TP-Link Archer C2 Quick Installation Manual

Equipment
Author Bravo Telecom
Update: 22-05-2024
Quick Installation Guide
AC750 Wireless Dual Band Gigabit Router
C2
Connect the Hardware
If your internet connection is through an Ethernet cable directly from the
wall instead of through a DSL / Cable / Satellite modem, connect the
Ethernet cable to the router's Internet port, and follow Step 4 and 5 to
complete the hardware connection.
Internet
Power adapter
1
2
Modem
3
Router
and remove the backup
battery if it has one.
Connect the modem to the
router's Internet port with
an Ethernet cable.
Turn on the modem, and
then wait about 2 minutes
for it to restart.
Power adapter
4
Connect the Power
adapter to the router and
turn on the router.
5
Verify that the following LEDs are on
and solid to con rm the hardware is
connected correctly.
Power Internet
2.4G 5G
On On
On On
Note: If the 2.4G LED and 5G LED are
button on the back panel for about 5
seconds to turn them on.
