LED Indicators

Power
Off: Power is off.
On: Power is on.
Wireless 2.4G/5G
Off: The wireless function is disabled.
On: The wireless function is enabled.The router is
working on 2.4GHz or 5GHz or both radio bands.
Ethernet
Off: No device is connected to the Ethernet ports.
On: At least one device is connected to the Ethernet
ports.
Internet
Off: The Internet connection is not available.
On: The network is available with a successful Internet
connection.
USB
Off: No USB device is plugged into the USB port.
Flashing: A plugged-in USB device is being recognized.
On: The USB device has been successfully recognized.
WPS
Slow Flash: A wireless device is connecting to the
network by WPS function. This process will last in the
first 2 minutes.
On: A wireless device has been successfully added to
the network by WPS function.
Quick Flash: A wireless device failed to be added to the
network by WPS function.
