MPLAB ICD 4 User's Guide
®
RECOMMENDED READING
This user's guide describes how to use MPLAB ICD 4 In-Circuit Debugger. Other useful
documents are listed below. The following Microchip documents are available and
recommended as supplemental reference resources.
Multi-Tool Design Advisory (DS51764)
Please read this first! This document contains important information about
operational issues that should be considered when using the MPLAB ICD 4 with your
target design.
Release Notes for MPLAB ICD 4 In-Circuit Debugger
For the latest information on using MPLAB ICD 4 In-Circuit Debugger, read the notes
under "Release Notes and Support Documentation" on the MPLAB X IDE Start Page.
The release notes contain update information and known issues that may not be
included in this user's guide.
MPLAB ICD 4 Quick Start Guide Poster (DS50002538A)
This poster shows you how to connect the hardware and install the software for the
MPLAB ICD 4 In-Circuit Debugger using standard communications and a target board.
MPLAB ICD 4 In-Circuit Debugger Online Help File
A comprehensive help file for the debugger is included with MPLAB X IDE. Usage,
troubleshooting and hardware specifications are covered. This help file may be more
up-to-date than the printed documentation.
Processor Extension Pak and Header Specification (DS50001292)
This booklet describes how to install and use headers. Headers are used to better
debug selected devices, without the loss of pins or resources. See also the PEP and
Header online Help file.
Transition Socket Specification (DS51194)
Consult this document for information on transition sockets available for use with
headers.
