SERVICE MANUAL
DVD PLAYER Hi-Fi VIDEO CASSETTE RECORDER
HR-XV1EK, HR-XV1EU-C,
HR-XV1EU-S, HR-XV1EU-Y

SPECIFICATIONS

GENERAL
Power supply:
AC 230V 50Hz
Power consumption:
Operation: 22W
Stand by: 5W
Weight:
4.5 kg
Dimensions:
Width : 430 mm
Height : 99 mm
Depth : 310.5 mm
Input Level:
SCART-socket:
Audio IN jack:
Output Level:
SCART-socket:
Audio OUT jack: 500 mV, 1 kΩ
Hi-Fi Frequency Response:
20Hz to 20,000Hz
Hi-Fi Dynamic Range:
More than 75dB
VCR section
Video Head:
4 Rotary Heads
Audio Track:
Hi-Fi Sound - 2 Tracks /
MONO Sound - 1 Track
Channel covevage:
2-12, X, Y, Z, S1-S41, 21-69
RF Channel Output:
UHF channel 36 (23 to 69)
F.FWD/REW Time at 25˚C:
Approx. 1minute and 48 seconds
(with E-180 Cassette Tape)
(The specifications shown pertain specifically to the model HR-XV1EU-C.)
VIDEO: 1 Vp-p, 75Ω
AUDIO: 500 mV, 50 kΩ
500 mV, 50 kΩ
VIDEO: 1 Vp-p, 75Ω
AUDIO: 500 mV, 1 kΩ
This service manual is printed on 100% recycled paper.
COPYRIGHT © 2002 VICTOR COMPANY OF JAPAN, LTD
DVD section
Signal system:
PAL
Applicable disc:
DVD (12cm, 8cm), CD (12cm, 8cm)
Audio characteristics:
DVD: 4Hz - 22KHz
Frequency response:
CD: 4Hz - 20KHz
S/N Ratio:
90dB
Harmonic distortion:
1%
Wow and flutter:
Below Measurable Level
Dynamic range:
90dB
Output:
Audio :
Digital Audio : 0.5Vp-p/75 ohm
CD :
Pickup:
DVD : Wavelength: 640 - 660 nm
ACCESSORIES:
Remote control x 1
75 ohm Coaxial Cable x 1
Battery (UM-3) x 2
DIGITAL VIDEO
(RCA) 500 mV, 1Kohm
Wavelength: 775 - 805 nm
Maximum output power: 0.5 mW
Maximum output power: 1.0 mW
V14PV1
No.82927
June 2002
