Chapter 2. Using the Router

2.1 Cautions for using the ADE-4120

Do not place the ADE-4120 under high humidity and high temperature.
Do not use the same power source for ADE-4120 with other equipment.
Do not open or repair the case yourself. If the ADE-4120 is too hot, turn off
the power immediately and have a qualified serviceman repair it.
Place the ADE-4120 on a stable surface.
Only use the power adapter that comes with the package.

2.2 The Front Panel LEDs

LED
PWR
POST
ADSL
READY
LAN port LNK/ACT
1 ~ 4
100
FDX/COL
ADE-4120
Lit when power ON
Blinks when the device is booting
Lit when successfully connected to an ADSL DSLAM
Lit when the device is ready to use
Lit when connected to Ethernet device
Blinks when data transmit/received
Lit when connected at 100Mbps speed
Lit when connected at Full Duplex and blinks when there
is collision.
