  • Page 1 Acer Projector H7532BD/E152D/HE-812 Series User's Guide Downloaded From projector-manual.com Acer Manuals...
  • Page 2 Serial number: ___________________________________ Date of purchase: ________________________________ Place of purchase: ________________________________ Acer and the Acer logo are registered trademarks of Acer Incorporated. Other companies' product names or trademarks are used herein for identification purposes only and belong to their respective companies.
  • Page 3 Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind onto or into the product. Downloaded From projector-manual.com Acer Manuals...
  • Page 4 Use the product only with the supplied power supply cord set. If you need to replace the power cord set, make sure that the new power cord meets the following requirements: detachable type, UL listed/CSA certified, VDE approved or its equivalent, 4.5 meters (15 feet) maximum length. Downloaded From projector-manual.com Acer Manuals...
  • Page 5 Locations where the altitudes are higher than 10000 feet. • Unplug immediately if there is something wrong with your projector. Do not operate if smoke, strange noise or odor comes out of your projector. It Downloaded From projector-manual.com Acer Manuals...
  • Page 6 • This product is capable of displaying inverted images for ceiling mount installation. Only use acer ceiling mount kit for mounting the projector and ensure it is securely installed. Downloaded From projector-manual.com Acer Manuals...
  • Page 7 Do not throw this electronic device into the trash when discarding. To minimize pollution and ensure utmost protection of the global environment, please recycle. For more information on the Waste from Electrical and Electronics Equipment (WEEE) regulations, visit http://www.acer-group.com/public/ Sustainability/sustainability01.htm Mercury advisory For projectors or electronic products containing an LCD/CRT monitor or display: “Lamp(s) contain Mercury,...
  • Page 8: Precautions

    When the lamp reaches the end of its life, it will burn out and may make a loud popping sound. If this happens, the projector will not turn back on until the lamp module has been replaced. To replace the lamp, follow the procedures listed under "Replacing the Lamp". Downloaded From projector-manual.com Acer Manuals...
  • Page 9: Table Of Contents

    How to optimize image size and distance How to get a preferred image size by adjusting distance and zoom User Controls Installation menu Acer Empowering Technology Onscreen Display (OSD) Menus Color Image Setting Management Audio Language Downloaded From projector-manual.com Acer Manuals...
  • Page 10 Appendices Troubleshooting LED & Alarm Definition Listing Replacing the Lamp Ceiling Mount Installation Specifications Compatibility modes Regulations and safety notices Downloaded From projector-manual.com Acer Manuals...
  • Page 11: Introduction

    Enables projecting 3D content via DLP Link Technology: Blue-Ray 3D supported and Nvidia 3DTV Play Ready • Enrich 3D experience for 2D contents via 2D to 3D convert function • Acer ColorBoost technology delivers nature’s true colors for vivid, life-like images • High brightness and contrast ratio •...
  • Page 12: Package Overview

    Projector with lens cap Power cord VGA cable Compostive video cable Security card User's Guide Remote control Quick start guide 2 x Batteries Carrying case 3D glasses (Optional) MHL cable (Optional) Downloaded From projector-manual.com Acer Manuals...
  • Page 13: Projector Overview

    HDMI 2 connector USB ctrl connector HDMI 1/MHL connector YPbPr/YCbCr input connector Audio input connector Composite video input connector RS232 connector S-Video input connector 12V DC output connector PC analog signal/HDTV/component Kensington™ lock port video input connector Downloaded From projector-manual.com Acer Manuals...
  • Page 14: Control Panel

    (± 40 degrees). SOURCE Changes the active source. Four directional select keys Use to select items or make adjustments to your selection. TEMP Temp Indicator LED. Empowering key Unique Acer functions: e3D, eView, eTimer, ePower Management. Downloaded From projector-manual.com Acer Manuals...
  • Page 15: Remote Control Layout

    MUTE To turn on/off the volume. ZOOM Zooms the projector display in or out. Empowering Unique Acer functions: e3D, eView, eTimer, ePower Management. MENU • Press "MENU" to launch the Onscreen display (OSD) menu, back to the previous step for the OSD menu operation or exit the OSD menu.
  • Page 16 1080i), YCbCr (480i/576i) and RGBsync. S-VIDEO To change source to S-Video. SD/USB A No function. USB B No function. HDMI/DVI To change source to HDMI™ or MHL (HDMI 1/MHL connector only). (no DVI function) LAN/WiFi No function. Downloaded From projector-manual.com Acer Manuals...
  • Page 17: Mhl (Mobile High-Definition Link) Control

    (only for Multi-Media mode) Forward Scans forward through the file playback. (only for Multi-Media mode) KeyPad 0~9 Number buttons. (only for Numeric mode) PgUp/PgDn Use the button to select the next or previous page. (only for Navigation mode) Downloaded From projector-manual.com Acer Manuals...
  • Page 18: Getting Started

    Note: To ensure the projector works well with your computer, please make sure the timing of the display mode is compatible with the projector. Note: USB cable needs powered extender if the length is over 5 m. Downloaded From projector-manual.com Acer Manuals...
  • Page 19: Turning The Projector On/Off

    If you connect to multiple sources at the same time, use the "Source" button on either control panel or the remote control or direct source key on the remote control to switch between inputs. Power button Lens cap Downloaded From projector-manual.com Acer Manuals...
  • Page 20: Turning The Projector Off

    LED temp indicator will blink. Contact your local dealer or service center. Note: Whenever the projector automatically shuts down and the LED lamp indicator turns solid red, contact your local reseller or service center. Downloaded From projector-manual.com Acer Manuals...
  • Page 21: Adjusting The Projected Image

    Lower the image to the desired height angle (Illustration #2) , then release the button to lock the elevator foot into position. Use Tilt adjusting wheel (Illustration #3) to fine-tune the display angle. Elevator foot release button Tilt adjusting wheel Elevator foot Tilt adjusting wheel Downloaded From projector-manual.com Acer Manuals...
  • Page 22: How To Optimize Image Size And Distance

    Note: Remind as below figure, the space of 131 cm height is required when located at 3m distance. Height: 131 cm from base to top of image Height: 109 cm 3 m Desired Distance Figure: Fixed distance with different zoom and screen size. Downloaded From projector-manual.com Acer Manuals...
  • Page 23 500 x 281 444 x 250 533 x 300 472 x 266 567 x 319 500 x 281 600 x 338 528 x 297 633 x 356 556 x 313 667 x 375 Zoom Ratio: 1.2x Downloaded From projector-manual.com Acer Manuals...
  • Page 24: How To Get A Preferred Image Size By Adjusting Distance And Zoom

    For example: to obtain an image size of 60" set the projector at a distance 2.0 m and 2.4 m from the screen and adjust the zoom level accordingly. Downloaded From projector-manual.com Acer Manuals...
  • Page 25 155 x 87 177 x 100 199 x 112 221 x 125 266 x 149 332 x 187 398 x 224 443 x 249 553x 311 10.0 664 x 374 10.0 12.0 Zoom Ratio: 1.2x Downloaded From projector-manual.com Acer Manuals...
  • Page 26: User Controls

    The new settings will be saved automatically upon exiting the menu. Push the menu button anytime to exit the menu and return to the Acer welcome screen. Downloaded From projector-manual.com Acer Manuals...
  • Page 27: Acer Empowering Technology

    Acer Empowering Technology Acer Empowering Key provide four Acer unique functions, they are "Acer eView Management", "Acer eTimer Management", "Acer ePower Management" and "Acer e3D Management respectively. Press " " key to launch the Onscreen display main menu to modify its function.
  • Page 28: Onscreen Display (Osd) Menus

    The OSD menu will close and the projector will automatically save the new settings. Color Standard Display Mode Main menu Wall color Brightness Contrast Saturation Setting Tint Color Temperature Press Dynamic Black Gamma Advanced Press Adjust Select Main Menu Sub menu Downloaded From projector-manual.com Acer Manuals...
  • Page 29: Color

    Tint Adjusts the color balance of red and green. • Press to increase the amount of green in the image. • Press to increase the amount of red in the image. Downloaded From projector-manual.com Acer Manuals...
  • Page 30: Color Temperature

    Adjusts signal noise reduction."0" means the noise reduction is off, ">0" increase noise reduction. Black Extension This ensures optimum black level for each analog source. Note: "Saturation" and "Tint" functions are not supported under computer or HDMI mode. Downloaded From projector-manual.com Acer Manuals...
  • Page 31: Image

    Adjust image distortion caused by tilting projection. (±40 degrees) <Note> The Manual Keystone function is unavailable under Auto Keystone setting to "On". Sharpeness Adjusts the sharpness of the image. • Press to decrease the sharpness. • Press to increase the sharpness. Downloaded From projector-manual.com Acer Manuals...
  • Page 32 Overscan: Always keep overscan on HDMI image. Note: "H. Position", "V. Position", "Frequency" and "Tracking" functions are not supported under HDMI or Video mode. Note: "HDMI Color Range" and "HDMI Scan Info" functions are only supported under HDMI mode. Downloaded From projector-manual.com Acer Manuals...
  • Page 33: Setting

    The factory default setting of "Timeout(Min.)" is "Off". • Once the security function is enabled, the projector will request user to enter password when switch on the projector . Both "User Password" and "Administrator Password" can be accepted for this dialogue. Downloaded From projector-manual.com Acer Manuals...
  • Page 34 Security Card (please check accessory in the box). This unique password is the number which will be accepted by projector anytime no matter what the Administrator Password is. • If losing this security card and number, please contact with an Acer service center. Downloaded From projector-manual.com Acer Manuals...
  • Page 35: Management

    Alarm Volume Middle Select Adjust Main Menu Volume • Press to decrease the volume. • Press to increase the volume. • Mute Choose "On" to mute the volume. • Choose "Off" to restore the volume. Downloaded From projector-manual.com Acer Manuals...
  • Page 36 If you see a discrete or overlapping image while wearing DLP 3D glasses, you may need to execute "Invert" to get best match of left/right image sequence to get the correct image (for DLP 3D). Downloaded From projector-manual.com Acer Manuals...
  • Page 37: Language

    Note: There has reminder screen if 3D still enable when power on projector. Please adjust setting depended on your purpose. Language Language Select Confirm Main Menu Language Choose the multilingual OSD menu. Use the to select your preferred menu language. • Press to confirm the selection. Downloaded From projector-manual.com Acer Manuals...
  • Page 38: Appendices

    Appendices Troubleshooting If you experience a problem with your Acer projector, refer to the following troubleshooting guide. If the problem persists, please contact your local reseller or service center. Image Problems and Solutions Problem Solution No image appears • Connected as described in the "Getting Started"...
  • Page 39 Set up the display format to 16:9 (wide) aspect ratio on your DVD player. • If you play an Letterbox(LBX) format DVD title, please change the format to Letterbox(LBX) in the projector OSD. Downloaded From projector-manual.com Acer Manuals...
  • Page 40: Problems With The Projector

    If this happens, the projector will not turn on until the lamp module has been replaced. To replace the lamp, follow the procedures in the "Replacing the Lamp" section. Downloaded From projector-manual.com Acer Manuals...
  • Page 41: Osd Messages

    Lamp will automatically turn off soon. Replace the lamp - the lamp is about to reach its maximum lifetime. Prepare to replace it soon. Lamp is approaching the end of its useful life in full power operation. Replacement suggested! Downloaded From projector-manual.com Acer Manuals...
  • Page 42: Led & Alarm Definition Listing

    “Projector Overheated.” Fan lock error OSD shows 0.5 second red “Fan Fail, Will H(On), 0.5 automatically turn off second L(Off) soon” flashing Lamp error (Lamp, ballast) Color Wheel fail 0.5 second H(ON), 0.5 second L(OFF) flashing Downloaded From projector-manual.com Acer Manuals...
  • Page 43: Replacing The Lamp

    To replace the lamp module, reverse the previous step. Warning: To reduce the risk of personal injury, do not drop the lamp module or touch the lamp bulb. The bulb may shatter and cause injury if it is dropped. Downloaded From projector-manual.com Acer Manuals...
  • Page 44: Ceiling Mount Installation

    Ceiling Mount Base - Attach to ceiling Short Rod Long Rod Extension Rod Long Cylinder Cap Allen Key Screw Type A - For tightening/loosening 50 mm length / 8 mm diameter - Tightening Screw Medium Rod Downloaded From projector-manual.com Acer Manuals...
  • Page 45 Use two washers for extra support, if deemed necessary. Attach the ceiling bracket to the ceiling rod. Large cylinder cap Allen Key - For tightening/loosening Screw Type A Tightening Screw 50 mm length/ 8 mm diameter Downloaded From projector-manual.com Acer Manuals...
  • Page 46 3 mm diameter screws are enclosed in the screw pack. Models Screw Type B Washer Type Diameter (mm) Length (mm) Large Small H7532BD/E152D/ HE-812 SCREW SPEC. M3 x 25 mm 150.00 mm Downloaded From projector-manual.com Acer Manuals...
  • Page 47: Specifications

    Specifications The specifications listed below are subject to change without notice. For final specs, please refer to Acer's published marketing specifications. Projection system ® Resolution Native: 1080P (1920 x 1080), Maximum: UXGA (1600 x 1200), WSXGA+ (1680 x 1050), 1080P (1920 x 1080),...
  • Page 48 Remote control x1 • Batteries x2 (for remote control) • User's Guide (CD-ROM) x1 • Quick start guide x1 • Security card x1 • Carrying case x1 * Design and specifications are subject to change without notice. Downloaded From projector-manual.com Acer Manuals...
  • Page 49: Compatibility Modes

    1400x1050 65.3 UXGA 1600x1200 75.0 PowerBook G4 640x480 34.4 PowerBook G4 640x480 66.6(67) 34.9 PowerBook G4 800x600 37.9 PowerBook G4 1024x768 48.4 PowerBook G4 1152x870 68.7 PowerBook G4 1280x960 75.0 i Mac DV(G3) 1024x768 60.0 Downloaded From projector-manual.com Acer Manuals...
  • Page 50 1080p 1920x1080 23.97/24 1080p 1920x1080 67.5 1080p 1920x1080 56.3 B. HDMI Digital HDMI - PC Signal Modes Resolution V.Frequency [Hz] H.Frequency [KHz] 640x480 31.5 640x480 37.9 640x480 37.5 640x480 43.3 640x480 61.9 SVGA 800x600 35.1 Downloaded From projector-manual.com Acer Manuals...
  • Page 51 1024x768 60.0 HDMI - Extended Wide timing Modes Resolution V.Frequency [Hz] H.Frequency [KHz] WXGA 1280x768 47.8 1280x768 60.3 1280x768 68.6 1280x720 44.8 1280x720 92.9 1280x800 49.6 1440x900 55.9 WSXGA+ 1680x1050 65.3 1366x768 47.7 1920x1080 67.5 Downloaded From projector-manual.com Acer Manuals...
  • Page 52 1080p (Side by Side (Half)) 1920x1080 56.3 1080p (Side by Side (Half)) 1920x1080 67.5 Horizontal scan rate: 15k-100 kHz Graphic source monitor range limits Vertical scan rate: 24-120 Hz Analog:165 MHz Max. pixel rate: Digital:165 MHz Downloaded From projector-manual.com Acer Manuals...
  • Page 53 1920x1080 50(25) 28.1 1080p 1920x1080 23.97/24 27.0 1080p 1920x1080 28.1 1080p 1920x1080 29.97/30 33.8 Horizontal scan rate: 15k-50 kHz Graphic source monitor range limits Vertical scan rate: 24-60 Hz Max. pixel rate: Digital: 75 MHz Downloaded From projector-manual.com Acer Manuals...
  • Page 54: Regulations And Safety Notices

    (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Notice: Canadian users This Class B digital apparatus complies with Canadian ICES-003. Downloaded From projector-manual.com Acer Manuals...
  • Page 55: Declaration Of Conformity For Eu Countries

    Cet appareil numérique de la classe B est conforme a la norme NMB-003 du Canada. Declaration of Conformity for EU countries Acer hereby declares that this projector series is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Compliant with Russian regulatory certification...
  • Page 56: Declaration Of Conformity

    New Taipei City 221, Taiwan Declaration of Conformity Acer Incorporated 8F, 88, Sec. 1, Xintai 5th Rd., Xizhi, New Taipei City 221, Taiwan Contact Person: Mr. RU Jan, e-mail:ru_jan@acer.com.tw And, Acer Italy s.r.l Via Lepetit, 40, 20020 Lainate (MI) Italy Tel: +39-02-939-921, Fax: +39-02 9399-2913, www.acer.it...
  • Page 57 Article 3.2 Spectrum Usages -. EN300 328 -. EN301 893 (Applicable to 5GHz high performance RLAN). Year to begin affixing CE marking 2012. Dec. 7, 2012 _______________________________ RU Jan/Sr. Manager Date Regulation Center, Acer Inc. Downloaded From projector-manual.com Acer Manuals...
  • Page 58 Name of Responsible Party: Acer America Corporation Address of Responsible Party: 333 West San Carlos St. Suite 1500 San Jose, CA 95110 U. S. A. Contact Person: Acer Representative Phone No.: 254-298-4000 Fax No.: 254-298-4147 Downloaded From projector-manual.com Acer Manuals...
