Crown XTi 1000 Specification Sheet

XTi Series
T he XTi Series of Crown ® amplifi ers are
professional tools designed and built for
portable PA applications. The series
includes four models which are similar except
for output power: XTi 1000, 2000, 4000 and
6000. All are rugged and lightweight, and offer
unmatched value in their class.
XTi-Series amplifi ers feature an LCD screen
with speaker presets for crossover frequen-
cies, EQ, limiting, delay, and a subharmonic
synthesizer. Other features include a switch-
mode universal power supply, useful function
indicators, proportional-speed fan-assisted
cooling, XLR inputs, Speakon ® and bind-
ing-post outputs, short-circuit protection and
more.
With their powerful, reliable performance,
XTi-Series amps easily handle 2-ohm loads
and are capable of chest-thumping lows. Plus,
your investment in an XTi-Series amplifi er is
backed by Crown's Three-Year, No-Fault, Fully
Transferable Warranty.
For more details about the Crown XTi Series,
contact the Crown Technical Support Group at
800-342-6939 or 574-294-8200. Also, visit the
Crown Audio website at www.crownaudio.com.
Specifi cations
Output Power: See power charts below.
Voltage Gain at 1kHz:
XTi 1000: 30.5 dB
XTi 2000: 32.9 dB
XTi 4000: 34.2 dB
XTi 6000: 37.1 dB
Frequency Response: +0/–1 dB from 20 Hz to
20 kHz at 1 watt into 4 ohms.
Load Impedance: Safe with all types of loads.
Rated for 2 to 8 ohms in Stereo mode, 4 to 16
ohms in Bridge-Mono mode. The XTi 1000 A1
(100V version) is rated for 4 to 8 ohms Stereo,
8 to 16 ohms Bridge Mono.
Sensitivity: 1.4V
Signal to Noise Ratio (below rated 1 kHz
power at 8 ohms): XTi 1K, 2K, 4K: 100 dB (A
weighted). XTi 6K: 103 dB (A weighted).
Damping Factor: Better than 500 from 20 Hz
to 400 Hz.
Crosstalk: > 70 dB below rated power, 20 Hz
to 1 kHz.
Input Stage: Input is electronically balanced
and employs precision 1% resistors.
Input Impedance (nominal): 20 k ohms, bal-
anced;10 k ohms, unbalanced.
Maximum Input Signal: +22 dBu typical.
X T i S E R I E S
Features
• Integrated speaker presets with LCD front
panel display
• Accurate, uncolored sound with very low
distortion for the best in music and voice re-
production
• Advanced protection circuitry guards against:
shorted outputs, open circuits, DC, mis-
matched loads, general overheating, high-fre-
quency overloads and internal faults
• Extremely versatile, handling a wide range of
speaker impedances and outputs
AC Line Voltage and Frequency Confi gura-
tions Available: 100V, 120V, 220-240V
50/60 Hz.
AC Line Current (120VAC amplifi er playing 1/8
power pink noise into 4 ohms per ch):
XTi 1000: 6.8A, XTi 2000: 8.3A, XTi 4000:
10.5A; at idle draws no more than 38 watts.
XTi 6000: 15.3A; at idle draws no more than
180 watts.
Operating Temperature: 0° C to 40° C at 95%
relative humidity (non-condensing).
XTi 1000
2 ohm Stereo (per channel)
4 ohm Stereo (per channel)
8 ohm Stereo (per channel)
1,400W*
4 ohm Bridge-Mono
1,000W
8 ohm Bridge-Mono
With 0.5% THD.
*With 1% THD.
†Not rated for 100V versions.
XTi 2000
1,000W*
2 ohm Stereo (per channel)
4 ohm Stereo (per channel)
8 ohm Stereo (per channel)
2,000W*
4 ohm Bridge-Mono
1,600W
8 ohm Bridge-Mono
With 0.5% THD.
*With 1% THD.
• Switch-mode universal power supply
• Speaker presets for crossover frequencies, EQ,
limiting, and delay
• All products fi ll 2U rack spaces and weigh under
19 lb (24 lb for XTi 6000); weight sets a new
standard in lightweight amps
• Speakon ® and binding post outputs, XLR inputs
and loop-thrus
• Comprehensive LED status per channel
• Three-Year, No-Fault, Fully Transferable War-
ranty completely protects your investment and
guarantees its specifi cations
XTi 4000
2 ohm Stereo (per channel)
4 ohm Stereo (per channel)
8 ohm Stereo (per channel)
4 ohm Bridge-Mono
8 ohm Bridge-Mono
With 0.5% THD.
*With 1% THD.
1 kHz
XTi 6000
Power
†
700W*
2 ohm Stereo (per channel)
500W
4 ohm Stereo (per channel)
275W
8 ohm Stereo (per channel)
†
4 ohm Bridge-Mono
8 ohm Bridge-Mono
With 0.5% THD.
*With 1% THD.
1 kHz
Power
800W
475W
1 kHz
Power
1,600W*
1,200W
650W
3,200W*
2,400W
1 kHz
Power
3,000W*
2,100W
1,200W
6,000W*
4,200W
