Summary of Contents for FishHunter Pro
- Page 1 SER MANUAL...
- Page 2 The Fishfinder Sonar Thank you for purchasing a FishHunter. This quick start guide will tell you the main things you need to know to start using our product. If you would like more information you can also go directly to our web site where we have video’s and additional content.
- Page 3 The Fishfinder Sonar A military grade fishfinder Engineered with military grade technology, FishHunter is a powerful sonar fishfinder for Apple and Android phones and tablets. The sonar floats on the top of the water and tracks water temperature, depth and fish locations.
- Page 4 CHARGING YOUR FISHFINDER Using your new FishHunter can be easy you just need to charge it up! Step 1: Connect the sonar to the charging base Step 2: Connect USB cable to the charging base Step 3: Connect USB cord into the charger Step 4: Check to see 2 charging lights are on.
- Page 5 CHARGING YOUR FISHFINDER Step 1: Connecting the sonar and the charging base...
- Page 6 CHARGING YOUR FISHFINDER Step 2: Connecting the USB Cable to the charging base The connection between USB-mini cable and the charging base is shown below: Connect the charging base and USB cord by inserting the cord into the opening on the charging base as shown below:...
- Page 7 CHARGING YOUR FISHFINDER Step 3: Connect USB cord into the charger Connect the other end of the USB cord to the computer or a USB charger.
- Page 8 CHARGING YOUR FISHFINDER Step 4: Check to see both charging lights are You will notice that a red light appears on the charging base which means that the base has power and is ready to charge the sonar.
- Page 9 When the sonar is attached to the charging base, the sonar body will lit up yellow while charging is in progress. This light will turn green when the charging is complete. Step 5. Download the “FishHunter Pro” app to your smartphone/tablet...
- Page 10 6. BLUE TOOTH PAIR THE APP WITH SONAR Important reminders: - It takes about 2 hours to fully charge your FishHunter sonar. - Your fishfinder body does not operate in air; it only works when it is placed on the water surface.
- Page 11 BLUE TOOTH PAIR WITH APP Step 3: Open the FishHunter app. If this is the first time you have opened the app, you will need to login. Please login. If you have already logged in, then please go to the bottom menu and select sonar by pressing on the fish icon labeled “Sonar”...
- Page 12 BLUE TOOTH PAIR WITH APP...
- Page 13 BLUE TOOTH PAIR WITH APP Step 5: The app will scan for available FishHunter fishfinders within blue tooth range. This step may have to be repeated a few times depending on your phone or tablet.
- Page 14 BLUE TOOTH PAIR WITH APP Once your phone finds the FishHunter, it will populate the app with the device name and number. Select your FishHunter hardware by pressing on the screen where you see the name listed. After the pairing is complete your FishHunter will appear on the “PAIR SONARS”...
- Page 15 BLUE TOOTH PAIR WITH APP Step 6: Click on your fishfinder name and our app will open the “SONAR SETTINGS” screen. The “Sonar Settings” screen will allow you to change the settings to your preference.
- Page 16 UNDERSTANDING THE DISPLAY – RAW...
- Page 17 UNDERSTANDING THE DISPLAY – RAW How to read raw sonar screen? When Reading sonar data output you are generally interpreting color variations. In simple terms, the sonar will display more dense material with darker colors. We have provided you with a sample screen on the left here that shows the surface, the water body, a small “disturbance/object”...
- Page 18 UNDERSTANDING THE DISPLAY – RAW How to read fishview sonar screen:...
- Page 19 UNDERSTANDING THE DISPLAY – RAW 1. The “X” button lets you go back to the previous screen (iOS device only). 2. This indicates the water depth. 3. This indicates the water temperature. 4. This shows the battery life of the sonar. 5.
- Page 20 FISHHUNTER FISHFINDER CARE Please operate this device where the temperature is between -30ºC and 40º C (-22ºF to 104º F). Extreme low or high temperature conditions might temporarily shorten battery life or cause the device to alter its behavior to regulate its temperature.
- Page 21 FISHHUNTER FISHFINDER CARE 4. Dry the sonar completely with a dry towel before charging or putting it in storage.
-
Page 22: Warranty
What is covered? FishHunter Inc. warrants this product against defects in material or workmanship as follows: FishHunter Inc. will replace at no charge for parts only or, at its option, replace any product or part of the product that proves defective... - Page 23 (including removal of any component or external cover). How to File a Claim? FishHunter Inc. will not provide any warranty coverage unless claims are made in compliance with all terms of the controlling warranty...
- Page 24 2. A description of the problem. 3. Delivery of the product or the defective part, postage prepaid and carefully packed and insured, to FishHunter Inc., 5520 Explorer Drive, 4th Floor, Mississauga, ON L4W 5L1 When warranty service is completed, any repaired or replacement product or part will be returned to you postage prepaid.
- Page 25 THE PURCHASER. FISHHUNTER INC. NEITHER ASSUMES NOR AUTHORIZES ANY PERSON TO CREATE FOR IT ANY OTHER OBLIGATION OR LIABILITY IN CONNECTION WITH THIS PRODUCT. The laws of Toronto, in the Province of Ontario Canada govern FishHunter Inc. and this warranty.
- Page 26 CONTACT 5520 Explorer Drive, 4th Floor, Mississauga, ON L4W 5L1 P. 416-695-1246 F. 416-695-0246 info@fishhunter.com www.fishhunter.com...
