Bin Master C-100 Operator's Manual page 17

The Scroll Up and Down Indicators, displayed as little up and down arrows towards the right of the
screen, will be present when more selections or information is available off screen. The Scroll Up
Indicator will be present when the user can scroll up to obtain more selections or information and the
Scroll Down Indicator will be present when the user can scroll down to obtain more selections or
information.
Navigating through the menu system is straight-forward, position the selection bar on the desired menu or
selection item and press the
key. The menu system is structured as shown in the following diagram.
Main Menu Measure/View
Setup
925-0270 Rev G
key. To go back a menu or escape from the current screen, press the
Measure All
001
002
more... up to 120
SB-485 Protocol
SB-485 Termination
Auto Add/Remove
Add/Remove
Units of Measure
Weight Calculations
Vessel Setup
C-50 Setup
I/O Assignment
4-20mA Output
4-20mA Error
Interval Timer
Measurement Format
Measurement Type
Access Code
Language/Idioma
Info/About
17
Capacity
Headroom
Product
Capacity
Headroom
Product
