CORDLESS 2-IN-1 STICK VAC

INSTRUCTION MANUAL

CATALOG NUMBERS
HSV320J32
HSV420J42
HSV520J01
Thank you for choosing BLACK+DECKER!
PLEASE READ BEFORE RETURNING THIS PRODUCT FOR ANY REASON.
SAVE THIS MANUAL FOR FUTURE REFERENCE.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HSV320J32 and is the answer not in the manual?

Questions and answers

Summary of Contents for Black+Decker HSV320J32

  • Page 1: Instruction Manual

    CORDLESS 2-IN-1 STICK VAC INSTRUCTION MANUAL CATALOG NUMBERS HSV320J32 HSV420J42 HSV520J01 Thank you for choosing BLACK+DECKER! PLEASE READ BEFORE RETURNING THIS PRODUCT FOR ANY REASON. SAVE THIS MANUAL FOR FUTURE REFERENCE.
  • Page 2: Safety Guidelines - Definitions

    ENGLISH SAFETY GUIDELINES - DEFINITIONS It is important for you to read and understand this manual. The information it contains relates to protecting YOUR SAFETY and PREVENTING PROBLEMS. The symbols below are used to help you recognize this information. DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
  • Page 3: Additional Safety Warnings

    4. Use of an attachment not recommended or charger that is suitable for one type of sold by BLACK+DECKER may result in a risk battery pack may create a risk of fire of fire, electric shock, or injury to persons.
  • Page 4 Symbols • When using an extension cord, be sure to use one heavy enough to carry the current • The label on your tool may include the your product will draw. An undersized following symbols. The symbols and cord will cause a drop in line voltage their definitions are as follows: resulting in loss of power and overheating.
  • Page 5 FUNCTIONAL DESCIPTION 1. On/off power switch 2. Handle 3. Rotary brush on/off button 4. Hand vac 5. Hand vac release button 6. Dust bowl 7. Floor head 8. Dust bowl release button 9. Charging indicator 10. Charger 11. Brush tool (HSV420J42/ 520J01 only) 12.
  • Page 6: Attaching Accessories

    ATTACHING ACCESSORIES The brush tool (11) is designed for more effective cleaning of upholstered furniture and fabric. The crevice tool (12) allows for vacuuming in narrow and hard to-reach places. CHARGING THE BATTERY CHARGE HOURS 1. Make sure the appliance is switched off. The battery will not be charged with the on/off switch in the on position.
  • Page 7 ON / OFF When using the unit with a fully charged battery, all four LEDs will be illuminated on the charging indicator (9). As the battery discharges during use, the top LED on the charging indicator (9) will turn off, then the next LED down, until the bottom LED.
  • Page 8: Replacing The Filter

    Replacement filter: SVF11. The filters should be replaced every 6 to 9 months and whenever worn or damaged. Replacement filters are available from BLACK+DECKER. REMOVING ROTARY BRUSH • Pinch and lift the plastic tab on the pivoting clip (17) away from the floor head.
  • Page 9: Maintenance

    BLACK+DECKER service center or to your local retailer for recycling. You may also contact your local recycling center for information on where to drop off the spent battery.
  • Page 10: Troubleshooting

    TROUBLESHOOTING Problem Possible Cause Possible Solution • Unit will not start. • Battery not charged. • Check battery charging requirements. • Battery will not charge. • Charger not plugged in. • Plug charger into a working outlet. Refer to “Important Charging Notes”...
