Joerns Healthcare UltraCare XT User & Service Manual page 16

Joerns® Bed Frames
UltraCare®XT
Drainage Bag Holder (Figure 35)
1. Drainage Bag Holder is designed as an
attachment point for items such as urine collection
bags. Make sure items attached to holder are
safely secured. Prior to use, please read important
warnings related to Drainage Bag Holder and
follow all instructions below
2. Install Drainage Bag Holder and attach items
to holder according to supplied instructions.
3. It is important to operate all bed functions through
their entire ranges to ensure that items attached to
Drainage Bag Holder have proper clearance and
are not pinched or caught.
4. Attach Drainage Bag Holder only to the point
and position outlined in installation instructions.
Operate all bed functions through their full ranges
to ensure that items attached to holder have
proper clearance and are not pinched or caught.
5. Many items that attach to Drainage Bag Holder
are gravity fed and must be below bed user to
function. Do not allow items suspended from
holder to rest on the floor, particularly when bed is
in its lowest position. Otherwise, a safety condition
may occur or the function of attached items may
be impacted.
Figure 35: Note 4-Inch clearance from hook to floor
16
© 2015 Joerns Healthcare • 6110045 RevI • 15-2010
Bed Transport Bar (Figure 36)
1. Bed Transport Bar is designed to ease moving the
UltraCare XT bed, particularly when it is lowered
®
on to its casters. Note: The UltraCare XT bed is
not designed for use as resident/patient transport
devices. Prior to use, please read important
warnings related to Bed Transport Bar and follow
all instructions below.
2. Install Bed Transport Bar according to supplied
instructions.
3. When using Bed Transport Bar to move beds,
always push down and forward on handle. Pushing
up or attempting to use transport bar to lift bed,
especially when crossing over thresholds, may
cause it to disconnect from bed, resulting in loss of
control of bed.
4. Take extra care when moving bed (remember, do
not move bed while occupied by resident) on any
sloped surface. Moving a bed on a sloped surface
requires two people, one at each end of the bed.
Never use Bed Transport Bar to move bed on a
slope that exceeds ANSI and/or ADA requirements
for accessibility.
Figure 36
