal. Always check the road conditions. Do not rely on the warning chime.
  • Page 267 Driving your vehicle ■ Type A OHG050057 ■ Type B OHG052055K OHG052053K To resume cruise control set To turn cruise control off: speed: Push the cruise ON/OFF button (the CRUISE indicator light in the instrument If any method other than the cruise cluster will go off).
  • Page 268 Driving your vehicle The vehicle to vehicle distance will auto- ■ ■ Without brake applied With brake applied matically activate when the smart cruise control system is on. Select the appropriate distance accord- ing to road conditions and vehicle speed. Each time the button is pressed, the vehi- cle to vehicle distance changes as fol- lows:...
  • Page 269 Driving your vehicle CAUTION • The warning chime sounds and malfunction indicator blinks if it is hard to maintain the selected distance to the vehicle ahead. • If the warning chime sounds, actively adjust the vehicle speed, as well as the distance to the vehicle ahead by depressing the accelerator or brake pedal.
  • Page 270 If this occurs, have your vehicle vehicle ahead. checked authorized If the sensor is covered with dirt or other HYUNDAI dealer as soon as pos- foreign matter, the vehicle to vehicle dis- sible. tance control may not operate correctly. • Use only a genuine HYUNDAI Always keep the area in front of the sen- sensor cover for your vehicle.
  • Page 271 Driving your vehicle To convert to cruise control mode: The driver may choose to only use the cruise control mode (speed control func- tion) by doing as follows: 1. Turn the smart cruise control system on (the cruise indicator light will be on but the system will not be activated).
  • Page 272 Driving your vehicle OBH058053 OBH058045 OHG050074 On inclines Lane changing • Your vehicle may accelerate when a vehicle ahead of you disappears. • During uphill or downhill driving, the • A vehicle which moves into your lane smart cruise control system may not from an adjacent lane cannot be rec- •...
  • Page 273 Driving your vehicle A vehicle ahead cannot be recognized correctly by the sensor if any of following occurs: - When the vehicle is pointing upwards due to overloading in the trunk - While making turns by steering - When driving to one side of the lane - When driving on narrow lanes or on curves Apply the brakes or accelerator pedal if...
  • Page 274 Driving your vehicle WARNING • The smart cruise control system cannot guarantee the stop for every emergency situation. If an emergency stop is neces- sary, you must apply the brakes. • Keep a safe distance according to road conditions and vehicle speed.
  • Page 275 Driving your vehicle (Continued) CAUTION • The smart cruise control system The smart cruise control system is not a substitute for safe driving may not operate temporarily due to practices but a convenience electrical interference. function only. It is the responsi- bility of the driver to always check the speed and the distance to the vehicle ahead.
  • Page 276 Driving your vehicle ECONOMICAL OPERATION Your vehicle's fuel economy depends • Do not "ride" the brake pedal. This can • Keep your car in good condition. For mainly on your style of driving, where you increase fuel consumption and also better fuel economy and reduced drive and when you drive.
  • Page 277 Therefore, have an authorized speeds. loss of vehicle steering which HYUNDAI dealer perform scheduled could cause serious injury or inspections and maintenance. death.
  • Page 278 Driving your vehicle SPECIAL DRIVING CONDITIONS Rocking the vehicle WARNING - If it is necessary to rock the vehicle to Do not pump the brake pedal on a free it from snow, sand, or mud, first turn vehicle equipped with ABS. the steering wheel right and left to clear the area around your front wheels.
  • Page 279 Driving your vehicle WARNING - Spinning tires Do not spin the wheels, especially at speeds more than 56 km/h (35 mph). Spinning the wheels at high speeds when the vehicle is station- ary could cause a tire to overheat which could result in tire damage that may injure bystanders.
  • Page 280 Driving your vehicle • Adjust your mirrors to reduce the glare Driving in the rain Driving in flooded areas from other driver's headlights. Rain and wet roads can make driving Avoid driving through flooded areas • Keep your headlights clean and prop- dangerous, especially if you’re not pre- unless you are sure the water is no high- erly aimed on vehicles not equipped...
  • Page 281 Driving your vehicle Fuel, engine coolant and engine oil WARNING High speed travel consumes more fuel than urban motoring. Do not forget to • Underinflated overinflated check both engine coolant and engine tires can cause poor handling, oil. loss of vehicle control, and sud- den tire failure leading to acci- dents, injuries, and even death.
  • Page 282 Driving your vehicle WINTER DRIVING Snow tires Snowy or icy conditions If you mount snow tires on your vehicle, To drive your vehicle in deep snow, it may make sure they are radial tires of the be necessary to use snow tires or to same size and load range as the original install tire chains on your tires.
  • Page 283 Driving your vehicle Chain installation CAUTION When installing chains, follow the manu- • Make sure the snow chains are facturer's instructions and mount them as the correct size and type for your tightly as you can. Drive slowly with tires. Incorrect snow chains can chains installed.
  • Page 284 7. The level of charge in your battery can pension, body and wheels. be checked by an authorized HYUNDAI • Stop driving and retighten the dealer or a service station. chains any time you hear them hitting the vehicle.
  • Page 285 Window washer anti-freeze is Under some conditions, snow and ice failure or combustion. The manufacturer available from an authorized HYUNDAI can build up under the fenders and inter- is not responsible for the damage caused dealer and most auto parts outlets. Do fere with the steering.
  • Page 286 Driving your vehicle VEHICLE WEIGHT This section will guide you in the proper Cargo weight GVWR (Gross vehicle weight rat- loading of your vehicle, to keep your ing) This figure includes all weight added to loaded vehicle weight within its design the Base Curb Weight, including cargo This is the maximum allowable weight of rating capability.
  • Page 287 Driving your vehicle TRAILER TOWING We do not recommend using this vehicle for trailer towing.
  • Page 288 Road warning / 6-2 In case of an emergency while driving / 6-3 If the engine will not start / 6-4 Emergency starting / 6-5 If the engine overheats / 6-7 If you have a flat tire / 6-8 Tire pressure monitoring system (TPMS) / 6-16 Towing / 6-21 Emergency commodity / 6-25 What to do in an emergency...
  • Page 289 What to do in an emergency ROAD WARNING It should be used whenever emergency repairs are being made or when the vehi- cle is stopped near the edge of a road- way. Press the flasher switch with the ignition switch in any position. The flasher switch is located in the center console switch panel.
  • Page 290 When the car has slowed to such authorized HYUNDAI dealer or seek a speed that it is safe to do so, brake other qualified assistance.
  • Page 291 3. Turn on the interior light. If the light 3. If the engine still does not start, call an dims or goes out when you operate the authorized HYUNDAI dealer or seek starter, the battery is discharged. other qualified assistance.
  • Page 292 What to do in an emergency EMERGENCY STARTING Jump starting ■ Engine compartment WARNING - Battery Jump starting can be dangerous if done • Keep all flames or sparks away incorrectly. Therefore, to avoid harm to from the battery. The battery pro- yourself or damage to your vehicle or duces hydrogen gas which may battery, follow the jump starting proce-...
  • Page 293 If the cause of your battery discharging is on the booster battery (2). not apparent, you should have your vehi- cle checked by an authorized HYUNDAI Proceed to connect one end of the dealer. other jumper cable to the negative ter-...
  • Page 294 2. Place the shift lever in P (Park) and set heating happens again, call an author- the parking brake. If the air condition- ized HYUNDAI dealer for assistance. ing is on, turn it off. WARNING 3. If engine coolant is running out under...
  • Page 295 What to do in an emergency IF YOU HAVE A FLAT TIRE Jacking instructions (Continued) The jack is provided for emergency • Be sure to use the correct tire changing only. front and rear jacking posi- To prevent the jack from “rattling” tions on the vehicle;...
  • Page 296 What to do in an emergency OTF060005L OBH068002L 1JBA6504 Removing and storing the spare Changing tires 4. Remove the wheel lug nut wrench, tire jack, jack handle, and spare tire 1. Park on a level surface and apply from the vehicle. Turn the tire hold-down wing bolt the parking brake firmly.
  • Page 297 What to do in an emergency WARNING - Changing a tire • To prevent vehicle movement while changing a tire, always set the parking brake fully, and always block the wheel diagonally opposite the wheel being changed. • We recommend that wheels of the vehicle be blocked, and that no person...
  • Page 298 What to do in an emergency 9. Loosen the wheel nuts and WARNING - Jack location remove them with your fingers. Slide the wheel off the studs and To reduce the possibility of lay it flat so it cannot roll away. To injury, be sure to use only the put the wheel on the hub, pick up jack provided with the vehicle...
  • Page 299 This may cause serious injury sequence shown in the image until or death. they are all tight. Then double-check each nut for tightness. After changing wheels, have authorized HYUNDAI dealer tighten the wheel nuts to their proper torque as soon as possible.
  • Page 300 Refer to “Tires and wheels” sec- If in doubt, consult an author- proper storage locations. tion 8. ized HYUNDAI dealer. 6 13...
  • Page 301 What to do in an emergency Jack label 1. Model Name 2. Maximum allowable load ■ Example • Type A 3. When using the jack, set your parking brake. 4. When using the jack, stop the engine. 5. Do not get under a vehicle that is supported by a jack.
  • Page 302 What to do in an emergency EC Declaration of Conformity for Jack JACKDOC14S 6 15...
  • Page 303 What to do in an emergency TIRE PRESSURE MONITORING SYSTEM (TPMS) (IF EQUIPPED) Each tire, including the spare (if pro- Please note that the TPMS is not a vided), should be checked monthly substitute for proper tire mainte- when cold and inflated to the inflation nance, and it is the driver’s responsi- pressure recommended by the vehi- bility to maintain correct tire pres-...
  • Page 304 Take your vehicle to the nearest If either telltale illuminates, immedi- mended tire inflation pressure authorized HYUNDAI dealer and ately reduce your speed, avoid hard in warm weather. It does not have the system checked if any of...
  • Page 305 TPMS malfunction indicator. mobile charger, remote starter Have the system checked by an or navigation etc., are used in authorized HYUNDAI dealer as soon the vehicle. This can interfere as possible to determine the cause with normal operation of the of the problem.
  • Page 306 1.6 km (1 mile) during that and installed on the vehicle is initiat- NEVER use a puncture-repair- 3 hour period). ed by an authorized HYUNDAI deal- ing agent to repair and/or inflate er, the TPMS malfunction indicator Allow the tire to cool before measur- a low pressure tire.
  • Page 307 Pressure Monitoring System a safe position off the road. market, use a TPMS sensor (TPMS) components may void approved by a HYUNDAI deal- the warranty for that portion of er. If your vehicle is not the vehicle. equipped with a TPMS sensor...
  • Page 308 ✽ NOTICE If the EPB does not release normally, take your vehicle to an authorized HXD03 HYUNDAI dealer by loading the vehicle OMC045012 on a flatbed tow truck and have the sys- Towing service tem checked.
  • Page 309 OHG060010 secured. Emergency towing 4. Remove the towing hook and install If towing is necessary, we recommend the cover after use. you to have it done by an authorized HYUNDAI dealer or a commercial tow truck service.
  • Page 310 Contact an • Before emergency towing, check that from which the vehicle cannot be driven authorized HYUNDAI dealer or a the hook is not broken or damaged. out under its own power. commercial tow truck service for •...
  • Page 311 What to do in an emergency • More steering effort will be required Tie-down hook because the power steering system will be disabled. WARNING • If you are driving down a long hill, the Do not use the hooks under the brakes may overheat and brake per- vehicle for towing purposes.
  • Page 312 What to do in an emergency EMERGENCY COMMODITY (IF EQUIPPED) There are some emergency commodities First aid kit To check the tire pressure, take the fol- in the vehicle to help you respond to the lowing steps; There are some items such as scissors, emergency situation.
  • Page 313 Engine compartment / 7-2 Maintenance services / 7-3 Owner maintenance / 7-4 Scheduled maintenance service / 7-6 Explanation of scheduled maintenance items / 7-24 Engine oil / 7-27 Engine coolant / 7-28 Brake fluid / 7-31 Power steering fluid / 7-32 Washer fluid / 7-33 Parking brake / 7-33 Air cleaner / 7-34...

  • Page 314: Fuse Box

    Maintenance ENGINE COMPARTMENT ■ 2.4L 1. Engine oil dipstick 2. Engine oil filler cap 3. Engine coolant reservoir 4. Radiator cap 5. Brake fluid reservoir 6. Power steering fluid reservoir 7. Windshield washer fluid reservoir 8. Air cleaner ■ 3.0L 9.
  • Page 315 An authorized HYUNDAI dealer has fac- ✽ NOTICE shown on the following pages. You need tory-trained technicians and genuine this information to establish your compli-...
  • Page 316 The following lists are vehicle checks and CAUTION WARNING inspections that should be performed by - Maintenance the owner or an authorized HYUNDAI work • Do not put heavy objects or apply dealer at the frequencies indicated to excessive force on top of the •...

  • Page 317: Engine Coolant Reservoir

    Clean wiper blades tion, take your vehicle to an authorized to-push” brake pedal. with clean cloth dampened with wash- HYUNDAI dealer. • If any slipping or changes in the oper- er fluid. ation of your transaxle occurs, check •...
  • Page 318 Maintenance SCHEDULED MAINTENANCE SERVICE At least once a year: If your vehicle is operated under the Follow Normal Maintenance Schedule if the vehicle is usually operated where above conditions, you should inspect, • Clean body and door drain holes. none of the following conditions apply. If replace or refill more frequently than the •...
  • Page 319 : Driving in summer season temperature over 40 °C (104 °F : Inspect for excessive valve noise and/or engine vibration - SAUDI, UAE, OMAN, KUWAIT, BAHRAIN, QATAR, IRAN, and adjust if necessary. An authorized HYUNDAI dealer YEMEN ETC) or driving over 170 km/h (106 mile/h) must should perform the operation.
  • Page 320 Maintenance NORMAL MAINTENANCE SCHEDULE - EXCEPT EUROPE (CONT.) 15,000 km (10,000 miles) or 12months 30,000 km (20,000 miles) or 24months ❑ Inspect air cleaner filter - Except Middle East ❑ Inspect air cleaner filter - Except Middle East ❑ Inspect air conditioner refrigerant/compressor (if equipped) ❑...
  • Page 321 Maintenance NORMAL MAINTENANCE SCHEDULE - EXCEPT EUROPE (CONT.) (Continued) 45,000 km (30,000 miles) or 36months ❑ Inspect air conditioner refrigerant/compressor (if equipped) ❑ Replace engine oil and filter - For Middle East * ❑ Inspect battery condition (Every 10,000 km (6,500 miles) or 12months) ❑...
  • Page 322 Maintenance NORMAL MAINTENANCE SCHEDULE - EXCEPT EUROPE (CONT.) 60,000 km (40,000 miles) or 48months (Continued) ❑ Replace engine oil and filter - Except Middle East * ❑ Inspect air cleaner filter - Except Middle East ❑ Replace engine oil and filter - For Middle East * ❑...
  • Page 323 Maintenance NORMAL MAINTENANCE SCHEDULE - EXCEPT EUROPE (CONT.) 75,000 km (50,000 miles) or 60months 90,000 km (60,000 miles) or 72months ❑ Inspect air conditioner refrigerant/compressor (if equipped) ❑ Inspect air cleaner filter - Except Middle East ❑ Inspect battery condition ❑...
  • Page 324 Maintenance NORMAL MAINTENANCE SCHEDULE - EXCEPT EUROPE (CONT.) 105,000 km (70,000 miles) or 84months (Continued) ❑ Replace engine oil and filter ❑ Inspect air cleaner filter - Except Middle East ❑ Inspect air conditioner refrigerant/compressor (if equipped) - Except Middle East * ❑...
  • Page 325 Maintenance NORMAL MAINTENANCE SCHEDULE - EXCEPT EUROPE (CONT.) 120,000 km (80,000 miles) or 96months (Continued) ❑ Replace air cleaner filter - For Middle East ❑ Inspect air cleaner filter - Except Middle East ❑ Replace climate control air filter (if equipped) ❑...
  • Page 326 Maintenance MAINTENANCE UNDER SEVERE USAGE CONDITIONS (EXCEPT EUROPE) The following items must be serviced more frequently on cars mainly used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and if necessary, adjust, correct, clean or replace Maintenance Maintenance item Maintenance intervals...
  • Page 327 Maintenance Maintenance Maintenance item Maintenance intervals Driving condition operation Inspect more frequently Front suspension ball joints C, D, E, F, G depending on the condition Inspect more frequently Disc brakes and pads, calipers and rotors C, D, E, G, H depending on the condition Inspect more frequently Parking brake...
  • Page 328 Additives are schedule depends on fuel quality. If there are some impor- available from your authorized HYUNDAI dealer along with tant matters like fuel flow restriction, surging, loss of power, information on how to use them. Do not mix other additives...
  • Page 329 Maintenance NORMAL MAINTENANCE SCHEDULE - FOR EUROPE (CONT.) 15,000 km (10,000 miles) or 12months 30,000 km (20,000 miles) or 24months ❑ Add fuel additives * ❑ Add fuel additives * ❑ Inspect air cleaner filter ❑ Inspect air cleaner filter ❑...
  • Page 330 Maintenance NORMAL MAINTENANCE SCHEDULE - FOR EUROPE (CONT.) 45,000 km (30,000 miles) or 36months 60,000 km (40,000 miles) or 48months ❑ Add fuel additives * ❑ Add fuel additives * ❑ Inspect air conditioner refrigerant/compressor (if equipped) ❑ Inspect air cleaner filter ❑...
  • Page 331 Maintenance NORMAL MAINTENANCE SCHEDULE - FOR EUROPE (CONT.) 75,000 km (50,000 miles) or 60months (Continued) ❑ Add fuel additives * ❑ Replace climate control air filter (if equipped) ❑ Inspect air cleaner filter ❑ Replace engine oil and filter * ❑...
  • Page 332 Maintenance NORMAL MAINTENANCE SCHEDULE - FOR EUROPE (CONT.) 90,000 km (60,000 miles) or 72months 105,000 km (70,000 miles) or 84months ❑ Add fuel additives * ❑ Add fuel additives * ❑ Inspect air cleaner filter ❑ Inspect air conditioner refrigerant/compressor (if equipped) ❑...
  • Page 333 Maintenance NORMAL MAINTENANCE SCHEDULE - FOR EUROPE (CONT.) 120,000 km (80,000 miles) or 96months (Continued) ❑ Inspect steering gear rack, linkage and boots ❑ Add fuel additives * ❑ Inspect tire (pressure & tread wear) ❑ Inspect air cleaner filter ❑...
  • Page 334 Maintenance MAINTENANCE UNDER SEVERE USAGE CONDITIONS (FOR EUROPE) The following items must be serviced more frequently on cars mainly used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and if necessary, adjust, correct, clean or replace Maintenance Maintenance item Maintenance intervals...
  • Page 335 Maintenance Maintenance Maintenance item Maintenance intervals Driving condition operation Inspect more frequently Front suspension ball joints C, D, E, F, G depending on the condition Inspect more frequently Disc brakes and pads, calipers and rotors C, D, E, G, H depending on the condition Inspect more frequently Parking brake...
  • Page 336 Inspect the surface of hoses for evidence at the connections. Fuel filters should be ration and replace if necessary. Drive of heat and/or mechanical damage. Hard installed by an authorized HYUNDAI belts should be checked periodically for and brittle rubber, cracking, tears, cuts, dealer.
  • Page 337 Maintenance ✽ NOTICE Air cleaner filter Cooling system Automatic transaxle fluid color is basi- A Genuine HYUNDAI air cleaner filter is Check cooling system components, such recommended when filter as radiator, coolant reservoir, hoses and cally red. As the vehicle is driven, the automatic replaced.
  • Page 338 Brake fluid excessive wear, oiliness and proper ten- Hyundai web site. Check brake fluid level in the brake fluid sion. Replace or adjust it if necessary. (http://brakemanual.hmc.co.kr) reservoir.
  • Page 339 Maintenance ENGINE OIL 5. Pull the dipstick out again and check the level. The level should be between F (Full) and L (Low). CAUTION • Do not overfill with engine oil. Engine damage may result. • Do not spill engine oil, when adding or changing engine oil.

  • Page 340: Radiator Cap

    Have engine oil and filter changed by an • Turn the engine off and wait until slowly in small quantities. authorized HYUNDAI dealer according to it cools down. Use extreme care the Maintenance Schedule at the begin- • Do not drive with no engine when removing the radiator cap.
  • Page 341 F (Full), but do not overfill. If fre- shut off. This is a normal condition. quent additions are required, see an If your vehicle is equipped with authorized HYUNDAI dealer for a cooling GDI, the electric motor (cooling fan) system inspection. may operate until you disconnect the negative battery cable.
  • Page 342 Maintenance For mixture percentage, refer to the fol- Changing the coolant lowing table. Have coolant changed by an authorized HYUNDAI dealer according to the Maintenance Schedule at the beginning Mixture Percentage (volume) Ambient of this section. Temperature Water Antifreeze CAUTION Put a thick cloth around the radiator -15°C (5°F)
  • Page 343 (Maximum) level. The level will fall with accumulated mileage. This is a normal condition associated with the wear of the brake linings. If the fluid level is exces- sively low, have the brake system checked by an authorized HYUNDAI dealer. 7 31...
  • Page 344 HYUNDAI dealer. • When adding fluid, be careful that dirt does not get into the tank. • Too little fluid can result in...
  • Page 345 However, use washer solvent windshield washer fluid. Serious brake adjusted authorized with antifreeze characteristics in cold cli- injury or death could occur. HYUNDAI dealer. mates to prevent freezing. Stroke : 5 notch 7 33...

  • Page 346: Air Cleaner

    Maintenance AIR CLEANER OHG070009 OHG070010 OVG079012 Filter replacement 1. Loosen the air cleaner cover attaching 2. Wipe the inside of the air cleaner. clips and open the cover. 3. Replace the air cleaner filter. It must be replaced when necessary, and 4.
  • Page 347 • When removing the air cleaner fil- ter, be careful that dust or dirt does not enter the air intake, or damage may result. • Use a HYUNDAI genuine part. Use of non-genuine parts could dam- age the air flow sensor. 7 35...
  • Page 348 Maintenance CLIMATE CONTROL AIR FILTER (IF EQUIPPED) Filter inspection If the vehicle is operated in the severely air-polluted cities or on dusty rough roads for a long period, it should be inspected more frequently and replaced earlier. When you, the owner, replace the climate control air filter, replace it per- forming the following procedure, and be careful to avoid damaging other compo-...
  • Page 349 Maintenance OHG070014 OHG070041 3. Remove the climate control air filter 4. Replace the climate control air filter. cover while pressing the lock on the 5. Reassemble in the reverse order of right side of the cover. disassembly. ✽ NOTICE When replacing the climate control air filter install it properly.
  • Page 350 Maintenance WIPER BLADES Contamination of either the windshield or Blade replacement the wiper blades with foreign matter can When the wipers no longer clean ade- reduce the effectiveness of the wind- quately, the blades may be worn or shield wipers. Common sources of con- cracked, and require replacement.
  • Page 351 Maintenance OHM078059 OHM078060 OHG070043 Front windshield wiper blade 2. Lift up the wiper blade clip. Then pull 3. Install the new blade assembly in the down the blade assembly and remove reverse order of removal. 1. Raise the wiper arm. CAUTION Do not allow the wiper arm to fall against the windshield, since it may...
  • Page 352 We recommend that you contact • Keep the battery top clean and dry. with clean water for at least an authorized HYUNDAI dealer. • Keep the terminals and connections 15 minutes and get immedi- clean, tight, and coated with petroleum ate medical attention.
  • Page 353 Battery capacity label Separating the battery from the Lift with a battery carrier or with vehicle should be done in an 1. CMF60L-BCI : The HYUNDAI model your hands on opposite corners. authorized HYUNDAI dealer. name of battery • Never attempt to recharge the 2.

  • Page 354: Positive Battery Terminal

    • Operation related to the battery should be done in an authorized • Watch the battery during charg- HYUNDAI dealer. ing, and stop or reduce the charg- ing rate if the battery cells begin gassing (boiling) violently or if the temperature of the electrolyte of any cell exceeds 49°C (120°F).
  • Page 355 If a tire frequently needs refilling, Recommended cold tire inflation have it checked by an author- pressures ized HYUNDAI dealer. All tire pressures (including the • Overinflation produces OHG050081L spare) should be checked when the...
  • Page 356 Maintenance Checking tire inflation pressure CAUTION CAUTION - Tire pressure Check your tires once a month or • Warm tires normally exceed Always observe the following: more. recommended cold tire pres- • Check tire pressure when the Also, check the tire pressure of the sures by 28 to 41 kPa (4 to 6 tires are cold.
  • Page 357 • Remember to check the pres- sure your spare tire. HYUNDAI recommends that you check the spare every time you check the pressure of the other tires on your vehi- cle. 7 45...
  • Page 358 Maintenance Disc brake pads should be inspected Wheel alignment and tire balance With a full-size spare tire (if equipped) for wear whenever tires are rotated. The wheels on your vehicle were aligned and balanced carefully at the ✽ NOTICE factory to give you the longest tire life and best overall performance.
  • Page 359 Align the tire bal- size, type, tread, brand and load- ance. If the problem is not carrying capacity. solved, we recommend that you contact an authorized HYUNDAI • The use of any other tire size or OEN076053 dealer. type may seriously affect ride,...
  • Page 360 Maintenance Wheel replacement Tire traction (Continued) When replacing the metal wheels for Tire traction can be reduced if you • The ABS works by comparing any reason, make sure the new drive on worn tires, tires that are the speed of the wheels. Tire wheels are equivalent to the original improperly inflated or on slippery size can affect wheel speed.
  • Page 361 Maintenance 2. Tire size designation Wheel size designation A tire’s sidewall is marked with a tire Wheels are also marked with impor- size designation. You will need this tant information that you need if you information when selecting replace- ever have to replace one. The follow- ing explains what the letters and ment tires for your car.
  • Page 362 Maintenance 3. Checking tire life (TIN : Tire Tire speed ratings Identification Number) WARNING - Tire age The chart below lists many of the dif- Any tires that are over 6 years old, ferent speed ratings currently being Tires degrade over time, even based on the manufacturing date, used for passenger car tires.
  • Page 363 Maintenance 5. Maximum permissible inflation Tread wear Traction - AA, A, B & C pressure The tread wear grade is a compara- The traction grades, from highest to This number is the greatest amount tive rating based on the wear rate of lowest, are AA, A, B and C.
  • Page 364 Because the low aspect ratio tires authorized HYUNDAI dealer. when tested under controlled condi- are optimized for handling and brak- - To prevent damage to the tire,...
  • Page 365 Avoid using other metal object to remove fuses the system involved and immediately because it may cause a short circuit consult an authorized HYUNDAI dealer. and damage the system. Normal Blown Three kinds of fuses are used: blade type for lower amperage rating, cartridge type, ✽...
  • Page 366 5. Push in a new fuse of the same rating, HYUNDAI dealer. and make sure it fits tightly in the clips. • Do not input any other objects If it fits loosely, consult an authorized except fuses or relays into HYUNDAI dealer.
  • Page 367 Always place the fuse switch in the 4. Push in a new fuse of the same rating, ON position while driving the vehi- and make sure it fits tightly in the clips. cle. If it fits loosely, consult an authorized HYUNDAI dealer. 7 55...
  • Page 368 5. Reinstall in the reverse order of 5. Replace the fuse with a new one of the removal. same rating. 6. Reinstall in the reverse order of removal. ✽ NOTICE If the multi fuse is blown, consult an authorized HYUNDAI dealer.
  • Page 369 Maintenance Fuse/relay panel description Inside the fuse/relay panel covers, you can find the fuse/relay label describing fuse/relay name and capacity. ✽ NOTICE Instrument panel fuse panel Engine compartment fuse panel Not all fuse panel descriptions in this manual may be applicable to your vehi- cle.
  • Page 370 Maintenance Instrument panel (Driver’s side fuse panel) Fuse rating Symbol Protected component 7.5A Immobilizer Module, Smart Key Control Module 7.5A Instrument Cluster SPARE 1 AMP, MAP Lamp, Front Monitor, E/R Fuse & Relay Box(RLY.13), A/V & Navigation Head Unit, AUDIO Smart Key Control Module, Audio ABS/ESP Control Module, Steering Angle Sensor, Rear Seat Warmer LH/RH, MODULE...
  • Page 371 Maintenance Fuse rating Symbol Protected component A/C Control Module, E/R Fuse & Relay (RLY.14), Cluster Ionizer, Driver/Passenger Seat Warmer 7.5A Module, Driver/Passenger CCS Control Module Steering Wheel Heater E/R Fuse & Relay Box (F11, F12, F13) Data Link Connector, A/C Control Module, Driver/Passenger Door Module, Instrument Cluster, Tire Pressure Monitoring Module, Auto Light &...
  • Page 372 Maintenance Fuse rating Symbol Protected component Power Seat Relay Box RH, Passenger Reclining Limit Switch Panorama Sunroof Trunk Lid Relay, Fuel Filler Door & Trunk Lid Switch Rear Seat Warmer LH/RH Driver Massage Module Driver Safety Window Module, Rear Power Window Switch LH Passenger Safety Window Module, Rear Power Window Switch RH Smart Key Control Module Key Solenoid, Sport Mode Switch, Steering Tilt &...
  • Page 373 Maintenance Engine compartment main fuse panel Fuse rating Symbol Protected component Smart Junction Box (Fuse - F20/F25/F28/F35, IPS 1, IPS 2, ARISU-LT 1) Smart Junction Box (Fuse - F26/F29/F32/F36) W/O Smart Key - Ignition Switch With Smart Key - RLY. 2 (PDM 1 (ACC) Relay), LY. 9 (PDM 2 (IG1) Relay) ESP Control Module, ABS Control Module MULTI FUSE...
  • Page 374 Maintenance Fuse rating Symbol Protected component Electronic Parking Brake Module RLY. 5 (S tart Relay), W/O Smart Key - Ignition Switch, With Smart Key - RLY. 10 (PDM 3 (IG2) Relay) Electronic Parking Brake Module EMS Box (Fuse - F36 / F37 / F38 / F39) ESP Control Module, ABS Control Module RLY.
  • Page 375 Maintenance Fuse rating Symbol Protected component ICM Relay Box (Head Lamp Washer Relay) Driver Lumbar Support Limit Switch(W/O Massage), Driver IMS Module, FUSE Power Seat Relay Box LH, Driver Reclining Limit Switch Smart Junction Box (Fuse - F37/F34, Leak Current Autocut Device (Leak Current Autocut Relay, Leak Current Autocut Switch, IPS 5)), E/R Fuse &...
  • Page 376 Maintenance Engine compartment main fuse panel (3.0L) Fuse rating Symbol Protected component Ignition Coil #1~#6, Condenser #1/#2 Camshaft Position Sensor #1~#4, E/R Fuse & Relay Box (RLY. 3 : C/FAN (HI) Relay) EMS Box (RLY. 1 : Fuel Pump Relay), Injector #1 ~ #6 Oxygen Sensor #1~#4, Purge Control Solenoid Valve, Variable Intake Solenoid Valve, Oil Control Valve #1~#4, PCM EMS Box (RLY.
  • Page 377 This is similar to the condensation on your windows inside your vehicle during the rain and doesn’t indicate a problem with your vehicle. If the water leaks into the lamp bulb circuitry, have the vehicle checked by an authorized HYUNDAI dealer. 7 65...
  • Page 378 (XENON bulb) due to electric shock danger. If the low beam (XENON bulb) is not working, have your vehicle checked OHD076046 by an authorized HYUNDAI Dealer WARNING - Halogen bulbs • Halogen bulbs contain pressur- ized gas that will produce flying pieces of glass if broken.
  • Page 379 ■ Low beam after the headlight assembly is rein- If a headlamp goes out after a period of stalled at an authorized HYUNDAI operation but will immediately relight dealer. when the headlamp switch is cycled it is likely the HID lamp needs to be replaced.
  • Page 380 If the light bulb does not operate, have change system, adhesive sheet, down the vehicle checked by an authorized aiming). This headlamps are designed HYUNDAI dealer. not to dazzle opposite drivers. So, you do not need to change your headlamps in a country with opposite traffic direction.
  • Page 381 Maintenance Stop and tail light If the light bulb does not operate, have the vehicle checked by an authorized HYUNDAI dealer. OHG070026 OHG070027 Side repeater light bulb replace- Rear combination light bulb ment replacement If the light bulb does not operate, have...
  • Page 382 Maintenance 4. Remove the socket from the assembly by turning the socket counterclockwise until the tabs on the socket align with the slots on the assembly. 5. Remove the bulb from the socket by pressing it in and rotating it counter- clockwise until the tabs on the bulb align with the slots in the socket.
  • Page 383 Maintenance Rear fog light (if equipped) If the light bulb does not operate, have the vehicle checked by an authorized HYUNDAI dealer. OHG070040 OHG070031 5. Remove the bulb by pulling it straight High mounted stop light out. replacement (if equipped) 6.
  • Page 384 Maintenance ■ Interior light bulb replacement Glove box lamp Glove box lamp, sunvisor lamp and luggage lamp 1. Using a flat-blade screwdriver, gently pry the lens from the interior light housing. 2. Remove the bulb by pulling it straight out. WARNING ■...
  • Page 385 Map lamp, room lamp and door cour- ■ ■ Map lamp Room lamp tesy lamp Type A If the light bulb does not operate, have the vehicle checked by an authorized HYUNDAI dealer. ■ Door courtesy lamp Type B OHG070037/OHG070038 OHG070035/OHG070036 7 73...
  • Page 386 Maintenance APPEARANCE CARE Finish maintenance Exterior care CAUTION Washing Exterior general caution • Do not use strong soap, chemical To help protect your vehicle’s finish from It is very important to follow the label detergents or hot water, and do rust and deterioration, wash it thoroughly directions when using any chemical not wash the vehicle in direct...
  • Page 387 Maintenance Finish damage repair Waxing Wax the vehicle when water will no Deep scratches or stone chips in the longer bead on the paint. painted surface must be repaired promptly. Exposed metal will quickly rust Always wash and dry the vehicle before and may develop into a major repair waxing.
  • Page 388 Maintenance Bright-metal maintenance Underbody maintenance WARNING • To remove road tar and insects, use a Corrosive materials used for ice and tar remover, not a scraper or other snow removal and dust control may col- After washing the vehicle, test the sharp object.
  • Page 389 Maintenance Aluminum or chrome wheel mainte- Corrosion protection High-corrosion areas nance If you live in an area where your car is Protecting your vehicle from corrosion The aluminum or chrome wheels are regularly exposed to corrosive materials, By using the most advanced design and corrosion protection is particularly impor- coated with a clear protective finish.
  • Page 390 Maintenance To help prevent corrosion • When cleaning lower door panels, Keep paint and trim in good condition rocker panels and frame members, be You can help prevent corrosion from get- Scratches or chips in the finish should be sure that drain holes are kept open so ting started by observing the following: covered with "touch-up"...
  • Page 391 Maintenance Cleaning the upholstery and interior Cleaning the lap/shoulder belt web- Interior care trim bing Interior general precautions Clean the belt webbing with any mild Vinyl Prevent chemicals such as perfume, cos- soap solution recommended for cleaning Remove dust and loose dirt from vinyl metic oil, sun cream, hand cleaner, and upholstery or carpet.
  • Page 392 In order to assure the proper function of vapors from escaping into the atmos- the emission control systems, it is rec- phere. ommended that you have your car inspected and maintained by an author- ized HYUNDAI dealer in accordance with the maintenance schedule in this manu-...
  • Page 393 Maintenance Canister Engine exhaust gas precautions (car- 3. Exhaust emission control bon monoxide) system Fuel vapors generated inside the fuel tank are absorbed and stored in the • Carbon monoxide can be present with The Exhaust Emission Control System is onboard canister.
  • Page 394 It may present a tem. All inspections and adjustments must be made by an authorized fire risk under certain conditions. HYUNDAI dealer. • Avoid driving with a extremly low fuel level. Running out of fuel could cause the engine to misfire, damaging the catalytic converter.
  • Page 395 Engine / 8-2 Dimensions / 8-2 Bulb wattage / 8-2 Tires and wheels / 8-3 Load and speed capacity tires / 8-3 Weight and volume / 8-4 Recommended lubricants and capacities / 8-5 Vehicle identification number (VIN) / 8-7 Vehicle certification label / 8-8 Tire specification and pressure label / 8-8 Engine number / 8-8 Air conditioner compressor label / 8-9...
  • Page 396 Specifications & Consumer information ENGINE BULB WATTAGE Item Light Bulb Wattage Bulb type 2.4L 3.0L Headlights (Low) 55 or 35 (HID) H7 or D1S Displacement 2359 2999 (cu. in) (143.95) (183.01) Headlights (High) Front turn signal lights HY21W Bore x Stroke 88x97 92x75.2 Front...
  • Page 397 Specifications & Consumer information TIRES AND WHEELS Inflation pressure bar (psi, kPa) Wheel lug nut torque Item Tire size Wheel size Normal load * Maximum load kg•m (lb•ft, N•m) Front Rear Front Rear 225/55R17 7.0Jx17 (32, 220) (32, 220) (32, 220) (32, 220) 9~11 Full size tire...
  • Page 398 Specifications & Consumer information WEIGHT AND VOLUME Item 2.4L 3.0L Gross vehicle weight 2050 (4519) 2120 (4673) kg (lbs.) 461 (16.2) Luggage volume l (cu ft) 546 (19.2)

  • Page 399: Recommended Lubricants And Capacities

    MAX. 1 l /1000 km 7.1 l (7.50 US qt.) 2.4L Automatic transaxle MICHANG ATF SP-IV, SK ATF SP-IV fluid NOCA ATF SP-IV, HYUNDAI genuine ATF SP-IV 3.0L 7.8 l (8.24 US qt.) 0.9 l (0.95 US qt.) Power steering fluid PSF-4 2.4L...
  • Page 400 Specifications & Consumer information Recommended SAE viscosity Engine oil viscosity (thickness) has an When choosing an oil, consider the range effect on fuel economy and cold weather number of temperature your vehicle will be oper- operating (engine start and engine oil ated in before the next oil change.
  • Page 401 Specifications & Consumer information VEHICLE IDENTIFICATION NUMBER (VIN) ■ Type A The vehicle identification number (VIN) is VIN label the number used in registering your car 2.4L • and in all legal matters pertaining to its ownership, etc. The number is punched on the engine compartment bulkhead or on the floor under the front passenger’s seat.
  • Page 402 Specifications & Consumer information VEHICLE CERTIFICATION TIRE SPECIFICATION AND ENGINE NUMBER LABEL PRESSURE LABEL ■ 2.4L ■ Type A OHG080005L OHG080002 OHG050081L ■ 3.0L ■ Type B The tires supplied on your new vehicle are chosen to provide the best perform- ance for normal driving.
  • Page 403 Directive ber, production number, refrigerant (1) 1995/5/EC. and refrigerant oil (2). Further information including the manu- facturer's declaration of conformity is available on HYUNDAI web site as fol- lows; http://service.hyundai-motor.com...

Table of Contents

Save PDF
