Summary of Contents for Crown XTi series

  • Page 1: Service Manual

    找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 Service Manual XTi Series...
  • Page 2 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 Table of Contents Section 1…………………….Digital systems Overview 1.1…………………..Amplifier Operation 1.2…………………..Power Supply Operation 1.3…………………..Tracker Supply Operation Section 2…………………….Assembly Drawings 2.1…………………..XTi1000 PWA BOM 139087-14 2.2………………..XTi1000 Schematic 139087-14 2.3…………………..XTi2000 PWA BOM 139086-14 2.4………………..XTi2000 Schematic 139086-14 2.5…………………..XTi4000 PWA BOM 138349-14 2.6…..……………..XTi4000 Schematic 138349-14 Section 3…………………….Firmware Notes Section 4…………………….Tech Notes...
  • Page 3 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 CEquel Digital Systems Overview...
  • Page 4 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 CEquel Digital Systems Overview Page 2 of 16...
  • Page 5 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 CEquel Digital Systems Overview Modes of Operation The CEquel microprocessor, LPC2142 can function in several different modes of operation. This document will describe what those modes are, how to get to them and how to use them. The Modes are listed below along with a brief description.
  • Page 6 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 CEquel Digital Systems Overview Chassis Diagnostic Test Mode (Amp Info – Diagnostics): NOTE: This mode is available to all users. Entered by pressing all three front panel buttons for > 3 seconds. Exit by successfully pressing SEL at any time. IMPORTANT!!!!: When you are in the “AMP INFO”...
  • Page 7 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 CEquel Digital Systems Overview rmware Page 5 of 16...
  • Page 8 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 CEquel Digital Systems Overview Page 6 of 16...
  • Page 9 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 CEquel Digital Systems Overview Updating Firmware RS-232 Method Part 1. If the microcontroller (U1, LPC2142) has NEVER been programmed before Connect the Serial 4-pin header to J2. IMPORTANT!! The header MUST be connected with the correct polarity or fatal damage can result.
  • Page 10 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 CEquel Digital Systems Overview Part 2. If the microcontroller (U1, LPC2142) has been previously programmed. To reprogram a device, it is first necessary to put it in bootloader mode. This is done by shorting TP17 to ground during a power up. After the unit powers up, the ground can be removed or left connected, doesn’t matter.
  • Page 11 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 CEquel Digital Systems Overview Programming the microcontroller (U1) and serial flash (U15) via USB Connect the amplifier to a PC via USB. Open up the CLoader Utility 2.10 or newer If fw is older than 1.0.22.0 send .hex file. Otherwise, send .s file How to Use the CLoader Utility Instructions: Simply run this utility with an amplifier connected to USB, it should show up in the dialog window.
  • Page 12 This is where we store the released version of firmware for all products. It can also usually be found in the forums section of the Crown web site (www.crownaudio.com) -The next place to look would be my share drive. I usually keep beta firmware and different versions of the CLoader Utility there.
  • Page 13 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 CEquel Digital Systems Overview Quick explanation of firmware update operation (Bootloaders) There are two sources of non-volatile flash on the CEquel amps. 1. 64kBytes of on-chip flash on U1 the microcontroller. (Program) 2. 2M-bits (256 kBytes) of serial flash U15. (Program and Data Memory) When firmware is loaded via RS-232, it uses a very low level bootloader on the microcontroller and only the on-chip flash is reprogrammed.
  • Page 14 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 CEquel Digital Systems Overview Serial Flash Memory Map (M45PE20) Page 12 of 16...
  • Page 15 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 CEquel Digital Systems Overview Protection Features Thermal Limiter The thermal limiter should have the following profile. The limiter threshold should be ramped down very smooth and slow to -24dB (0.25 dB/sec). The release from -24dB to 0 should also be very smooth and slow (0.125 dB/sec).
  • Page 16 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 CEquel Digital Systems Overview Clip Eliminator The clip eliminator is based completely on the clip signal from the amplifier. The DSP/uP has no other information about output signal of the amplifier. Given the latency of the amplifier and conversion stages, the fastest the output signals can be limited is about 15ms.
  • Page 17 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 CEquel Digital Systems Overview Shorted Output Protection (2000/4000 models only) This is really an extension of the clip limiter. It is based on the number of clip events. If the clip eliminator routine has counted 243 clip events and run the limiter all the way down to -24dB, it continues to count clip events.
  • Page 18 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 CEquel Digital Systems Overview Page 16 of 16...
  • Page 19 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 Section 1.1 Amplifier Operation...
  • Page 20 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 Cequal Amplifier Operation Details Rev A 8-28-2006 AA OVERVIEW Note: Sketches and waveform tifs have been added to this section to clarify the various concepts related to the amplifier and its system level behavior. For XTI 1000 and DSI 1000 amplifier schematics with voltage and currents references, use channel 1 of 139087-6ref.tif which is sheet 4.
  • Page 21 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 voltage stresses on Q105 and Q107. The temperature compensated servo transistor Q109 is located under the same heat sink ( + ) and near the LM75. The bias set string with D174, R180, R144 and R179 run about 400ua and are not under that heat sink. With the pot R144 centered an bias on the collector to emitter voltage of Q109 measured across C109 should land about 1.9 to 2 volts.
  • Page 22 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 C124 is a dc block and thus provides some high pass. R130, R132 (main feedback) and C104 form the voltage feedback and high pass function for the power stage. D3 is a clamp function. Using standard long stepped bursts of waveforms will result a normal high pass step recovery of the at the amplifier output, which may initially look abnormal to other high passed amplifiers.
  • Page 23 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 Other suspects; Q116,Q134 leakey? Try REPAIRnotes.txt 1 page with “power off”. c) Destructive. Discharge power caps. TP26 to TP27. Remove any load. Measure the following; 1) TO-220 to TO-220 sink…should be >90 ohms. If not, D180, D181, D182, D191 are shorted. 2) Q114 (TO-220 sink) to HS1 amp + sink…should be >>1K….suspect Q114 device 3) Q115 (TO-220 sink) to HS2 amp –...
  • Page 24 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 Section 1.2 Power Supply Operation...
  • Page 25 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 XTi Power Supply Operation Rev 1 8/9/06 EMB Note: Any component references will be to the –8 revision level but should be backward compatible except where additions have been made. 1K: 139087, 2K: 139086, 4K: 138349 Brief summary of operation The power supplies within all of the XTi models are very similar.
  • Page 26 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 The energy is magnetically coupled to the secondary of the transformer and hence C43- C48. Energy is also transferred back to C196 through D26. If the voltage at C196 is maintained at a point greater then the lower bound for the Vkstart sense comparator, U16B, then the controller circuitry becomes sustained by the converter itself and the kick start cycle is terminated.
  • Page 27 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 The current through the converter is passively limited two main variables. The current through the converter is directly proportional to the input voltage. The current is also limited by the tank design itself, C68 and L3.
  • Page 28 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 Section 1.3 Tracker Supply Operation...
  • Page 29 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 Tracker Theory of Operations Ben Carroll 8/4/2006 Rev 1 – initial version The tracker operation in the XTi products and its derivatives is an extension of the classic class H supply (used in the XS amplifier) and is also similar to the VZ supply used in the MA3600 and MA5000.
  • Page 30 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 Error Amplifier U23A is an error amplifier is of the inverting type. The demands and feedback signal both feed a virtual ground at the inverting input. Both local feedback around the error amplifier and global feedback from the amplifier rail are employed. A single diode (D73) provides an asymmetric voltage clamp that properly bounds the error amplifier.
  • Page 31 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 commanded by the TL494 control IC at about 500kHz. The power stage connects to the high (+V1) and low (+LR1) voltage rails. L4 in combination with C84 and C49 form a order lowpass filter that filters the high frequency switching energy to form the output voltage that feeds the amplifier power stage predrivers, drivers, and outputs.
  • Page 32 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 Section 2 XTi Assembly Drawings...
  • Page 33 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载...
  • Page 34 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载...
  • Page 35 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载...
  • Page 36 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载...
  • Page 37 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载...
  • Page 38 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 Section 2.1 XTi1000 BOM PWA 139087-14...
  • Page 39 INCLUDING ASSOCIATED ELECTRONIC REPRODUCTIONS ARE FOR REFERENCE ONLY THESE DRAW INGS AND SPECIFICATIONS ARE THE PROPERTY OF CROWN INTERNATIONAL, INC. AND SHALL NOT BE REPRODUCED, COPIED, OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION.
  • Page 40 CAP, 1UF X2 REDUCED SIZE 137030-1 CAP, 1UF X2 REDUCED SIZE 137455-1 CAP, 4700 PF 10% FILM Y2 137455-1 CAP, 4700 PF 10% FILM Y2 OPEN OPEN XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 2 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 41 .1UF 250V 5% MTL POLY FILM T/A C113 139705-1 CAP, 0.33UF 50V 5% X7R 1206 C114 103429-472K5 .0047UF 250V 10% X7R 1206 T/R C115 126623-1 47UF 16V 6.3X5.5MM 20% SMT XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 3 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 42 1500PF 50V 5% NPO MLC 0805 T/R C171 102438-470J2 47PF 200V 5% NPO 0805 C172 A10434-472JD .0047UF 250VDC 5% MET POLY T/A N 11 C173 OPEN B 10 C174 OPEN B 10 XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 4 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 43 CAP, 0.1UF 25V 10% X7R 0603 B 11 C228 102438-150J2 CAP, 15PF 5% 200V NPO 0805 C229 OPEN C230 OPEN C231 OPEN L 10 C232 OPEN M 11 C233 OPEN XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 5 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 44 .1UF 250V 5% MTL POLY FILM T/A C291 102438-150J2 CAP, 15PF 5% 200V NPO 0805 C292 102438-150J2 CAP, 15PF 5% 200V NPO 0805 C293 OPEN K 12 XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 6 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 45 CAP, 0.1UF 25V 10% X7R 0603 C966 135505-1 CAP, 0.1UF 25V 10% X7R 0603 C967 135505-1 CAP, 0.1UF 25V 10% X7R 0603 C968 135505-1 CAP, 0.1UF 25V 10% X7R 0603 XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 7 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 46 DIODE, ZENER 500MW 16V SOD 123 OPEN OPEN B 10 OPEN OPEN OPEN OPEN K 10 OPEN OPEN 126549-1 DIODE,30V 200MA SCHOTTKY SOT23 OPEN OPEN OPEN OPEN OPEN XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 8 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 47 DIODE, DUAL MMBD4148SE SOT-23 D134 135343-1 DIODE, DUAL MMBD4148SE SOT-23 D135 135343-1 DIODE, DUAL MMBD4148SE SOT-23 D136 135343-1 DIODE, DUAL MMBD4148SE SOT-23 D137 135343-1 DIODE, DUAL MMBD4148SE SOT-23 XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 9 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 48 Q 10 F1XX C 8908-3 CLIP, DUAL FUSE PC MOUNT Q 10 125846-1 FERRITE BEAD, 600 OHM .5A 0805 125846-1 FERRITE BEAD, 600 OHM .5A 0805 XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 10 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 49 HS6E 102719-1 6-32X.312 TORX PAN HD TFS HS6F 139737-1 XSISTOR, PNP MJ15025G HS6G 102719-1 6-32X.312 TORX PAN HD TFS HS6H 102719-1 6-32X.312 TORX PAN HD TFS XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 11 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 50 K 12 139530-1 CONN, 20PIN HEADER 0.1" CTR SHROUDED TH OPEN F 11 OPEN H 12 101571-1 HDR, 2 POS .1 CTR MTA SHRD J 11 OPEN XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 12 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 51 C 7448-1 MMBT3904 CHIP NPN J 11 125798-1 XSTR,MMBT3906 LT3 10K REEL 131046-1 TRANSISTOR, KSC3265 NPN SOT-23 131047-1 TRANSISTOR, KSA1298 PNP SOT-23 139706-1 PRP, 137992-1 (40NC60VD) .420 XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 13 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 52 PRP, 136168/137779 GRN (15033) Q115 139425-1 PRP, 136167/137779 BLU (15032) Q116 501972-1 MPSA92 300V PNP T/A Q117 C 3810-6 MPSA42 300V NPN T/R Q119 501972-1 MPSA92 300V PNP T/A XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 14 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 53 RES, 2.49 KOHM 1/16W 1% 0603 A11368-24910 RES, 2.49 KOHM 1/16W 1% 0603 A11368-10020 RES, 10.0 KOHM 1/16W 1% 0603 A11368-24910 RES, 2.49 KOHM 1/16W 1% 0603 XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 15 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 54 301 OHM .1W 1% 0805 T/R N 12 A11368-1R001 1 OHM .1W 1% 0805 T/R N 12 OPEN OPEN B 10 A11368-10010 RES, 1.0 KOHM 1/16W 1% 0603 XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 16 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 55 100 OHM 0.25W 1% 1210 T/R R151 A11368-51R10 RES, 51.1 OHM 1/16W 1% 0603 R152 A11368-51R10 RES, 51.1 OHM 1/16W 1% 0603 R153 OPEN R154 OPEN XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 17 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 56 RES, 47.5 K OHM 1/16W 1% 0603 R212 A11368-36511 3.65KOHM .1W 1% 0805 T/R R213 A11368-47520 RES, 47.5 K OHM 1/16W 1% 0603 R214 A11368-20021 20.KOHM .1W 1% CHIP 0805 XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 18 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 57 A11371-0R01 RES, 0 OHM 0805 50 MILOHM MAX R272 A11371-0R01 RES, 0 OHM 0805 50 MILOHM MAX R273 A11371-0R01 RES, 0 OHM 0805 50 MILOHM MAX XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 19 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 58 RES, 10.0 KOHM 1/16W 1% 0603 R332 A11368-35720 RES, 35.7K OHM 1% 1/16W 0603 R333 A11368-10010 RES, 1.0 KOHM 1/16W 1% 0603 R334 A11368-47510 RES, 4.75 KOHM 1/16W 1% 0603 XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 20 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 59 R390 A11368-42200 RES, 422 OHM 1/16W 1% 0603 I 11 R391 OPEN R392 OPEN C 10 R393 A11368-10R00 RES, 10 OHM 1/16W 1% 0603 G 11 XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 21 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 60 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R R451 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R R452 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 22 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 61 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R R510 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R R511 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 23 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 62 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R R569 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R R570 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 24 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 63 R617 OPEN R618 OPEN R619 OPEN R620 OPEN R621 OPEN R622 OPEN R623 OPEN R624 OPEN R625 OPEN R626 OPEN R627 OPEN R628 OPEN R629 OPEN XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 25 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 64 133.KOHM .1W 1% CHIP 0805 R688 A11368-13331 133.KOHM .1W 1% CHIP 0805 R689 A11368-51111 5.11KOHM .1W 1% 0805 T/R R690 A11368-30120 RES, 30.1 KOHM 1/16W 1% 0603 XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 26 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 65 OPEN R748 OPEN K 10 R749 OPEN R750 A11371-0R01 RES, 0 OHM 0805 50 MILOHM MAX R751 A11368-10R00 RES, 10 OHM 1/16W 1% 0603 F 11 XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 27 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 66 29.4 KOHM .1W 1% 0805 T/R R816 A11368-20003 RES, 200 OHM 1% 0.25W 1210 T/R R817 A11368-20003 RES, 200 OHM 1% 0.25W 1210 T/R R818 OPEN XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 28 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 67 TP18 OPEN TP19 OPEN TP20 OPEN A 11 TP21 127064-1 TEST POINT, SMT 1206 TP22 127064-1 TEST POINT, SMT 1206 TP26 127064-1 TEST POINT, SMT 1206 XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 29 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 68 IC, 28-BIT PROCESSOR AD1940 OPEN J 11 OPEN K 11 OPEN K 11 OPEN L 11 132014-1 XTAL, 16MHZ 20PF LOAD SMT Y901 137778-1 OSC, 12.288MHZ XTi1000 BOM 139087-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 30 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 69 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 Section 2.2 XTi1000 Schematic 139087-14...
  • Page 70 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载...
  • Page 71 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载...
  • Page 72 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载...
  • Page 73 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载...
  • Page 74 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载...
  • Page 75 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载...
  • Page 76 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载...
  • Page 77 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 Section 2.3 XTi2000 BOM PWA 139086-14...
  • Page 78 INCLUDING ASSOCIATED ELECTRONIC REPRODUCTIONS ARE FOR REFERENCE ONLY THESE DRAW INGS AND SPECIFICATIONS ARE THE PROPERTY OF CROWN INTERNATIONAL, INC. AND SHALL NOT BE REPRODUCED, COPIED, OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION.
  • Page 79 CAP, 1UF X2 REDUCED SIZE 137030-1 CAP, 1UF X2 REDUCED SIZE 137455-1 CAP, 4700 PF 10% FILM Y2 137455-1 CAP, 4700 PF 10% FILM Y2 OPEN OPEN XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 2 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 80 .1UF 250V 5% MTL POLY FILM T/A C113 139705-1 CAP, 0.33UF 50V 5% X7R 1206 C114 103429-472K5 .0047UF 250V 10% X7R 1206 T/R C115 126623-1 47UF 16V 6.3X5.5MM 20% SMT XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 3 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 81 .0047UF 250VDC 5% MET POLY T/A N 11 C173 A11369-471F2 470.PF 50V 1% NPO MLC 0805 B 10 C174 A11369-102F2 1000PF 50V 1% CHIP CAP B 10 XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 4 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 82 CAP, 10PF 5% 50V NPO 0603 L 10 C232 A10434-472JD .0047UF 250VDC 5% MET POLY T/A M 11 C233 139719-1 CAP, 1.0UF 25V X7R 10% 0805 XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 5 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 83 .1UF 250V 5% MTL POLY FILM T/A C291 102438-150J2 CAP, 15PF 5% 200V NPO 0805 C292 102438-150J2 CAP, 15PF 5% 200V NPO 0805 C293 OPEN K 12 XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 6 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 84 CAP, 0.1UF 25V 10% X7R 0603 C966 135505-1 CAP, 0.1UF 25V 10% X7R 0603 C967 135505-1 CAP, 0.1UF 25V 10% X7R 0603 C968 135505-1 CAP, 0.1UF 25V 10% X7R 0603 XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 7 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 85 DIODE, ULTRAFAST 200V 1A SMA 140328-1 PRP; 133708-1 (R3060P2) .360 140328-1 PRP; 133708-1 (R3060P2) .360 125255-1 DIODE, ULTRAFAST 200V 1A SMA 131648-1 DIODE, ZENER 500MW 16V SOD 123 XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 8 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 86 DIODE, DUAL MMBD4148SE SOT-23 D134 135343-1 DIODE, DUAL MMBD4148SE SOT-23 D135 135343-1 DIODE, DUAL MMBD4148SE SOT-23 D136 135343-1 DIODE, DUAL MMBD4148SE SOT-23 D137 135343-1 DIODE, DUAL MMBD4148SE SOT-23 XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 9 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 87 Q 10 F1XX C 8908-3 CLIP, DUAL FUSE PC MOUNT Q 10 125846-1 FERRITE BEAD, 600 OHM .5A 0805 125846-1 FERRITE BEAD, 600 OHM .5A 0805 XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 10 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 88 HS6E 102719-1 6-32X.312 TORX PAN HD TFS HS6F 139739-1 XSISTOR, PNP MJ21193G HS6G 102719-1 6-32X.312 TORX PAN HD TFS HS6H 102719-1 6-32X.312 TORX PAN HD TFS XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 11 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 89 CONN, 20PIN HEADER 0.1" CTR SHROUDED TH OPEN F 11 OPEN H 12 101571-1 HDR, 2 POS .1 CTR MTA SHRD J 11 127064-1 TEST POINT, SMT 1206 XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 12 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 90 C 7448-1 MMBT3904 CHIP NPN J 11 125798-1 XSTR,MMBT3906 LT3 10K REEL 131046-1 TRANSISTOR, KSC3265 NPN SOT-23 131047-1 TRANSISTOR, KSA1298 PNP SOT-23 139543-1 PRP, 134423-1 (30N60A4D) .420 XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 13 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 91 C 8104-9 MPSW92 300V 1 WATT PNP T/R Q117 C 8103-1 MPSW42 300V 1 WATT NPN T/R Q119 C 8104-9 MPSW92 300V 1 WATT PNP T/R XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 14 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 92 RES, 2.49 KOHM 1/16W 1% 0603 A11368-24910 RES, 2.49 KOHM 1/16W 1% 0603 A11368-10020 RES, 10.0 KOHM 1/16W 1% 0603 A11368-24910 RES, 2.49 KOHM 1/16W 1% 0603 XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 15 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 93 1 OHM .1W 1% 0805 T/R N 12 A11368-75000 RES, 750 OHM 1/16W 1% 0603 A11368-10020 RES, 10.0 KOHM 1/16W 1% 0603 B 10 A11368-10010 RES, 1.0 KOHM 1/16W 1% 0603 XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 16 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 94 RES, 51.1 OHM 1/16W 1% 0603 R152 A11368-51R10 RES, 51.1 OHM 1/16W 1% 0603 R153 A11368-13011 1.3KOHM .1W 1% 0805 T/R R154 A11368-13011 1.3KOHM .1W 1% 0805 T/R XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 17 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 95 RES, 47.5 K OHM 1/16W 1% 0603 R212 A11368-36511 3.65KOHM .1W 1% 0805 T/R R213 A11368-47520 RES, 47.5 K OHM 1/16W 1% 0603 R214 A11368-35721 35.7 KOHM 0.1W 1% 0805 T/R XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 18 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 96 R270 A11368-12111 RES, 1.21K 1% 0.1W SMT 0805 R271 A11368-12111 RES, 1.21K 1% 0.1W SMT 0805 R272 A11368-12111 RES, 1.21K 1% 0.1W SMT 0805 R273 OPEN XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 19 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 97 RES, 10.0 KOHM 1/16W 1% 0603 R332 A11368-35720 RES, 35.7K OHM 1% 1/16W 0603 R333 A11368-10010 RES, 1.0 KOHM 1/16W 1% 0603 R334 A11368-47510 RES, 4.75 KOHM 1/16W 1% 0603 XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 20 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 98 RES, 100 OHM 1/16W 1% 0603 R392 A11368-49910 RES, 4.99 KOHM 1/16W 1% 0603 C 10 R393 A11368-10R00 RES, 10 OHM 1/16W 1% 0603 G 11 XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 21 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 99 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R R451 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R R452 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 22 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 100 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R R510 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R R511 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 23 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 101 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R R569 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R R570 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 24 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 102 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R R628 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R R629 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 25 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 103 200K 0.1W 1% SMD CHIP 0805 R688 A11368-20031 200K 0.1W 1% SMD CHIP 0805 R689 A11368-51111 5.11KOHM .1W 1% 0805 T/R R690 A11368-24920 RES, 24.9 KOHM 1/16W 1% 0603 XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 26 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 104 K 10 R749 A11368-49910 RES, 4.99 KOHM 1/16W 1% 0603 R750 A11368-10011 1.KOHM .1W 1% CHIP 0805 R751 A11368-10R00 RES, 10 OHM 1/16W 1% 0603 F 11 XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 27 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 105 A11368-20003 RES, 200 OHM 1% 0.25W 1210 T/R R817 A11368-20003 RES, 200 OHM 1% 0.25W 1210 T/R R818 A11371-0R01 RES, 0 OHM 0805 50 MILOHM MAX XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 28 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 106 TP18 OPEN TP19 OPEN TP20 OPEN A 11 TP21 127064-1 TEST POINT, SMT 1206 TP22 127064-1 TEST POINT, SMT 1206 TP26 127064-1 TEST POINT, SMT 1206 XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 29 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 107 IC, 28-BIT PROCESSOR AD1940 OPEN J 11 OPEN K 11 OPEN K 11 OPEN L 11 132014-1 XTAL, 16MHZ 20PF LOAD SMT Y901 137778-1 OSC, 12.288MHZ XTi2000 BOM 139086-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 30 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 108 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 Section 2.4 XTi2000 Schematic 139086-14...
  • Page 109 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载...
  • Page 110 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载...
  • Page 111 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载...
  • Page 112 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载...
  • Page 113 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载...
  • Page 114 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载...
  • Page 115 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载...
  • Page 116 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 Section 2.5 XTi4000 BOM PWA 138349-14...
  • Page 117 INCLUDING ASSOCIATED ELECTRONIC REPRODUCTIONS ARE FOR REFERENCE ONLY THESE DRAW INGS AND SPECIFICATIONS ARE THE PROPERTY OF CROWN INTERNATIONAL, INC. AND SHALL NOT BE REPRODUCED, COPIED, OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION.
  • Page 118 CAP, 1UF X2 REDUCED SIZE 137030-1 CAP, 1UF X2 REDUCED SIZE 137455-1 CAP, 4700 PF 10% FILM Y2 137455-1 CAP, 4700 PF 10% FILM Y2 OPEN OPEN XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 2 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 119 .1UF 250V 5% MTL POLY FILM T/A C113 139705-1 CAP, 0.33UF 50V 5% X7R 1206 C114 103429-472K5 .0047UF 250V 10% X7R 1206 T/R C115 126623-1 47UF 16V 6.3X5.5MM 20% SMT XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 3 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 120 .0047UF 250VDC 5% MET POLY T/A N 11 C173 A11369-471F2 470.PF 50V 1% NPO MLC 0805 B 10 C174 A11369-102F2 1000PF 50V 1% CHIP CAP B 10 XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 4 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 121 CAP, 10PF 5% 50V NPO 0603 L 10 C232 A10434-472JD .0047UF 250VDC 5% MET POLY T/A M 11 C233 139719-1 CAP, 1.0UF 25V X7R 10% 0805 XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 5 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 122 .1UF 250V 5% MTL POLY FILM T/A C291 102438-150J2 CAP, 15PF 5% 200V NPO 0805 C292 102438-150J2 CAP, 15PF 5% 200V NPO 0805 C293 OPEN K 12 XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 6 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 123 CAP, 0.1UF 25V 10% X7R 0603 C966 135505-1 CAP, 0.1UF 25V 10% X7R 0603 C967 135505-1 CAP, 0.1UF 25V 10% X7R 0603 C968 135505-1 CAP, 0.1UF 25V 10% X7R 0603 XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 7 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 124 DIODE, ULTRAFAST 200V 1A SMA 140328-1 PRP; 133708-1 (R3060P2) .360 140328-1 PRP; 133708-1 (R3060P2) .360 125255-1 DIODE, ULTRAFAST 200V 1A SMA 131648-1 DIODE, ZENER 500MW 16V SOD 123 XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 8 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 125 DIODE, DUAL MMBD4148SE SOT-23 D134 135343-1 DIODE, DUAL MMBD4148SE SOT-23 D135 135343-1 DIODE, DUAL MMBD4148SE SOT-23 D136 135343-1 DIODE, DUAL MMBD4148SE SOT-23 D137 135343-1 DIODE, DUAL MMBD4148SE SOT-23 XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 9 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 126 Q 10 F1XX C 8908-3 CLIP, DUAL FUSE PC MOUNT Q 10 125846-1 FERRITE BEAD, 600 OHM .5A 0805 125846-1 FERRITE BEAD, 600 OHM .5A 0805 XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 10 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 127 HS6E 102719-1 6-32X.312 TORX PAN HD TFS HS6F 139739-1 XSISTOR, PNP MJ21193G HS6G 102719-1 6-32X.312 TORX PAN HD TFS HS6H 102719-1 6-32X.312 TORX PAN HD TFS XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 11 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 128 CONN, 20PIN HEADER 0.1" CTR SHROUDED TH OPEN F 11 OPEN H 12 101571-1 HDR, 2 POS .1 CTR MTA SHRD J 11 127064-1 TEST POINT, SMT 1206 XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 12 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 129 C 7448-1 MMBT3904 CHIP NPN J 11 125798-1 XSTR,MMBT3906 LT3 10K REEL 131046-1 TRANSISTOR, KSC3265 NPN SOT-23 131047-1 TRANSISTOR, KSA1298 PNP SOT-23 139543-1 PRP, 134423-1 (30N60A4D) .420 XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 13 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 130 C 8104-9 MPSW92 300V 1 WATT PNP T/R Q117 C 8103-1 MPSW42 300V 1 WATT NPN T/R Q119 C 8104-9 MPSW92 300V 1 WATT PNP T/R XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 14 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 131 RES, 2.49 KOHM 1/16W 1% 0603 A11368-24910 RES, 2.49 KOHM 1/16W 1% 0603 A11368-10020 RES, 10.0 KOHM 1/16W 1% 0603 A11368-24910 RES, 2.49 KOHM 1/16W 1% 0603 XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 15 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 132 1 OHM .1W 1% 0805 T/R N 12 A11368-75000 RES, 750 OHM 1/16W 1% 0603 A11368-10020 RES, 10.0 KOHM 1/16W 1% 0603 B 10 A11368-10010 RES, 1.0 KOHM 1/16W 1% 0603 XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 16 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 133 RES, 100 OHM 1/16W 1% 0603 R152 A11368-10000 RES, 100 OHM 1/16W 1% 0603 R153 A11368-13011 1.3KOHM .1W 1% 0805 T/R R154 A11368-13011 1.3KOHM .1W 1% 0805 T/R XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 17 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 134 RES, 47.5 K OHM 1/16W 1% 0603 R212 A11368-75011 7.50K .10W 1% CHIP 0805 R213 A11368-47520 RES, 47.5 K OHM 1/16W 1% 0603 R214 A11368-35721 35.7 KOHM 0.1W 1% 0805 T/R XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 18 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 135 R270 A11368-12111 RES, 1.21K 1% 0.1W SMT 0805 R271 A11368-12111 RES, 1.21K 1% 0.1W SMT 0805 R272 A11368-12111 RES, 1.21K 1% 0.1W SMT 0805 R273 OPEN XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 19 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 136 RES, 10.0 KOHM 1/16W 1% 0603 R332 A11368-35720 RES, 35.7K OHM 1% 1/16W 0603 R333 A11368-10010 RES, 1.0 KOHM 1/16W 1% 0603 R334 A11368-47510 RES, 4.75 KOHM 1/16W 1% 0603 XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 20 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 137 RES, 100 OHM 1/16W 1% 0603 R392 A11368-49910 RES, 4.99 KOHM 1/16W 1% 0603 C 10 R393 A11368-10R00 RES, 10 OHM 1/16W 1% 0603 G 11 XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 21 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 138 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R R451 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R R452 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 22 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 139 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R R510 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R R511 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 23 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 140 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R R569 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R R570 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 24 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 141 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R R628 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R R629 A11368-7R503 RES, 7.5 OHM 1% 0.25W 1210 T/R XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 25 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 142 200K 0.1W 1% SMD CHIP 0805 R688 A11368-20031 200K 0.1W 1% SMD CHIP 0805 R689 A11368-51111 5.11KOHM .1W 1% 0805 T/R R690 A11368-22120 RES, 22.1 KOHM 1% 1/16W 0603 XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 26 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 143 K 10 R749 A11368-49910 RES, 4.99 KOHM 1/16W 1% 0603 R750 A11368-10011 1.KOHM .1W 1% CHIP 0805 R751 A11368-10R00 RES, 10 OHM 1/16W 1% 0603 F 11 XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 27 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 144 A11368-20003 RES, 200 OHM 1% 0.25W 1210 T/R R817 A11368-20003 RES, 200 OHM 1% 0.25W 1210 T/R R818 A11371-0R01 RES, 0 OHM 0805 50 MILOHM MAX XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 28 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 145 TP18 OPEN TP19 OPEN TP20 OPEN A 11 TP21 127064-1 TEST POINT, SMT 1206 TP22 127064-1 TEST POINT, SMT 1206 TP26 127064-1 TEST POINT, SMT 1206 XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 29 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 146 IC, 28-BIT PROCESSOR AD1940 OPEN J 11 OPEN K 11 OPEN K 11 OPEN L 11 132014-1 XTAL, 16MHZ 20PF LOAD SMT Y901 137778-1 OSC, 12.288MHZ XTi4000 BOM 138349-14_A.xls CROWN AUDIO, INC. ELKHART, IN. 30 OF 30 R04.1CDE-004_(Fm) JAW 10/6/01...
  • Page 147 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 Section 2.6 XTi4000 Schematic 138349-14...
  • Page 148 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载...
  • Page 149 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载...
  • Page 150 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载...
  • Page 151 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载...
  • Page 152 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载...
  • Page 153 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载...
  • Page 154 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载...
  • Page 155 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 Section 3.0 Firmware Notes...
  • Page 156 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 Crown XTi V1.1.5.6 Software Release Notes Date: November 14, 2007 Product: Crown XTi Amplifier Previous Software Version: v1.1.4.1 Crown XTi Additions: 1. None Crown XTi Changes: 1. Changed the sequence of events at power up. After initialization the DSP output is muted for a longer period of time to guarantee the amplifier has enough time to bias up before getting signal.
  • Page 157 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 Crown XTi Known Issues: 1. Amplifiers built before September 2006 must use the CLoader utility and .hex file to update firmware. See detailed instructions at: http://www.crownaudio.com/amp_htm/cdi-dsi-xti-firmware-update.htm 2. Older versions of firmware (prior to 1.1.2.9) sent the full serial number to the Windows HID driver. If this driver receives any zeros in the serial number, it will not allow more than one USB amplifier online at a time and will in fact crash very hard when this occurs.
  • Page 158 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 About the CLoader Utility: When you download System Architect from the web, or get it from a CD, the CLoader Utility will be included. The CLoader is a very small and simple program that is used to load new firmware into a USB enabled amplifier.
  • Page 159 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 Section 4.0 Tech Notes...
  • Page 160 Figure 1 Summary: Performing the procedure outlined in this Tech Note assures the conditions listed will not be present. Updates covered in this Tech Note have been incorporated into the Main PWA production modules for this series of Crown amplifiers.
  • Page 161 Figure 1 Summary: Performing the procedure outlined in this Tech Note assures the conditions listed will not be present. Updates covered in this Tech Note have been incorporated into the Main PWA production modules for this series of Crown amplifiers...
  • Page 162 1 – T-15 Torx head Screw driver 1 – T-20 Torx head Screw driver 1 – 220 KOhm, 2W, 5%, metal film resistor. (Crown Part Number (CPN)– 140034-1) Kapton Tape ¼”: Whole roll; (Crown Part Number (CPN)- S 6285-1) Qualified Service Personnel should only perform this procedure. Make sure the unit has been unplugged from the wall receptacle before removing top cover.
  • Page 163 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 Tech Note Crown Technical Support PO Box 1000 Elkhart IN 46515 Ph 800-342-6939/574-294-8200 Fax 574-294-8301 Page 2 of 3 Issue Date: March 26, 2007 Ref. No: Tech Note #184 Rev. A Subject: Discharge resistor modification procedure for all XTi, DSi, and CDi models.
  • Page 164 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 Tech Note Crown Technical Support PO Box 1000 Elkhart IN 46515 Ph 800-342-6939/574-294-8200 Fax 574-294-8301 Page 3 of 3 Issue Date: March 26, 2007 Ref. No: Tech Note #184 Rev. A Subject: Discharge resistor modification procedure for all XTi, DSi, and CDi models.
  • Page 165 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 Tech Note Crown Technical Support PO Box 1000 Elkhart IN 46515 Ph 800-342-6939/574-294-8200 Fax 574-294-8301 Page 1 of 1 Issue Date: 19-Jul-07 Ref. No: Tech Note #186 Subject: XTi4000 does not appear in System Architect Information Only Apply to Service Units Only Update Stock &...
  • Page 166 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 Tech Note Crown Technical Support PO Box 1000 Elkhart IN 46515 Ph 800-342-6939/574-294-8200 Fax 574-294-8301 Page 1 of 1 Issue Date: 3-Aug-07 Ref. No: Tech Note# 187 Subject: Electrolytic Capacitors C47 and C48 Information Only Apply to Service Units Only Update Stock &...
  • Page 167 找资料学技术，故障求助 请到http://bbs.bjjdwx.com 海量维修资料免费下载 Tech Note Crown Technical Support PO Box 1000 Elkhart IN 46515 Ph 800-342-6939/574-294-8200 Fax 574-294-8301 Page 1 of 1 Issue Date: 16-Aug-07 Ref. No: Tech Note# 190 Subject: XTi/CDi/DSi Display boards Information Only Apply to Service Units Only Update Stock &...

This manual is also suitable for:

Xti 1000Xti 2000Xti 4000

Table of Contents

Save PDF
