K-Mate BTH018 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
BTH018
User's Manual
Content
Brief introduction.....................................................1
............................................................1
Before use..............................................................2
..................................................................2
...................................................3
Using the headsets...................................................4
1. Turn on/off the headsets.........................................................4
2. Pairing headsets with Bluetooth devices.....................................5
1) How to entering pairing mode..............................................5
2) Pairing headsets with Bluetooth devices..................................5
4) Pairing headsets with Multi-devices.......................................7
3. Reconnect the headsets with devices..........................................7
4. Wearing the headset.............................................................8
5. Making calls with the headset.................................................8
6. Playing music....................................................................10
7. LED indicator....................................................................11
8. Indication tone...................................................................12
.....................................................
.............................................................................13
...................................................................14
..........................1
12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BTH018 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for K-Mate BTH018

Summary of Contents for K-Mate BTH018

  • Page 1: Table Of Contents

    BTH018 User’s Manual Content Brief introduction…………...…………………………..…...1 ……...……………..1 1. Bluetooth wireless communication technology …………………………………………………...1 2. About BTH018 Before use……………………………………………………..2 …………………………………………………………2 1.Overview ……………………………………………3 2. Charging for Headsets Using the headsets……………………………………………4 1. Turn on/off the headsets………………………………………………...4 2. Pairing headsets with Bluetooth devices……………………………….5 1) How to entering pairing mode……………………………………….5 2) Pairing headsets with Bluetooth devices…………………………….5...

  • Page 2: Brief Introduction

    Stereo music playback AVRCP Remote control music(pause/play/previous track/next track) You can enjoy music wirelessly by using the BTH018. Fetures as following: 1) Pairing with the Bluetooth mobile phone and PDA which support HFP. Answer, end and reject call from the headset...

  • Page 3: Before Use

    2) Pairing with Bluetooth music devices and Bluetooth transmitter which support A2DP. Enjoy music wirelessly Adjust the volume Remote control pause/ play Remote control last/next song 3) Easy to switch between conversation and music, you will not miss the incoming call during listening to music. 4) Every time the headset is switched on, it will automatically connect to the last paired device.

  • Page 4: Charging For Headsets

    Right speaker Volume down/next track 2. Charging for Headsets First time charging： Before you use this Bluetooth headset, please charge the battery of BTH018 fully. Low power： When you hear three “DONG” tones every 20 seconds, at the same time, the red LED blinks twice.

  • Page 5: Using The Headsets

    There are two ways of charging for headset: Using travel charger: 1. Plug charger into standard AC power socket 2. Plug another side of charger jack into charging port of the headset RED light on→Charging RED light off→Finish charging 3. It will take about two hours to finish charging Using USB cable charger: 1.

  • Page 6: Pairing Headsets With Bluetooth Devices

    Make the headsets enter pairing mode(please refer to “How to entering pairing mode” Activate your mobile phone’s Bluetooth function and search Bluetooth devices within available range, and select “BTH018” from the list of devices shown after search According to the indication, enter password or PIN No: “0000”, and...

  • Page 7: Pairing Headsets With Bluetooth Transmitter

    “Yes” or “Confirm” button to confirm After pairing sucessfully, choose “BTH018” from the list of device shown and connect it After connect sucessfully, headsets’s blue light blinks twice every 4 seconds or blinks three times every 4 seconds Note: If the pairing is not successful, please switch off headset firstly, and then re-pair according to the steps 1-6 mentioned above.

  • Page 8: Pairing Headsets With Multi-Devices

    Note: The pairing password of the headset is “0000”. So, the headset can only pair with a Bluetooth transmitter whose pairing password is “0000”. If pairing still fails after several tries, please refer to the Bluetooth transmitter’s user’s manual for further information. 4) Pairing headset with Multi-devices The headset can connect with two devices at most.

  • Page 9: Wearing The Headset

    multi-function button, the headset will try to connect the last connected HFP devices. When the headset not connect A2DP device, please long press “―” for two seconds, the headsets will try to connect the last connected A2DP devices. 4. Wearing the headset As per the following pictures show, hang the headset on the ears with your both hands.
  • Page 10 Reject call Ringing Long press multifunction button for about 2 seconds and release it till you listen prompt tone End call Conversation mode Short press multifunction button one time Volume up Conversation mode Short press “+”button Volume Conversation mode Short press “―”button down Call Conversation mode...

  • Page 11: Playing Music

    2) The operation of three-way call Function Status of the headset Operation Answer new call There second Short press and end current incoming call multifunction button call Answer new call There second Double-click and retain current incoming call multifunction button call Switch call Keep conversation...

  • Page 12: Led Indicator

    You have to select “transmit the sound via Bluetooth” in the settings menu and then choose “BTH018” as speaker device. The music will be transmitted to the headset. Please refer to your mobile phone’s user’s manual for further information.

  • Page 13: Indication Tone

    30 seconds Care and maintenance Read the following recommendations carefully before using BTH018. Following these you will be able to enjoy this product for many years. Keep it dry and don’t put it in the dump place to avoid the product’s internal circuit being affected.

  • Page 14: Faqs

    FAQs 1. What does it mean when red LED blink twice every 30 seconds? Battery is low power, need to be recharged. 2. Why is the red LED off when charging? a) Please make sure the charging device connect with headset Well; b) You didn’t use the headset for a long time, the battery may dry up.

  • Page 15: Specification

    Specifications Bluetooth version Bluetooth V2.1+EDR Bluetooth profiles Headset, Handsfree, A2DP, AVRCP Operating distance 10meters Headset working time Music: up to 7 houurs Talk: up to 8 hours Headset standby time Approx 180 hours Charging input DC5.0V 130mA Headset charging time Approx 2 hours Dimension 132*134.5*61mm...
