Right / Rear side
1
2
3
#
Description
1
Power socket
2
Kensington™ lock port
3
LAN (RJ45 Port for 10/100M Ethernet)
4
RS232 connector
5
HDMI 1 connector
6
HDMI 2/MHL connector
PC analog signal/HDTV/component
7
video input connector
Note: Functions vary depending on model definition.
4
5
6
7
#
8
9
10
11
12
13
8
10
12
9 11 13
Description
Monitor loop-through output
connector
Audio in connector
Audio out connector
5V DC output connector
12V DC output connector
Service connector (for firmware
upgrade)
