Page 1 TR150 and TR170 Service Manual BAS-SVM04B-EN BAS-SVM04B-EN February 2017...
Page 2: Table Of Contents
Contents TR150 and TR170 Service Manual Contents 1 Introduction 1.1 Purpose 1.2 Product Overview 1.3 Safety 1.4 Electrostatic Discharge (ESD) 1.5 Tools Required 1.6 Electrical Installation in General 1.6.1 Electrical Installation in General 1.7 Exploded Views – H Frame Size 1.8 Exploded Views - I Frame Size...
Page 3 Contents 4.3 Fault Symptom Troubleshooting 4.4 Visual Inspection 4.5 Fault Symptoms 4.5.1 No Display 4.5.2 Intermittent Display 4.5.3 Display (Line 2) Flashing 4.5.4 WRONG or WRONG LCP Shown 4.5.5 Motor Will Not Run 4.5.6 Incorrect Motor Operation 4.6 Warnings and Alarms 4.6.1 Alarms 4.6.2 Warnings 4.6.3 Warning And Alarm Messages...
Page 4 Contents TR150 and TR170 Service Manual 6.4.2 Input Voltage Test 6.4.3 Basic Control Card Voltage Test 6.4.4 Input Imbalance of Supply Voltage Test 6.4.5 Input Waveform Test 6.4.6 Output Imbalance of Motor Supply Voltage Test 6.4.7 Input Terminal Signal Tests 6.5 Initial Start-up Or After Repair Drive Tests...
Page 5 Contents 7.6.1 Control Card and Control Card Mounting Plate 7.6.2 Power Card Cover 7.6.3 Power Card 7.6.4 Heat Sink and DC Coils 7.6.5 Heat Sink Fan Assembly 8 I-Frame Size Disassembly and Assembly Procedures 8.1 General Disassembly Procedure 8.2 I6 Frame Size Disassembly and Assembly Instructions 8.2.1 Control Card and Control Card Mounting Plate 8.2.2 Cable Mounting Plate 8.2.3 Heat Sink Fan Assembly...
Page 6 Contents TR150 and TR170 Service Manual 8.4.8 Terminal Plate 8.4.9 DC Bus Bar Assembly 8.4.10 Heat Sink Fan Assembly 8.4.11 Capacitor Bank 8.4.12 DC Coil 8.4.13 IGBT 8.4.14 Thyristor 9 Block Diagrams 9.1 Block Diagrams, Frame Sizes H and 9 9.1.1 H6 Frame Size...
Page 7: Introduction
LEDs are turned off. Before touching any instructions required, for a qualified technician approved potentially live parts of the frequency converter, by Trane to identify faults and perform repairs and wait at least as stated in Table 1.1. maintenance on the frequency converter: Before conducting repair or inspection, •...
Page 8 IP20 P15K 20.0 15.0 IP20 P18K 25.0 18.5 IP20 P22K 30.0 22.0 IP20 P30K 40.0 30.0 IP20 P37K 50.0 37.0 IP20 P45K 60.0 45.0 IP20 Table 1.2 TR150 and TR170 Frequency Converters 200–240 V AC BAS-SVM04B-EN 02/2017 All rights reserved.
Page 9 IP54 P30K 40.0 30.0 IP54 P37K 50.0 37.0 IP54 P45K 60.0 45.0 IP54 P55K 70.0 55.0 IP54 P75K 100.0 75.0 IP54 P90K 125.0 90.0 IP54 Table 1.3 TR150 and TR170 Frequency Converters 380–480 V AC 02/2017 All rights reserved. BAS-SVM04B-EN...
Page 10: Tools Required
P90K 125.0 90.0 IP20 Table 1.4 Repairable Yes/No Frequency Converters 525–600 V AC 1.5 Tools Required Quick Guide for TR150 and TR170. ESD Protection Kit Wrist strap and Mat Metric socket set 7–19 mm Torque wrench 0.5 N · m to 19 N · m Socket extensions 100–150 mm (4 in and 6 in)
Page 11: Electrical Installation In General
Torque [N · m (in-lb)] Enclosure IP class 3x200–240 V 3x380–480 V Mains Motor Control Ground Relay size connection terminals TR150 IP20 0.25–1.5 0.37–1.5 (0.5–2) 0.8 (7) 0.8 (7) 0.8 (7) 0.5 (4) 0.8 (7) 0.5 (4) (0.33–2) IP20 2.2 (3) 2.2–4.0 (3–5)
Page 12: Exploded Views - H Frame Size
Introduction TR150 and TR170 Service Manual 1.7 Exploded Views – H Frame Size NOTICE Non-repairable units are not shown with exploded views. Blind cover Filter protection cover Front cover LCP RFI filter Cradle EMC shield Control card Bus bar unit...
Page 13 Introduction Blind cover Relay/transducer card mounting plate DC coil cover plate Front cover Bus bar EMC shield Plastic cover Cradle Rectifier modules Control card Heat sink fan assembly Control card mounting plate DC coils Power card Capacitors Power card mounting plate Base plate RFI filter Relay/transducer card...
Page 14 Introduction TR150 and TR170 Service Manual SMPS card Front cover Cable mounting plate Cradle, control card, and mounting plate IGBT EMC shield Relay/transducer card mounting plate Power card Relay/transducer card Power card mounting plate Bus bar Support bracket Rectifier modules...
Page 15: Exploded Views - I Frame Size
Introduction 1.8 Exploded Views - I Frame Size Local Control Panel (LCP) DC coil Front cover Heat sink Cradle Fan assembly Control card Cable mounting plate Control card mounting plate RFI filter Connectors Bus bar unit EMC shield Power card Cable entry Illustration 1.4 Exploded View - I6 Frame Size 02/2017 All rights reserved.
Page 16 Introduction TR150 and TR170 Service Manual Local Control Panel (LCP) DC coil Front door Thyristors Cradle Back plate Control card IGBT Control card mounting plate Capacitor Terminal plates Heat sink fan Support bracket Bus bar unit RFI filter Relay/transducer card...
Page 17 Introduction DC coil Front cover Rectifier modules Cradle IGBTs LCP gasket Capacitors Control card Heat sink fan assembly Control card mounting plate Support bracket Cable mounting plate RFI filter Relay/transducer card with mounting plate Power Card Cable entry Power card mounting plate Illustration 1.6 Exploded View - I8 Frame Size 02/2017 All rights reserved.
Page 18: Ratings
Introduction TR150 and TR170 Service Manual 1.9 Ratings 1.9.1 Short Circuit and Overcurrent Trips The frequency converter is protected against short circuits with current measurement in each of the 3 motor phases or in the DC link. A short circuit between 2 output phases causes an overcurrent in the inverter. The inverter turns off the IGBTs individually when the short-circuit current exceeds the permitted value (Alarm 16 Trip Lock).
Page 19: Frequency Converter Control
Frequency Converter Control 2 Frequency Converter Control 2.1 Introduction Supplies commands and references to the frequency converter. This section describes the optional display interfaces Programs the frequency converter. available for the frequency converter, the inputs and Reads status data from the frequency outputs, and the control terminal functions.
Page 20: Output Signals
Frequency Converter Control TR150 and TR170 Service Manual 2.3.2 Output Signals See the Quick Guide for detailed information on accessing and showing parameters, and for descriptions and procedures for service information available in parameter The frequency converter also produces output signals that group 6-** Analog In/Out.
Page 21: Control Terminal Functions
Frequency Converter Control 2.6 Control Terminal Functions Table 2.2 describes the functions of the control terminals. Many of these terminals have multiple functions determined by parameter settings. See Illustration 2.1. Terminal Function number 01, 02, 03 Form C relay output on control card. Maximum 240 V AC, 2 A.
Page 22 Illustration 2.1 Control Terminal Electrical Overview Control terminals must be programmed. Each terminal has specific functions and a numbered parameter associated with it. The setting selected in the parameter enables the function of the terminal. See the TR150 and TR170 Quick Guide for details. BAS-SVM04B-EN...
Page 23: Grounding Shielded Cables
Frequency Converter Control 2.7 Grounding Shielded Cables Serial communication control cables Low-frequency noise currents between frequency Connect the shielded control cables to the metal cabinet converters can be eliminated by connecting 1 end of the of the frequency converter with cable camps at both ends. shielded cable to frequency converter terminal 61.
Page 24: Internal Frequency Converter Operation
Internal Frequency Converte... TR150 and TR170 Service Manual 3 Internal Frequency Converter Operation 3.1 General undesired program changes. With the addition of a remote mounting kit, the LCP can be mounted in a remote This chapter provides an operational overview of the main location.
Page 25: Logic To Power Interface
Internal Frequency Converte... 3.2.2 Logic to Power Interface The logic to power interface isolates the high-voltage components of the power section from the low voltage signals of the logic section. The interface consists of two sections. • Power Card • Gate Driver Illustration 3.2 Typical Power Section The control card handles much of the fault processing for...
Page 26: Inverter Section
Internal Frequency Converte... TR150 and TR170 Service Manual The voltage on a fully charged DC link is equal to the peak the voltage delivered to the motor. A thermal sensor voltage of the input AC line. Theoretically, this voltage can mounted inside the IGBT module provides heat sink temp be calculated by multiplying the AC line value by 1.414...
Page 27 Internal Frequency Converte... IP54 Enclosure FAN maximum speed temperature °C FAN stop temperature °C Table 3.3 Fan Speed Control, IP54, I6–I8 IP20 Enclosure Voltage T6 T6 T6 T6 T6 T6 T6 T6 T6 T6 T6 T6 Power rating 2.2 3.0 5.5 7.5 11 15 22 30 45 55 75 90 [kW] FAN start tempera-...
Page 28: Troubleshooting
Troubleshooting TR150 and TR170 Service Manual 4 Troubleshooting 4.1 Troubleshooting Tips CAUTION RISK OF INJURY OR PROPERTY DAMAGE Before repairing a frequency converter, read and understand the following instructions. Never assume that a motor is wired properly after a service of the frequency converter. Check for: Note all warnings concerning voltages present in •...
Page 29: Visual Inspection
Troubleshooting 4.4 Visual Inspection Visually inspect the conditions in Table 4.1 as part of any initial troubleshooting procedure. Inspect for Description • Auxiliary equipment Look if more auxiliary equipment, switches, disconnects, or input fuses/circuit breakers reside on the input power side of frequency converter or output side to motor. •...
Page 30 Troubleshooting TR150 and TR170 Service Manual Inspect for Description Input power wiring Check for: • Loose connections. • Proper fusing. • Blown fuses. • Memory module Check that the memory module is plugged in correctly. • Motor Check nameplate ratings of the motor.
Page 31: Fault Symptoms
Troubleshooting 4.5 Fault Symptoms If the display continues to cut out, follow the procedure for chapter 4.5.1 No Display as though the display was not lit 4.5.1 No Display at all. The LCP display provides 2 display indications. One with 4.5.3 Display (Line 2) Flashing the backlit alphanumeric display.
Page 32: Incorrect Motor Operation
Troubleshooting TR150 and TR170 Service Manual Unit ready Motor speed unstable Terminal 27 is low (no signal). Possible causes: • Ensure that terminal 27 is logic “1”. Refer to the Input Incorrect parameter settings. Terminal Signal Test. • Faulty current feedback circuit.
Page 33: Warnings And Alarms
[Reset], a digital input, condition has been cleared by pressing [Reset], or through or a serial bus command. For TR150 and TR170 frequency a digital input (parameter group 5-1* Digital Inputs). The converters, stop and reset are the same key. If [Off/Reset] is...
Page 34 Troubleshooting TR150 and TR170 Service Manual Description Warning Alarm Trip Lock Parameter Reference Live zero error 6–01 No motor 1–80 Mains phase loss 14–12 DC over voltage DC under voltage Inverter overloaded Motor ETR over temperature 1–90 Motor thermistor over 1–90...
Page 35 Troubleshooting frequency converter or connected parts. A trip lock Troubleshooting • situation can only be reset by a power cycling. Check that the supply voltage matches the frequency converter voltage. • Warning Yellow Perform an input voltage test. Alarm Flashing red •...
Page 36 Troubleshooting TR150 and TR170 Service Manual WARNING/ALARM 11, Motor thermistor over temp Troubleshooting • Check whether the thermistor is disconnected. Select Remove power to the frequency converter and whether the frequency converter issues a warning or an repair the ground fault.
Page 37 Check that the option is properly installed Disconnect power before proceeding. Check for loose or missing wiring Troubleshooting It may be necessary to contact your Trane supplier or • Remove the power from the frequency converter service department. Note the code number for further and check motor phase U.
Page 38 Parameter value is outside its limits parameters 1-20 to 1-25 is set correctly. Increase the current 5376-6231 Internal fault. Contact your Trane supplier or Trane limit if necessary. Ensure that the system can operate safely Service Department. at a higher limit.
Page 39: After Repair Tests
Troubleshooting 4.7 After Repair Tests WARNING 200, Fire mode The frequency converter is operating in fire mode. The Following any repair to a frequency converter or testing of warning clears when fire mode is removed. Refer to the a frequency converter suspected of being faulty, the fire mode data in the alarm log.
Page 40: Frequency Converter And Motor Applications
Frequency Converter and Mot... TR150 and TR170 Service Manual 5 Frequency Converter and Motor Applications NOTICE 5.1 Torque Limit, Current Limit, and Unstable Motor Operation Never adjust these parameters to random values even though it seems to improve operation. Such adjustments...
Page 41: Mains Phase Loss Trips
Frequency Converter and Mot... 5.1.2 Mains Phase Loss Trips The frequency converters are designed to accept various signals. First, determine which of these signals the frequency converter is receiving: The frequency converter monitors phase loss by • Digital inputs (18, 19, 27, and 29). monitoring the amount of ripple voltage on the DC bus.
Page 42: Motor/Load Problems
1 A of current, there is a defective whether the problem is in the motor wiring or the motor current sensor. All 3 current sensors in TR150 and TR170 itself. units are mounted on one circuit board (either power card, SMPS card, or current transducer card).
Page 43: Effects Of Emi
Frequency Converter and Mot... 5.2.4 Effects of EMI equipment has a high level of EMI immunity. However, non-industrial, commercial, and consumer equipment is often susceptible to lower levels of EMI. While electromagnetic interference-related (EMI) distur- bances to the operation of the frequency converter are uncommon, the following detrimental EMI effects Detrimental effects to these systems include the following: •...
Page 44: Emi Propagation
Frequency Converter and Mot... TR150 and TR170 Service Manual 5.2.6 EMI Propagation Frequency converter generated EMI is both conducted to the mains and radiated to nearby conductors. See Illustration 5.2. AC line Frequency converter Motor cable Motor Stray capacitance AC line...
Page 45: Preventive Measures
Frequency Converter and Mot... 5.2.7 Preventive Measures separately from the signal and mains wiring, no further consideration is needed. If the conductors are routed close to other susceptible conductors, or if the system is EMI-related problems are more effectively alleviated during suspected to cause EMI problems, consider alternate motor the design and installation phases rather than after the wiring methods.
Page 46: Test Procedures
Test Procedures TR150 and TR170 Service Manual 6 Test Procedures 6.1 Non-repairable Units H1–H5 and I2–I4 are non-repairable units and should not be repaired. The information about Line/Motor/UDC+- terminals is useful to verify what went wrong with these frequency converters, for statistics and WIIS purposes, but also to avoid replacing a frequency converter that is not defective.
Page 47 Test Procedures RS485 Line in RS485 Ground Line in Wire clamps Ground Motor Wire clamps Motor Relays Relays Illustration 6.4 I4 Frame IP54 380–480 V, 0.75–4.0 kW Illustration 6.3 I3 Frame IP54 380–480 V, 5.5–7.5 kW 02/2017 All rights reserved. BAS-SVM04B-EN...
Page 48: Introduction
Test Procedures TR150 and TR170 Service Manual • 6.2 Introduction Oscilloscope • Current meter WARNING 6.3 Static Test Procedures DISCHARGE TIME! The purpose of performing static testing is to check for Frequency converters contain DC-link capacitors that can any short circuit of the power components.
Page 49: Rectifier Circuit Test
Test Procedures 6.3.2 Rectifier Circuit Test 6.3.3 Inverter Section Tests Pay close attention to the polarity of the meter leads to The inverter section is primarily made up of the IGBTs used ensure the identification of any faulty component, in case for switching the DC bus voltage to create the output to an incorrect reading appears.
Page 50: Intermediate Section Tests
Test Procedures TR150 and TR170 Service Manual 6.3.4 Intermediate Section Tests 6.3.5 Location of UDC Terminals NOTICE Remove the IP20 front cover, then remove the capacitor This test is applicable for H7, H8, I7, and I8 units only. vibration support. The terminals K601 (+UDC) and K611 (-...
Page 51 Test Procedures Illustration 6.9 +/- UDC Terminals The UDC terminals are available on connectors at the bottom of the frequency converter. Static measurements can be done directly from here. Illustration 6.7 The UDC Terminals on the Circuit Board H7 and H8 Remove the IP20 front cover to access the terminals directly on the power card MK900.
Page 52 Test Procedures TR150 and TR170 Service Manual Remove the front terminal cover to access the connectors. The UDC terminals are located inside the frequency converter. Illustration 6.13 +/- UDC Terminals on Current Sensor Board Illustration 6.11 UDC Terminals Location on H10 Frequency...
Page 53: Dynamic Test Procedures
Test Procedures 6.4.1 No Display Test (Display is Optional) 6.4 Dynamic Test Procedures NOTICE A frequency converter with no display in the LCP can be the result of several causes. First, verify that there is no Test procedures in this section are numbered for display.
Page 54: Basic Control Card Voltage Test
Test Procedures TR150 and TR170 Service Manual Incorrect reading Voltage imbalances automatically result in a corresponding current imbalance. CAUTION Apply power to the frequency converter and Open (blown) input fuses or tripped circuit breakers place it in run. usually indicate a more serious problem. Before replacing fuses or resetting breakers, perform static tests.
Page 55: Output Imbalance Of Motor Supply Voltage Test
Test Procedures 6.4.6 Output Imbalance of Motor Supply Voltage Test Check the balance of the output voltage and current to measure the electrical functioning between the frequency converter and the motor. In testing the phase-to-phase output, both voltage and current are monitored. Conduct static tests on the inverter section of the frequency converter before this procedure.
Page 56: Input Terminal Signal Tests
Test Procedures TR150 and TR170 Service Manual Reconnect the motor to the frequency converter. If 24 V is present, proceed with checking the individual inputs as follows: Connect mains to the frequency converter, and Connect the (-) negative meter lead to reference start the frequency converter.
Page 57: Initial Start-Up Or After Repair Drive Tests
Test Procedures 6.5 Initial Start-up Or After Repair Drive Tests Perform these tests under the following conditions: • Starting a frequency converter for the first time. • Approaching a frequency converter that is suspected of being faulty. • After repair of the frequency converter. Following this procedure ensures that all circuitry in the frequency converter is functioning properly before putting it into operation.
Page 58: Frame Size Disassembly And Assembly Instructions
H-Frame Size Disassembly a... TR150 and TR170 Service Manual 7 H-Frame Size Disassembly and Assembly Instructions 7.1 Electrostatic Discharge (ESD) 7.3 H6 Frame Size Disassembly and Assembly Instructions CAUTION 7.3.1 Control Card and Control Card Frequency converters contain dangerous voltages when Mounting Plate connected to the main voltage.
Page 59: Heat Sink Fan Assembly
H-Frame Size Disassembly a... 7.3.2 Heat sink Fan Assembly Unplug the fan cable Remove 4 screws on fan cover plate. Remove the fan. Reinstall in the reverse order. Fan cover plate Cradle Screws Control card Fan assembly Control card mounting plate Illustration 7.2 Heat Sink Fan Assembly Illustration 7.1 Control Card and Control Card Mounting Plate 02/2017 All rights reserved.
Page 60: Dc Coil
H-Frame Size Disassembly a... TR150 and TR170 Service Manual 7.3.3 DC Coil 7.3.4 DC Link Card Remove the 4 screws on the DC coil cover to Remove the 6 screws on coil mounting plate. access the DC coils. Remove the coil mounting plate.
Page 61: Rfi Filter
H-Frame Size Disassembly a... 7.3.5 RFI Filter 7.3.6 Power Card Remove the protection cover. Remove the 3 screws on the U V W cable connector. Remove the 6 distance bushes. Remove the connector. Remove the 2 screws on the frame side. Remove the 3 small screws (T10) from the power Remove the 3 screws from U V W cables.
Page 62: H7 Frame Size Disassembly And Assembly Instructions
H-Frame Size Disassembly a... TR150 and TR170 Service Manual 7.4.2 Power Card 7.4 H7 Frame Size Disassembly and Assembly Instructions Remove the LCP ribbon cable from the power 7.4.1 Control Card and Control Card card. Mounting Plate Unplug all other cables from the power card,...
Page 63: Inrush Card
H-Frame Size Disassembly a... 7.4.3 Inrush Card 7.4.4 RFI Filter Remove the 2 screws (T20) from the filter shield. Remove the red/black cables from the filter cable. Remove the shield. Remove the protective foil. Remove the 4 screws (T20) from the power card Remove the 3 filter cables screws using a hex 8 mounting plate.
Page 64: Relay Transducer Card
H-Frame Size Disassembly a... TR150 and TR170 Service Manual 7.4.5 Relay Transducer Card 7.4.6 Rectifier Modules Unplug cables on the relay transducer card. Loosen and remove the 2 cables (T20). Loosen the right cable connector using a hex 5 Remove the 6 screws (T20) from the shield.
Page 65: Heat Sink Fan Assembly
H-Frame Size Disassembly a... 7.4.8 Heat Sink Fan Assembly Remove the 4 screws (T20) from the fan cover plate. Press the fan cover plate outwards using a screwdriver. Remove the fans and the fan cover plate. Reinstall in the reverse order. Cable mounting plate IGBT Fan cover...
Page 66: Dc Coil
H-Frame Size Disassembly a... TR150 and TR170 Service Manual 7.4.9 DC Coil 7.4.10 Capacitor Bank Remove the 4 screws (T20) from the DC coil cover Remove the foil. plate. Remove the 6 screws on the base plate. Remove the 4 screws (T20) from the heat sink.
Page 67: H8 Frame Size Disassembly And Assembly Instructions
H-Frame Size Disassembly a... 7.5.2 Power Card 7.5 H8 Frame Size Disassembly and Assembly Instructions Remove 2 screws (T20) from the EMC shield. 7.5.1 Control Card and Control Card Remove cables from EMC shield. Mounting Plate Remove the EMC shield. Remove the LCP by pressing the barbs on the Remove the LCP ribbon cable from the power side.
Page 68: Inrush Card
H-Frame Size Disassembly a... TR150 and TR170 Service Manual 7.5.3 Inrush Card 7.5.4 Rectifier Modules Remove the 4 screws (T20) from the power card CAUTION mounting plate. Wear protective gloves when cleaning up the thermal Remove the power card mounting plate.
Page 69: Rfi Filter
H-Frame Size Disassembly a... 7.5.5 RFI Filter Remove the 3 screws (T20) from the small EMC shield. Remove the EMC shield. Loosen left cable connector using a hex 8 key. Remove the 4 screws (T20) from the filter. Remove the entire filter assembly. Reinstall in the reverse order.
Page 70: Relay Transducer Card
H-Frame Size Disassembly a... TR150 and TR170 Service Manual 7.5.6 Relay Transducer Card 7.5.7 IGBT Remove the 4 screws (T20) on the plate. CAUTION Carefully remove cables before removing the Wear protective gloves when cleaning up the thermal plate. paste as it is poisonous.
Page 71: Heat Sink Fan Assembly
H-Frame Size Disassembly a... 7.5.8 Heat Sink Fan Assembly Remove the 4 screws (T20) from the fan cover plate. Press the fan cover plate outwards using a screwdriver. Remove the fans and the fan cover plate. Reinstall in the reverse order. Cable mounting plate IGBT Fan cover...
Page 72: Dc Coil
H-Frame Size Disassembly a... TR150 and TR170 Service Manual 7.5.9 DC Coil 7.5.10 Capacitor Bank Remove the 4 screws (T20) from the DC coil cover Remove the foil. plate. Remove the 4 screws from the base plate. Remove the 4 screws (T20) from the heat sink.
Page 73: H10 Frame Size Disassembly And Assembly Instructions
H-Frame Size Disassembly a... 7.6.2 Power Card Cover 7.6 H10 Frame Size Disassembly and Assembly Instructions Press and loosen the 3 barbs at the bottom, and 7.6.1 Control Card and Control Card the 3 barbs at the top. Mounting Plate Remove the power card cover.
Page 74: Power Card
H-Frame Size Disassembly a... TR150 and TR170 Service Manual 7.6.3 Power Card 7.6.4 Heat Sink and DC Coils Remove the 4 screws (T10) for the DC coil cables. Remove the 7 mounting screws from top surface. Remove the 5 screws (T10) for the heat sink.
Page 75: Heat Sink Fan Assembly
H-Frame Size Disassembly a... 7.6.5 Heat Sink Fan Assembly Remove 2 screws (T10) on the DC coil mounting plate Remove the plate. Press and loosen the 2 barbs on the fan. Remove the fan. Reinstall in the reverse order. Heat sink fan Fan mounting plate Illustration 7.31 Heat Sink Fan Assembly 02/2017 All rights reserved.
Page 76: Frame Size Disassembly And Assembly Procedures
I-Frame Size Disassembly an... TR150 and TR170 Service Manual 8 I-Frame Size Disassembly and Assembly Procedures 8.1 General Disassembly Procedure This procedure explains how to remove the outer parts of the frequency converter that are common for all I-frame sizes. When this procedure is completed, the inside components are accessible.
Page 77: Cable Mounting Plate
I-Frame Size Disassembly an... 8.2.2 Cable Mounting Plate 8.2.3 Heat Sink Fan Assembly Remove the ribbon cable. Unplug cable from power card. Remove 1 screw (T20) from shield metal. Remove 2 screws (T20) from the fan mounting plate. Use a flat screwdriver to release the retainers and connection terminals.
Page 78: Smps Card
I-Frame Size Disassembly an... TR150 and TR170 Service Manual 8.2.4 SMPS Card 8.2.5 Bus Bar Unit Remove the 3 black plastic covers. Remove the 2 screws from the snubber capacitor on the bus bar unit. Unplug and remove the fan.
Page 79: Power Card
I-Frame Size Disassembly an... 8.2.6 Power Card 8.2.7 DC Coil Remove 7 screws (T20) Remove 4 screws (T20) from the coil. Remove 5 screws (T10) on the Power Card. Lift the coil. Lift out the power card. Reinstall in the reverse order. Reinstall in the reverse order.
Page 80: Rfi Filter
I-Frame Size Disassembly an... TR150 and TR170 Service Manual 8.2.8 RFI Filter 8.3 I7 Frame Size Disassembly and Assembly Instructions Remove 2 screws (T20) from the filter. 8.3.1 Control Card and Control Card Lift out the filter. Mounting Plate Reinstall in the reverse order.
Page 81: Power Card Mounting Plate
I-Frame Size Disassembly an... 8.3.2 Power Card 8.3.3 Power Card Mounting Plate Unplug and remove the LCP ribbon cable. Remove 4 screws (T20) from the power card mounting plate. Unplug all other cables from the power card. Remove the power card mounting plate with the Remove 3 screws (T20) on the power card.
Page 82: Inrush Card
I-Frame Size Disassembly an... TR150 and TR170 Service Manual 8.3.4 Inrush Card 8.3.5 Bus Bar Unplug all cables. Unplug and remove the red/black cable. Remove 6 screws (T20) from the inrush card. Remove the black plastic cover. Remove the inrush card.
Page 83: Rfi Filter
I-Frame Size Disassembly an... 8.3.6 RFI Filter 8.3.7 Relay Transducer Card Unplug the 3 filter cables from the thyristors Remove the 3 clamps on each side of the 2 cable using a hex 8 key. connectors. Loosen the 3 cables from the cable connector Remove the cable connector with no cables using a hex 5 key.
Page 84: Fan
I-Frame Size Disassembly an... TR150 and TR170 Service Manual 8.3.8 Fan 8.3.9 Terminal Plate Remove 2 screws (T20) on the fan bracket. Remove the black plastic cover. Remove 2 screws (T20) from the fan. Remove 4 screws (T20) on the cover plate.
Page 85: Dc Bus Bar Assembly
I-Frame Size Disassembly an... 8.3.10 DC Bus Bar Assembly 8.3.11 Heat Sink Fan Assembly Remove 2 screws (T20) from the 2 snubbers. Remove gate cables from IGBTs. Remove the snubbers. Remove 2 screws (T20) from the heat sink fan assembly. Loosen and remove cables from bus bar assembly and DC coil.
Page 86: Capacitor Bank
I-Frame Size Disassembly an... TR150 and TR170 Service Manual 8.3.12 Capacitor Bank 8.3.13 DC Coil Remove 4 screws (T20) from each of the Remove 5 screws (T20) on the potted coil. capacitors. Remove the DC coil. Remove the capacitors. Reinstall in the reverse order.
Page 87: Igbt
I-Frame Size Disassembly an... 8.3.14 IGBT 8.3.15 Thyristor Remove 2 screws (T20) from each of the 3 IGBTs. Remove 2 screws (T20) from each of the 3 thyristors. CAUTION CAUTION The IGBTs and the heat sink have thermal paste on them. Wear protective gloves as the paste is poisonous.
Page 88: Power Card
I-Frame Size Disassembly an... TR150 and TR170 Service Manual 8.4.2 Power Card Unplug and remove the LCP ribbon cable. Unplug all other cables from the power card. Remove 3 screws (T20) on the power card. Remove the power card. Reinstall in the reverse order.
Page 89: Power Card Mounting Plate
I-Frame Size Disassembly an... 8.4.3 Power Card Mounting Plate 8.4.4 Inrush Card Remove 4 screws (T20) from the power card Unplug all cables. mounting plate. Remove 6 screws (T20) from the inrush card. Remove the power card mounting plate with the Remove the inrush card.
Page 90: Bus Bar
I-Frame Size Disassembly an... TR150 and TR170 Service Manual 8.4.5 Bus Bar 8.4.6 RFI Filter Unplug and remove the red/black cable. Unplug the 3 filter cables from the thyristors using a hex 8 key. Remove the black plastic cover. Loosen the 3 cables from the cable connector Remove 6 screws (T20) and 2 screws (T30) from using a hex 5 key.
Page 91: Relay Transducer Card
I-Frame Size Disassembly an... 8.4.7 Relay Transducer Card 8.4.8 Terminal Plate Remove 2 screws (T20) from each of the 2 cable Remove 4 screws (T20) on the cover plate. connectors. Remove the complete terminal plate including Remove the cable connector. cable connector.
Page 92: Dc Bus Bar Assembly
I-Frame Size Disassembly an... TR150 and TR170 Service Manual 8.4.9 DC Bus Bar Assembly 8.4.10 Heat Sink Fan Assembly Remove 2 screws (T30) from each of the 2 Remove 4 screws (T20) from the heat sink fan snubbers. assembly. Remove the snubbers.
Page 93: Capacitor Bank
I-Frame Size Disassembly an... 8.4.11 Capacitor Bank 8.4.12 DC Coil Remove 4 screws (T20) from each of the Remove 5 screws (T20) on the potted coil. capacitors. Remove the DC coil. Remove the capacitors. Reinstall in the reverse order. Reinstall in the reverse order. Bus bar Illustration 8.34 Capacitors DC coil...
Page 94: Igbt
I-Frame Size Disassembly an... TR150 and TR170 Service Manual 8.4.13 IGBT 8.4.14 Thyristor Remove 4 screws (T20) from each of the 3 IGBTs. Remove 2 screws (T20) from each of the 3 thyristors. CAUTION CAUTION The UGBTs and the heat sink have thermal paste on them.
Page 100: Index
Index TR150 and TR170 Service Manual Index Diode............... 24, 39, 47, 48, 49, 53, 54 Display Flashing (line 2)................. 30 Intermittent..................30 AMA..................31, 33, 39, 40 No display................... 30 Wrong....................30 Warning....................37 Display line....................19 Analog Signal....................34 Analog output..................
Page 101 Index Main assembly..................23 Serial communication................. 18 MOC......................25 Short circuit..............17, 35, 47, 48, 49 Motor Signal conductor................... 43 Imbalance................... 31 Status line....................18 Incorrect operation................. 31 Status message..................18 current....................37 data....................34, 37 Status messages..................30 power....................37 Switch....................
Page 103 February 2017 Supersedes November 2013 www.trane.com Trane has a policy of continous product and product data improvement and reserves the right to For more information, contact your local Trane change design and specifications without notice. office or e-mail us at comfort@trane.com...
