WELCOME TO
Fishhunter™ PRO
THE WORLD'S FASTEST
TRI-FREQUENCY, WIRELESS
PORTABLE FISH FINDER.
TM
THE PORTABLE FISH FINDER FOR ALL FISHING TYPES
KAYAK FISHING
BOAT FISHING
SHORE FISHING
ICE FISHING

Advertisement

Table of Contents
loading

Related Manuals for FishHunter PRO

Summary of Contents for FishHunter PRO

  • Page 1 WELCOME TO FishHunter™ PRO THE WORLD'S FASTEST TRI-FREQUENCY, WIRELESS PORTABLE FISH FINDER. THE PORTABLE FISH FINDER FOR ALL FISHING TYPES KAYAK FISHING BOAT FISHING SHORE FISHING ICE FISHING...
  • Page 2 We strive to improve our product each month and this means this manual is already outdated. Please go online and download the most recent version of our manual: www.fishhunter.com/support...
  • Page 3 Using our free FishHunter™ software app, you will also have the ability to access and store critical fishing information like your fishing spots, your catch details and share your information with your friends and other fishermen.
  • Page 4 FISHHUNTER™ Night-time Fish Attraction Illumination FRONT VIEW Towing Point...
  • Page 5 Tri-Frequency Transducer ( 381KHz, 475 KHz, 675 KHz ) BOTTOM VIEW USB Charging Port...
  • Page 6 HOW TO CHARGE Charging your FishHunter™ PRO can be done in 4 easy steps: Step 1: Take the USB charge cord from the Step 1 box and hold the end that has 3 pins holes in it. Step 2: Locate the 3 pin charging port on the bottom of the sonar.
  • Page 7 KNOW WHERE TO CAST ™ 95% OF THE FISH ARE IN 5% OF THE WATER...
  • Page 8 Ensure you have charged your FishHunter PRO for minimum of 4 hours before first usage. Attach your FishHunter PRO to the braided line on the end of your fishing line or tether it to the red leash that was provided in your box by threading the red leash through the tow point on the front of your FishHunter PRO.
  • Page 9 Once connected, open the FishHunter App and go to the Sonar section. Select one of the following functions you would like to use: Start Fishing: allows you to use the sonar and offers dif- ferent view modes. Press on one of these modes to activate your sonar.
  • Page 10 WI-FI CONNECTIVITY & FISHHUNTER In order for you to get the best possible signal and connection with your FishHunter, we recommend that you follow the pictures below. For the best connection, your smartphone/tablet should be looking down towards the sonar and should be elevated above the floating sonar.
  • Page 11 BEST PRACTICES 1. Line of Sight 2. Good Elevation 3. No Obstructions...
  • Page 12 FISHHUNTER APP - MAIN MENU SPOTS This is the area of the app where you can save and retrieve all your favorite fishing spots. Use the “Filter” feature to explore the map for: • Catches (species, length, bait used etc.) •...
  • Page 13 CATCHES Here you can log all your catch information and see/explore other FishHunters recent catches too. Steps to log a catch: 1. Select GPS location 2. Add catch details 3. Add photo 4. Share catch MAPS You can find all your saved Bathymetric Maps here for review and analysis.
  • Page 14 OPEN WATER FISHING DEPTH TO FISH DEPTH TO 13 ft BOTTOM 25 ft 12 ft...
  • Page 15 Simply toss into the water and watch everything come into focus. Take advantage of either our RAW VIEW or FISH VIEW settings to see the bottom depth, determine bottom structure and locate fish. You can even toggle between RAW VIEW and FISH VIEW in real-time, by pressing on the top menu button and selecting the view you prefer.

  • Page 16: Getting Started

    OPEN WATER FISHING GETTING STARTED Place your FishHunter PRO in water for it to turn on. (Note: it must be in a minimum 4 ft of water to work effectively) The sonar will have a red light appear and an additional slow flashing red light to identify that it is on.
  • Page 17 WONDER LESS, SEE MORE...
  • Page 18 These icons identify the location of the disturbance in relation to your location. This makes it easy for you to identify where the fish are under your FishHunter PRO sonar. In addition, you can have your phone make a sonar “ping”...
  • Page 19 RAW VIEW RAW VIEW produces actual results from the powerful Tri- Frequency Transducer in real time. In this mode, you become an instant expert, interpreting the different coloured lines at the bottom of the screen to see depth and structure while watching for disturbances in the water column to locate fish.
  • Page 20 SHALLOW WATER MODE FishHunter is the only wireless portable fish finder that comes with a shallow water mode that allows you to get into water that is only 1.4ft (0.4m) deep. This mode uses our patent pending tri-frequency technology to allow for the...
  • Page 21 On your Smartphone/Tablet open your Wi-Fi settings. Refresh the list and select "FishHunter Wi-Fi XXX" ( Note: this can take up to 1 minute ) Open the FishHunter app on your smartphone or tablet and go into the sonar section. Select your prefered view.
  • Page 23 Just troll your FishHunter across the area that you are interested in mapping and FishHunter starts to track the depth and bottom contour as it travels around your lake. Once completed, you can navigate back to any location on your map, or see the bottom contour...
  • Page 24 BATHYMETRIC MAPPING Depth range Area covered Color scale Water Temperature Depth SIDE MENU Continue current map Boat location TOP MENU Surface reverb (See p.36) Bottom contour SPLIT VIEW...
  • Page 25 (We recommend the sonar be directly behind your boat and less than 5ft from your smartphone/tablet.) Ensure you are connected to the FishHunter Wi-Fi in your settings. Open the FishHunter app and go into the Sonar section.
  • Page 26 (We recommend the sonar be directly behind your boat and less than 5ft from your smartphone/tablet) Ensure you are connected to the FishHunter Wi-Fi in your settings Open the FishHunter app and go into the Sonar section Select MY BATHYMETRIC MAPS...
  • Page 27 STEPS FOR SOLUTION: Navigate to missing spot (Note: you must be within 500m of the last recorded position) Place FishHunter Sonar in water Follow steps 1-9 of how to add to existing map Troll over area to retrieve missing data Visit our website for additional support videos: www.fishhunter.com/support...
  • Page 28 ICE FISHING FLASHER DEPTH TO BOTTOM 11 meters...
  • Page 29 Unlike traditional flashers, FishHunter PRO floats on the surface of the water in the ice hole, withstanding weather conditions as cold as -22ºF (-30ºC). The Ice Fishing Flasher View uses 2 powerful ultra high frenquencies 475 kHz and 675 kHz to enable you to see your jig in real time.
  • Page 30 ICE FISHING FLASHER Temperature Bait and jig line movement FULL FLASHER MODE Fish detected Depth SPLIT VIEW Bait and jig line movement Fish detected Change View RAW VIEW...
  • Page 31 ICE FISHING FLASHER STEPS Clear any snow debris from your ice hole. Place FishHunter PRO in the ice hole to turn it on. Open your Wi-Fi settings and select FishHunter Wi-FI XXXX. Open the FishHunter™ app and go into the sonar section.
  • Page 32 "KNOW WHERE TO DRILL" FishHunter PRO is very powerful and you can actually find the bottom depth in most cases, without having to drill a hole in through ice. Clear the snow from the surface of the ice, ensure ice surface is flat/smooth.
  • Page 33 Top Menu Side Menu There is one top menu and one side menu located within your FishHunter App. Each of these menus can be called by pressing on the small slider like icon on your screen. TOP MENU OPTIONS X: Clicking on this icon takes you back to view options (for iOS only)
  • Page 34 15ft of water. Please note that you must adjust the power slider when in this mode. Failure to adjust the power slider to your water conditions can result in the FishHunter giving you incorrect bottom values.
  • Page 35 FishHunter PRO. You can set the depth manually by going into the side menu and selecting the depth you will be fishing in. The side menu changes slightly depending on what view you have the sonar in when you open the menu.
  • Page 36 In more extreme conditions where you have high wind, high waves or when you are trolling your FishHunter behind a boat motor, you will want to turn UP the Surface Filter. Try to set the Surface Filter to a number that matches where you see the surface noise stop in the RAW data view on your screen.
  • Page 37 As you move the slider from left to right you can increase the sensitivity of your FishHunter from 0 to 5, with 5 being the most sensitive. The Fish Sensitivity Slider can be changed in real time, so you can see the direct impact each position change has on having the FishHunter display and notify you of fish that have been found in FISH VIEW.
  • Page 38 The Power Slider allows you to adjust the gain and pulsewidth for your FishHunter. In Ice Fishing Flasher mode, the FishHunter does not know the thickness of the ice, giving you the ability to adjust the power you want to use when ice fishing.
  • Page 39 ZOOM FEATURES This feature within the FishHunter app allows you to look more closely at the sonar display on your phone. This is useful when you want to look at the bottom area OR review the top area of the sonar data to look for fish or other specific artifacts.
  • Page 40 Casting and reeling from shore: The FishHunter PRO is 153 grams, so when casting from shore we recommend that you use a stiff rod and braided line. We have tested casting the unit with all types and styles of rods and lines and have had no issues, but better to be safe in your approach when casting from shore.
  • Page 41 Kayak Fishing Usage: With a range of over 150 ft, you can cast the FishHunter away from the kayak and fish the broadest possible area. We have tested casting the unit on all types of rods and lines but do suggest a braided line for casting.
  • Page 42 II. Allow enough line to ensure your FishHunter will be behind your seat. When you are moving along (in this case we have used about 4 ft of the tether) the FishHunter may bounce off the side of your kayak from time to time, but that will not im- pact its performance.
  • Page 43 With a range of over 150 ft, you can also attach the FishHunter to a fishing rod and then cast it into the area that you would like to drift it across. This will allow you to fish a much broader area and also allow you to cast directly at your FishHunter.
  • Page 44 Trolling- 15 ft Leash Mounting: The FishHunter has been designed to troll at under 2 miles per hour for Android and under 1.5 miles per hour for iOS devices. The difference in the two devices is due to the difference in the Wi-Fi chips in the different devices.
  • Page 45 If you are having trouble with the connection to your phone or tablet when trolling using your leash or you would like to try to troll the FishHunter at a faster rate, you can attach the unit to the back of the trailer mount of your fishing boat. Please follow...
  • Page 46 WARRANTY Navico warrants that its products, when properly installed and used, will be free from defects in material and workmanship for the period stated for the applicable product and/or peripheral device as set out on www.lowrance.com from the date of first purchase (the Warranty Period).
  • Page 47 OBTAINING WARRANTY SUPPORT Customers can obtain warranty support by contacting: • Their local Navico Certified/Approved Dealer or Distributor (a list of Certified/Approved Dealers and Distributors can be found on www.lowrance.com) • Navico, Americas on 1 800 628 4487 • Navico, Australia on 1 300 628 426 •...
  • Page 48 FishHunter™ PRO Includes : • FishHunter™ PRO Sonar • USB Charging Cord • 15ft leash FishHunter Inc. Worldwide Offices www.fishhunter.com/support...
