Summary of Contents for FishHunter MILITARY
- Page 1 WELCOME TO FISHHUNTER™ MILITARY MADE TOUGH FOR RUGGED USE THE PORTABLE FISH FINDER FOR ALL FISHING TYPES KAYAK FISHING BOAT FISHING SHORE FISHING ICE FISHING...
- Page 2 Thank you for purchasing FishHunter™ MILITARY. Reading this user guide will help you to understand and learn how to use FishHunter™ MILITARY and the FishHunter Pro app properly. FishHunter™ MILITARY Includes : • FishHunter™ MILITARY Sonar • Charger • USB Cord...
- Page 3 OVERVIEW A fi sh fi nder engineered with military grade technology, FishHunter™ MILITARY is a powerful sonar for Apple and Android phones and tablets. The fi shfi nder fl oats on the top of the water and tracks water temperature, depth and fi sh locations.
- Page 4 FISHHUNTER™ LED Light and Antennae FRONT VIEW Towing Point...
-
Page 5: Bottom View
MILITARY Transducer (381KHz) BOTTOM VIEW USB Charging Port... -
Page 6: How To Charge
HOW TO CHARGE Charging yor FishHunter™ MILITARY can be done in 4 easy steps: Step 1 Step 2 Connect the sonar onto the Connect the other end of the USB charging base properly and plug cord to the computer or a USB USB cord in the base. - Page 7 KNOW WHERE TO CAST ™ 95% OF THE FISH ARE IN 5% OF THE WATER...
- Page 8 “waking up.” If the red light is NOT on, your FishHunter™ MILITARY is OFF. Open the FishHunter app. If this is the first time you have opened the app, you will need to login. If you have already logged in, please go to the bottom menu and select icon labeled “Sonar”.
- Page 9 Bluetooth range. (Note:This step may have to be repeated a few times depending on your phone or tablet.) Once your phone fi nds the FishHunter™, it will populate the app with the device name and number. Select your FishHunter™ MILITARY sonar by pressing on the screen where you see it listed.
- Page 10 OPEN WATER FISHING DEPTH TO FISH DEPTH TO 13 ft BOTTOM 25 ft 12 ft...
- Page 11 Simply toss the FisHunter™ MILITARY portable fi sh fi nder into the water and watch everything come into focus. Take advantage of either our RAW VIEW or FISH VIEW settings to see the bottom depth, determine bottom structure and locate fi sh. You can even toggle between RAW VIEW and FISH VIEW in real-time, by pressing on the right side menu button and selecting the view you prefer.
- Page 12 OPEN WATER FISHING GETTING STARTED Place your FishHunter™ MILITARY in water for it to turn on. (Note: it must be in a minimum 6 ft of water to work effectively) The sonar will have a red light appear and an additional slow flashing red light to identify that it is on.
- Page 13 WONDER LESS, SEE MORE...
- Page 14 In addition, you can have your phone make a sonar “ping” whenever fi sh are found beneath your FishHunter™ MILITARY so you don’t have to look at your phone. Weeds appear...
- Page 15 RAW VIEW RAW VIEW produces actual results from the powerful transducer in real time. This powerful hands on view gives you everything you need to rapidly identify and catch more fi sh. The darker the color on the screen the more dense the material the sonar is seeing, with red being the most dense possible.
- Page 16 ICE FISHING FLASHER DEPTH TO BOTTOM 11 meters...
- Page 17 Unlike traditional fl ashers, FishHunter™ MILITARY fl oats on the surface of the water in the ice hole, withstanding weather conditions as cold as -22ºF (-30ºC). The Ice Fishing Flasher View allows both the SPLIT Screen (Flasher / RAW Data) and FULL Screen (RAW DATA only) view allow you to see the bottom, the bottom depth and the temperature conveniently on your smartphone or tablet.
-
Page 18: Ice Fishing Flasher
ICE FISHING FLASHER Bait and jig line Fish disturbance Depth Bottom Bait and jig line movement Depth Fish disturbances... -
Page 19: Ice Fishing
Clear all snow debris from your ice hole (Note: debris may cause reflections in the sonar readings) Place your FishHunter™ MILITARY in water for it to turn on. (Note: it must be in a minimum 6 ft of water to work effectively) The sonar will have a red light appear and an additional slow flashing red light to identify that it is on. - Page 20 WONDER LESS, SEE MORE...
-
Page 21: Menus And Settings
MENUS AND SETTINGS There is one vertical menu and one side menu located within your FishHunter™ PRO app. Each of these menus can be called by selecting the small slider like icon on your screen. When you press/push on the “slider icon n you press/push on the “slider icon... - Page 22 In most cases, we recommend leaving it on "auto ranging" for the best results. If you are taking your FishHunter™ MILITARY in and out of the water repeatedly, example when casting, we recommend manually setting the depth range to increase the speed of your FishHunter™...
- Page 23 In very calm conditions, you can set the Surface Filter to a very low number to allow you to search for fi sh that are located very close to the surface. In more extreme conditions where you have high wind, high waves or when you are trolling your sonar behind a boat motor, you will want to turn UP the Surface Filter.
- Page 24 As you move the slider from left to right you can increase the sensitivity of your FishHunter™ MILITARY from 0 to 5, with 5 being the most sensitive. Sometimes, you will want the FishHunter™ MILITARY to detect and display all the fi sh no matter how small they are, and other times you will want the FishHunter™...
- Page 25 INCREDIBLE PERSPECTIVE...
- Page 26 FISH FINDER CARE For optimal use of the sonar only use while in temperatures of between -30ºC and 40ºC (-22ºF to 104ºF). Extreme low or high temperature conditions may cause shortened battery life or altered device behavior. Store the device where the temperature is between -10ºC and 30º C (14ºF to 86º...
- Page 27 30 DAY SATISFACTION GUARANTEE We want you to be excited and completely satisfied with your new FishHunter™ MILITARY. We think you will be, but if for some rea- son you are not, you have 30 days to return it for a refund ( not including shipping cost ).
-
Page 28: Warranty
FishHunter™ Inc. warrants this product against defects in material or workmanship as follows: FishHunter™ Inc. will replace at no charge for parts only or, at its option, replace any product or part of the product that proves defective because of improper workmanship and/or material, under normal installation, use, service and maintenance. - Page 29 When warranty service is completed, any repaired or replacement product or part will be returned to you postage prepaid. FishHunter Inc will provide warranty coverage with claims made in compliance with the terms of our warranty.
- Page 30 FishHunter Inc. Worldwide Offices Toronto | Los Angeles | Seoul, Korea www.fishhunter.com/support...
