Tektronix 067-0484-02 Instructions Manual page 31

Replaceable Parts List
Fig. &
Tektronix Serial no.
index
part number effective
number
16- - 1 129- - 1557- - 00
- - 2 174- - 4401- - 00
- - 3 432- - 0176- - 00
- - 4 348- - 0430- - 00
- - 5 211- - 1050- - 00
- - 6 131- - 6562- - 00
- - 7 071- - 7022- - XX
- - 8 131- - 3721- - 00
- - 9 129- - 1558- - 00
- - 10 214- - 5005- - 00
- - 11 343- - 0401- - 00
- - 12 352- - 1099- - 00
Deskew Fixture Instructions
Serial no.
discont'd
Qty Name & description
Deskew Fixture
3 POST:GUIDE,DESKEW,FEMALE,SMX.IGS,STAINLESS STEEL
1 CABLE ASSY,I/O:USB, 26 AWG, 3.281 FT, A TO B, MALE
1 BASE ASSEMBLY:W/LEXAN LABEL,3.0 X 5.50 X 0.175
4 FOOT:BUMPER,PLASTIC:POLYURETHANE,BLACK
2 SCREW,MACHINE:6- - 32 X 0.312 L,PNH,STL CAD PLT,T15
1 CONN:PCB,USB SERIES B,FEMALE,RTANG
1 MANUAL,TECH:INSTRUCTION, DESKEW FIXTURE
1 CONN, RF JACK:BNC SERIES B, FEMALE
3 POST:GUIDE,DESKEW,MALE,SMXGS,STAINLESS STEEL
3 SPRING:DESKEW,SMX IGS,0.008 SSTL FULL HARD
4 RETAINER,CABLE:PLASTIC
2 HOLDER, PROBE: DESKEW P6249, P7240,W/tips
Mechanicl Parts List
Mfr.
code
Mfr. part number
TK0588 129- - 1557- - 00
6D224 72380- - B100BC
0KB05 432- - 0176- - 00
2K262 ORDER BY
DESCRIPTION
0KB01 OBD
TK0AT 787780- - 2
TK2548 071- - 7022- - XX
00779 227699- - 2
TK0588 129- - 1558- - 00
TK1326 214- - 5005- - 00
06915 KKU- - 4RT
80009 352- - 1099- - 00
