ASSEMBLY INSTRUCTIONS
1. Hold the bracket (DD) against the wall
at the desired height.Mark the hole
positions with a marking pencil (not
included). Make sure the holes are level.
Using a 1/4 in. masonry bit (not included),
drill three holes into the pre-marked
keyhole positions.
2.
Insert the wall anchors (BB).
Hardware Used
BB
Wall Anchor
3.
Install bracket (DD) by securing the
pinhead screws (AA) into the anchors
(BB) through the bracket (DD).
Hardware Used
AA
Pinhead
Screw
1
2
x 7
3
x 7
4
BB
DD
AA
