- Page 1 USER MANUAL...
- Page 2 The Fishhunter Thank you for purchasing a FishHunter. This quick start guide will tell you the main things you need to know to start using our product. If you would like more information you can also go directly to our website where we have videos and additional content.
- Page 3 The Fishhunter A military grade fishfinder Engineered with military grade technology, FishHunter is a powerful fishfinder for Apple and Android phones and tablets. The fishfinder floats on the top of the water and tracks water temperature, depth and fish locations.
- Page 4 The FishHunter Using your new FishHunter can be easy you just need to charge it up! Step 1: Connect the fishfinder to the charging base Step 2: Connect USB cable to the charging base Step 3: Connect USB cord into the charger Step 4: Check to see 2 charging lights are on.
- Page 5 Charging Your FishHunter Step 1: Connecting the fishfinder and the charging base FISHHUNTER.COM / 5...
- Page 6 Charging Your FishHunter Step 2: Connecting the USB Cable to the charging base The connection between USB-mini cable and the charging base is shown below: Connect the charging base and USB cord by inserting the cord into the opening on the charging base as shown below: FISHHUNTER.COM / 6...
- Page 7 Charging Your FishHunter Step 3: Connect USB cord into the charger Connect the other end of the USB cord to the computer or a USB charger. FISHHUNTER.COM / 7...
- Page 8 Charging Your FishHunter Step 4: Check to see both charging lights are on You will notice that a red light appears on the charging base which means that the base has power and is ready to charge the fishfinder. FISHHUNTER.COM / 8...
- Page 9 When the fishfinder is attached to the charging base, the body will lit up yellow while charging is in progress. This light will turn green when the charging is complete. Step 5. Download the “FishHunter Pro” app to your smartphone/tablet FISHHUNTER.COM / 9...
- Page 10 Please deploy it in water before you begin the following Bluetooth connection process. • Your fishfinder connects to your mobile device using Bluetooth connection. The fishfinder broadcasts a signal that your phone will pick up and connect with. FISHHUNTER.COM / 10...
- Page 11 Step 2: Place your fishfinder into water. You will see that the fishfinder’s red lights are blinking fast and eventually stay lit to indicate that the fishfinder is “waking up.” If the red light is not on, the fishfinder is OFF. FISHHUNTER.COM / 11...
- Page 12 Bluetooth Pair with App Step 3: Open the FishHunter app. If this is the first time you have opened the app, you will need to login. Please login. If you have already logged in, then please go to the bottom menu and select sonar by pressing on the fish icon labeled “Sonar”...
- Page 13 Bluetooth Pair with App Step 4: Select the “PAIR FISHHUNTER” option. Please note that the app may prompt you to turn on your Bluetooth. You should do so before you continue this process. FISHHUNTER.COM / 13...
- Page 14 Bluetooth Pair with App Step 5: The app will scan for available FishHunter fishfinders within blue tooth range. This step may have to be repeated a few times depending on your phone or tablet. FISHHUNTER.COM / 14...
- Page 15 Bluetooth Pair with App Once your phone finds the FishHunter, it will populate the app with the device name and number. Select your FishHunter hardware by pressing on the screen where you see the name listed. After the pairing is complete your FishHunter will appear on the “PAIR SONARS”...
- Page 16 Bluetooth Pair with App Step 6: Click on your fishfinder name and our app will open the “SONAR SETTINGS” screen. The “Sonar Settings” screen will allow you to change the settings to your preference. FISHHUNTER.COM / 16...
- Page 17 Understanding the Display – Raw FISHHUNTER.COM / 17...
- Page 18 3. GREEN - All colors except blue (such as green, yellow or red) indicate that there is something in that space. Darker the color the more dense the material the fishfinder is picking up. FISHHUNTER.COM / 18...
- Page 19 Understanding the Display – Raw 4. This shows the variation of color which indicates a variation of the density of the material being seen. In this case it is the bottom of the water. FISHHUNTER.COM / 19...
- Page 20 Understanding the Display – Raw How to read fishview screen: FISHHUNTER.COM / 20...
- Page 21 7. The “Drop Pin” button allows you to drop a pin on the map. 8. The “ON” button indicates that the fishfinder has been turned on. Click on it to turn it off. FISHHUNTER.COM / 21...
- Page 22 9. The fish symbol means that there could potentially be a fish in the indicated area. 10. This area indicates the mapped bottom of the water body. 11. This ruler helps you determine the depth of each fish. FISHHUNTER.COM / 22...
- Page 23 Fishhunter Fishfinder Care Please operate this device where the temperature is between -30ºC and 40º C (-22ºF to 104º F). Extreme low or high temperature conditions might temporarily shorten battery life or cause the device to alter its behavior to regulate its temperature.
- Page 24 Fishhunter Fishfinder Care 3. Make sure the 3 tiny stainless steel pads on the bottom of the fishfinder are completely clean and shiny, and do not have any salt residues on them. 4. Dry the fishfinder completely with a dry towel before charging or putting it in storage.
- Page 25 Warranty FishHunter Limited Warranty This product has been manufactured and tested to the highest quality standards by FishHunter Inc. This Limited Warranty offered by FishHunter Inc. covers defects in material or workmanship in new FishHunter Inc. products. This warranty extends to the original purchaser only and is non-transferable.
- Page 26 FishHunter Inc. warrants this product against defects in material or workmanship as follows: FishHunter Inc. will replace at no charge for parts only or, at its option, replace any product or part of the product that proves defective because of improper workmanship and/or material, under normal installation, use, service and maintenance.
- Page 27 B. Conditions, malfunctions or damage resulting from normal wear and tear, improper installation, improper maintenance, misuse, abuse, negligence, accident or alteration. C. Accessories, connected materials and products, or related products not manufactured by FishHunter Inc. FISHHUNTER.COM / 27...
- Page 28 The Fishhunter This limited warranty is void if a product is returned with removed, damaged or tampered labels or any alterations (including removal of any component or external cover). FISHHUNTER.COM / 28...
- Page 29 The Fishhunter How to File a Claim? FishHunter Inc. will not provide any warranty coverage unless claims are made in compliance with all terms of the controlling warranty statement included with your product, and you follow proper return procedure. To request...
- Page 30 Fishhunter inc. neither assumes nor authorizes any person to create for it any other obligation or liability in connection with this product. The laws of Toronto, in the Province of Ontario Canada govern FishHunter Inc. and this warranty. FISHHUNTER.COM / 30...
- Page 31 CONTACT 5520 Explorer Drive, 4th Floor, Mississauga, ON L4W 5L1 P. 416-695-1246 F. 416-695-0246 info@fishhunter.com www.fishhunter.com...
