Summary of Contents for Pixio PX347c Prime

  • Page 3 I. Safety Prevention Measures Please always place The altitude and the Do not hold the plug Do not use a broken this device on a stable tropical environment with wethand ; power plug nor keep surface; otherwise, it the adapter fits depend otherwise, electric a power cord near may fall and be dam-...

  • Page 4: Installation Instructions

    II. Installation Instructions 1. Accessories Power cord Base/Stand Warranty card and certificate of conformity Signal cable User manual (The above pictures are for illustration only and the physical accessories shall govern.) 2. Angle Adjustment 2.1 The screen can be adjusted by 2.2 When adjusting the angle of the inclining forward and backward;...
  • Page 5 III. Connect the Monitor to PC Before connecting the LCD monitor to PC, please power the PC and the monitor Power Plug Connect the power cord of the monitor into the POWER port in the back of the monitor. DVI Port Connect the DVI cable into the DVI IN port in the back of the monitor (this needs the support of the monitor).

  • Page 6: User Setup

    IV. User Setup 1. Schematic Diagram of Keys 2. Description of Keys' Functions Pops up the menu/Backs to the previous menu ( in case of main menu, exits from the whole menu) . When the menu is activated, used as the left function selection key, and decreases progressively the value of the progress bar.
  • Page 7 V. Operation Menu (OSD) Function Descriptions Mai n Men u Main Menu Su bmen u Main Menu Su bmen u Main Menu Des cr i pti on Item Icon Item Icon Opti on s Icon Brightness Adjust display brightness NONE NONE NONE NONE...
  • Page 8 Mai n Men u Main Menu Su bmen u Main Menu Su bmen u Main Menu Des cr i pti on Item Icon Item Icon Opti on s Icon Win1Input Switch split screen 1 signal source Win2Input Switch split screen 2 signal source Reset the window display PBP2WIN Reset...
  • Page 9 1. PIP (Picture in Picture) Input Information Picture in Picture Additional Input Source Main screen Window picture input source Swap mode HDMI HDMI Note:"O" means this feature is supported while "X" means it is not supported. The above information is related to input options and the monitor's OSD Menu. For more information on these, refer to the "Basic Setup"...
  • Page 10 VI. FAQ Faults occurring Possible solutions Check if the power is on. The power indicator ◆ light is not on Check if the power cord is connected. ◆ Impossible plug-and-play Check if the function of plug-and-play of the device ◆ is compatible with PC.

  • Page 11: Product Specifications

    VII. Product Specifications Picture Picture Diagonal Dot distance (mm) Optimal resolution aspect ratio dimensions (mm) dimensions 34"(86.36cm) 21:09 797.22*333.72 0.07725*0.23175 3440*1440@60Hz Storage -20 ℃ to 45 ℃ temperature Ambient temperature Working 0 ℃ to 40 ℃ temperature RH for Humidity 10% to 85% operation NNote: The actual application of the above parameters shall be subject to the...
