12V Jaguar CX-75
Owner's Manual and Assembly Instructions
Model #: W466AC, W466AC-F
Read and understand the entire manual before assembly and operation. The vehicle must be
assembled by an adult who has read and understands the instructions.
Made in China.
Styles and colors may vary. Do not return to store. Call 1-888-982-9309 for assistance and
replacement parts.
IMPORTANT:
Save this manual with your sales receipt.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 12V Jaguar CX-75 and is the answer not in the manual?

Questions and answers

Summary of Contents for Rollplay 12V Jaguar CX-75

  • Page 1 12V Jaguar CX-75 Owner’s Manual and Assembly Instructions Model #: W466AC, W466AC-F Read and understand the entire manual before assembly and operation. The vehicle must be assembled by an adult who has read and understands the instructions. Made in China.
  • Page 2: Specifications

    Introduction Thank you for purchasing this Rollplay vehicle. We hope the rider enjoys it for miles to come. Please read this instruction guide carefully before assembling and operating the vehicle. Please have your model number and serial number ready before calling. Please have proof of purchase.
  • Page 3 Call Customer Service if you need assistance or replacement parts. Please have your model number and serial number ready before calling. Please have proof of purchase. Keep your sales receipt or register your product at www.rollplay.com as we may require proof of purchase. 1-888-982-9309 Read this entire manual to ensure proper assembly and safe operation of the vehicle.
  • Page 4 This page is intentionally left blank.
  • Page 5: Table Of Contents

    Table of Contents Safety ............6 Parts ............8 Charging Instructions .......9 Assemble the Front Wheels ....10 Assemble the Rear Wheels .....11 Attach the Mirrors ........12 Attach the Steering Wheel ......13 Attach the Seat ........14 Door Operation ........15 Operation Instructions ......16 Maintenance ..........17 General Care ..........18 Troubleshooting Guide ......19 FCC Information ........21...
  • Page 6: Safety

    Safety WARNING: SAFETY RIDING RULES The user must follow all safety rules and guidelines, or serious injury or death may occur to the user. • Always use common sense and safe practices when using the vehicle. The user must be at least years old and weigh no more than 35 kg (77 lbs).
  • Page 7 Safety (Continued) WARNING: BATTERY SAFETY • Battery posts, terminals and related accessories contain lead and lead compound (asic) chemicals known to the state of California to cause cancer, reproductive harm, and are toxic and corrosive. DO NOT open the battery. •...
  • Page 8: Parts

    Parts 1. Body 10. Snap Pins (4 + 2 extra) 2. Mirrors (2) 11. Steering Wheel Screw 3. Steering Wheel Assembly 12. Steering Wheel Nut Not Included: 4. Seat 13. MP3 Cable 5. Rear Wheels (2) 14. Blister Pack 6. Front Wheels (2) 15.
  • Page 9: Charging Instructions

    Charging Instructions YOU MUST CHARGE THE BATTERY FOR 24 HOURS BEFORE THE FIRST USE! ONLY AN ADULT SHOULD HANDLE THE BATTERY AND CHARGER. To connect the battery: 1. Ensure the vehicle is stopped and turned off. 2. Unlock and remove the seat. 3.
  • Page 10: Assemble The Front Wheels

    Assemble the Front Wheels Right Wheel Rims Left Wheel Rims 1. Locate the front washer (9) and snap pin (10) from the blister pack. 2. Slide a front washer (9) onto the front axle. 3. Slide the front wheel (6) onto the front axle. 4.
  • Page 11: Assemble The Rear Wheels

    Assemble the Rear Wheels 1. Locate the rear washer (8) and snap pin (10) from the blister pack. 2. Slide the rear wheel (5) with the gear teeth facing inward onto the right rear wheel axle. 3. Line up the gear teeth on the wheel with the grooves on the gear box. 4.
  • Page 12: Attach The Mirrors

    Attach the Mirrors 1. Insert the left mirror into the slot on the left door near the windshield. 2. Push down on the mirror until it clicks into place. 3. Repeat steps 1-2 for the right mirror.
  • Page 13: Attach The Steering Wheel

    Attach the Steering Wheel 1. Open the right door. 2. Locate the steering wheel screw (11) and nut (12) from the blister pack. 3. Plug the steering wheel connector (A) into the dashboard connector (B). 4. Carefully slide the wires into the steering column. 5.
  • Page 14: Attach The Seat

    Attach the Seat 1. Position the seat (4) over the battery compartment. 2. Insert the hooks on the back of the seat into the slots on the body of the car. 3. Ensure the seat is properly clicked into place, then turn the thumbscrew on the seat clockwise to lock it into place.
  • Page 15: Door Operation

    Door Operation 1. Press the button on the inside of one of the doors. 2. Then slightly push the door outward to open the door. 3. Both doors open on the vehicle.
  • Page 16: Operation Instructions

    Operation Instructions Dashboard Lights MP3 Jack Battery Life Indicator Sounds Reset Tuning Power Switch Foot Pedal Shifter • Power Switch: Push the power switch to turn on the car. The power indicator light will turn on when the car is on. Press the power switch again to turn off the car.
  • Page 17: Maintenance

    Maintenance Important Battery and Charger Information • Only an adult who has read and understands the safety warnings may handle and operate the battery and battery charger. Keep away from children. • Charge the battery for 24 hours before using the vehicle for the first time.
  • Page 18: General Care

    General Care • Regularly inspect all vehicle parts to ensure they are in good working condition. • Regularly inspect the charger, cord, plug, and other related parts for damage. • Remove any damaged parts and immediately contact Customer Service for replacement parts. See Service information on Page 22. •...
  • Page 19: Troubleshooting Guide

    Troubleshooting Guide Completely read through the manual and troubleshooting guide before contacting Customer Service. Problem Potential Cause Solution Vehicle does not run Battery is low Recharge the battery Thermal fuse tripped Reset fuse Snap pins are loose Tighten snap pins Loose wires or loose Ensure the battery connectors connectors...
  • Page 20 Problem Potential Cause Solution Vehicle needs a push to Loose wires or loose Ensure the battery connectors start connectors are securely attached. If wires are loose, contact Customer Service “Dead spot” on motor A “dead spot” means electricity is not being delivered to the terminal.
  • Page 21: Fcc Information

    FCC Information This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 22: Service And Repairs

    Hours: 9 AM - 5 PM (CST), Monday - Friday 888-982-9309 Phone: 1- Email: customerservice@rollplay.com Web: www.rollplay.com For a list of available replacement parts, please visit www.rollplay.com. WE WILL REQUIRE PROOF OF PURCHASE. Please save your sales receipt or register your product at www.rollplay.com.
  • Page 23: Warranty

    This warranty does not cover, and is not intended to exclude any liability on the part of Rollplay, whether under this warranty or implied by law for any indirect or consequential damages for breach of warranty. Some states may not allow the exclusion or limitation so this limitation may not apply to you.
  • Page 24: Product Registration

    City: State: Zip Code: Email: Phone: Date of Purchase: The following product information is on the cover of the owner’s manual. Product Name: Model Number: Serial Number: Retailer Place of Purchase: Questions or comments? Contact us at www.rollplay.com or 1-888-982-9309...
