Profort MultiGuard Quick Manual page 5

1234 ON
Connect/disconnect
the unit
1234 OF
1234 S0
Activation of
output x
1234 B0
1234 P0
1234 OK
Download
1234 V1 R
1234 EH USERNAME
Connection to the
Internet
1234 EH
The unit can also be controlled by use of the PC program and all functions can be controlled directly on the
Internet.
On the print there's a button with the following three functions:
1. If button is pressed down while power supply is connected, a "beep" is heard after 7 secs. This resets
the multiGuard DIN9 to default settings.
2. If button is pressed down during normal operations a "beep" is heard after 7 secs. If button is
released immediately hereafter, macro 1 is performed. If no function has been saved on macro 1,
nothing happens.
3. If button is pressed down after 7 secs., an additional "beep" will be heard after 14 secs. The
'sabotage' alarm is hereby activated.
See more in the manual or log on Internet management via www.profort.com
Ver. 4.01
CONTROL
Control with text message
Inputs are activated, red diode flashes
Inputs are deactivated, red diode turns off
Closes output 0. (S0..S1)
Breaks output 0. (B0..B1)
Pulses output 0 for 10 secs. (P0..P1)
Downloads information about GSM transmission power
and battery level
Example: OK>>OK SQ: xx%
xx = transmission power in percentage. 25 % is smallest
acceptable value
Downloads measurements on analogue input 1. (V1 ..
V2)
GPRS traffic starts
GPRS traffic stops
Additional control
www.profort.com
Pg. 5
