Page 14: Quick Reference Specifications
Part # Tank Size ( DxH ) Media Volume (ft3) Service Flow Rate (GPM) WD SP35BFJCT 10”x44” WD SP46BFJCT 10”x54” WD SP56BFJCT 10”x54” 12.0 WD SP66BFJCT 12”x52” 15.0 Table below contains a summary of specifications for the control valve and bypass valve. QUICK REFERENCE SPECIFICATIONS CLASSIFICATION: Demand initiated regeneration (metered) - Page 15 Service flow rate 1” 27 gpm (102.2 lpm) @ 15 psig (103 kPa) drop Backwash flow rate 1” (includes bypass) 27 gpm (102.2 lpm) @ 25 psig (172) kPa) drop 34 gpm (128.7 lpm) @15 psig (103 kPa) drop Service Flow Rate 1.25” (includes meter) Service Flow Rate 1.25”...
- Page 16 1. Timer does not display time of day a. AC adapter unplugged a. Connect Power b. No electric power at b. Repair outlet or use working outlet outlet c. Defective AC adapter c. Replace AC adapter d. Defective PC board d.
- Page 17 ERROR code: 1004 - Motor ran to long, e. Motor not inserted fully to e. Check motor and wiring. Replace timed out trying to reach engage piston, motor wires motor if necessary. home position broken or disconnected motor failure If other ERROR codes display contact the f.
