Hyundai AZERA 2015 Quick Reference Manual

WALK THE CUSTOMER THROUGH EACH OF
THE FOLLOWING KEY DELIVERY FEATURES
☐
DEFROST - page 15
1 Press the front defrost button.
2 Set to warmest temperature setting.
3 Set to highest fan speed.
☐
TIRE PRESSURE MONITORING SYSTEM
(TPMS) – page 29
Explain TPMS function to customer.
- When illuminated, one or more
tires are under-inflated.
- Blinks for approximately one minute
then remains illuminated when there
is a malfunction with the TPMS.
☐
CLOCK ADJUSTMENT – page 27
- Demonstrate how to adjust the clock.
☐
VEHICLE SETTINGS – pages 12-13 & 24-26
- Demonstrate vehicle settings
in instrument cluster
- Demonstrate navigation use,
enter dealer address
- Show radio presets
☐
BLUETOOTH – pages 18
- Demonstrate phone pairing
Refer to www.hyundaiusa.com/bluetooth
- Demonstrate QR code
☐
BLUE LINK – pages 21-23
- Assist with creating MyHyundai.com account
- Assist with Blue Link enrollment
Show Blue Link Users Manual & tear out Voice
Commands/Quick Tip Card
- Encourage customers to press the Blue link button
after enrollment to initiate Welcome Call
MAINTENANCE
Scheduled Maintenance Normal Usage
Engine Oil And Filter* Replace 7,500 or 12 mos.
Fuel Additives Add 7,500 or 12 mos.
Tire Rotation Perform 7,500
Inspect 7,500
Air Cleaner Filter
Replace 30,000
Battery Condition Inspect 7,500
Vacuum Hose Inspect 7,500
Climate Control Air Filter
Replace 15,000
(For Evaporator And Blower Unit)
Air Conditioning Refrigerant Inspect 15,000
Brake Hoses & Lines Inspect 15,000
Drive Shafts & Boots Inspect 15,000
Exhaust Pipe & Muffler Inspect 15,000
Front Disc Brake/Pads Inspect 15,000
Rear Brake Disc/Pads Inspect 15,000
Steering Gear Box, Linkage & Boots/
Inspect 15,000
Lower Arm Ball Joint, Upper Arm Ball Joint
Suspension Mounting Bolts Inspect 15,000
Brake Fluid Inspect 30,000
Fuel Filter Inspect 30,000
Fuel Lines, Fuel Hoses and Connections Inspect 30,000
Fuel Tank Air Filter Inspect 30,000
Parking Brake Inspect 30,000
Vapor Hose & Fuel Filler Cap Inspect 30,000
Valve Clearance Inspect 60,000
1st Inspect 60,000 or 72 mos.
Drive Belt (Alt, A/C)
Add. Inspect 15,000 or 24 mos.
Spark Plugs (Iridium Coated) Replace 105,000 or 10 yrs. Replace
1st Replace 120,000 or 10 yrs.
Coolant
Add Replace 30,000 or 24 mos.
Automatic Transaxle Fluid No check, No service required
*Check the engine oil regularly between recommended oil change. Hyundai recommends Quaker State oil.
*See Owner's Manual for details.
Looking for more detailed information? This Quick Reference Guide does not replace your vehicle's Owner's
Manual, If you require additional information or are unsure of a specific issue, you should always refer to the vehicle's
Owner's Manual or contact your authorized Hyundai dealer.
The information contained in this Quick Reference Guide was correct at the time of printing, however, specifications
and equipment can change without notice. No warranty or guarantee is being extended in this Quick Reference
Guide, and Hyundai reserves the right to change product specifications and equipment at any time without incurring
obligations. Some vehicles are shown with optional equipment. Specifications apply to U.S. vehicles only. Please
contact your Hyundai dealer for current vehicle specifications.
Severe Usage*
Replace 3,750 or 6 mos.
AZERA
Perform 7,500 HYUNDAI
Inspect Same As Normal
Quick Reference Guide
Replace More Frequently
Inspect Same As Normal
Inspect Same As Normal
Replace More Frequently
Inspect Same As Normal
Inspect Same As Normal
Inspect 7,500 or 6 mos.
Inspect Same As Normal
Inspect More Frequently
Inspect More Frequently
Inspect More Frequently
Inspect Same As Normal
Inspect Same As Normal
Inspect Same As Normal
Inspect Same As Normal
Inspect Same As Normal
Inspect More Frequently
Inspect Same As Normal
Inspect Same As Normal
Inspect Same As Normal
More Frequently
Replace Same As Normal
Replace 60,000
