Applicable Tire Size Capacity:
any 24-inch – 700 x 40c
(Max Tire Outer Diameter = 712mm)
Main Features
• Thick outer edge flywheel design generates more initial inertia through virtual weight
• Super strong Neodymium magnet provides extremely wide and controllable resistance range
• New double-thread knob type roller pressure system enables quick & easy setup/release operation
• Unique U-shaped leg design reduces weight but increases stability
• Each leg is foot point adjustable in +/-10mm travel for perfect fit to any floor condition
• Quick release type hub clamping mechanism
Please Note
Contact
MINOURA NORTH AMERICA
(for U.S. residents ONLY)
Phone: 1-510-538-8599 (8 am - 5 pm, M - F, PST)
Fax:
1-510-538-5899
Email: support@minourausa.com
indoor bicycle trainer
(ETRTO 42-622)
This trainer must be used with a completely smooth (no knobs or raised tread) tire.
Failure to do so will ruin the mag unit, your tire, and void any possible warranty.
If you need help, please contact the shop first where you originally purchased this product
or call the distributors in your country. The distributors list can be found on our web site.
When you cannot get enough service, you can contact us;
MADE IN JAPAN
V270
instructions manual
MINOURA JAPAN HEADQUARTERS
(for ALL customers)
1197-1 Godo, Anpachi, Gifu 503-2305 Japan
Phone: +81-584-27-3131
Fax:
+81-584-27-7505
Email: minoura@minoura.jp
Web: www.minoura.jp
(ver.3)
(ver. 3.0 2012/2)
